Bartscher IK 20 Quick start guide

IK 20
105820
0613/4V

- 17 -
ENGLISH
Translation
of the original instruction manual
1. General information................................................................................................ 18
1.1 Information about the instruction manual ............................................................ 18
1.2 Key to symbols.................................................................................................... 18
1.3 Liability and Warrantees...................................................................................... 19
1.4 Copyright protection............................................................................................ 19
1.5 Declaration of conformity..................................................................................... 19
2.Safety ........................................................................................................................ 20
2.1 General information............................................................................................. 20
2.2 Safety instructions for use of the device.............................................................. 20
2.3 Intended use ....................................................................................................... 21
3. Transport, packaging and storage......................................................................... 22
3.1 Delivery check..................................................................................................... 22
3.2 Packaging ........................................................................................................... 22
3.3 Storage................................................................................................................ 22
4. Technical data......................................................................................................... 23
4.1 Technical specification........................................................................................ 23
4.2 Control panel....................................................................................................... 23
5. Installation and operation....................................................................................... 24
5.1 Functionality of induction cookers ....................................................................... 24
5.2 Safety instructions............................................................................................... 25
5.3 Suitable and unsuitable cookware....................................................................... 26
5.4 Installation and connection.................................................................................. 27
5.5 Operation ............................................................................................................ 28
6. Cleaning and maintenance..................................................................................... 30
6.1 Safety advice....................................................................................................... 30
6.2 Cleaning.............................................................................................................. 30
6.3 Safety instructions for maintenance .................................................................... 30
7. Possible Malfunctions ............................................................................................ 31
8. Waste disposal........................................................................................................ 32
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
GB/UK
Read these instructions before using and
keep them available at all times!

- 18 -
1. General information
1.1 Information about the instruction manual
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
1.2 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
WARNING!
This symbol highlights hazards, which could lead to injury.
Please follow the instructions very carefully and proceed with particular attention
in these cases.
WARNING! Electrical hazard!
This symbol draws attention to potential electrical hazards. If you do not follow
the safety instructions, you may risk injury or death.
CAUTION!
This symbol highlights instructions, which should be followed to avoid any risk of
damage, malfunctioning and/or breakdown of the device.
NOTE!
This symbol highlights tips and information, which have to be followed for
an efficient and trouble-free operation of the device.
WARNING! Hot external surface!
This symbol is a warning that the device surface is hot when in use. Ignoring this
warning may result in burns!

- 19 -
CAUTION! Magnetic fields!
Do not remove the unit’s bottom cover.
1.3 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology. If you have any
questions, you should contact the manufacturer.
NOTE!
Read the instruction manual carefully before using the device. The manufacturer
does not accept liability for any damage or malfunction resulting from not
following the instructions for use.
The instruction manual should be kept near the device, easily accessible for anyone
wishing to work with or using it. We reserve the right to make technical changes for
purposes of developing and improving the useful properties.
1.4 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any
form or by any means without permission in writing from the manufacturer. Any person
who commits any unauthorized act in relation to this publication shall be liable to claims
for damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are copyright
and subject to other protection rights. Any person unlawfully using this
publication is liable to criminal prosecution.
1.5 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity.
If required we will be glad to send you the according declaration of conformity.

- 20 -
2.Safety
This section provides an overview of all important safety aspects.
In addition every chapter provides precise safety advice for the prevention of dangers
which are highlighted by the use of the above mentioned symbols.
Furthermore, attention should be paid to all pictograms, markers and labels on the
device, which must be kept in a permanent state of legibility.
By following all the important safety advice you gain an optimal protection against all
hazards as well as the assurance of a safe and trouble-free operation.
2.1 General information
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
Knowing the contents of the instruction manual as well as avoiding mistakes and thus
operating this device safely and in a fault-free manner is very essential to protect
yourselves from the hazards.
To prevent hazards and to ensure optimum efficiency, no modifications or alterations to
the device that are not explicitly approved by the manufacturer may be undertaken.
This device may only be operated in technically proper and safe condition.
2.2 Safety instructions for use of the device
The specifications regarding the industrial safety are based on the Regulations of the
European Union applicable at the time of manufacturing the device.
If the device is used commercially, the user is obliged to ensure that the said industrial
safety measures concur with the state of the rules and regulations applicable at the time
in question for the entire period of use of the device and to comply with the new
specifications.
Outside the European Union, the industrial safety laws applicable at the place of
installation of the device and the regional territorial provisions must be complied with.
Besides the industrial safety instructions in the instruction manual, the general safety and
accident prevention regulations as well as environment protection regulations applicable
for area of application of the device must be followed and complied with.

