Barnstead MaxQ 2000 Series User manual

MaxQ 2000
Open-Air Platform Shakers
MODEL NO.
SHKA2000
SHKE2000
SHKA2000-1CE
SHKE2000-1CE
057-278-00 • 1/17/05
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Safety Information ..............................................................................................................................................3
Alert Signals ................................................................................................................................................3
Warnings ......................................................................................................................................................3
General Specifications ........................................................................................................................................5
Environmental Operating Conditions............................................................................................................8
Declaration of Conformity............................................................................................................................ 8
SHKA2000, SHKA2000-1CE A-Class Control Panel Features ..........................................................................9
SHKE2000, SHKE2000-1CE E-Class Control Panel Features ........................................................................10
Unpacking and Installation ................................................................................................................................11
Shipping Carton ..........................................................................................................................................11
Unpacking ..................................................................................................................................................11
Location ......................................................................................................................................................11
Electrical Requirements ............................................................................................................................12
Platform Installation....................................................................................................................................12
Flask Clamp Installation ............................................................................................................................13
Test Tube Rack Installation ........................................................................................................................13
Operation ..........................................................................................................................................................14
SHKA2000, SHKA2000-1CE......................................................................................................................14
Power Switch ........................................................................................................................................14
Speed Control and Display ..................................................................................................................14
Time(r) ..................................................................................................................................................14
SHKE2000, SHKE2000-1CE......................................................................................................................15
Turning Shaker On................................................................................................................................15
Setting Shaking Speed ........................................................................................................................15
Calibrating Shaking Speed ..................................................................................................................15
Setting Timer for Timed Shaking ..........................................................................................................16
Setting Timer for Continuous Shaking ..................................................................................................17
RS232 Interface Port..................................................................................................................................17
Hyperterminal Configuration ......................................................................................................................18
Maintenance......................................................................................................................................................19
Cleaning ....................................................................................................................................................19
Troubleshooting ................................................................................................................................................20
Replacement Parts............................................................................................................................................21
Ordering Procedures ........................................................................................................................................22
Warranty ............................................................................................................................................................24
2
Table of Contents
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Your Barnstead|Lab-Line MaxQ 2000 Shaker has been
designed with function, reliability, and safety in mind. It is
your responsibility to install it in conformance with local
electrical codes. For safe operation, please pay attention
to the alert signals throughout the manual.
This manual contains important operating and safety
information. The user must carefully read and understand
the contents of this manual prior to the use of this equip-
ment.
Warnings
To avoid electrical shock, always:
1. Use a properly grounded electrical outlet of cor-
rect voltage and current handling capacity.
2. Disconnect from the power supply prior to main-
tenance and servicing.
To avoid personal injury:
1. Do not use in the presence of flammable or
combustible materials — fire or explosion may
result. This device contains components which
may ignite such materials. Not rated for use in
hazardous atmospheres.
2. Use appropriate hand and eye protection when
handling hazardous chemicals.
3. Refer servicing to qualified personnel.
4. Do not modify construction and/or assembly of
equipment.
5. Do not remove tags, labels, decals, or other
information from the unit.
6. Stand clear of equipment when it is operating.
7. If shaking action will result in the evolution of
gases or fumes, carry out the operation in a
well-ventilated laboratory hood.
3
Safety Information
Warning
Warnings alert you to a possibility of per-
sonal injury.
Caution
Cautions alert you to a possibility of
damage to the equipment.
Note
Notes alert you to pertinent facts and
conditions.
Hot Surface
Hot surfaces alert you to a possibility of
personal injury if you come in contact
with a surface during use or for a period
of time after use.
Alert Signals
Electric Shock
Cautions you to risks of electric shock.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4
SAFETY INFORMATION
8. Use equipment only for its intended purpose.
Use only the accessories and attachments that
are shipped with the equipment or are specified
for it. Substituting other attachments or acces-
sories can produce hazards or make the unit
inoperative.
9. Perform regular maintenance service as speci-
fied in this manual and keep unit in good repair.
Do not operate with known defects.
10. User is to determine optimum load/speed combi-
nations to ensure that shaker operates safely
with a balanced load. Normal operation can
include the requirements of the type of studies
to be performed I.E. aeration, solubility, mixing,
etc. The vessels should be securely clamped
before turning on shaker and contain a stopper
whenever possible to prevent hazardous sub-
stances from being thrown out during shaking
action. Shaking action should be set to begin at
a slow speed and gradually increased to desired
speed. The following stability chart indicates if
additional bracing is required.
Note
If installing these shakers on an
uneven surface, a leveling kit may be
ordered directly from the factory at
no charge.
10 lbs 20 lbs 30 lbs 40 lbs 50 lbs
100 rpm No No No No No
200 rpm No No No No No
300 rpm No No No No No
325 rpm No No No No No
350 rpm No No No No No
400 rpm No No No No No
450 rpm No No No Yes Yes
475 rpm No No No Yes Yes
500 rpm No No No Yes Yes
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

