Baron 90800 Original instruction manual
1100W MEAT GRINDER
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER)
OWNER’S MANUAL AND SAFETY INSTRUCTIONS
ITEM: 90800
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: 909.628.0880 MON-FRI 9AM TO 3PM PST
1
IMPORTANT SAFETY INFORMATION
GENERAL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to follow the warnings and instructions may
result in electric re and/or serious injury. Save all warnings and instructions for future reference.
The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but must be supplied by the operator. Read
carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to
follow the safety rules and other basic safety precautions may result in serious personal injury.
Read and understand all instructions. Failure to follow all instructions may result in serious injury or
property damage.
DO NOT allow persons to operate or assemble the product until they have read this manual and have
developed a thorough understanding of how it works.
DO NOT modify this product in any way. Unauthorized modication may impair the function and/or
safety and could affect the life of the product. There are specic applications for which the product was
designed.
NEVER operate this appliance unattended.
ALWAYS ensure that the appliance is properly assembled and safely set up before use.
CAUTION: This appliance is not recommended for use near or by children or persons with certain
disabilities. Set up and store the appliance out of reach of children. When not in use, store device in a
secure and dry place out of reach of children
Store appliance in upright position to extend life of motor .
The appliance must be connected to a 120V AC electric supply only.
DO NOT operate with a damaged cord or plug, after the unit malfunctions, has been damaged in any way
or if appliance has been immersed in water or other liquid. Return unit to LEM Products for assessment
and repair. ALWAYS unplug unit when not in use, when changing parts or cleaning.
Indoor use only. To protect against the risk of electrical shock, never immerse the device in water and
DO NOT expose the device to rain or moisture. WARNING: In the event the device should fall into water,
remove the plug from the wall socket before attempting to remove the unit from the water. If submergence
occurs, have the appliance examined by an authorized technician before use.
To protect against the risk of electrical shock, DO NOT use the appliance if your hands are wet or if you are
standing on a wet oor. DO NOT use the appliance if it is wet or moist. DO NOT operate this device with
wet hands or bare feet. DO NOT operate near running water.
DO NOT use the appliance to grind bones, deep frozen food, hard items or non-food items.
Use the appliance with the supplied accessories only. WARNING: The use of attachments not recommended
or sold by the manufacturer may cause injury and/or damage to personal property.
2
PARTS LIST
WARNING: DO NOT use while under the inuence of alcohol or drugs (prescription or non-prescription) as
these may impair user’s ability to properly assemble or safely operate the appliance.
Avoid contacting moving parts. Wait until all parts have come to a complete stop and disconnect from the
power source before removing any parts of the grinder.
WARNING: NEVER feed food into grinder by hand as serious injury may occur, always use provided meat
stomper. DO NOT use ngers to scrape food away from the grinding plate while the grinder is running.
Thoroughly hand-wash all grinder parts in warm soapy water prior to use. DO NOT soak. This product is
NOT DISHWASHER SAFE (discoloration may occur)
Tie back loose hair and clothing. Remove neckties, rings, watches, bracelets or other jewelry before
operating the grinder.
DO NOT run grinder without meat in the Grinder Head, severe damage to the Grinder Head and Auger
could result.
Use grinder on a level, stable surface to prevent tipping. NEVER move the grinder while unit is in use.
WARNING: Knife and plates are SHARP! To avoid injury, use extreme caution when handling.
If your unit fails to operate, contact Barton for technical assistance at 909.628.0880. If meat is mashing
instead of extruding in strings from the grinding plate, chill the meat to 40˚, and check to see that the plate
and knife are properly installed. A dull knife or plate will also cause mashing of the meat.
To protect against risk of electrical shock, DO NOT put appliance in water or any other liquids
DO NOT place this appliance on or near gas or electric burners or stoves. DO NOT place this appliance
inside or on top of a heated conventional oven, microwave oven, or other heat source or a dishwasher.
DO NOT submerse or expose the electrical components of this product to water or any other liquids.
WARNING: The cutting blade is sharp; always handle with care when using and while cleaning.
CAUTION: NEVER PUT YOUR FINGERS NEAR THE FOOD CHUTE WHILE GRINDER IS IN OPERATION.
To avoid a circuit overload, do not operate another electrical product on the same electrical circuit as this
product.
Disconnect the plug (DO NOT pull on Power Cord) from the electrical outlet. DO NOT put any stress on
the Power Cord where it connects to the product, as the Power Cord could fray and break.
NEVER operate this appliance if it has a damaged Power Cord or plug, is not working properly, has been
dropped or damaged in any manner, or the Power Cord or Handle has been exposed to water or any other
liquids. DO NOT attempt to examine or repair this product yourself.
