LUBE BIOLUBE 1000 Series User manual

Operating Instructions
for
LUBE MASTER SPRAY SYSTEM
1000 Series
 



4611 NEWAYGO ROAD, SUITE D, FORT WAYNE INDIANA 46808
PH:260-414-9633 EMAIL: [e-mail] www.biolube1.com
2
Operation:
The function of the Lubie sprayer is to apply a small amount of lubricant/coolant through
atomizing nozzles onto the cutting tool. The high-pressure air drives the lubricant/coolant
onto the tooling.
The higher the speed of the tooling the higher the air pressure you will use. Band saws
generally use 20-60 psi, moulders, finger jointers and circle saws 90-120 psi.
Disconnect or shut off air supply to the spray system.
1. After tank is completely de-pressurized remove cap.
2. Fill tank with Lubie approved lubricant.
3. Replace cap and reconnect or turn on air supply.
4. Maximum air pressure: 150 PSI
IMPORTANT NOTES:
1. Use Lubie approved lubricants only.
2. Never use any flammable or combustible liquids (class 3 or 4) in Lubie spray
systems; DIESEL FUEL IS CLASS 4.
3. Never remove the fill cap while the tank is pressurized. Always allow system to de-
pressurize before attempting to remove fill cap.
4. Water-based lubricants will freeze in winter. If the temperature of your mill falls
below 32° F then install a belly band tank heater (PN: OP-4) or build a heated
enclosure around the tank.
5. It is important that you install the air pressure regulator with filter. Rust, scale and
other contamination in air lines can clog the very small ports in the metering venturi.
6. The closer the nozzle to the tooling the better the lubricant delivery. Make sure and
leave enough room to easily remove the tooling.

4611 NEWAYGO ROAD, SUITE D, FORT WAYNE INDIANA 46808
PH:260-414-9633 EMAIL: [e-mail] www.biolube1.com
3
Assembly and Mounting
Unpack the box and check to make sure the tank, nozzles, tubing, air pressure regulator and
any option parts are un-damaged. Generally mounting will take 45 minutes or less. You will
need a compressed air line with ball valve and a ½” male NPT fitting going to the air
pressure regulator.
We do not recommend nozzles on the outside of the band unless you are having problems
with extreme pitch build-up, which is rare for most large vertical head saws and resaws
cutting hardwoods. Two nozzles above the guide and two nozzles on the inside back.
Sometimes a narrow band has pitch problems on the outside and the Lube Master can help.
Direct the outside nozzle to the band just before it enters the cut. Outside nozzles should
only be installed at the guide just before the blade goes into the wood.
1. Sit the tank upright (it will not work laying on its side) somewhere close to the
machine where you can fill the tank easily and where employees do not trip over the
air line or tubing that runs to the nozzles.
2. Mount the spray nozzles/brackets so that they are between ½” and 3” away from the
tooling. This will vary depending upon whether it’s a band saw, circle saw, finger
jointer or other tooling. See nozzle mounting pictures. The closer the nozzle to the
saw the better but leave room for saw removal.
3. Run the ¼” poly tubing from the tank to the nozzles and wire tie them so they don’t
get caught in your machine.
4. Fill the tank with lube and attach your air line to the air pressure regulator.
5. You are now ready to start the sprayer. See Lubricator adjustment & pressure
settings.

4611 NEWAYGO ROAD, SUITE D, FORT WAYNE INDIANA 46808
PH:260-414-9633 EMAIL: [e-mail] www.biolube1.com
4
Nozzle Mounting:
12” Band Saw with 2 nozzles mounted just
above guide, 2 additional nozzles go on the
inside of the saw. Any place that is easy to
attach the nozzles on the inside back is OK.
The objective is to coat the blade before it
reaches the top wheel. This prevents any pitch
transfer to the wheel.
1 ½” narrow band inside mount.
1 ½” narrow band standard mount
Finger Jointer

4611 NEWAYGO ROAD, SUITE D, FORT WAYNE INDIANA 46808
PH:260-414-9633 EMAIL: [e-mail] www.biolube1.com
5
Now that the nozzle mounting is done, fill the tank with lube and attach your airline to the
air pressure regulator. Turn on the air and set the air pressure regulator for the saw or
tooling you are using. See the pressure settings below. Next set the lubricant flow by turning
the black knob on the top of the clear sight dome.
Lubricator Adjustment & Pressure Settings
LEANER – Clockwise
RICHER –Counter Clockwise
Drops per Minute Total Volume
25 dpm 1oz/hr (1/2 pint per 8 hours)
50 dpm 2 oz/hr (1 pint per 8 hours) standard narrow band setting, 2 nozzle
100 dpm 4 oz/hr (1 quart per 8 hours) standard 7”-12” band setting, 4 nozzle
200 dpm 8 oz /hr ( ½ gal per 8 hours) standard 12-14” band setting, 4 nozzle
¾-2” band saws 20-30 psi
3-8” band saws 30-40 psi
10-14” band saws 50-70 psi
Circle saws, moulders, finger jointers 90-110 psi
Your final adjustment will be to adjust the lubricant flow to each nozzle. This is done by
opening or closing the ball valves on the top of the lubrication unit. The yellow handles.
For band saws the best general adjustment is for the line that runs to the inside of the band
pointing at the gullet and tooth area is left fully open. The nozzle that points to the inside
body of the band is 50% open and the two nozzles spraying the outside of the band are 25%
open. If you see build-up stating in any area of the band you can then fine tune the amount
of lubricant to that area.