General Specifications
Model No. SHKA2000 SHKA2000-1CE SHKE2000 SHKE2000-1CE
Width 13.5” (34.4 cm) 13.5” (34.4 cm) 13.5” (34.4 cm) 13.5” (34.4 cm)
Height 6.4” (16.3 cm) 6.4” (16.3 cm) 6.4” (16.3 cm) 6.4” (16.3 cm)
Length 17.4” (44.2 cm) 17.4” (44.2 cm) 17.4” (44.2 cm) 17.4” (44.2 cm)
Weight lbs (kg) 40 lbs (18.1 kg) 40 lbs (18.1 kg) 40 lbs (18.1 kg) 40 lbs (18.1 kg)
Volts (AC) 120 220-240 120 220-240
Amps 0.6 1.0 0.8 0.4
Watts 45 100 45 45
Freq. 50/60 50/60 50/60 50/60
Exterior Unit Dimensions in. (cm)
5
Speed 40 to 400 rpm
+2 rpm
40 to 400 rpm
+2 rpm
15 to 500 rpm
+1 rpm
15 to 500 rpm
+1 rpm
Timer Continuous or timed
from 1-60 mins.
Continuous or timed
from 1-60 mins.
Continuous or timed
0.1-999 hours or
0.1-999 min.
Continuous or timed
0.1-999 hours or
0.1-999 min.
Recorder Output None None None None
RS232 Interface * None None Monitor speed and
time with a computer
Monitor speed and
time with a computer
Display
Analog tachometer
displays speed
in rpm
Analog tachometer
displays speed
in rpm
2 individual LED
displays indicate
time and speed
simultaneously.
3 characters
height 1/2 inches
(1.27 cm)
2 individual LED
displays indicate
time and speed
simultaneously.
3 characters
height 1/2 inches
(1.27 cm)
Soft Start Feature None None
Software algorithms
prevent sudden
start/stops
Software algorithms
prevent sudden
start/stops
Mutable Alarms None None
Audible portion of
the alarm can be
silenced for a period
of 1hr. without
deactivating the
actual alarm
condition by
depressing any key
Audible portion of
the alarm can be
silenced for a period
of 1hr. without
deactivating the
actual alarm
condition by
depressing any key
Electrical
* Interface cables not to exceed 9.8’ (3m) in length
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Model No. SHKA2000 SHKA2000-1CE SHKE2000 SHKE2000-1CE
Motor Permanent Magnet
DC
Permanent Magnet
DC
Solid State
Brushless DC
Solid State
Brushless DC
Speed None None
Audible with flashing
LED indicates
when speed
deviates more than
10% of set point
Audible with flashing
LED indicates
when speed
deviates more than
10% of set point
Speed Shut Off None None
When speed
deviates 10% of set
point, unit will shut
down immediately
When speed
deviates 10% of set
point, unit will shut
down immediately
Timer None None
Beeps twice when
time has expired.
Shaking motion
stops
Beeps twice when
time has expired.
Shaking motion
stops
Unbalanced Load None None
If the unit is running
in an unbalanced
condition, an alarm
will sound and the
shaker will stop
until the end user
corrects the condi-
tion. The speed dis-
play will flash “bAL”
on speed panel LED.
If the unit is running
in an unbalanced
condition, an alarm
will sound and the
shaker will stop
until the end user
corrects the condi-
tion. The speed dis-
play will flash “bAL”
on speed panel LED.
Alarms
6
GENERAL SPECIFICATIONS
Catalog Number LxW
30100 Universal 13” x 11” (33 x 27.9 cm)
30110 Universal 18” x 18” (45.7 x 45.7 cm)
30106 Universal 18” x 24” (45.7 x 60.9 cm)
Optional Platform Dimensions in. (cm)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

