User's Guide

Notations Used in This Guide
•Safety indications
The documentation and the projector use graphical symbols to show how to use the projector safely.
Please understand and respect these caution symbols in order to avoid injury to persons or property.
Warning
This symbol indicates information that, if ignored, could possibly result in personal injury or even death due to incorrect handling.
Caution
This symbol indicates information that, if ignored, could possibly result in personal injury or physical damage due to incorrect handling.
•General information indications
Attention
Indicates procedures which may result in damage or injury if sufficient care is not taken.
a
Indicates additional information and points which may be useful to know regarding a topic.
sIndicates a page where detailed information regarding a topic can be found.
g Indicates that an explanation of the underlined word or words in front of this symbol appears in the glossary of terms. See the "Glossary"
section of the "Appendix".
s"Glossary" p.190
[Name] Indicates the name of the buttons on the remote control or the control panel.
Example: [Esc] button
Menu Name Indicates Configuration menu items.
Example:
Select Brightness from Image.
Image - Brightness

Make sure you read the following before you use the projector.
sSafety Instructions
Warning and Cautions on Installation
An optional ceiling mount is required when suspending the projector from
a ceiling.
s"Optional Accessories" p.171
Warning
•Do not use or install the projector where it may be subject to water or rain,
or high humidity, such as outdoors, in a bathroom, or shower room, and so
on. Otherwise, it could cause a fire or electric shock.
•A special method of installation is required when suspending the projector
from a ceiling (ceiling mount). If installation work is not carried out
correctly, the projector could fall down. This may result in injury or
accidents. Contact your local dealer or the nearest address provided in the
Epson Projector Contact List.
sEpson Projector Contact List
•If you use adhesives on the ceiling mount fixing points to prevent the screws
from loosening, or if you use things such as lubricants or oils on the
projector, the projector case may crack causing it to fall from its ceiling
mount. This could cause an accident or injury to anyone under the ceiling
mount.
When installing or adjusting the ceiling mount, do not use adhesives to
prevent the screws from loosening and do not use oils or lubricants and so
on.
•Do not cover the projector's air intake vent or air exhaust vent. If either of
the vents are covered, the internal temperature could rise and cause a fire.
•Do not place flammable objects in front of the lens. If you set the schedule to
turn on the projector automatically, any flammable objects placed in front of
the lens could cause a fire.
•Do not tie the power cord and other connection cables together. Otherwise, it
could cause a fire.
•Only use the specified power-supply voltage. Otherwise, it could cause a fire
or electric shock.
Safety Warning and Cautions
3

Warning
•Be careful when handling the power cord. Otherwise, it could cause a fire or
electric shock. Note the following when handling the power cord.
- Do not plug multiple power cords in a single electric outlet.
- Do not plug in the power cord if there are any foreign substances, such
as dust, stuck to it.
- Make sure you insert the power cord all the way in.
- Do not plug in or unplug the power cord with wet hands.
- Do not pull the cord when unplugging the power cord. Make sure you
hold it by the plug.
•Do not use a damaged power cord. Otherwise, it could cause a fire or electric
shock. Note the following when handling the power cord.
- Do not alter the power cord.
- Do not place any heavy objects on the power cord.
- Do not bend, twist, or pull the power cord forcibly.
- Do not layout the power cord near a heating device.
Caution
Do not place the projector on an unstable surface, such as on an unstable table
or tilted surface. When projecting vertically, install the projector appropriately
to prevent the projector from falling.
Otherwise it may cause an injury.
Attention
•Do not install the projector in a location that is subject to vibration or
shock.
•Do not install the projector near a high-voltage line or object that generates
magnetism. Otherwise the projector may not work correctly.
•Do not use or store the projector in a location that is subject to extreme
temperatures. Also, avoid sudden temperature changes.
Make sure you use or store the projector in a place that is within the
following operating or storage temperature ranges.
- Operating temperature range: 0 to +45˚C
*
(No condensation)
- Storage temperature range: -10 to +60˚C (No condensation)
*At an altitude of 0 to 1,499 m, the operating temperature is 0 to
+45˚C when Power Consumption is set to ECO or Temp
Interlock, and 0 to +40˚C when it is set to Normal.
At an altitude of 1,500 to 3,048 m, the operating temperature is
0 to +40˚C when Power Consumption is set to ECO or Temp
Interlock, and 0 to +35˚C when it is set to Normal.
•When using at an altitude of 1,500 m or more, set High Altitude Mode to
On.
sExtended - Operation - High Altitude Mode p.112
Safety Warning and Cautions
4

