Bartscher A150668 User manual

A150.670
A150.669
A150.668
A150.671
A150.672
A150.673
V6/0111

- 15 -
1. General Information 16
1.1 Information about the instruction manual 16
1.2 Key to symbols 16
1.3 Liability and Warrantees 17
1.4 Copyright protection 17
1.5 Declaration of conformity 17
2. Safety 18
2.1 General information 18
2.2 Safety instructions for use of the device 18-19
2.3 Intended use 19
3. Delivery, packaging and storage 20
3.1 Delivery check 20
3.2 Packaging 20
3.3 Storage 20
4. Technical data 21
4.1 Technical specification 21
4.2 Overview of parts 22
5. Installation and operation 22
5.1 Safety instructions 22-23
5.2 Installation and connection 23-24
5.3 Operating 24-25
6. Cleaning and maintenance 25
6.1 Safety advice 25
6.2 Cleaning 25-26
6.3 Safety instructions for maintenance 26
7. Possible Malfunctions 27
8. Waste disposal 28
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
GB/UK

- 16 -
1. General information
1.1 Information about the instruction manual
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device and
easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
1.2 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
WARNING!
This symbol highlights hazards, which could lead to injury.
Please follow the instructions very carefully and proceed with particular attention
in these cases.
WARNING! Electrical hazard!
This symbol draws attention to potential electrical hazards. If you do not follow
the safety instructions, you may risk injury or death.
CAUTION!
This symbol highlights instructions, which should be followed to avoid any risk of
damage, malfunctioning and/or breakdown of the device.
NOTE!
This symbol highlights tips and information, which have to be followed for
an efficient and trouble-free operation of the device.
WARNING! Hot external surface!
This symbol is a warning that the unit surface is hot when in use. Ignoring this
warning may result in burns!

- 17 -
1.3 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology. If you have any
questions, you should contact the manufacturer.
NOTE!
Read the instruction manual carefully before using the device. The manufacturer
does not accept liability for any damage or malfunction resulting from not
following the instructions for use.
The instruction manual should be kept near the device, easily accessible for anyone
wishing to work with or using it. We reserve the right to make technical changes for
purposes of developing and improving the useful properties.
1.4 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any form
or by any means without permission in writing from the manufacturer. Any person who
commits any unauthorized act in relation to this publication shall be liable to claims for
damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are copyright
and subject to other protection rights. Any person unlawfully using this
publication is liable to criminal prosecution.
1.5 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity.
If required we will be glad to send you the according declaration of conformity.

- 18 -
2. Safety
This section provides an overview of all important safety aspects.
In addition every chapter provides precise safety advice for the prevention of dangers
which are highlighted by the use of the above mentioned symbols.
Furthermore, attention should be paid to all pictograms, markers and labels on the
device, which must be kept in a permanent state of legibility.
By following all the important safety advice you gain an optimal protection against all
hazards as well as the assurance of a safe and trouble-free operation.
2.1 General Information
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
Knowing the contents of the instruction manual as well as avoiding mistakes and thus
operating this device safely and in a fault-free manner is very essential to protect
yourselves from the hazards.
To prevent hazards and to ensure optimum efficiency, no modifications or alterations to
the device that are not explicitly approved by the manufacturer may be undertaken.
This device may only be operated in technically proper and safe condition.
2.2 Safety instructions for use of the device
The specifications regarding the industrial safety are based on the Regulations of the
European Union applicable at the time of manufacturing the device.
If the device is used commercially, the user is obliged to ensure that the said industrial
safety measures concur with the state of the rules and regulations applicable at the time
in question for the entire period of use of the device and to comply with the new
specifications.
Outside the European Union, the industrial safety laws applicable at the place of
installation of the device and the regional territorial provisions must be complied with.
Besides the industrial safety instructions in the instruction manual, the general safety and
accident prevention regulations as well as environment protection regulations applicable
for area of application of the device must be followed and complied with.

- 19 -
CAUTION!
oThe unit is not intended for use by individuals (including children) with physical or
mental disabilities, insufficient experience, and/or insufficient knowledge unless
such persons are under the care of a person responsible for their safety or have
received instructions regarding appropriate use of the unit.
oChildren should be observed to ensure that they are not playing with the unit.
oPreserve this manual safely. When passing on/selling the device to a third party, the
manuals must be handed over along with the device.
oEvery person using the device must act in accordance to the manuals and under
consideration of the safety advice.
oThe device is to be used indoors only.
2.3 Intended use
CAUTION!
This device has been designed and built for commercial use only and should be
operated by qualified personnel only.
Safe operation is only guaranteed when using the device for its intended purpose.
Any technical interventions, as well as assembly and maintenance are to be made by a
qualified customer service only.
The electric contact grill is meant only for grilling dishes.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the device
is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use are
impossible.
The operator is liable for all damages resulting from inappropriate use.