4611 NEWAYGO ROAD, SUITE D, FORT WAYNE INDIANA 46808
PH:260-414-9633 EMAIL: [e-mail] www.biolube1.com
6
Cold Weather Operation
All water-based lubricants will freeze in the lines and tank at below 32F. There are a
number of solutions to this problem.
1. Tank freezing is easily remedied by;
a. Installing a 110-volt belly band heater on the tank (PN: 5W669)
b. Building a box around the tank and putting a 25-watt light bulb in the box.
c. Sitting the tank on top of a metal pail and putting a 50-watt light bulb in the
pail.
2. Lube freezing in the lines is the most common problem and to solve this first gently
turn the black drip adjustor knob on top of the lubricator until it stops dripping. Wait
for a minute or two and let the air pressure blow all the lube out of the lines. Then
turn off your air line ball valve or on the air pressure regulator turn off the air. In the
morning simply turn on the air and readjust the lube drip rate.

4611 NEWAYGO ROAD, SUITE D, FORT WAYNE INDIANA 46808
PH:260-414-9633 EMAIL: [e-mail] www.biolube1.com
7

4611 NEWAYGO ROAD, SUITE D, FORT WAYNE INDIANA 46808
PH:260-414-9633 EMAIL: [e-mail] www.biolube1.com
8
WARNING:
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS AND OR
SYSTEMS DESCRIBED HEREIN OR RELATED ITEMS CAN CAUSE DEATH, PERSONAL INJURY,
AND PROPERTY DAMAGE.
It is important to analyze all aspects of the applications, including consequences of any failure and review the
information concerning the product or system in the current product catalog. Due to the variety of operating
conditions and applications for these products or systems, the user, through its own analysis and testing, is solely
responsible for making the final selection of the products and systems and assuring that all performance, safety and
warning requirements of the application are met.
The products described herein, including without limitations, product features, specifications, designs, availability
and pricing, are subject to change by Biolube and its subsidiaries at any time without notice.
Contact your local representative for extra copies of these instructions.
To replace/remove the Drip Control (P# OP-6)
1. Turn off air supply and depressurize the unit
2. Unscrew drip control by rotating sight dome counterclockwise. Carefully remove seal plate. Note:
Do not damage surface on body underneath seal plate.
3. Lubricate seal plate with grease found in kit. Align pin on underside of seal plate with mating hole
in body and install seal plate.
4. Install sight dome and drip tube. Tighten to 10-15 inch pounds of torque.
5. Turn on air supply and check for leakage. If leaks occur, repeat repair procedure.

4611 NEWAYGO ROAD, SUITE D, FORT WAYNE INDIANA 46808
PH:260-414-9633 EMAIL: [e-mail] www.biolube1.com
9
WARNING
To avoid unpredictable system behavior that can cause personal injury and property damage.
•Disconnect air supply and depressurize all airlines connected to this product before installation, servicing, or
conversion.
•Operate within the manufacturer’s specified pressure, temperature and other conditions listed in these
instructions.
•Medium must be moisture-free if ambient temperature is below freezing.
•Service according to procedures listed in these instructions.
•Installation, service, and conversion of these products must be performed by knowledgeable personnel who
understand how pneumatic products are to be applied.
•After installation, servicing, or conversion, air supply should be connect4ed and the product tested for proper
function and leakage. If audible leakage is present, or the product sones not operate properly, do not put into
use.
•Warnings and specifications on the product should not be covered by paint, etc. If masking is not possible,
contact your local representative for replacement labels.
To service Venturi Lubricator (Use P# OP-5)
1. Turn off air supply and depressurize unit.
2. Unscrew thumb screw (P# C-2) and remove from the Venturi (P# C-1) from the tank.
3. Remove the two screws in the body holding the plastic insert. Notice the direction the little tip on the outside
of the plastic insert points!
4. Clean all internal sealing surfaces. The lubricant you use generally works well for cleaning.
5. Lubricate all seats and O-rings with grease found in kit.
6. Install O-ring into Lubricator body.
7. Sub-assemble the plastic insert and seal. Note: The flapper must be assembled so that the hole in the flapper
lines up with the hole in the insert.
8. Install plastic insert. Notice the direction the little tip on the outside of the plastic insert points!
9. Tighten the two screws to 10-12 inch pounds of torque.
10. Install Venturi body (P# C-1) onto tank and lock into place.
11. Tighten thumb screw (P# C-2).
12. Turn on air supply and check lubricator for leakage. If leakage occurs, Do Not Operate - repair again.
FLAPPER
Enlarged to show detail
Insert

4611 NEWAYGO ROAD, SUITE D, FORT WAYNE INDIANA 46808
PH:260-414-9633 EMAIL: [e-mail] www.biolube1.com
10
Lubie® Lubes
Lubie Lubes are formulated for specific uses to meet your particular needs. No silicones or waxes are used in any of
our products and most are free of toxic or hazardous chemicals and are biodegradable. Lubricants are available for
both saw and moulder bed applications.
Our coolants and cleaners are formulated for all types of manual and automatic grinding and machining operations.
They are commonly used with high-speed steel, carbide or coated carbide tooling. Economical and resistant to
bacterial growth, these coolants have excellent water dilution rates, resist cobalt leaching, provide effective corrosion
and rust protection extending tool life.