Attention
•When projecting with the projector tilted, do not tilt it at more than the
specified angle. This may cause malfunctions or accidents to occur.
Angle of tilt
Vertical: Can be installed at any angle in a complete 360 degrees.
90
45
0
135
180
-135
-90
-45
Horizontal: Can be tilted within the range of expansion and contraction for
the rear feet. The feet can be attached and removed. Note that the feet will
detach if they are extended more than 10 mm.
•Once installation is complete, make sure you set the Direction. Otherwise the
lamp's operating life may be reduced significantly.
s"Setting the direction" p.26
•Using the projector at an improper angle or setting the Configuration menu
incorrectly causes malfunctions and shortens the operating life of optical
parts.
Attention
•Make sure there is a gap as shown in the following illustration between the
wall and the air exhaust vent and the air intake vent.
Air exhaust vent Air intake vent
•When setting up multiple projectors, make sure there is a gap of at least
50 cm between the projectors. Also, make sure that the heat from the air
exhaust vent does not go into the air intake vent.
•Do not place the projector directly on top of another projector.
•Do not project the image putting the projector longitudinally.
Safety Warning and Cautions
5

a
•We recommend setting the focus, zoom, and lens shift at least
30 minutes after you start the projection, because images are not
stable right after turning on the projector.
•When adjusting the image height with the vertical lens shift dial,
adjust by moving the image from the bottom to the top. If it is
adjusted from the top to the bottom, the image position may move
down slightly after adjusting.
Warning and Cautions on Usage
Warning
•Do not cover the projector's air intake vent or air exhaust vent. If either of
the vents is covered, the internal temperature could rise and cause a fire.
•Do not look into the lens while projecting.
•During projection, do not block the light from the projector with the lens
cover (removable) or a book and so on.
If the light from the projector is blocked, the area on which the light shines
becomes hot which could cause it to melt, burn, or start a fire. Also, the lens
may get hot due to the reflected light which could cause the projector to
malfunction. To stop projection, use the A/V Mute function, or turn off the
projector.
•A mercury lamp with high internal pressure is used as the projector's light
source. If the lamp is subjected to vibrations, shocks, or if it is used for an
overly extended length of time, the lamp may break or it may not turn on. If
the lamp explodes, gases may escape and small fragments of glass may be
scattered which could cause an injury. Be sure to observe the instructions
below.
- Do not disassemble or damage the lamp or subject it to any impacts.
- Do not bring your face close to the projector while it is in use.
- Particular care should be taken when the projector is installed to a
ceiling, as small pieces of glass may fall down when the lamp cover is
removed.
When cleaning the projector or replacing the lamp yourself, be very
careful not to allow such pieces of glass to get into the eyes or mouth.
If the lamp breaks, ventilate the area immediately, and contact a doctor if any
fragments of broken glass are inhaled or get into the eyes or mouth. In
addition, consult your local regulations regarding proper disposal and do not
place in the trash.
Safety Warning and Cautions
6

