Barco F90-W13 User manual

F90–W13
User Manual
601–0400–00/00
18/08/2016

Barco Fredrikstad AS
Habornveien 53, N-1630 Gamle Fredrikstad, Norway
Phone: [phone]
Fax: [phone]
Support: [email protected]
Visit us at the web: www.barco.com
Printed in N0

Changes
Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war-
ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the
program(s) described in this publication at any time without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the information in this
publication; these changes are incorporated in new editions of this publication.
The latest edition of Barco manuals can be downloaded from the Barco web site www.barco.com or from the secured Barco web site
https://www.barco.com/en/signin.
Federal Communications Commission (FCC Statement)
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area may
cause harmful interference, in which case the user will be responsible for correcting any interference at his own expense
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment
Trademarks
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders.
All brand and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for
the products or their manufacturers.
Turkey RoHS compliance
Türkiye Cumhuriyeti: AEEE Yönetmeliğine Uygundur.
[Republic of Turkey: In conformity with the WEEE Regulation]
Disposal Information
Waste Electrical and Electronic Equipment
This symbol on the product indicates that, under the European Directive 2012/19/EU governing waste from electrical and electronic
equipment, this product must not be disposed of with other municipal waste. Please dispose of your waste equipment by handing it over to
a designated collection point for the recycling of waste electrical and electronic equipment. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly
to promote the sustainable reuse of material resources.
For more information about recycling of this product, please contact your local city office or your municipal waste disposal service.
For details, please visit the Barco website at: http://www.barco.com/en/AboutBarco/weee
Disposal of batteries in the product
This product contains batteries covered by the Directive 2006/66/EC which must be collected and disposed of separately from
municipal waste.
If the battery contains more than the specified values of lead (Pb), mercury (Hg) or cadmium (Cd), these chemical symbols will appear
below the crossed-out wheeled bin symbol.
By participating in separate collection of batteries, you will help to ensure proper disposal and to prevent potential negative effects on the
environment and human health.

Guarantee and Compensation
Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee. On receipt, the purchaser
must immediately inspect all delivered goods for damage incurred during transport, as well as for material and manufacturing faults Barco
must be informed immediately in writing of any complaints.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning,
at latest 30 days after the transfer of risks. In the event of justified notice of complaint, Barco can repair the fault or provide a replacement
at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a
reduction in the purchase price or cancellation of the contract. All other claims, in particular those relating to compensation for direct or
indirect damage, and also damage attributed to the operation of software as well as to other services provided by Barco, being a component
of the system or independent service, will be deemed invalid provided the damage is not proven to be attributed to the absence of properties
guaranteed in writing or due to the intent or gross negligence or part of Barco.
If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly,
in particular if the systems are operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in
the contract, all guarantee claims of the purchaser will be rendered invalid. Not included in the guarantee coverage are system failures
which are attributed to programs or special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear as well as normal
maintenance are not subject to the guarantee provided by Barco either.
The environmental conditions as well as the servicing and maintenance regulations specified in this manual must be complied with by the
customer.
Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be recorded, transmitted or
stored in a retrieval system without the prior written consent of Barco.