- 21 -
CAUTION!
oThe device can be used by children 8 years and up, as well as by people with
disabilities and those with limited experience/knowledge as long as they are under
supervision or have been instructed on proper use of the device and its possible
dangers.
oChildren should not play with the device.
oCleaning and maintenance cannot be performed by children younger than 8 years
old and must be done under supervision.
oChildren under the age of 8 years old must be kept away from the device and its
power cord.
oPlease keep these instructions and give them to future owners of the device.
oAll people using the device should follow the instructions and tips contained in these
instructions.
oOnly use the device indoors.
2.3 Intended use
Safe operation is only guaranteed when using the device for its intended purpose.
Any technical interventions, as well as assembly and maintenance are to be made by a
qualified customer service only.
The device is not designed for use with an external timer or remote control.
The induction cooker is designed for preparation and warming up of foods using
the appropriate crockery.
The induction cooker may not be used among other things for:
-heating and warming inflammable, harmful, volatile or similar liquids or
materials.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the
device is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use are
impossible.
The operator is liable for all damages resulting from inappropriate use.

- 22 -
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in your
country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
-Do not store outdoors.
-Keep it dry and dust-free.
-Do not expose it to aggressive media.
-Do not expose it to direct sunlight.
-Avoid mechanical shocks and vibration.
-In case of longer storage (> 3 months) make sure you check
the state of the packaging and the parts regularly.
If required refresh or renew.

- 23 -
4. Technical data
4.1 Technical specification
Name Induction cooker IK 20
Code No.:
105820
Construction: Heating plate: glass, casing: synthetic materials
Working temperature: 60 °C - 240 °C
Power: 230 V~ 50 Hz 2000 W
Power levels: 1 - 10 (1100 - 2000 W)
Dimensions: W 285 x D 340 x H 64 mm
Weight: 2.5 kg
We reserve the right to make technical changes!
4.2 Control panel
① Digital display
② Readiness indicator
③ On/off switch
④ : increase time, temperature or power
⑤ : decrease time, temperature or power
⑥ for selecting power ( ), temperature ( ) or time ( )
⑦ LED control lights for power ( ), temperature ( ) and time ( )
⑥
①②
⑦
③
④
⑤

- 24 -
5. Installation and operation
5.1 Functionality of induction cookers
With induction cooker, an electric voltage is applied on a conductor spool beneath the
glass. This creates magnetic fields, which directly heat up the bottom of the cookware
through a physical effect.
This means saving time and energy, because contrary to common hotplates, the
cookware is heated up, not the heating element and the glass.
Due to the technical characteristics described above, another advantage is the very short
start-up cooking time.
In addition, the heat supply promptly adapts to changed settings and can be controlled in
small steps. The induction cooker reacts to changed settings just as fast as a gas stove,
as the energy reaches the pot immediately without having to heat up other materials first.
The induction technology combines this fast reaction with the basic advantage of
electricity, meaning being able to exactly adjust the heat supply.
Additional advantages of an induction cooker:
•As the cooking zone is only heated up indirectly via the bottom of the cookware, over
spilling food cannot stick and burn and there is hardly any danger of burns for the user.
The glass cooking zone is only heated up by the hot cookware.
•If the device is turned on and no dish for cooking is present or is removed, a repeating
audio signal will sound and the device will turn itself off after approx. 30 seconds.
•The device will detect if the appropriate cookware is placed on the heating plate.
If the cookware is not appropriate for induction hotplates, energy will not flow.
The device will turn off after approx. 30 seconds.
•When operating the cooking zone with empty cookware, a temperature sensor turns
it off automatically.

- 25 -
5.2 Safety instructions
WARNING! Risk of electric shock!
The device must only be connected to a properly installed single socket with
protective contact.
Never remove the power cable by pulling the cable itself; always grab the plug
housing.
•Never allow the power cable to come into contact with heat sources or sharp edges.
The power cable should not hang over the side of the working surface. Ensure that
no one can step on or trip over the cable.
•The power cable must not be folded, bent or tangled, and must always remain fully
unrolled.
•Never place the device or other objects on the power cable.
•Do not lay the cable over carpets or heat insulations. Do not cover the cable.
Keep away the cable from operating range and do not dunk it into water.
WARNING! Hot external surface!
During operation some parts of the device become very hot.
Do not touch the hot surface of the glass field.
Please note: the induction cooker does not heat up itself during cooking,
but the temperature of the cookware heats up the cooking zone.
•Do not use the device in case it does not function properly, has been damaged or
dropped.
•Do not use any accessory or spare parts that have not been recommended by the
manufacturer. These can be dangerous for the user or lead to damages of the
device or personal injury, and further, the warranty expires.
WARNING! Hazard via electrical current!
Do not insert any objects like wires or tools into the ventilation slots.
This may cause electric shocks.
•Do not move the induction cooker during cooking or with hot cookware on top of it.
•Do not use the device as a surface for storing various items. Do not leave such
objects as empty containers, etc. on it.
•We recommend not placing any metal kitchen utensils, cookware or pan lids, knives
or other metal objects on the cooking zone. These may heat up when the device is
turned on.