Caution
Do not place objects that may become warped or otherwise affected by heat
near the air exhaust vent and do not put your face or hands near the vent
while projection is in progress.
Attention
•Do not repeatedly turn off the power and immediately back on. Turning the
power on and off frequently may shorten the lamp's operating life.
•Only remove the lens unit when necessary. If dust or dirt enter the projector,
projection quality deteriorates and it could cause a malfunction.
•Try not to touch the lens section with your hand or fingers. If fingerprints or
oils are left on the surface of the lens, projection quality deteriorates.
•Store the projector with the lens unit installed.
If the projector is stored without the lens unit, dust and dirt may get inside
the projector and cause malfunctions or lower the quality of projection.
•When storing, make sure you remove the batteries from the remote control.
If the batteries are left in the remote control for an extended period of time,
they may leak.
Notes on Transporting
There are many glass parts and precision components inside the projector.
To prevent damage due to impacts when transporting, handle the projector
as follows.
Caution
Do not carry the projector by one person. Two people are needed to unpack or
carry the projector.
Attention
•Moving Nearby
- Turn off the power to the projector and disconnect all cables.
- Attach the cover to the lens.
•When Transporting
After checking the points in "Moving Nearby", prepare the following and then
pack up the projector.
- Remove the lens unit if an option lens, other than the standard zoom
lens, is installed. Attach the standard zoom lens if the projector has a
built-in lens. If the projector does not have a lens, attach the cover that
was on the lens mount when you purchased the projector.
- The vertical and horizontal lens shifts are positioned in the center.
- Enclose the projector securely in packaging material to protect it from
shock, and place it into a strong cardboard container. Be sure to notify
the carrier company that it is precision equipment.
Safety Warning and Cautions
7

Notations Used in This Guide ........................ 2
Introduction
PartNamesandFunctions .................................. 13
Front/Top...................................................13
Rear.......................................................14
Interface...................................................15
Base......................................................16
ControlPanel................................................16
RemoteControl...............................................18
Replacingtheremotecontrolbatteries............................. 20
Remotecontroloperatingrange.................................22
Preparing the Projector
Installing the Projector ..................................... 24
RemovingandAttachingtheProjectorLensUnit ........................24
Attaching.................................................24
Removing.................................................25
InstallationSettings............................................ 26
Settingthedirection.........................................26
Changingthedirectionoftheimage(projectionmode).................27
ScreenSettings ...............................................27
Adjustingthepositionoftheimageontheprojectedscreen..............28
DisplayingaTestPattern........................................28
AdjustingthePositionoftheProjectedImage(LensShift)..................30
AdjustingtheImageSize ........................................32
CorrectingtheFocus ...........................................32
WhenusingtheshortthrowzoomlensELPLU01......................32
AdjustingtheHeightoftheProjectedImage(forNormalInstallment)..........33
AdjustingtheHorizontalTilt(forNormalInstallment).....................33
IDSettings..................................................34
SettheprojectorID..........................................34
CheckingtheprojectorID ......................................35
SettingtheremotecontrolID...................................35
SettingtheTime ..............................................35
OtherSettings ................................................37
Settingsrelatedtobasicoperations............................... 37
Settingsrelatedtodisplay ......................................38
Connecting Equipment ..................................... 39
ConnectingaComputer.........................................39
ConnectingImageSources.......................................41
ConnectingExternalEquipment...................................43
ConnectingaLANCable.........................................44
ConnectinganHDBaseTTransmitter................................45
AttachingtheCableCover .......................................47
Attaching.................................................47
Basic Usage
ProjectingImages ......................................... 49
Automatically Detect Input Signals and Change the Projected Image (Source Search)
..........................................................49
SwitchingtotheTargetImagebyRemoteControl.......................50
AdjustingtheVolume..........................................50
AdjustingProjectedImages ................................ 51
CorrectingDistortionintheProjectedImage ...........................51
H/V-Keystone..............................................52
QuickCorner ...............................................53
CurvedSurface.............................................54
PointCorrection ............................................61
CornerWall ................................................ 63
SelectingtheProjectionQuality(SelectingColorMode)...................71
SettingAutoIris..............................................72
ChangingtheAspectRatiooftheProjectedImage .......................72
Changingmethods ..........................................72
AdjustingtheImage...........................................75
Hue,Saturation,andBrightnessadjustment.........................75
Gammaadjustment.......................................... 75
Contents
8