Table of contents
TABLE OF CONTENTS
1. Safety................................................................................................................ 3
1.1 General considerations.............................................................................................................. 3
1.2 Important safety instructions ........................................................................................................ 4
1.3 Remote control warning............................................................................................................. 6
1.4 Projector Hazard Distances......................................................................................................... 7
1.5 High Brightness Precautions........................................................................................................ 7
1.6 Hazard Distance for fully closed projection system ................................................................................ 8
1.7 HD in function of the lens Throw Ratio (TR)........................................................................................ 9
1.8 Safety symbols ......................................................................................................................10
1.9 RoHS compliance ...................................................................................................................11
2. Getting to know the projector...................................................................................13
2.1 Main components. . . .................................................................................................................13
2.2 Service and maintenance . . .........................................................................................................14
2.3 LED status light......................................................................................................................14
2.4 LCD panel . . .........................................................................................................................14
2.5 Local keypad.........................................................................................................................15
2.6 Wireless remote control .............................................................................................................15
2.7 Connector panel ..................................................................................................................... 16
2.8 Color Wheels ........................................................................................................................17
2.8.1 Color Wheel range . . . .........................................................................................................17
2.8.2 Change the color wheel ......................................................................................................17
2.9 Optional accessories ................................................................................................................18
3. Lenses...............................................................................................................19
3.1 Approved Lenses . . . .................................................................................................................19
3.2 Lens range . . . ........................................................................................................................19
3.3 Replace a lens.......................................................................................................................21
3.4 Adjust zoom, focus and iris..........................................................................................................23
4. Physical installation ..............................................................................................25
4.1 Installation process.................................................................................................................. 25
4.2 Installation conditions ............................................................................................................... 25
4.3 Initial inspection......................................................................................................................27
4.4 Positioning the projector............................................................................................................. 28
4.5 Mounting the projector...............................................................................................................28
4.6 Throw distance ...................................................................................................................... 29
4.7 Scheimpflug (Boresight) adjustment ................................................................................................32
4.8 Scheimpflug adjustment procedure .................................................................................................33
5. Getting started.....................................................................................................35
5.1 Projector source and control connections . . ........................................................................................ 35
5.1.1 Making connections. . ......................................................................................................... 35
5.1.2 Connector specifications......................................................................................................35
5.1.2.1 Single link DVI..........................................................................................................35
5.1.2.2 Display Port 1.2 ........................................................................................................36
5.1.2.3 HDMI 1.4 (No 3D functionallity)........................................................................................36
5.1.2.4 3G-SDI..................................................................................................................36
5.1.2.5 HDBase T...............................................................................................................37
5.1.3 Control interfaces .............................................................................................................37
5.1.3.1 RS-232..................................................................................................................37
5.1.3.2 LAN/Ethernet ........................................................................................................... 38
5.1.3.3 USB-A port .............................................................................................................38
5.2 Power up the projector ..............................................................................................................38
5.3 Power down the projector ...........................................................................................................38
5.4 Power modes ........................................................................................................................38
5.5 Customize projector settings........................................................................................................39
5.6 User interface........................................................................................................................39
5.6.1 On Screen Display (OSD) ....................................................................................................39
6. Source menu.......................................................................................................41
6.1 Connector selection ................................................................................................................. 41
6.2 Source configure ....................................................................................................................41
7. Image menu ........................................................................................................43
7.1 Contrast..............................................................................................................................43
7.2 Brightness ...........................................................................................................................43
7.3 Saturation............................................................................................................................ 43
7.4 Advanced image adjustments.......................................................................................................43
8. Installation menu..................................................................................................45
8.1 Lens . . ................................................................................................................................45
8.2 Orientation ........................................................................................................................... 45
601–0400–00 F90–W13 18/08/2016 1

Table of contents
8.3 Warp ................................................................................................................................. 46
8.4 Illumination...........................................................................................................................46
9. Settings menu......................................................................................................47
9.1 Communication ......................................................................................................................47
9.2 Apply a menu theme ................................................................................................................47
9.3 Service...............................................................................................................................47
10. Status menu........................................................................................................49
10.1 Source status........................................................................................................................49
10.2 Product...............................................................................................................................49
10.3 Illumination........................................................................................................................... 49
10.4 Communication ...................................................................................................................... 49
11. Reset Menu.........................................................................................................51
11.1 Factory Reset........................................................................................................................51
11.2 Selectable Reset ....................................................................................................................51
12. Cleaning the projector............................................................................................53
12.1 Projector lenses ..................................................................................................................... 53
12.2 Projector cabinet.....................................................................................................................53
12.3 Filters ................................................................................................................................53
2601–0400–00 F90–W13 18/08/2016

1. Safety
1. SAFETY
About this chapter
Read this chapter thoroughly before attempting to install or operate the projector.
To prevent personal injury to users or physical damage to the projector while installing and using your projector, ensure that you
understand and follow all safety guidelines, instructions and warnings included in this chapter and this manual.
Clarification of the term ’F90-series’ used in this document
Use in this document of the term, ’F90-series’, means that the content is applicable for the following products:
• F90–W13
• F90–4K13
Overview
• General considerations
• Important safety instructions
• Remote control warning
• Projector Hazard Distances
• High Brightness Precautions
• Hazard Distance for fully closed projection system
• HD in function of the lens Throw Ratio (TR)
• Safety symbols
• RoHS compliance
1.1 General considerations
Notice on optical radiation
• The projector is Class 1 laser product that conforms with IEC EN 60825-1:2014. For Northern America, the projector is class
3R laser product up to throw ratio 2.33. The projector conforms with IEC 60825–1:2007, 21 CFR 1040.10 and 1040.11 except
for deviations pursuant to Laser Notice No 50 dated june 24.
Do not stare into Beam.
• This projector is Risk Group 2 (RG2) according to IEC EN 62471-5.
This projector may become Risk Group 3 (RG3) when an interchangeable lens with throw ratio greater than 3.15 is installed.
For Northern America, installation requirements according to Risk group 3 (RG3) must be followed when interchangeable lens
with throw ratio greater than 2.33 is installed.
Refer to the manual for the lens list and throw ratio before operation.
Such combination of projector and lens are intended for professional use only, and are not intended for consumer use.
• For RG3, no direct exposure to the beam shall be permitted.
For RG3, operators shall control access to the beam within the hazard distance or install the product at a height that will prevent
eye exposure within the hazard distance.
• This projector has two (2) built-in Class 4 laser clusters. Disassembly or modification is very dangerous and should never be
attempted.
• Any operation or adjustment not specifically instructed by the user’s guide creates the risk of hazardous laser radiation expo-
sure.
• Do not open or disassemble the projector as this may cause damage by the exposure of laser radiation.
General safety instructions
• This product contains no user serviceable parts except the Color Wheel. Attempts to modify/replace mechanics or electronics
inside the housing or compartments will violate any warranties and may be hazardous.
Do not remove/replace any other parts than the Color Wheel. Other parts, service personnel only – Warranty void if Removed.
Follow the instructions in the User Guide to replace the Color Wheel.
• Do not stare into beam when the projector is on. The bright light may result in permanent eye damage.
• Not following the prescribed control, adjustment or operation procedure may cause damage by the exposure of laser radiation.
• Before operating this equipment please read this manual thoroughly and retain it for future reference.
• Installation and preliminary adjustments should be performed by properly trained and qualified personnel.
• All warnings on the projector and in the documentation manuals must be adhered to.
• All instructions for operating and use of this equipment must be followed precisely.
• All local installation codes should be adhered to.
601–0400–00 F90–W13 18/08/2016 3