7
GENERAL SPECIFICATIONS
The Barnstead|Lab-Line MaxQ 2000 series bench top,
orbital, open-air shakers are available in one of two con-
trol configurations:
•SHKA2000 and SHKA2000-1CE incorporate a
mechanical timer for the control of time and
speed, adjustable with rotary dials. Analog
tachometer displays speed in RPM, verifying
accuracy of speed setting.
•SHKE2000 and SHKE2000-1CE control time
and speed by a microprocessor controller,
adjustable with membrane switches on keypad
in one rpm increments. Flashing display indi-
cates power interruption. Pressing any key will
clear display. Non-volatile memory maintains
speed and time set points in the event of a
power interruption. Speed and time set points
are automatically reactivated after power is
restored.
In addition, both versions offer:
•3/4 inch (1.9 cm) triple eccentric orbital drive
•6permanently lubricated ball bearings
•35 lb (15.9 kg) platform load capacity at safe
speeds less than 400 rpm for
SHKA2000/SHKA2000-1CE and less than 500
rpm for SHKE2000/SHKE2000-1CE
•UL, cUL and CE certification
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

GENERAL SPECIFICATIONS
Pollution Degree** 2
Installation Category** II
Altitude 2000 meters MSL (Mean Sea Level)
Relative Humidity 20% to 80% maximum, non-condensing
Electrical Supply 120 VAC or 240 VAC
Voltage Tolerance +10% of normal rated line
Temperature 0°C to 40°C
Product Usage This product is intended for use indoors only
Environmental Operating Conditions
**Refer to IEC 664-1
8
Declaration of Conformity
(for CE models only)
Barnstead International hereby declares under its sole responsibility that this product conforms with the tech-
nical requirements of the following standards:
EMC: EN 61000-3-2 Limits for harmonic current emissions
EN 61000-3-3 Limits for voltage fluctuations and flicker
EN 61326-1 Electrical equipment for measurement, control, and
laboratory use; Part I: General Requirements
Safety: EN 61010-1 Safety requirements for electrical equipment for
measurement, control, and laboratory use;
Part I: General Requirements
EN 61010-2-051 Part II: Particular requirements for laboratory equipment for
mixing and stirring
per the provisions of the Electromagnetic Compatibility Directive 89/336/EEC, as amended by 92/31/EEC and
93/68/EEC, and per the provisions of the Low Voltage Directive 73/23/EEC, as amended by 93/68/EEC.
The authorized representative located within the European Community is:
Electrothermal Engineering Ltd.
419 Sutton Road
Southend On Sea
Essex SS2 5PH
United Kingdom
Copies of the Declaration of Conformity are available upon request.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

9
GENERAL SPECIFICATIONS
SHKA2000, SHKA2000-1CE, A-Class Control Panel
Features
1. Power Switch: Turns power on and off to shaker
2. Speed Control: Sets platform rotation speed
3. Speed Tachometer: Analog display of platform rotation speed
4. Time(r): Allows user to choose either continuous or timed operation
Caution
It’s not recommended to operate shaker in a CO2enriched atmosphere. The formation of
carbonic acid could cause electrical failures.
1234
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

10
1. Power Switch: Turns power on and off to shaker
2. Speed Display: 3 digit LED indicates actual or set point speed
3. Up Arrow Key: Increases platform rotation speed
4. Down Arrow Switch: Decreases platform rotation speed
5. Speed Light: Red light Illuminates when a locked rotor or over-speed condition exists
6. RPM Light: Illuminates to indicate actual speed
7. Set RPM Light: Illuminates when speed is being set
8. Stop Switch: Stops platform rotation
9. Start Switch: Starts platform rotation
10. Time(r) Display: 3 digit LED indicates time remaining or elapsed time
11. Up Arrow Key: Increases shaking time
12. Down Arrow Key: Decreases shaking time
13. Elapsed Timer Light: Indicates accumulated time
14. Hours: Timer indicates hours
15. Minutes: Timer indicates minutes
16. Set Time: Illuminates when time is being set
17. Timer/Elapsed: Allows the user to choose elapsed time operation, Elapsed, or timed operation, Timer
18. Hours/Minutes Membrane Switch: Allows user to choose timing operation in either hours or minutes
GENERAL SPECIFICATIONS
SHKE2000, SHKE2000-ICE, E-Class Control Panel Features
1
2
3
4
5
6789
10
1112
13
14 15
16
1817
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