Frame Interpolation (EB-G6970WU only) . . . . . . . . . . . .................77
Projecting3Dimages...........................................77
Useful Functions
Multi-Projection Function . ................................. 79
Preparation................................................. 79
AdjusttheEdgesoftheImages(EdgeBlending) .........................80
Adjustingthebrightnessofthelamp ..............................80
Performingedgeblending.....................................80
AdjustingtoMatchColors........................................ 84
ScalinganImage(Scale).........................................85
ProjectionFunctions ....................................... 87
ProjectingTwoImagesSimultaneously(SplitScreen).....................87
Operatingprocedures........................................87
Restrictionsduringsplitscreenprojection...........................89
HidingtheImageandSoundTemporarily(A/VMute).....................90
FreezingtheImage(Freeze)......................................91
EnlargingPartoftheImage(E-Zoom)................................ 91
SavingaUser'sLogo ...........................................92
MemoryFunction .......................................... 94
Saving/Loading/ErasingtheMemory................................94
SchedulingFunction ....................................... 96
SavingaSchedule ............................................. 96
Settingmethods............................................96
Editingaschedule...........................................97
SecurityFunctions ......................................... 99
ManagingUsers(PasswordProtection) ...............................99
KindsofPasswordProtection ...................................99
SettingPasswordProtection ....................................99
Enteringthepassword ....................................... 100
RestrictingOperation .......................................... 101
ControlPanelLock ..........................................101
Remotecontrolbuttonlock ....................................102
Anti-TheftLock.............................................. 102
Installingthewirelock ....................................... 103
Configuration Menu
Using the Configuration Menu ............................. 105
ListofFunctions .......................................... 106
ConfigurationMenuTable ...................................... 106
Networkmenu............................................ 107
ImageMenu ................................................ 107
SignalMenu ................................................ 109
SettingsMenu ...............................................110
ExtendedMenu ..............................................112
NetworkMenu.............................................. 115
NotesonoperatingtheNetworkmenu............................116
Softkeyboardoperations..................................... 116
Basicmenu ............................................... 117
WiredLANmenu ........................................... 118
Mailmenu............................................... 118
Othersmenu ..............................................120
Resetmenu ............................................... 120
InfoMenu(DisplayOnly)........................................121
ResetMenu .................................................122
BatchSetup .............................................. 123
Setup by Connecting the Computer and Projector with a USB Cable . . . . . . . . . . 123
Savingsettingstoacomputer .................................. 123
Reflectingsavedsettingstootherprojectors ........................ 125
WhenSetupFails .............................................126
Contents
9

Troubleshooting
UsingtheHelp ........................................... 128
ProblemSolving .......................................... 129
ReadingtheIndicators ......................................... 129
WhentheIndicatorsProvideNoHelp ............................... 133
ProblemsRelatingtoImages .....................................134
Noimagesappear.......................................... 134
Movingimagesarenotdisplayed ................................134
Projectionstopsautomatically..................................135
Notsupportedisdisplayed .................................... 135
NoSignalisdisplayed ........................................135
Imagesarefuzzy,outoffocus,ordistorted......................... 136
Interferenceordistortionappearinimages ......................... 136
The image is truncated (large) or small, the aspect is not suitable, or the image has
beenreversed.............................................137
Imagecolorsarenotright ..................................... 138
Imagesappeardark ......................................... 139
ProblemswhenProjectionStarts .................................. 139
Theprojectordoesnotturnon................................. 139
OtherProblems ..............................................140
Nosoundcanbeheardfromthespeakers,orthesoundisfaint........... 140
Theremotecontroldoesnotwork ............................... 141
Nothingappearsontheexternalmonitor .......................... 142
Iwanttochangethelanguageformessagesandmenus ................ 142
Emailisnotreceivedevenifaproblemoccursintheprojector............ 142
Thebatterythatsavesyourclocksettingsisrunninglow.isdisplayed....... 143
CannotchangesettingsusingaWebbrowser....................... 143
Maintenance
Cleaning ................................................. 145
CleaningtheProjector'sSurface ...................................145
CleaningtheLens ............................................ 145
CleaningtheAirFilter ..........................................145
Cleaningtheairfilter ........................................ 145
ReplacingConsumables ................................... 148
ReplacingtheLamp ........................................... 148
Lampreplacementperiod .....................................148
Howtoreplacethelamp ......................................148
Resettingthelamphours..................................... 151
ReplacingtheAirFilter ......................................... 151
Airfilterreplacementperiod ................................... 151
Howtoreplacetheairfilter .................................... 151
ImageMaintenance ....................................... 153
PanelAlignment ............................................. 153
ColorUniformity............................................. 154
AdjustingtheLensBalance...................................... 156
Appendix
Monitoring and Controlling ............................... 161
AboutEasyMPMonitor .........................................161
AboutMessageBroadcasting.................................. 161
ChangingSettingsUsingaWebBrowser(WebControl) ................... 161
Projectorsetup............................................ 161
DisplayingtheWebControlscreen ...............................161
UsingtheMailNotificationFunctiontoReportProblems..................162
Readingerrornotificationmail .................................. 162
ManagementUsingSNMP ...................................... 163
DisplayingtheWebRemoteScreen................................ 163
ESC/VP21Commands..........................................164
Commandlist ............................................. 164
Cablelayouts............................................. 165
AboutPJLink ................................................166
About Crestron RoomView
®
..................................... 166
Operatingaprojectorfromyourcomputer......................... 167
Optional Accessories and Consumables .................... 171
OptionalAccessories.......................................... 171
Consumables............................................... 171
Contents
10