1. Safety
Notice on safety
This equipment is built in accordance with the requirements of the international safety standards IEC60950-1, as basis for National
safety regulation world wide. The safety standard covers information technology equipment including electrical business equipment
intended to operate in “normal” environments (offices and homes). This safety standard imposes important requirements on the
use of safety critical components, materials and insulation, in order to protect the user or operator against risk of electric shock and
energy hazard and having access to live parts. Safety standards also impose limits to the internal and external temperature rises,
radiation levels, mechanical stability and strength, enclosure construction and protection against the risk of fire. Simulated single
fault condition testing reduce the risk of hazards and contribute to ensure the safety of the equipment to the user even when the
equipment’s normal operation fails.
Users definition
Throughout this manual, the term SERVICE PERSONNEL refers to Barco authorized persons having appropriate technical training
and experience necessary to be knowledgeable of potential hazards to which they are exposed (including, but not limited to HIGH
VOLTAGE ELECTRIC and ELECTRONIC CIRCUITRY and HIGH BRIGHTNESS PROJECTORS) in performing a task, and of mea-
sures to minimize the potential risk to themselves or other persons. Only Barco authorized SERVICE PERSONNEL, knowledgeable
of such risks, are allowed to perform service functions inside the product enclosure. The term USER and OPERATOR refers to any
person other than SERVICE PERSONNEL. When an interchangeable lens with throw ratio 3.15 or more is installed, the F90-series
projector becomes RG3. Refer to the manual for the lens list and hazard distance before operation. Such combination of projector
and lens are intended for professional use only, and are not intended for consumer use.
FOR PROFESSIONAL USE ONLY means installation can only be carried out by Barco AUTHORIZED PERSONNEL familiar with
potential hazards associated with high intensity light beams.
1.2 Important safety instructions
To prevent the risk of electrical shock
• This product should be operated from a mono phase AC power source.
• This apparatus must be grounded (earthed) via the supplied 3 conductor AC power cable. If none of the supplied power cables
are the correct one, consult your dealer.
If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the
purpose of the grounding-type plug.
Never use 2-prong power cords, as this is dangerous and could lead to electrical shock.
• Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on the cord. To disconnect
the cord, pull it out by the plug. Never pull the cord itself.
• Use only the power cord supplied with your device or original replacement cords. While appearing to be similar, other power
cords have not been safety tested at the factory and may not be used to power the device. For a replacement power cord,
contact your dealer.
• Do not operate the projector with a damaged cord. Replace the cord.
Do not operate the projector if the projector has been dropped or damaged - until it has been examined and approved for
operation by a qualified service technician.
• Position the cord so that it will not be tripped over, pulled, or contact hot surfaces.
• If an extension cord is necessary, a cord with a current rating at least equal to that of the projector should be used. A cord rated
for less amperage than the projector may overheat.
• Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out
parts that could result in a risk of fire or electrical shock.
• Make sure that no objects enter into the vents and openings of the set.
• Do not expose this projector to rain or moisture.
• The projector is designed for indoor use only. Never operate the unit outdoors.
• Do not immerse or expose this projector in water or other liquids.
• Do not spill liquid of any kind on this projector.
• Should any liquid or solid object fall into the cabinet, unplug the set and have it checked by qualified service personnel before
resuming operations.
• Do not disassemble this projector, always take it to an authorized trained service person when service or repair work is required.
• Do not use an accessory attachment which is not recommended by the manufacturer.
• Lightning - For added protection for this video product during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet. This will prevent damage to the device due to lightning and AC power-line surges.
4601–0400–00 F90–W13 18/08/2016