11
Shipping Carton
This should be inspected upon delivery. When received,
carefully examine for any shipping damage before
unpacking. If damage is discovered, the delivering carrier
should specify and sign for the damage on you copy of
the delivery receipt.
Open the carton carefully making certain that all parts are
accounted for before packaging materials are discarded.
After unpacking, if damage is found, promptly report it to
the carrier and request a damage inspection properly.
IMPORTANT: Failure to request an inspection of damage
within a few days after receipt of shipment absolves the
carrier from any liability for damage. You must call for a
damage inspection promptly.
Unpacking
Use the packing list below when unpacking to verify that
the complete unit has been received. Do not discard
packing materials until all is accounted for.
The following items are included in the shipment:
Model No. SHKA2000, SHKE2000, SHKA2000-1CE, or
SHKE2000-1CE
Operator’s Manual- 057-278-00
Product Registration Card- 528-022-00
Mounting Plate Mat- 790-316-11
Thumb Screw Knob- 562-184-10
Inspection Tag- 528-028-00
If any items are missing, contact Barnstead International
at 1-800-553-0039.
Location
Put the shaker on a level table or bench capable of sup-
porting the weight of the shaker with any accessories
while in operation. Place shaker near an electrical outlet
that matches the unit nameplate requirements. Allow
clearance around the unit for free air convection, acces-
sory attachments and user convenience.
Unpacking and Installation
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

UNPACKING AND INSTALLATION
12
Electrical Requirements
SHKA2000 and SHKE2000 require a 120 VAC, 50/60 Hz
power source. They are supplied with a 3-wire line cord and
should be plugged into an outlet designed for 3-prong plugs.
If an extension cord is used, it also should be the 3-wire
grounded type. For an outlet designed to accept 2-prong
plugs (ungrounded), it is required that a qualified electrician
replaces the outlet with a new, grounded type.
SHKA2000-1CE and SHKE2000-1CE require a 240 VAC,
50/60 Hz power source. They are supplied with a Schuko
cordset.
If a plug must be installed, use only the 3-prong grounded
type, rated for the unit load requirements and matching the
power outlet. Make sure the green ground wire is secured to
the plug ground terminal.
To eliminate hazard of electrical shock, make sure floor
around shaker is dry. In the event of accidental spilling or
splashing of liquids, clean up and/or neutralize the spilled liq-
uids before continuing.
Leave shaker disconnected when not in use.
Platform Installation
1. Select the appropriate platform for the vessels to be
shaken. A wide variety of platforms and
accessories are available:
• Dedicated platforms have the maximum number of
flask clamps attached for safe operation.
• Combination platforms allow the user to shake a
wide variety of different sized vessels on the same
platform.
2. Carefully position the platform horizontally over
the shaker’s mounting plate, allowing the 4 thumb
knobs on the sides of the mounting plate to line up
with the corresponding cut outs on the platform’s
sides.
3. Once the platform is in place over the outside edges
of the mounting plate, tighten the 4 thumb knobs to
secure platform to the mounting plate.
Warning
Do not operate shaker with a dam-
aged electrical cord.
Caution
Do not operate shaker with an unbal-
anced load. Platforms should be
loaded for optimum stability and
operation. Do not lift shaker by the
platform.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

13
Flask Clamp Installation
1. Carefully place the desired vessel in the clamp
by first pulling the clamp spring far enough apart
to enable the flask base to be positioned inside
the clamp. Gently slide the flask into its proper
position securing it to the wider bottom of the
clamp. The spring will hold the neck of the flask
securely in place and provide security during
shaking.
• Each flask clamp contains a support spring
located at the narrow top of the clamp.
• Depending on the size of the clamp, the clamp
base may contain one or several screws
necessary to secure the clamp to the platform.
All screws provided with the clamp must be
properly attached to the platform.
2. Make sure all vessels are securely clamped
before turning on unit.
Wherever possible, vessels should contain a stopper to
prevent hazardous substances being thrown out during
the mixing action.
Test Tube Rack Installation
1. Position the test tube rack on the combination
platform so that the cutouts on the rack’s out-
side bottom are aligned with corresponding
mounting holes on the platform. There are two
cutouts on each side of the rack.
2. Secure the rack to the platform with mounting
screws provided with the rack.
Warning
Do not operate the shaker at speeds
that will cause the contents of vessels
to be thrown out.
UNPACKING AND INSTALLATION
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