Screen Size and Projection Distance ........................ 173
Projection Distance (For EB-G6970WU) .............................. 173
StandardzoomlensELPLS07 ...................................173
ShortthrowzoomlensELPLU01 .................................174
RearprojectionwidelensELPLR03 ............................... 174
MiddlethrowzoomlensELPLM04 ............................... 175
MiddlethrowzoomlensELPLM05 ............................... 176
LongthrowzoomlensELPLL06 ................................. 177
Projection Distance (For EB-G6870) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
StandardzoomlensELPLS07 ...................................178
ShortthrowzoomlensELPLU01 .................................179
RearprojectionwidelensELPLR03 ............................... 180
MiddlethrowzoomlensELPLM04 ............................... 180
MiddlethrowzoomlensELPLM05 ............................... 181
LongthrowzoomlensELPLL06 ................................. 182
SupportedMonitorDisplays ............................... 184
SupportedResolutions ......................................... 184
Computersignals(analogRGB) ................................. 184
ComponentVideo.......................................... 184
Compositevideo........................................... 184
Input Signals from the HDMI port, DisplayPort, and HDBaseT port
*1
........ 185
InputsignalsfromSDIport(EB-G6970WUonly) ...................... 185
Specifications ............................................ 186
ProjectorGeneralSpecifications ...................................186
Appearance .............................................. 189
Glossary ................................................. 190
GeneralNotes ............................................ 192
AboutNotations............................................. 192
TrademarksandCopyrights ......................................193
Index .................................................... 194
Contents
11

Introduction
This chapter explains the names for each part.

The illustrations in this guide are for EB-G6970WU (with the standard
zoom lens ELPLS07 attached).
Front/Top
Name Function
AAir exhaust vent Exhaust vent for air used to cool the projector internally.
Warning
Do not look into the vents. If the lamp explodes,
gases may escape and small fragments of glass may
be scattered which could cause an injury. Contact
a doctor if any fragments of broken glass are in‐
haled or get into the eyes or mouth.
Caution
While projecting, do not put your face or hands
near the air exhaust vent, and do not place objects
that may become warped or damaged by heat near
the vent. Hot air from the air exhaust vent could
cause burns, warping, or accidents to occur.
BFocus ring Adjusts the image focus.
s"Correcting the Focus" p.32
CProjection lens Images are projected through here.
DZoom ring Adjusts the image size.
s"Adjusting the Image Size" p.32
ELens unit removal
button
When replacing the lens unit, press this button and then
remove the lens unit.
s"Removing and Attaching the Projector Lens Unit"
p.24
FRemote receiver Receives signals from the remote control.
GStatus indicators The color of the indicators and whether they are flashing
or lit indicate the status of the projector.
s"Reading the Indicators" p.129
Part Names and Functions
13