DO NOT use any abrasive cleaning agents or cleaning cloths or sponges when cleaning the appliance.
yourself.
DO NOT use ngers to scrape food away from the cutting blade while appliance is in operation as injury
may result.
Only use this unit when it is completely and properly assembled.
Longer power-supply cords or extension cords are available and may be used if care is exercised in their
use. If an extension cord is used: (1) the marked electrical rating of the extension cord should be at least
as great as the electrical rating of the product.
PRODUCT INFORMATION
1100W Stainless Steel Electric Meat Grinder Mincer 1HP
This electric powered commercial meat grinder suitable for industrial and home
use and the powerful 1100 watts (1HP) to grind through tough meats quickly. The
stainless steel makes it easy to clean up and ensures long lasting use. Fast grinding
speeds that can easily grind through 396lbs of meat in an hour. A blade speed so
fast it performs at 220 rotations each minute and works to compliment the unit’s
grinding capacity/speed.
Offset head design with high speed not only guarantees you a quiet use without
any noise, but maximizes your efciency becoming as a good helper for you. You
can also be satised with its long lifetime. Its reasonable price does provide a high-
quality performance of the grinder set itself
T-304 Stainless steel construction is easy to clean and is durable enough for
commercial use.
This electric meat grinder comes with 2 different cutting plates. You can easily grind
different sizes of meat by changing the cutting plate.
Made of food-grade material, it can provide safety to you and your families. Also it
will be easy to disassemble and wash. You just need to wash each parts with warm
soapy water.
3
PRODUCT INFORMATION
4
CUTTING
DISCS
CUTTING
BLADE
SCREW
RING
MEAT
TUBE
MEAT
TRAY
POWER
SWITCH
ELECTRICAL
PLUG
MOTOR
HOUSING
CUTTING
PLATES
MEAT
PUSHER
FEED
SCREW
BASE
MEAT SCREW
HOUSING
SPECIFICATIONS
ASSEMBLY
4
1. Place feed screw into the head, login rst by turning the feed screw slightly until it is set into the motor.
2. Place cutting blade onto feed screw shaft with the blade facing the front as illustrated below.
3. Place desired cutting blade next to the cutting blade, gap align the pin to head.
4. Screw cap into place into place until it is tight. DO NOT over-tighten. Place the hopper plate on the head
and afx it into position. The air passage at the bottom and the side of the motor housing should not be
blocked.
5. Cut meat into small pieces that will easily t into the throat of the grinder head. Meat should be 40˚ or colder
and free of gristle, sinew, silver skin, and bone. Feed meat slowly into the feed tube of the head.
7. Push food into the meat tube using the meat pusher tool (included).
6. Plug in the unit and turn the power on.
NEVER USE FINGERS TO PUSH MEAT INTO THE HEAD
8. Grind meat through the coarse plate rst, turn motor off and unplug the grinder. If a smaller grind is desired
chill meat. Then, remove the coarse plate and clean the head of sinew, fat or gristle that has accumulated
during the rst grind. Assemble the unit with the ne plate, plug grinder in and regrind the meat.
MAINTENANCE AND TROUBLESHOOTING
5
CLEANING
1. Make sure the motor is stopped completely and disconnect the plug from the power outlet.
2. Unscrew the side cap and locking knob and take out the knob (with cutting plates, cutting blade and the
feed screw) then put the head mouth downward in order to take out the cutting plate, cutting blade and feed
screw.
3. Remove meat etc. and wash parts in warm, soapy water.
A bleaching solution containing chlorine will discolor aluminium surfaces.
DO NOT immerse motor housing in water. Only wipe it with a damp cloth.
Thinners and benzenes will crack or change the color of the unit.
Caution is necessary when cleaning the cutting blade. DO NOT use a perforated disc of holes less than
8mm in diameter or smaller unless an additional protective hood is provided at the dicharge outlet.
DO NOT use harsh abrasive cleaners or materials that can harm the nish on the grinder.
The cutting blade and cutting disc should be thinly coated with cooking oil after washing to keep them
lubricated and rust free.
HINTS FOR BEST USE:
Cut food into strips or cubes slightly smaller than the opening on the feeding tube.
Make sure food is free of bone, tough tendons, nut shells, etc. before grinding.
Raw meat or sh should be thoroughly chilled (not frozen) before grinding to reduce the loss of juices.
Freshly ground meat should be refrigerated and cooked within 24 hours.
Occasionally use a small amount of vegetable oil on a cloth to grease the cutting parts.
MAINTENANCE
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available individually
as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
SAVE THESE INSTRUCTIONS
9
PRODUCT MADE IN CHINA