- 20 -
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately after
receipt.
In case of visible damage do not accept or accept the delivery with reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in your
country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
-Do not store outdoors.
-Keep it dry and dust-free.
-Do not expose it to aggressive media.
-Do not expose it to direct sunlight.
-Avoid mechanical shocks and vibration.
-In case of longer storage (> 3 months) make sure you check the state of the
packaging and the parts regularly. If required refresh or renew.

- 21 -
4. Technical data
4.1 Technical data
Description Electric contact grill
Order no.:
A150.670 A150.669 A150.668
Grill plates performance: grooved smooth Upper grooved,
lower smooth
Performance: The housing made of chromium and nickel steel,
plates made of cast iron
Temperature range: 50°- 300°C
Power: 230 V ~ 50 Hz 1800 W
Dimensions: W 290 x D 370 x H 200 mm
Dimensions top grill plate: W 214 x D 214 mm
Dimensions bottom grill
plate: W 220 x D 235 mm
Weight: 14 kg
Description Electric contact grill double
Order no.:
A150.671 A150.672 A150.673
Grill plates performance: grooved smooth Upper grooved,
lower smooth
Performance: The housing made of chromium and nickel steel,
plates made of cast iron
Temperature range: 50°- 300°C
Power: 230 V ~ 50 Hz 3600 W
Dimensions: W 570 x D 370 x H 200 mm
Dimensions top grill plate: W 215 x D 215 mm
Dimensions bottom grill
plate: W 470 x D 230 mm
Weight: 26 kg
We reserve the right to make technical changes!

- 22 -
4.2 Overview of parts
1. Temperature indicator light (red)
2. Temperature control knob
3. Network connection indicator light (green)
4. Bottom casing
5. Fat collection compartment
6. Bottom grill plate
7. Cable duct
8. Top grill plate
9. Handle
10. Mains connection cable
11. Rubber feet
5. Installation and operation
5.1 Safety instructions
WARNING! Electrical hazard!
The device must only be connected to a properly installed single socket with
protective contact.
Never yank cord to disconnect from outlet.
Cable must not touch any hot parts.
• See that the cable does not touch any heat sources or sharp edges. Do not let the
cable dangle over the counter edge.
WARNING! Hot surface!
During operation some elements of the unit very become hot. To avoid burns, do
not touch hot elements!
⑤
④
②
②
①
③ ③
①
⑥
⑥
⑦
⑦
⑧
⑧
⑨
⑨
⑩
⑩
⑪
⑪
⑤
④

- 23 -
• Do not use the device in case it does not function properly, has been damaged or
dropped.
• Do not use any accessory or spare parts that have not been recommended by the
manufacturer. These can be dangerous for the user or lead to damages of the
device or personal injury, and further, the warranty expires.
• Do not lay the cable over carpets or heat insulations. Do not cover the cable. Keep
away the cable from operating range and do not dunk it into water.
• Do not move or tilt the device when in operation.
• In case of thunderstorms and similar, disconnect the device from the mains
immediately! This prevents damage to the device by lightning.
CAUTION! Risk of injury!
Never remove the casing and never modify the degvice yourself! Modifying the
device may lead to sever damage to persons and objects!
WARNING! Hazard via electrical current!
The device can cause injuries due to improper installation!
Before installation the local power grid specification should be compared with that
of the device (see type label).
Connect the device only in case of compliance!
Take note of the security advice!
5.2 Installation and connection
CAUTION!
The installation and maintenance of the device should only be carried out by
trained personnel!
• Discard the complete packing material after unpacking the device.
• Remove the protective film from the unit. If any glue remains, remove it with an
appropriate solvent.
• Place the device on top of an even and safe surface which supports the weight of the
device and is not heat sensitive.
• Not at any time should you place the device on an inflammable surface (such as:
table cloth, carpet, etc.).
• You must not position the device near open fireplaces, electric ovens/arc furnaces,
furnaces/electric heaters or other heat sources.

- 24 -
• The electrical circuit in the socket must be secured to at least 16A. Only connect the
unit directly to the wall socket; do not use any extension cords or power strips.
• Place the unit so that the plug is easily accessible and can be quickly removed from
its socket in case of necessity.
• There is a ground pin on the back of the device. Please connect the earth cable with
a copper cable (diameter at least 2 mm²) in conformity with the valid general safety
regulations.
• The double grill shall be connected to two separate network sockets.
5.3 Operating
•Connect the device to a single outlet.
•A green network connection indicator light is on.
•The device is equipped with a temperature control knob. The adjustable temperature
is between 50°-300°C. We recommend maintaining the maximum operating
temperature between 200°-250°C.
•A red temperature indicator light turns on in the moment of setting the temperature
regulation knob on the desired value.
•After turning the device on, it need approx. 10 minutes to reach the temperature of
250°C.
•When the device reaches the desired temperature, the red temperature indicator light
turns off.
•If the temperature falls down for about. 10°C, the heating is turned on again and the
red temperature indicator light turns on.
•Now lift the top grill with the handle to an adequate position. Pour a bit of vegetable
oil onto the bottom grill and add the food. Close the grill halves. Keep an eye on the
food until it is done cooking.
WARNING! Hot surface!
The contact grill gets very hot during operation, also on the sides and the top.
Never touch the device during operation or shortly after!
Never operate the device in a slanted position!
•There is a fat receptacle on the front of the bottom grill, which catches the draining
fat. Wait until the device, the receptacle and the content have cooled off to drain it.