1. Safety
To prevent personal injury
• To prevent injury and physical damage, always read this manual and all labels on the system before connecting to the wall
outlet or adjusting the projector.
• To prevent injury, take note of the weight of the projector.
• To prevent injury, ensure that the lens and all covers are correctly installed. See installation procedures.
• Warning: high intensity light beam. NEVER look into the lens! High luminance could result in damage to the eye.
• Warning: extremely high brightness laser: This projector uses extremely high brightness laser. Never attempt to look directly
into the lens or at the laser.
• Always switch off the projector and disconnect from the mains power supply before attempting to remove any of the projector
covers or access parts inside the projector.
• This product contains no user serviceable parts except the Color Wheel. Attempts to modify/replace mechanics or electronics
inside the housing or compartments will violate any warranties and may be hazardous.
• Do not remove/replace any other parts than the Color Wheel. Other parts, service personnel only Warranty void if removed
• Do not place this equipment on an unstable cart, stand, or table. The product may fall, causing serious damage to it and
possible injury to the user.
• Only place the projector on a stable surface, or mount it securely using an approved ceiling-mount.
• It is hazardous to operate without lens or lens cap. Lenses or shields shall be changed if they have become visibly damaged,
for example with cracks or deep scratches, to such an extent that their effectiveness is impaired.
To prevent fire hazard
• Barco projection products are designed and manufactured to meet the most stringent safety regulations. This projector radiates
heat on its external surfaces and from ventilation ducts during normal operation, which is both normal and safe. Exposing
flammable or combustible materials into close proximity of this projector could result in the spontaneous ignition of that material,
resultinginafire. For this reason, it is absolutely necessary to leave an “exclusion zone” around all external surfaces of the
projector whereby no flammable or combustible materials are present. The exclusion zone in the exhaust area must be not
less than 100 cm (40”). The exclusion zone on the intake area must not be less than 50 cm (20”).
• Do not place flammable or combustible materials near the projector!
• The exclusion zone on lens side must be at least 1m.
• Caution! Hot air is exhausted from the rear vent. Do not place objects that are sensitive to heat nearer than 100 cm (40”) to
the exhaust vent.
• Slots and openings in this equipment are provided for ventilation. To ensure reliable operation of the projector and to protect it
from overheating, these openings must not be blocked or covered.
• The openings should never be blocked by placing the projector too close to walls, or other similar surface. Allow for sufficient
distance to walls and ceilings to avoid overheating. Minimum safety distance to the exhaust area of the unit must not be less
than 100 cm (40”) and to the intake area, not less than 50 cm (20”).
• This projector should never be placed near or over a radiator or heat register.
• This projector should not be placed in a built-in installation or enclosure unless proper ventilation is provided.
• Do not cover the projector or the lens with any material while the projector is in operation. Keep flammable and combustible
materials away from the projector at all times.
• Mount the projector in a well-ventilated area away from sources of ignition and out of direct sun light. Always allow ample airflow
through the projector.
• Never expose the projector to rain or moisture. In the event of fire, use sand, CO2 or dry powder fire extinguishers.
• Never use water on an electrical fire.
• Always have service performed on this projector by authorized Barco service personnel. Always insist on genuine Barco re-
placement parts. Never use non-Barco replacement parts as they may degrade the safety of this projector.
• Projection rooms must be well ventilated or cooled in order to avoid heat buildup.
• Let the projector cool down completely before storing. Remove cord from the projector when storing.
To prevent projector damage
• To ensure correct airflow is maintained the projector should only be operated when all of its covers in place.
• Always remove lens cap before switching on the projector. If the lens cap is not removed, it may melt due to the high energy
light emitted through the lens. Melting the lens cap may permanently damage the surface of the projection lens
• Only connect the projector to signal sources and voltages as described in the technical specification. Connecting to unspecified
signal sources or voltages may lead to malfunction and permanent damage of the unit.
• To ensure correct airflow is maintained, it should only be operated when all of its covers are in place.
• The projector must always be installed in a manner which ensures free flow of air into its air inlets and unimpeded evacuation
of the hot air from its cooling system.
• Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from
overheating, these openings must not be blocked or covered. The openings should never be blocked by placing the product
on a bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator or heat register. The
device should not be placed in a built-in installation or enclosure unless proper ventilation is provided. Ensure that nothing can
be spilled on, or dropped inside the projector. If this does happen, switch off and unplug the mains supply immediately. Do not
operate the projector again until it has been checked by Barco authorized service personnel.
601–0400–00 F90–W13 18/08/2016 5