Name Function
HAir intake vent
(air filter)
Takes in air to cool the projector internally.
s"Cleaning the Air Filter" p.145
IAir filter cover
operation knob
Use this knob to open the air filter cover.
s"Replacing the Air Filter" p.151
JCable cover Cover for the rear interface cable connection section.
s"Attaching the Cable Cover" p.47
KVertical lens shift dial Turn the dial to move the position of the projected image
up or down.
s"Adjusting the Position of the Projected Image (Lens
Shift)" p.30
LLens shift dial lock Locks or releases the lens shift dials.
MHorizontal lens shift
dial
Turn the dial to move the position of the projected image
left or right.
s"Adjusting the Position of the Projected Image (Lens
Shift)" p.30
NLamp cover Open when replacing the projector's lamp.
s"Replacing the Lamp" p.148
Rear
Name Function
AInterface s"Interface" p.15
BSecurity slot The security slot is compatible with the Microsaver
Security System manufactured by Kensington.
s"Anti-Theft Lock" p.102
CPower inlet Connects the power cord to the projector.
DControl panel s"Control Panel" p.16
ECable holder Insert the supplied cable clamp here to prevent the cable
from falling out.
sQuick Reference
Part Names and Functions
14

Interface
Name Function
AAudio1 port Inputs audio from equipment connected to the Computer
port.
BComputer port For analog RGB signals from a computer and component
video signals from other video sources.
CBNC port For analog RGB signals from a computer and component
video signals from other video sources.
DAudio2 port Inputs audio from equipment connected to the BNC port.
ERS-232C port When controlling the projector from a computer, connect
it to the computer with an RS-232C cable. This port is for
control use and should not normally be used.
s"ESC/VP21 Commands" p.164
FRemote port Connects the optional remote control cable set and inputs
signals from the remote control. When the remote control
cable is plugged into the Remote port, the remote receiver
on the projector is disabled.
s"Optional Accessories" p.171
GAudio-L/R port Inputs audio from equipment connected to the Video port
or the S-Video port.
HVideo port Inputs composite video signals from video sources.
Name Function
IS-Video port For S-video signals from video sources.
JAudio Out port Outputs audio from the currently projected image to an
external speaker.
KMonitor Out port Outputs to an external monitor the analog signal from the
computer connected to the Computer port or the BNC
port. You cannot output signals input from other ports or
component video signals.
LDisplayPort Inputs video signals from DisplayPort compatible
computers. This projector is compatible with HDCP
g .
MHDMI port Inputs video signals from HDMI compatible video
equipment and computers. This projector is compatible
with HDCP
g .
NAudio3 port Inputs audio from equipment connected to the
DisplayPort or the HDMI port.
OHDBaseT port Connects a LAN cable to the optional HDBaseT
Transmitter.
s"Connecting an HDBaseT Transmitter" p.45
s"Optional Accessories" p.171
PLAN port Connects a LAN cable to connect to a network.
QSDI port (EB-G6970WU
only)
Inputs SDI signals from a video equipment. This projector
supports SD-SDI (Standard Definition) and HD-SDI
(High Definition).
RService port This port is used by maintenance personnel to control the
projector. This should not normally be used.
Part Names and Functions
15

Base
Name Function
AFront adjustable foot When setup on a surface such as a desk, extend the foot to
adjust the position of the image.
s"Adjusting the Height of the Projected Image (for
Normal Installment)" p.33
BRear feet When setup on a surface such as a desk, turn to extend and
retract to adjust the horizontal tilt.
s"Adjusting the Horizontal Tilt (for Normal
Installment)" p.33
Name Function
CScrew holes to fix the
cable cover
Screw holes to fix the cable cover in place.
s"Attaching the Cable Cover" p.47
DSecurity cable
installation point
Pass a commercially available wire lock through here and
lock it in place.
s"Installing the wire lock" p.103
ECeiling mount fixing
points (four points)
Attach the optional Ceiling Mount here when suspending
the projector from a ceiling.
s"Installing the Projector" p.24
s"Optional Accessories" p.171
FScrew hole for the
screw to fix the lens
unit removal button
When installing a lens unit, use this screw hole to fix the
lens unit removal button using the screw supplied.
s"Removing and Attaching the Projector Lens Unit"
p.24
Control Panel
Name Function
A[t] button Turns the projector power on or off.
B[Source Search]
button
Changes to the next input source that is sending an image.
s"Automatically Detect Input Signals and Change the
Projected Image (Source Search)" p.49
Part Names and Functions
16