14
Operation
SHKA2000, SHKA2000-1CE
Please refer to page 8 for control panel reference.
Power Switch
1. Depress top portion of power switch to turn on
shaker.
2. Depress bottom portion of power switch to turn
off shaker.
Speed Control and Display
1. Slowly rotate the knob on the solid-state speed
control clockwise to increase speed and coun-
terclockwise to decrease speed. The markings
on the outside of the dial are for reference pur-
poses only.
2. The speed control tachometer provides an ana-
log readout of the actual platform rotation speed
up to a maximum of 400 rpm.
Time(r)
1. From the 12 o’clock off position, rotate timer
knob counterclockwise to the ON position to ini-
tiate continuous operation.
2. For timed operation, rotate timer knob clockwise
from 1 minute to 60 minutes. The markings on
the side of the dial are in 5-minute increments.
Caution
It is recommended that shaking
action be started at a low speed in
order to check that all vessels are
secure and that no spilling of
contents will occur.
Warning
Do not use shaker to mix flammable
materials or where the transfer of
mechanical energy to glass could
cause glass breakage.
Note
Shaker will not operate if the timer is
in the off position.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

15
OPERATION
Note
Speed can be changed without
pressing the start or stop membrane
switches. Simply press the appro-
priate up or down membrane switch
until desired rpm is reached.
SHKE2000 and SHKE2000-1CE
Please refer to page 9 for control panel reference.
Turning Shaker On
Beginning with the shaker power being turned off:
1. Press membrane POWER switch once (I) to turn
on shaker.
2. Press membrane POWER switch a second time
(0) to turn off shaker.
Setting Shaking Speed
1. Hold down appropriate arrow membrane switch
in the SPEED module of the control panel, up or
down, until desired speed is set up to 500 rpm.
SET RPM light will illuminate.
2. Press START membrane switch to begin shak-
ing. RPM light will illuminate.
3. Press STOP membrane switch to end shaking.
SET RPM light will illuminate.
Calibrating Shaking Speed
1. Choose a speed for which calibration is desired
by using the shaker’s UP or DOWN arrow keys.
2. Measure current shaker speed by using a digital
hand held tachometer.
3. If the tachometer reading matches the shaker
display, no calibration is necessary. If the
tachometer reading is different from the shaker’s
display, then calibration is required.
4. To get into the calibration mode, hold down the
START key, press and release the STOP key,
then release the START key.
5. The decimal point on the SPEED display will
flash indicating you are in the calibration mode.
Note
There will be a 3 second delay from
the time power is turned on to the
time the shaker is activated.
Control panel will illuminated when
shaker power is activated.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

OPERATION
16
6. Use the UP or DOWN arrow keys to set the
shaker speed to match the tachometer’s read-
out.
7. Press STOP key to enter the new speed value.
8. Press START key to exit the calibration mode.
Setting Timer for Timed Shaking
1. Press TIMER/ELAPSED membrane switch until
TIMER and SET TIME lights are illuminated.
The HOURS or MINUTES light will also light up
at this point depending on which option was pre-
viously chosen.
2. Press HOURS/MINUTES membrane switch for
desired timing mode.
3. Hold down appropriate arrow membrane switch
in the TIME module of the control panel, up or
down, until desired timing cycle is set from 0.1
hour up to 999 hours, or from 0.1 minute to 999
minutes depending on which timing mode is
chosen. SET TIME light will illuminate.
4. Press START to begin timed shaking countdown
will begin from time set. TIMER and MINUTES
or HOURS lights will illuminate and timer will
count down from time selected. An audible
alarm will sound at the end of the timing cycle
and platform rotation will cease.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

17
Setting Timer for Continuous Shaking
1. Press TIMER/ELAPSED membrane switch until
ELAPSED light is illuminated. The HOURS or
MINUTES light will also light up at this point
depending on which option was previously cho-
sen.
2. Press HOURS/MINUTES membrane switch for
desired timing mode.
3. TIME display should show 000. Press START to
begin timed shaking. Timer will begin to count
up and will display accumulated time in display
window. Platform rotation will cease and TIME
display will flash when ELAPSED time reaches
999 minutes or 999 hours.
RS232 Interface Port
The RS232 interface port is located on the left side rear of
the shaker cabinet and requires the use of a laptop or
desk top computer running Microsoft Windows 98 or
newer operating system.
RS232 Interface Port
OPERATION
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