1. Safety
• Do not block the projector cooling fans or free air movement around the projector. Minimum safety distance to the exhaust area
of the unit must not be less than 100 cm (40”) and to the intake area, not less than 50 cm (20”).
• Do not use this equipment near water.
• Do not operate the projector outside its temperature and humidity specifications as this may result in overheating and malfunc-
tion.
• Never place the projector in direct sun light. Sun light on the lens can severely damage the Digital Mirror Devices™ in which
case there is a loss of warranty.
• Save the original shipping carton and packing material. They will come in handy if you ever have to ship your equipment. For
maximum protection, repack your set as it was originally packed at the factory.
• Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning. Never use strong solvents, such as thinner or benzine, or abrasive cleaners, since these will damage the cabinet.
Stubborn stains may be removed with a cloth lightly dampened with mild detergent solution.
• To ensure the highest optical performance and resolution, the projection lenses are specially treated with an anti-reflective
coating, therefore, avoid touching the lens. To remove dust on the lens, use a soft dry cloth. Do not use a damp cloth, detergent
solution, or thinner.
On servicing
• Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage potentials
and risk of electric shock.
• Refer all servicing to Barco authorized repair centers.
• Attempts to alter the factory-set internal controls or to change other control settings not specially discussed in this manual can
lead to permanent damage to the projector and cancellation of the warranty.
• Unplug this product from the wall outlet and refer servicing to Barco authorized service personnel or technicians under the
following conditions:
- If liquid has been spilled into the equipment.
- If the product has been exposed to rain or water.
- If the product does not operate normally when the operating instructions are followed. Adjust only those controls that are
covered by the operating instructions since improper adjustment of the other controls may result in damage and will often
require extensive work by a qualified technician to restore the product to normal operation.
- If the product has been dropped or the cabinet has been damaged.
- If the product exhibits a distinct change in performance, indicating a need for service.
- When the power cord or plug is damaged or frayed.
• Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replace-
ment parts. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards.
Unauthorized substitutions may void warranty.
• Safety check: Upon completion of any service or repairs to this projector, ask the service technician to perform safety checks
to determine that the product is in proper operating condition.
1.3 Remote control warning
General
Laser radiation class II product, wavelength 670 nm; maximum output 1 mW.
Remote control complies with applicable requirements of 21 CFR 1040.10 and 1040.11
Remote control complies with applicable requirements of EN / IEC 60825–1/2007.
Image 1-1
6601–0400–00 F90–W13 18/08/2016

1. Safety
1.4 Projector Hazard Distances
WARNING. This may be a RG3 laser Product, dependent on which lens used.
This projector may become Risk Group 3 (RG3) when an interchangeable lens with throw ratio greater than 3.15 is installed. For
Northern America, installation requirements according to Risk group 3 (RG3) must be followed when interchangeable lens with throw
ratio greater than 2.33 is installed
Refer to the manual for the lens list and throw ratio before operation.
Do not look direct in to the beam from the projector lens.
No direct eye exposure to the beam is permitted.
Operators shall control access to the beam within the hazard distance or install the product at a height that will prevent eye exposure
within the hazard distance”.
See table below for a definition of hazardous distances versus the throw ratio of the lens.
1.5 High Brightness Precautions
Restriction Zone (RZ) based on the HD (Hazard Distance).
The HD depends on the amount of lumens produced by the projector and the type of lens installed. See next chapter"HD in function
of the lens Throw Ratio (TR)", page 8 .
To protect untrained end users (as cinema visitors) the installation shall comply with the following installation requirements: Opera-
tors shall control access to the beam within the hazard distance or install the product at the height that will prevent spectators’ eyes
from being in the hazard distance. Radiation levels in excess of the limits will not be permitted at any point less than 2.0 meter (SH)
above any surface upon which persons other than operators, performers, or employees are permitted to stand or less than 1.0 meter
(SH) lateral separation from any place where such persons are permitted to be. In non-cinema environments where unrestrained
behavior is reasonably foreseeable, the minimum separation height should be greater than or equal to 3.0 meter to prevent potential
exposure, for example by an individual sitting on another individual’s shoulders, within the HD.
These values are minimum values and are based on the guidance provided in IEC 62471-5:2015 section 6.6.5.
The end user must understand the risk and apply protective measures based upon the hazard distance as indicated on the label and
in the user information. Installation method, barriers, detection system or other applicable control measure shall prevent hazardous
eye access to the radiation within the hazard distance.
For example, projectors that have a HD greater than 1 m and emit light into an uncontrolled area where persons may be present
should be positioned in accordance with “the fixed projector installation” parameters, resulting in a HD that does not extend into
the audience area unless the beam is at least 2.0 meter above the floor level. In non-cinema environments where unrestrained
behavior is reasonably foreseeable, the minimum separation height should be greater than or equal to 3.0 meter to prevent potential
exposure, for example by an individual sitting on another individual’s shoulders, within the HD. For example, a sufficiently large
separation height may be achieved by mounting the image projector on the ceiling or through the use of physical barriers.
For applications installed in the USA market the above limits do not apply. The relevant minimum separation height is 2.5 meter (8.2
ft) and the separation width is defined as 1.0 meter (3.3 ft) by the FDA CDRH.
RA
TH
PR
RZ
HD
SW
1m
SW
SW
SW
HD
SH
RA TH
RZ
SH
(B) TOP VIEW(A) SIDE VIEW
Image 1-2
A Side View
BTopView
RA Restricted Area
PR Projector
TH Theater
RZ Restriction Zone in the theater
SH Separation Height
SW Separation Width
601–0400–00 F90–W13 18/08/2016 7