Name Function
C[]/[ ] buttons •Displays the Control Panel Lock screen allowing you to
make settings to lock the control panel buttons.
s"Restricting Operation" p.101
•If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s"Using the Configuration Menu" p.105
s"Using the Help" p.128
D[] button •When the Configuration menu or the Help screen is
displayed, it accepts and enters the current selection and
moves to the next level.
•If pressed while projecting analog RGB signals from the
Computer port or the BNC port, you can automatically
optimize Tracking, Sync., and Position.
E[]/[ ] buttons •Displays a test pattern.
s"Displaying a Test Pattern" p.28
•If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s"Using the Configuration Menu" p.105
s"Using the Help" p.128
F[]/[ ] buttons •Displays the Info menu from the Configuration menu.
s"Info Menu (Display Only)" p.121
•If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s"Using the Configuration Menu" p.105
s"Using the Help" p.128
G[A/V Mute] button Turns the video and audio on or off.
s"Hiding the Image and Sound Temporarily (A/V
Mute)" p.90
Name Function
H[Esc] button •Stops the current function.
•If pressed when the Configuration menu is displayed, it
moves to the previous menu level.
s"Using the Configuration Menu" p.105
I[]/[ ] buttons •Performs screen adjustments using the settings in
Geometric Correction from the Configuration menu.
sSettings - Geometric Correction p.110
•If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s"Using the Configuration Menu" p.105
s"Using the Help" p.128
J[Menu] button Displays and closes the Configuration menu.
s"Using the Configuration Menu" p.105
Part Names and Functions
17

Remote Control Name Function
A[] button Turns the projector on.
B[t] button Turns the projector off.
CChange input buttons Changes to images from each input port.
s"Switching to the Target Image by Remote Control"
p.50
The [SDI] button is only available for EB-G6970WU.
The [LAN] button is not available for this projector.
D[Auto] button If pressed while projecting analog RGB signals from the
Computer port or the BNC port, you can automatically
optimize Tracking, Sync., and Position.
E[Aspect] button Each time the button is pressed, the aspect mode changes.
s"Changing the Aspect Ratio of the Projected Image"
p.72
F[Test Pattern] button Displays a test pattern.
s"Displaying a Test Pattern" p.28
G[Freeze] button Images are paused or unpaused.
s"Freezing the Image (Freeze)" p.91
H[Menu] button Displays and closes the Configuration menu.
s"Using the Configuration Menu" p.105
I[][ ][ ][ ]
buttons
•When the Configuration menu or the Help screen is
displayed, pressing these buttons selects menu items
and setting values.
s"Using the Configuration Menu" p.105
•When using the optional wireless mouse receiver,
pressing these buttons moves the pointer.
s"Optional Accessories" p.171
Part Names and Functions
18

