F10AS3D
Compact Active Stereo DLP projector for professional applications
The F10 AS3D enables full 3D stereoscopic
visualisation from a small, single lens
chassis, and at full 120 Hz refresh rates
commonly used in stereoscopic systems.
Fully1080pcompatible,itisatoolnotonly
forthescientificvisualisationandsimulation
industries,butalsosuitedforvideoandfilm
production and DI and VFX creation. The
revolutionary F10 AS3D offers full active 3D
stereoscopicdisplayat120fpsrefreshrates
atallresolutionsupto1,920x1,200.
Uniquehighperformance
The F10 AS3D runs full resolution at double the bandwidth – all the time.
Hence,imagequality,detail,andaccuracyismuchhigherwiththeF10AS3D.
Who'sitfor?
Designedprimarily for therequirements of scientificvisualization, simulation
andmathematicalmodelling,itmakesiteasytodisplay3Dstereoscopicdata
analysis and other graphically challenging applications, such as design
feasibility studies and modelling, not to mention 3D video and motion
content.

Productspecifications F10AS3D
Technology patented3DstereotechnologysinglechipDLPdisplaywithfullyactive3Dstereo
compatibility
Concept singlelens,dualheadstereoscopicprojector
Resolution SXGA+(1400x1050)
Brightness Upto2000lumens(3Dmode:upto2000ansilumens2Dmode:upto2000ansi
lumens)
Contrast Upto3000:1(Prismlessopticaldesign)
AspectRatio 4:3(SXGA+)
Displaycolors 30bitRGB
Computergraphicsformats UXGA,SXGA+,SXGA,XGA,SVGA,VGA1920x1080640x480pixel
resolutioncustomformatsavailableRGBHV,RGBS,RGsB
Horizontalscanfrequencies 15150kHz(resolutiondependant)
Verticalscanfrequencies 48190Hz(resolutiondependant)
Videoformats EDTV(576p,480p)SDTV(576i,480i)HDTV(1080p,1080i,720p)NTSC,PAL,SECAM
Lensoperation FocusandManualzoom
Lenses Standardprojectionlens
⋅Lensnumber:EN08/503003400
⋅Focusrange:1.015.0m
⋅Throwratio⋅1.732.17:1(SXGA+)
WideAngle
⋅Lensnumber:EN10/503003500
⋅Focusrange:1.520.0m
⋅Throwratio⋅1.03:1(SXGA+)
Imagewidth 0.72.5m
Lightsource 220WUHP
Lamplifetime Upto2250hours(Fullpower)Upto3000hours(Ecomode)
Computerinputs 2xDVID2xVGA
VideoInput 1xYPbPr1xSvideo1xComposite
Controlpossibilities 1xRJ45TCP/IP1x9pinDSUBRS2321xUSB
Dimensions 278x110x278mm(WxHxD)
Weight 3.4kg
Powerrequirements 5.01.7A~100,5060Hz
Conformances CE,FCCClassA,UL,cULandcCSAus
Operatingtemperature 040°C
Storagetemperature 2060°C
Operatinghumidity 2080%RH
Storagehumidity 1090%RH
Color Blackmetallic
(E)TSO 3years,500hoursor90daysonlamp(whichevercomesfirst).
BTUperhour
Generatedon:17Apr2014
Technicalspecificationsaresubjecttochangewithoutpriornotice.
Pleasecheckwww.barco.comforthelatestinformation.