- 25 -
CAUTION! Danger of burning!
Protect your hands and face from possible fat splashes.
•Do not use any hard or sharp object on the grill to prevent damage to the surface or
the operating elements.
•Put the temperature control knob to „0“ once you are finished grilling. Remove the
grilled food and pull the mains plug.
ATTENTION!
The device is equipped in the overheat protection system.
After turning the overheat protection system on, one shall turn the device off the
network socket (take out the plug!) and leave the grill to cool down. Push the
RESET buton located at the bottom of the device.
In case of frequent turning on of the overheat protection system within the short
intervals, it is recommended to contact the service.
• If the device is not in use, remove it from the outlet (pull out the plug!)
6. Cleaning and maintenance
6.1 Safety advice
oBefore beginning with repair or cleaning works make sure the device has been
disconnected from power socket (pull the power plug!!!) and has cooled down.
oDo not use any acid agents and make sure no water ingresses the device.
oTo protect yourself from electric shock, never immerse the device, its cables and the
plug in water or other liquids.
CAUTION!
The device is not suited for direct washing via water jets. Therefore, you must not
use any kind of pressure water jet for cleaning the device!
6.2 Cleaning
oClean the device after each use.
oUse soft cloth only and make sure you never use any kind of abrasive agents or pads,
which could scratch the surface.
oNever use any aggressive cleaning agents or sprays.

- 26 -
oClean the casing, the handle and the outside of the top grill with a damp cloth. Use a
mild detergent in case the device is really dirty.
oGrill plates shall be washed inside with a soft damp cloth and sensitive cleaning
agent.
oWipe the grill plates grooved on the inside with warm water and a damp cloth.
oRemove heavier dirt with the enclosed brush from the grills.
oIf the device is really dirty, lubricate the still warm grills with oil on the inside, leave to
soak for a few minutes and then clean off the grills with soft cloth.
oClean the fat receptacle with warm water and a mild detergent. Be careful when
cleaning the removable fat receptacle. Always leave the fat to cool down before
disposing of it.
oAfter the cleaning procedure you should use a soft and dry cloth to wipe dry and
polish the surface.
oBefore storing the device in a dry place you should make sure it has been cleaned
properly.
6.3 Safety instructions for maintenance
oCheck the mains connection cable for damage from time to time. Never operate the
device when the cable is damaged. A damaged cable must immediately be replaced
by customer service or a qualified electrician to avoid dangers.
oIn case of damage or malfunction, please contact your stockist or our customer
service centre. Pay attention to the troubleshooting tips in pt. 7.
oOnly a qualified technician and using original spare parts and accessories should
carry out repairs and maintenance of the device. Do not attempt to repair the
device yourself.

- 27 -
7. Possible Malfunctions
Problem Cause Solution
Grill plates do not get
warm although the
device has been
turned on and the red
temperature indicator
light is on.
1. Temperature control
knob is defect.
2. At least one of the heater
cables is defect.
3. The overheat protection
system is on.
1. Contact the retailer
2. Contact the retailer
3. Leave the grill to cool
down, push the RESET
button at the bottom of
the device.
The device has been
turned on, the tempe-
rature regulation knob
has been started, the
red temperature
indicator light is on,
but it is not possible
to regulate
temperature.
1. Temperature control
knob is defect.
1. Contact the retailer
The red temperature
indicator light is not
on, although the device
is turned on and the
process of cooking
goes in usual way.
1.Temperature indicator
light is damaged.
1. Contact the retailer
The green network
connection indicator
light is not on,
although the device is
turned on.
2. Abnormal or interrupted
power supply.
3. Fuse has blown.
1. Check the power
supply and the cable
for damage or faults.
2. Contact the retailer
The above problems only serve for orientation and as examples. Should these or
similar problems occur, turn the device off immediately and discontinue using it.
For having the device checked and repaired, contact qualified service personnel or
the dealer immediately.

- 28 -
8. Waste disposal
Discarding old devices
At the end of its service life the discarded device has to be disposed in accordance with
the national regulations. It is advisable to contact a company which is specialized in
waste disposal, or just contact the local disposal service in your community.
WARNING!
To exclude any abuse and the dangers involved make the waste device unfit for
use before disposal. For that purpose disconnect device from mains supply and
remove mains connection cable from the device.
NOTE!
For the disposal of the device please consider and
act according to the national and local rules and
regulations.
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