- 26 -
•Remember that items of jewelry such as rings, watches etc. can get hot if they are
close to the heating surface.
•The cooking zone's surface consists of temperature-resistant glass. In case of damage,
even if this concern only a small tear, disconnect the device from the power supply
immediately and contact the customer service.
•Do not place any magnetically objects like credit cards, cassettes etc. on the glass
surface while the device is in operation.
•On order to avoid overheating, do not place any aluminum foil or metal plates on the
device.
•Do not use any flammable, acidy or alkaline materials or substances near the device,
as this may reduce the service life of the device and lead to deflagration when the
device is turned on.
•Scientific tests have proven that induction cookers do not pose a risk. However,
persons with a pacemaker should keep a minimum distance of 60 cm to the device
while it is in operation.
WARNING! Hazard via electrical current!
The device can cause injuries due to improper installation!
Before installation the local power grid specification should be compared with
that of the device (see type label).Connect the device only in case of compliance!
Take note of the safety advice!
5.3 Suitable and unsuitable cookware
osteel or enamelled cast iron;
oiron, steel or non-enamelled cast iron;
o18/0 stainless steel and aluminium, if it
is marked as suitable for induction
(follow the description of the cookware).
For proper functioning, all pots and pans must have a plane magnetic bottom
(a magnet must stick to it).
For best results, use only pots and pans with a diameter between 12 and 24 cm.

- 27 -
e.g.
Induction cookware, 9-piece cooking pot set
chromium-nickel steel ●edge suitable for pouring ●cold handles
4 pots with lid 1 pan
2.0 litres ●Ø 16 cm ●height 10.0 cm 2.8 litres ●Ø 24 cm ●height 6.5 cm
2.7 litres ●Ø 18 cm ●height 11.0 cm
5.1 litres ●Ø 24 cm ●height 11.5 cm
6.1 litres ●Ø 20 cm ●height 20.0 cm
Bartscher order no. A130442
Unsuitable cookware
ovessels with round bottom;
oceramic, glass;
ostainless steel, aluminium, bronze
or copper unless, it is expressly
marked as suitable for induction;
opots/pans with a diameterof less
than 12 cm;
ocookware with feet.
CAUTION!
Please use only the cookware marked suitable for induction cooker.
If the induction hotplate detects too great a separation from the magnetizing
container, it will cause a reduction in power. This may cause the overheating
prevention device to malfunction. For this reason, do not use aluminum, bronze
or non-metallic containers.
5.4 Installation and connection
•Discard the complete packing material after unpacking the device.
•Place the device on top of an even and safe surface which supports the weight of
the device and is not heat sensitive.
•Never place the device on a flammable surface.
•Do not place the device near open fireplaces, electric ovens/arc furnaces,
furnaces/electric heaters or other heat sources.
•Do not block or partially cover the ventilation opening allowing the inflow and outflow
of air to the device. This may cause the device to overheat. Keep the device a
minimum of 5 – 10 cm from walls and other objects.
•Do not place the induction cooker next to devices or objects, which react sensitively
to magnetic fields (e.g. radios, TVs, etc.).

- 28 -
•The electrical circuit in the socket must be secured to at least 16A. Only connect the
device directly to the wall socket; do not use any extension cords or power strips.
•The device should be placed in an area with easy access to the plug, in order to
quickly remove it from the socket if necessary.
5.5 Operation
•Insert the plug into an appropriate single outlet.
•The readiness indicator will come on and an audio signal will sound.
The device is now in sensory mode.
•Place the food in cookware in the middle of the heating zone.
•To turn on the induction cooker, press the ON/OFF button .
The control light for power levels ( ) will begin flashing and an audio signal will
sound.
•Next, press .
1 time Power level „5“ is selected, and the device will come on.
(Levels: 1, 2, 3, 4, 5, 6, 7, 8, 9 and 10).
The buttons or can be used at any moment to change the power level
from 1 – 10.
Level 1 is equivalent to 1100 W, and level 10 is equivalent to 2000 W.
The digital display will show the selected power level.
2 times A temperature level of „120 °C“ is set and the device will come on.
(Temperature levels: 60, 80, 100, 120, 140, 160, 180, 200, 220 and 240 °C).
The buttons or can be used at any moment to change the temperature
within a range of 60 – 240 °C at levels of 20 °C. The digital display will show
the selected temperature.
The device heats dishes and maintains constant temperature. Regulation of
power is thus performed automatically.
NOTE!
If the device is turned on and no dish for cooking is present or is removed,
a repeating audio signal will sound and the device will turn itself off after
approx. 30 seconds.