1. Safety
Regarding the SH Distance: For Cinema applications, the distance must be >2m. For Concert applications,
thedistancemustbe>3m.
Based on national requirements, no person is allowed to enter the projected beam within the zone between the projection lens and
the related hazard distance (HD). This shall be physically impossible by creating sufficient separation height or by placing barriers.
The minimum separation height takes into account the surface upon which persons other than operator, performers or employees
are permitted to stand.
On image 1-2 a typical setup is displayed. It must be verified if these minimum requirements are met. If required a restricted zone
(RZ) in the theater must be established. This can be done by using physical barrier, like a red rope as illustrated in image 1-2.
The restricted area sticker can be replaced by a sticker with only the symbol.
PR
RESTRICTED
AREA
RESTRICTED
AREA
Image 1-3
1.6 Hazard Distance for fully closed projection system
HD
Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface
unit becomes lower than the applicable exposure limit on the cornea or on the skin. The light beam is considered (to
be) unsafe for exposure if the distance from a person to the light source is less than the HD.
Restriction Zone RZ Based on the HD
The projector is also suitable for rear projection applications; projecting a beam onto a defuse coated projection screen. As displayed
in image 1-3 two areas should be considered: the restricted enclosed projection area (RA) and the observation area (TH).
8601–0400–00 F90–W13 18/08/2016

1. Safety
RA TH
sw
PD
HDDIFFUSE
sw
RZ
sw sw
PR
HD
REFLECTION
RESTRICTED
AREA
RESTRICTED
AREA
Image 1-4
RA Restricted Access location (Enclosed projection area)
PR Projector.
TH Theater (observation area).
RZ Restriction Zone
PD Projection Distan
SW Separation Width. Must be minimum 1 meter.
Restriction zone (RZ) based on the HD continued.
For this type of setup 3 different HD shall be considered:
• HD as discussed in "High Brightness precautions: Hazard Distance (HD)", page 6 , relevant for intrabeam exposure.
• HDreflection : the distance that has to be kept restrictive related to the reflected light from the rear projection screen.
• HDdiffuse : the relevant distance to be considered while observing the defuse surface of the rear projection screen.
As described in "High Brightness precautions: Hazard Distance (HD)", page 6 , it is mandatory to create a restricted zone within
the beam areas closer than any NOHD. In the enclosed projection area the combination of two restricted zones are relevant: The
restricted zone of the projected beam toward the screen; taking into account 1 meter Separation Width (SW) from the beam onward.
Combined with the restricted zone related to the rear reflection from the screen (HDreflection); also taking into account a 1 meter
lateral separation.
The HDreflection distance equals 25% of the difference between the determined HD distance and the projection distance to the rear
projection screen. To determine the HD distance for the used lens and projector model see graphs in chapter "HD in function of the
lens Throw Ratio (TR)", page 8 .
HDreflection = 25% (HD – PD)
The light emitted from the screen within the observation shall never exceed the RG2 exposure limit, determined at 10 cm. The
HDdiffuse can be neglected if the measured light at the screen surface is below 5000 cd/m² or 15000 LUX.
1.7 HD in function of the lens Throw Ratio (TR)
TR (Throw Ratio)
The ratio of the distance to the screen (throw) to the screen width.
601–0400–00 F90–W13 18/08/2016 9

1. Safety
HD versus Throw Ratio
Image 1-5
Graph shows Hazard Distance in meters versus Throw ratio of the lens
1.8 Safety symbols
Description of safety symbols used in product documentation or on product.
Image Description
Refer to user manual for further information!
Caution! Do not stare into beam, RG2
product.
No telephone! Do not connect to telephone
lines.
This projector may become RG3 when an interchangeable lens with throw ratio greater than 3.15 is
installed. Refer to the manual for the lens list and hazard distance before operation.Such combinations
of projector and lens are intended for professional use only, and are not intended for consumer use.
Ce projecteur peut devenir un projecteur RG3 en cas d'installation d'un objectif interchangeable
dont le rapport de projection est supérieur à 3,15. Veuillez vous reporter au manuel pour en savoir
plus sur la liste des objectifs et la distance de sécurité avant toute utilisation.De telles combinaisons
entre projecteur et objectif sont conçues pour des applications professionnelles uniquement et pas
pour des applications grand public.
ᵜᣅᖡᵪᆹ㻵ᣅሴ∄བྷҾ3.15Ⲵᦒ䮌ཤˈᡀѪRG3DŽ󰪞֌ࡽˈ䈧৲㘳᡻޼ѝ䮌ཤ␵অ઼ড
䲙
䐍⿫DŽ
ᵜᣅᖡᵪо䮌ཤ㓴ӵ׋уъ֯⭘ˈ䶎Პ䙊⎸䍩㘵֯⭘DŽ
FOR NORTH AMERICA, WITH USE OF INTERCHANGEABLE LENS UP TOTR 2.33:
LASER LIGHT
AVOID DIRECT EYE EXP0SURE CLASS 3R LASER PRODUCT400-700 NM - CW - 255 mW, IEC 60825-1:2007
---------------------------------------------------------------
COMPLIES WITH 21 CFR 1040.10 AND1040.11 EXCEPT FOR DEVIATIONS PURSUANT TO LASER NOTICE
NO. 50 DATED JUNE 24
Caution! With interchangeable lens
with throw ratio greater than 2.33,
consider hazard distance and installation
requirements for RG3 product. Refer User
Manual.
Caution! With Interchangeable lens
with throw ratio greater then 3.15,
consider hazard distance and installation
requirements for RG3 product. Refer User
manual.
Location of Safety Label
8
9
Image 1-6
10 601–0400–00 F90–W13 18/08/2016