Name Function
J[] button •When the Configuration menu or the Help screen is
displayed, it accepts and enters the current selection and
moves to the next level.
s"Using the Configuration Menu" p.105
•Acts as a mouse's left button when using the optional
wireless mouse receiver.
s"Optional Accessories" p.171
K[Split] button Each time the button is pressed, the image changes
between projecting two images simultaneously by
splitting the projected screen, or projecting one image as
normal.
s"Projecting Two Images Simultaneously (Split
Screen)" p.87
L[Page] buttons
[[][]]
When using the optional wireless mouse receiver, you can
change the PowerPoint file page during projection by
pressing the page up/page down buttons.
M[Volume] buttons
[a][b]
Adjusts the volume for audio output from the Audio Out
port.
[a] Decreases the volume.
[b] Increases the volume.
s"Adjusting the Volume" p.50
N[User1] button
[User2] button
[User3] button
Select any frequently used item from the eight available
Configuration menu items, and assign it to one of these
buttons. By pressing the button, the assigned menu item
selection/adjustment screen is displayed, allowing you to
make one-touch settings/adjustments.
s"Settings Menu" p.110
ONumeric buttons •Enter the Password.
s"Setting Password Protection" p.99
•Use this button to enter numbers in Network settings
from the Configuration menu.
Name Function
P[ID] button Hold down this button and press the numeric buttons to
select the ID for the projector you want to operate using
the remote control.
s"ID Settings" p.34
Q[ID] switch Use this switch to enable (On)/disable (Off) ID settings for
the remote control.
s"ID Settings" p.34
RRemote port Connects the optional remote control cable set and
outputs signals from the remote control.
s"Optional Accessories" p.171
When the remote control cable is plugged into this remote
port, the remote control light-emitting is disabled.
S[Help] button Displays and closes the Help screen which shows you how
to deal with problems if they occur.
s"Using the Help" p.128
T[Num] button Hold down this button and press the numeric buttons to
enter passwords and numbers.
s"Setting Password Protection" p.99
U[E-Zoom] buttons
[z][x]
Enlarges or reduces the image without changing the
projection size.
s"Enlarging Part of the Image (E-Zoom)" p.91
V[Default] button Enabled when [Default]: Reset is displayed on the
configuration menu guide. The settings being adjusted are
returned to their default values.
s"Using the Configuration Menu" p.105
W[Esc] button •Stops the current function.
•If pressed when the Configuration menu is displayed, it
moves to the previous level.
s"Using the Configuration Menu" p.105
•Acts as a mouse's right button when using the optional
wireless mouse receiver.
s"Optional Accessories" p.171
Part Names and Functions
19

Name Function
X[A/V Mute] button Turns the video and audio on or off.
s"Hiding the Image and Sound Temporarily (A/V
Mute)" p.90
Y[Color Mode] button Each time the button is pressed, the Color Mode changes.
s"Selecting the Projection Quality (Selecting Color
Mode)" p.71
Z[Search] button Changes to the next input source that is sending an image.
s"Automatically Detect Input Signals and Change the
Projected Image (Source Search)" p.49
a[] button Illuminates the buttons on the remote control for
approximately 15 seconds. This is useful when using the
remote control in the dark.
bIndicator A light is emitted when outputting remote control signals.
cRemote control light-
emitting area
Outputs remote control signals.
You can perform the following operations by simply pressing one of the
buttons on the remote control.
Operation Settings
Reverse the projected image vertically.
(Switch the Projection between Front and
Front/Ceiling)
s"Changing the direction of the image
(projection mode)" p.27
Hold down the [A/V Mute] button for more
than five seconds.
Selecting the password security settings.
s"Managing Users (Password
Protection)" p.99
Hold down the [Freeze] button for more
than five seconds. The Password Protection
screen is displayed, and you can select
various settings.
Locking or unlocking some of the operation
of the buttons on the remote control.
s"Remote control button lock" p.102
Hold down the [Help] button for more than
five seconds.
Initializing the settings for the Remote
Receiver in the Configuration menu.
(Enables all Remote receiver for this
projector.)
Hold down the [Menu] button for more than
15 seconds.
Displaying frequently used Configuration
menu items.
Press the [User1], [User2], or [User3]
button. You can set the menu item you want
to assign to each button in User Button.
sSettings - User Button p.110
The following items can be assigned.
Power Consumption, Info, Progressive,
Geometric Correction, Multi-Projection,
Resolution, Memory, or Image Processing
Replacing the remote control batteries
If delays in the responsiveness of the remote control occur or if it does not
operate after it has been used for some time, it probably means that the
batteries are becoming flat. When this happens, replace them with new
Part Names and Functions
20
