MDSC2224
24inch full HD surgical display
Barco'sMDSC2224isa24inchnearpatient
surgicaldisplaywithLEDbacklight,featuring
full HD resolution and a wide color gamut.
Purposebuilt for the operating room, the
MDSC2224 offers an easyclean design,
smart mechanics and the most detailed
imagesintheprocedureroomtoday.
Colorcalibrated,artifactfreeimages
Thanks to its high brightness, high contrast and high resolution, the
MDSC2224 presents surgeons with accurate, realistic images and excellent
depth perception. It also offers the fastest, lagfree transmission of surgical
imagesandthehighestimagequalityavailabletoday.
Our nextgeneration motion adaptive deinterlacing and noise reduction
algorithms,usingfull10bitimageprocessing,areyourguaranteefordetailed,
sharp,andnoisefreepictures,soyoucandetectthemostsubtlechangesin
tissuecolor.
Multisource,multidisplayimagingoverIP
Withitsbroadinputconnectivity,theMDSC2224offersthehighestflexibility
formultimodalityimaging(PiP&PaP),enablingreproductionofimagesfrom
multiplesourcesandtomultipledisplaysintheintegratedoperatingroom.
The 24inch display is one of Barco's networkenabled surgical displays and
offers integrated functionality (optional) for use with Nexxis digital OR,
ensuring smooth distribution of uncompressed video and data over the IP
networkwithoutdelay.

MDSC2224
24inch full HD surgical display
Designedforuseintheoperatingroom
Barco'sMDSC2224allowseasycleaninganddisinfectionthankstoitssmooth
surface,splashproofhousing,andfullscreenprotection.The fanless design
avoidsthespreadofcontaminants.
The display comes with a smart cable management system that hides the
cables for a clutterfree setup. It is light and compact, allowing easy
(dualmonitor)mountingonsurgicalboomsandspringarms.

Productspecifications MDSC2224
Tecnologíadevisual TFTAMLCD/SIPStechnology/LEDbacklight
Tamañodepantallaactiva(diagonal) 611.3mm(24")
Tamañodepantallaactiva(HxV) 518.4x324mm(20.4”x12.7")
relacióndeapecto 16:10
resolución 1920x1200
pasodepixel 0.270mm
Imágenesencolor Yes
Compatibilidaddecolor 1073million(10bit)
Gamadecolores Widegamut(AdobeRGB1998)
Ángulodevisualización 178°Hor/178°Ver
Luminanciamáxima 350cd/m²(typical)
relacióndecontraste 1000:1(typical)
Tiempoderespuesta 6msec(GtGtyp)
Relojdepuntos (max)165Mhz
Curvagamma Native,1.8,2.0,2.2,2.4,DICOM
Colordelacarcasa WhiteRAL9003
Entradasdevídeo Videoinputsignals:
DVIISingleLink(Digital&Analog–HDMIvideosupportwithHDCP)
ComponentVideoRGBS/YPbPr(4xBNC)
Svideo(4pinMiniDIN)
Compositevideo(1xBNC)
3GSDI(1xBNC)
DisplayPort(VESAstd1.1a)
Optional:integratedBARCONexxisnetworkadapter
Videoinputformats:
VGA&DVI:Upto1920x1200at60Hz(reducedblanking)
Maximumpixelclock:165MHz
MaximumHorfreq:90kHz
MaximumVerfreq:75Hz
StandardPALandNTSCforSVideo,CompositeandComponent
ComponentYPbPr/RGBS:HDTVupto1080i&1080p
SDIFormatSupported:625/25PAL,525/29.97NTSC,1080i50,1080i59.94,
1080i60,720p50,720p59.94,720p60,1080p50,1080p59.94,1080p60
SDICompliance:SMPTE425M(LevelA),SMPTE424M,SMPTE292M,SMPTE
259MC,SMPTE296M,ITURBT.656,ITURBT.601
Displayport1.1a:upto1920x120060Hz
Salidasdevídeo DVID
Svideo(4pinMiniDIN)
Compositevideo(1xBNC)
3GSDI(1xBNC)
controlremoto RS232(Dsub9pin)
Requisitosdealimentación(nominal) Powersourceforexternalpowersupply:100–250VAC/4763Hzautoswitch
Powersourcefordisplaypowerinput:+24VDC/2.5A
Powersupplyforexternalmodule:+5VDC±10%@500mA(max)throughtheDVI
connectorsDVIin&DVIout(onpin14orpin16OSDprogrammable)
Gestióndeenergía DVIDMPMstatessupported
PowerOnstate
ActiveOffstate
Consumoenergético(nominal) lessthan60W(LEDversion)
LenguajesOSD English,French,German,Spanish,Italian
Dimensionessinpie(AnxAlxP) 595x414x84mm(23,4”x16,3”x3,3”)
Pesonetosinpie 7.7kg(17.0lbs)withoutpowersupply
Pesonetoembaladosinpie 10.0kg(22.0lbs)
Montajeestándar 100x100mmVESA
Proteccióndelapantalla IP21/Frontface:IPx5
Doublecoated,antireflectivePMMA/WhiteRAL9003

Productspecifications MDSC2224
Modalidadesrecomendadas Endoscopy,laparoscopy,Xray,CT,MR,US
cumplimientoderegulación IEC606013rdEdition
Approvals/Marking:CE,CULUS,DEMKO,CCC
Safety(Medicalequipment):IEC606011,UL606011,CSAC22.2nr6011M90
ElectromagneticCompatibility:EMCMedicalEMCStandards:IEC6060112,
EN55011/CISPR11,FCCCFR47part15&18/ClassA
Environment:ROHS2,REACH,WEEEcompliant
Temperatura Operating:0°40°C/Storage:20°60°C
humedad Operating:10%–90%R.H./Storage:5%–90%R.H.
Teclado/ratón Touchsensitive,7key,backlit,bottomright
Accesoriossuministrados UserManual,DVIDualLinkcable3.0m,Mainscables(EU(CEBEC/KEMA)&US
(HospitalgradeUL)),Externalpowersupply
Accesoriosopcionales BarcoSurgicalLCDDisplayDeskStand,BarcoMDSCSurgicalMedicalLCDDisplay
ExtensionCable10m
Garantía 3years
Generadoen:25ene2014
Lasespecificacionestécnicaspuedenestarsujetasacambiossin
previoaviso.
Consultewww.barco.comparaobtenerlainformaciónmásactual.