1. Safety
Disposal Information
Waste Electrical and Electronic Equipment
This symbol on the product indicates that, under the European Directive 2012/19/EU governing waste from electrical and
electronic equipment, this product must not be disposed of with other municipal waste. Please dispose of your waste equipment by
handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste
and recycle them responsibly to promote the sustainable reuse of material resources.
For more information about recycling of this product, please contact your local city office or your municipal waste disposal service.
For details, please visit the Barco website at: http://www.barco.com/en/AboutBarco/weee
WEEE Information
This product conforms to all requirements of the EU Directive on waste electrical and electronic equipment (WEEE). This product
shall be recycled properly. It can be disassembled to facilitate proper recycling of it’s individual parts.
Consult your dealer or relevant public authority regarding drop-off points for collection of WEEE. For details, please visit the Barco
website at: http://www.barco.com/en/ AboutBarco/weee.
WARNING:This product contains chemicals, including lead, known to the State of California to cause birth
defects or other reproductive harm. Recycle properly, do not dispose of in ordinary waste!
Turkey RoHS compliance
Türkiye Cumhuriyeti: AEEE Yönetmeliğine Uygundur.
[Republic of Turkey: In conformity with the WEEE Regulation]
1.9 RoHS compliance
中国大陆RoHS (Chinese Mainland RoHS)
根据中国大陆《电器电子产品有害物质限制使用管理办法》（也称为中国大陆RoHS）， 以下部分列出了Barco产品中可能包含的有毒
和/或有害物质的名称和含量。中国大陆RoHS指令包含在中国信息产业部MCV标准：“电子信息产品中有毒物质的限量要求”中。
According to the “Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Prod-
ucts” (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances
that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information
Industry of China, in the section “Limit Requirements of toxic substances in Electronic Information Products”.
零件项目(名称)
Component Name
有毒有害物质或元素
Hazardous Substances or Elements
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr6+)
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印制电路配件
Printed Circuit Assemblies
XOXOOO
外接电(线)缆
External Cables
XOOOOO
內部线路
Internal wiring
XOOOOO
镜头支架
Lensholder
XOOOOO
激光发生器
Laser
XOOOOO
601–0400–00 F90–W13 18/08/2016 11

1. Safety
零件项目(名称)
Component Name
有毒有害物质或元素
Hazardous Substances or Elements
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr6+)
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
底架
Chassis
OOO O OO
外壳
Enclosure
OOO O OO
螺帽,螺钉(栓),螺旋(钉),垫圈,紧固件
Nuts, bolts, screws, washers, Fasteners
XOOOOO
电源供应器
Power Supply Unit
XOOOOO
散热片(器)
Heatsinks
OOO O OO
风扇
Fan
XOOOOO
塑胶外壳
Plastic Enclosure
OOO O OO
外壳
Enclosure
OOO O OO
电池(组)
Batteries
OOO O OO
文件说明书
Paper Manuals
OOO O OO
装置配件
Installation kit
OOO O OO
附電池遙控器
Remote control
XOOOOO
本表格依据SJ/T 11364的规定编制
This table is prepared in accordance with the provisions of SJ/T 11364.
O: 表示该有毒有害物质在该部件所有均质材料中的含量均在 GB/T 26572 标准规定的限量要求以下.
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit
requirement in GB/T 26572.
X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 标准规定的限量要求.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials used for this part
is above the limit requirement in GB/T 26572.
在中国大陆销售的相应电子信息产品（EIP）都必须遵照中国大陆《电子电气产品有害物质限制使用标识要求》标准贴上环保使用期
限（EFUP）标签。Barco产品所采用的EFUP标签（请参阅实例，徽标内部的编号使用于指定产品）基于中国大陆的《电子信息产品环
保使用期限通则》标准。
All Electronic Information Products (EIP) that are sold within Chinese Mainland must comply with the “Marking for the restriction of
the use of hazardous substances in electrical and electronic product” of Chinese Mainland, marked with the Environmental Friendly
Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General
guidelines of environment-friendly use period of electronic information products” of Chinese Mainland.
10
12 601–0400–00 F90–W13 18/08/2016