- 29 -
Setting time
After selecting the desired mode (power level or temperature), press the button
marked . The number „0” will appear on the digital display and the LED time
control light will come on.
Using or you may set the time of operation in 5-minute intervals (max. 180 min.).
The time is counted down, and after several seconds the digital display returns to previous
displays.
To check the remaining time, press and it will be shown on the digital display.
When time has run out, an audio signal will sound and the device will automatically shift
into sensory mode.
NOTE!
When in use, the time may be adjusted at any moment using or . The memory
function that the device is equipped with allows for the set power or temperature
levels to remain unchanged.
Any change may be made at any moment. The device will function in accordance with
the most recently provided settings or information.
CAUTION!
Do not place empty cookware on the heating plate.
Heating an empty pot or pan will activate the overheating protection mechanism,
an audio signal will sound and the device will turn off.
The error code „E02“ will be displayed.
If this happens, remove the cookware from the device and leave it for several
minutes to cool. The device will return to proper functioning.
•Ensure that the cookware used will not scratch the surface of the heating plate,
although this should not negatively affect the device’s functioning.
•When cooking or heating is finished, remove the plug from its socket
(do not rely solely on the sensory function)!

- 30 -
6. Cleaning and maintenance
6.1 Safety advice
oBefore beginning with repair or cleaning works make sure the device has been
disconnected from power supply and has cooled down.
oDo not use any acid agents and make sure no water ingresses the device.
oTo protect yourself from electric shock, never immerse the device, its cables and
the plug in water or other liquids.
CAUTION!
The device is not suited for direct washing via water jets.
Therefore, you must not use any kind of pressure water jet for cleaning the device!
6.2 Cleaning
oClean the device after each use.
oWipe the cooking surface, service panel and casing with a soft, damp cloth with a
mild, non-abrasive cleaner.
oUse only a soft cloth. Never use abrasive pads that could scratch the surface.
oDo not use any aggressive cleaning agents containing gasoline or solvents as well
as sharp, pointy objects to clean the device.
oAfter washing the device use a soft, dry cloth to dry and polish the surface.
oIf the unit is to remain unused for a longer time, store it in a dry, clean place safe from
frost and sunlight, inaccessible to children. Do not place heavy objects on the unit.
6.3 Safety instructions for maintenance
oInspect the power cable regularly for damage. Never use the device if the cable is
damaged. If the power cable is damaged, have an authorised service center or
qualified electrician replace it.
oIn case of damage or malfunction, please contact your stockist or our customer
service centre. Pay attention to the troubleshooting tips in pt. 7.
oOnly a qualified technician and using original spare parts and accessories should
carry out repairs and maintenance of the device. Do not attempt to repair the
device yourself.

- 31 -
7. Possible Malfunctions
Error
Message Cause Solution
E00
•There is no cookware on
the heating plate or the
cookware is inappropriate
for induction cookers.
•Do not turn on the device when
there is no cookware placed on it
and only use cookware adapted
for induction cookers.
E01
•The device becomes too
hot (e.g. due to blocked
ventilation slots).
•Parts are damaged (e.g.
transistor).
•Clear/unblock ventilation slots.
Let the device cool off for a few
minutes; the device is ready for
operation afterwards.
Contact the retailer in case the
error message remains indicated
in the digitaldisplay after the
device has cooled off.
•Contact retailer.
E02
•Overheating-protection was
activated and the device
switched off.
•Remove the cookware from the
hob. Let the device cool off for a
few minutes. The device is ready
for operation afterwards.
E03 •Short-lasting power surge
or lower tension. •Remove the device from the socket (remove the plug!).
Re-connect the device after
several minutes.

- 32 -
8. Waste disposal
Discarding old devices
At the end of its service life the discarded device has to be disposed in accordance with
the national regulations. It is advisable to contact a company which is specialized in
waste disposal, or just contact the local disposal service in your community.
WARNING!
To exclude any abuse and the dangers involved make the waste device unfit for
use before disposal. For that purpose disconnect device from mains supply and
remove mains connection cable from the device.
NOTE!
For the disposal of the device please consider and act
according to the national and local rules and
regulations.
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