18
OPERATION
Hyperterminal Configuration
1. Power up the host computer and close any run-
ning applications.
2. Open the HyperTerminal application by clicking
on “Start” \ “Programs” \ “Accessories” \
“Communications” \ “HyperTerminal.”
3. In the “Connection Description” box, enter the
name “Max Q Shaker” and choose an icon and
click “OK.”
4. In the “Connect To” box, verify that “COM1” is
selected under “Connect Using.” Click “OK.”
5. In the “COM1 Properties” box \ “Port Settings”
folder select the following options:
Bits per second: 19200
Data bits: 8
Parity: None
Stop bits: 1
Flow control None
After verifying the above settings, click “OK.”
6. In the main dialog box click on “File” \ “Save.”
7. Exit the program by clicking on “File” \ “Exit” \
“Yes”.
8. Verify the program was saved by going to “Start”
\ “Programs” \ “Accessories” \
“Communications” \ “HyperTerminal” \ “Max Q
Shaker.”
9. This completes the configuration of
HyperTerminal.
10. Turn shaker off and connect computer (COM 1)
to shaker (COM PORT) with DB-9 serial printer
cable.
11. Start HyperTerminal by clicking on “Max Q
Shaker.”
12. Power up shaker. Shaker will screen print
Note
RS232 Interface Port is for output
only. Interface cables must not
exceed 9.8’ (3m) in length.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

19
Maintenance
Cleaning
Wash the exterior of the unit with a soft cloth using a
solution of mild soap and water, rinse off with clean water
and dry thoroughly.
Suggested with every 3 months of constant use
Any internal adjustments or repairs must be performed by
a qualified service representative.
Remove the platform by loosening 4 flat head screws in
the platform center. Remove the sheet metal panel under
the platform to expose the belt and interior parts. Inspect
the drive belt for wear and proper tension. Order a
replacement if necessary.
SHKA2000 and SHKA2000-1CE only
1. Take out the 3 large motor mount screws and lift
the motor out.
2. 2 brushes are located under plastic caps on
opposite sides of the lower part of the motor.
Unscrew the plastic caps and slide the brushes
out. Replace brushes when they are worn down
to 3/16" (.48 cm) in length.
3. Belt tension is automatically set by the location
of the motor and is not adjustable.
4. To align a pulley, loosen the motor pulley set
screw, slide the pulley up or down into alignment
then securely tighten the motor pulley set screw.
Maintenance
Note
Make no attempt to service or repair
a Barnstead|Labline product under
warranty before consulting your
Barnstead International dealer. After
the warranty period, such consulta-
tion is still advised, especially when
the repair may be technically sophis-
ticated or difficult. If assistance is
needed beyond what the distributor
can provide, please call Barnstead
International Customer Service at
800-553-0039. No merchandise
should be returned directly to
Barnstead International without prior
approval from Barnstead
International.
Warning
Disconnect plug from electrical outlet
before attempting any maintenance or
repair of this unit.
Note
The shaking mechanism is equipped
with sealed ball bearings which do
not require further lubrication or
adjustment.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

20
melborPsesuaCelbissoPsnoituloS
etarepot'nseodrekahSnideggulpsidrocrewopfikcehC
sehctamylppusrewopfikcehC
lebalatadnostnemeriuqer
esufkcehC,ssalC-E
nosthgilgnihsalfrofkcehc,ssalC-E
lenaplortnoc
siremitdespalefikcehc,ssalC-E
gnihsalf
"ffo"nisiremitfikcehc,ssalC-A
noitisop
sihctiwsrewopfikcehc,ssalC-A
gninoitcnuf
nigulP
tinusehctamtahtylppusrewopehtetacoL
stnemeriuqer
esufecalpeR
lenaplortnocnohctiwsenarbmemynasserP
remitteseR
noitarepodemitrosuounitnocrofremitteS
evitcefedfiecalpeR
roetatort'nseodmroftalP
deepscitarresah
rotomotrewoprofkcehC
tlebevirdkcehC
deepsotrewoprofkcehc,ssalC-A
lortnoc
evitcefedfirotomecalpeR
yellupffodeppilsronekorb,nrowfiecalpeR
evitcefedfiecalpeR
Troubleshooting
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