2. Getting to know the projector
2. GETTING TO KNOW THE PROJECTOR
Overview
• Main components
• Service and maintenance
• LED status light
• LCD panel
• Local keypad
• Wireless remote control
• Connector panel
• Color Wheels
• Optional accessories
2.1 Main components
Naming conventions
B
R
F
L
T
Image 2-1
L Left
TTop
BBack
R Right
F Front
601–0400–00 F90–W13 18/08/2016 13

2. Getting to know the projector
Projector Front
1
1
2
1
2
6
3
4
8
7
1
2
1
9
5
5
Image 2-2
1 LED status light
2 Adjustable feet
3 Projector lens
4 Lens holder
5 IR Receiver: for remote control communication
6 LCD panel
7 Keypad
8 Connector panel
9 Front USB and triggerboard
2.2 Service and maintenance
General
The F90 does not have any user-serviceable parts.
All service tasks must only be carried out by the manufacturer, or a Barco authorized service personnel or Barco technicians.
The projector color wheel can be replaced by users in the field. See "Change the color wheel ", page 17 for more information.
2.3 LED status light
About
The F90 status is located on the top side of the projector, near the IR receiver (ref. 1, image 2-2).
During normal operation the LED is unlit. In the event of a critical error or high temperature, the LED will display red.
By critical error, the projector cannot be restarted until the projector is disconnected from the power supply and then reconnected
again. If the reason for the error persist, the projector will again go to critical error status.
By high temperature, the projector will restart when it has cooled down, and temperatures are back within the normal operating
limitations.
2.4 LCD panel
About
The LCD panel (reference 1, image 2-3) is located on the right side of the projector. It shows the following information for the
projector, and is a mirror of the OSD. (On Screen Display)
• Projector status
• Network address
•Activesource
• Current firmware version
14 601–0400–00 F90–W13 18/08/2016

2. Getting to know the projector
2.5 Local keypad
About
123 4
9 8
5
7
6
10
Image 2-3
Item
No.
Name Description
2 Navigation keys Navigation arrows (up, down, left, right), confirm selection ( )
3 OSD Display Turn the On Screen Display (OSD) menu ON or OFF.
4 Standby Power on / standby
5Back Undo action / back to previous screen.
6 OSD ON/OFF Deactivate the On Screen Display (OSD). Only critical warnings will be displayed.
7Input Activates input source menu on OSD or in LCD
8 Shutter Open or close lens shutter
9 Test Patterns Activates test pattern menu on OSD or in LCD
10 Lens Activates test pattern menu on OSD or in LCD
2.6 Wireless remote control
General
The projector remote control is a full feature wireless remote control, powered by two (2) standard AA batteries. The battery com-
partment is on the back side of the remote control.
The remote control is backlit for use in dark environments. It also has a data-jack that allows for wired connection to the projector.
When the wire is connected, the IR beam and internal batteries are switched off.
The projector has 2 IR receivers, one at the front and one at the top rear, which are used to receive signals from the wireless remote
control.
Source/input compatibility is dependant on projector configuration. The OSD will display “Not available” when
an unsupported source or input is selected.
601–0400–00 F90–W13 18/08/2016 15

2. Getting to know the projector
ZM
ZOOM
ZM
FCS
FOCUS
FCS
SHUTTER
OP
LENS SHIFT
RGB
RGB
R1
OSD
OSD
R2
LCD
LCD
R3
PAT
PATTERN
R4
INPUT
INPUT
DEFAULT
DEFLT
ADDRESS
ADR MCR
CL
BACK
BACK
MACRO
*#
MENU
MENU
LASER
LASER
Light On/Off
Lens Shift
Shift lens position
Menu
Activate main menu
R1-R4
Not in use
Shutter OP + CL
Open + Close Mech. Shutter
Power
Toggle power.
Confirm power off.
Input
Select input source
Address
Not in use
Image 2-4
WARNING:Laser radiation class II product; wavelength 670nm; maximum output 1mW.
Remote control complies with applicable requirements of 21 CFR 1040.10 and 1040.11.
Remote control complies with applicable requirements of EN/IEC 60825-1/2007.
Specifications
Parameter Value
Type IR, NEC protocol
Sensors 2
Carrier 38 kHz
Range 7m
Laser 1 mW, 670nm
2.7 Connector panel
General
The source input panel is located at the back of the projector. For source specifications, see "Connector specifications", page 35.
16 601–0400–00 F90–W13 18/08/2016
