Barco Communicator Touch Panel User manual

Communicator touch panel
PC touch panel
Full version of Communicator software provided as standard
on the PC touch panel. Available for DP-1500, DP-2000, DP-3000
and via an upgrade for DP100 and DP90
System interfaces
USB ports x2
RS232 x1
Ethernet 10/100 Mb/s
LCD panel
8.4” viewable image size
Active display area: 800x600 pixels
Dimensions 170.4H x 127.8V
Active input selection
Control of active projector input and total configuration
of all related parameters
Macros
Automatic save to macro
Creation of macros
Projector preset activation
Activate the stored projector preset configurations
Projector preset configuration
Full control and configuration of the projector presets
Projector diagnostics
Access to projector diagnostics and diagnostics log file
Detailed diagnostics on fans speeds, all relevant voltages and internal
temperatures
Graphical configuration of resizing and masking
WYSIWYG interface for projector resizing and masking capabilities
CLO calibration
Calibration and read out of the CLO
Extended test and diagnostics utilities
Utilities to test ethernet connections, automation system, input signal er-
rors
Project color calibration capabilities
Color calibration utilities to calibrate your projector on site
Server monitoring
Monitor the server communication and commands for subtitle and meta-
data (equals Cine Canvas)
Look-up table management
Access and activate color, gamma and 3D look-up tables
User management
Administrator defines user level and password for all operators
Technical specifications
128844 - Leaflets.indd 7 23-02-2007 10:22:00

Barco nv
Media & Entertainment Division
Noordlaan 5, 8520 Kuurne, Belgium
T [phone] - F [phone]
email: [e-mail]
11101 Trade Center Drive,
Rancho Cordova, CA 95670, USA
T [phone] - F [phone]
www.barco.com
R599150 © 2007 Barco Technical specifications are subject to change without prior notice
Communicator navigation structure
Module Submodule Functionality User
all (default user + tt + st) • tt (theater technician + st) • st (service technician)
Read Write
Control Presets Basic lamp control all all
Dowser control all all
Preset control all all
Test patterns Pattern control all all
Other pattern control all all
Lamp control Lamp control all all
Configuration Presets Preset configuration all tt
Macro Read active MACRO file all na
Activate a macro file na all
Save to macro na tt
Edit macro file na tt
Image (PCF) Read active PCF file all na
Activate a PCF file na all
Change active area all tt
Save to macro na tt
Screen Read active screen file all na
Activate a screen file na tt
Anamorphic factor all na
Resizing all tt
Masking all tt
Save to macro na tt
Lens Read active lens file all tt
Activate a lens file na tt
Control all tt
Save to macro na tt
Other (extra) Read active EXTRA file all na
Activate a EXTRA file na all
Change input selection all tt
Change input packing all tt
Change processing path all tt
all tt
Edit change 3D settings all tt
GPI configuration all tt
Edit advanced source settings all tt
Save to macro na tt
Diagnostics Actual Actual diagnostics all na
History Projector all na
Security all na
Tests Test pattern na tt
Image freeze na tt
Self tests na tt
Port 292 error counts all tt
General purpose outputs all tt
Server settings Graphical overview all na
Timeline control all tt
Subtitle control all tt
MetaData control all tt
ACS-2048 Setup all na
Version info Version info all na
Installation Communication Network properties all tt
ACS-2048 properties all tt
Lamp Current light output all na
Mode selection all st
Light output calibration all st
CLO key all st
Auto lamp alignment na tt
Lamp settings all tt
Reset na tt
Color calibration Measure native color gamut all st
Select TCGD file na st
Verify corrected color gamut all st
Automation GPI configuration all tt
Advanced SNMP all st
Internal clock all tt
Touch panel Communication PC touch panel IP address all tt
Primary projector IP address and display name all tt
User Theater technician management st st
Service technician management st (Barco) st (Barco)
Display Navigation menu position all tt
PC touch panel brightness all tt
Sound all tt
Screensaver all tt
Orientation all tt
Language Language all tt
Diagnostics Version info all na
PC touch panel ID all na
PC touch panel log file all na
