Bartscher 2500 1R User manual

2500 1R
A150691
Original-Gebrauchsanleitung
V1/1216

- 19 -
ENGLISH
Table of contents
1.Safety ........................................................................................................................ 20
1.1 Key to symbols..................................................................................................... 20
1.2 Safety instructions................................................................................................ 21
1.3 Proper use............................................................................................................ 25
2. General information................................................................................................ 26
2.1 Liability and Warrantees....................................................................................... 26
2.2 Copyright protection ............................................................................................. 26
2.3 Declaration of conformity...................................................................................... 26
3. Transport, packaging and storage......................................................................... 27
3.1 Delivery check...................................................................................................... 27
3.2 Packaging............................................................................................................. 27
3.3 Storage................................................................................................................. 27
4. Technical data ......................................................................................................... 28
4.1 Technical data...................................................................................................... 28
4.2 Overview of parts ................................................................................................. 29
5. Installation and operation....................................................................................... 30
5.1 Installation............................................................................................................ 30
5.2 Operation.............................................................................................................. 32
6. Cleaning and maintenance..................................................................................... 35
7. Waste disposal........................................................................................................ 36
Bartscher GmbH
Franz-Kleine-Str. 28
33154 Salzkotten phone: [phone]
Germany fax: [phone]
GB/UK

- 20 -
Read this instruction manual before using and
keep them available at all times!
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
Please keep these instructions and give them to future owners of the device.
1.Safety
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
All persons using the device must follow the recommendations and instructions
in this instruction manual.
1.1 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
DANGER!
This symbol highlights hazards which could lead to injury.
WARNING!
This symbol highlights dangerous situations which could lead to injury or death.

- 21 -
HOT SURFACE!
This symbol is a warning that the device surface is hot when in use.
Ignoring this warning may result in burns!
CAUTION!
This symbol highlights dangerous situations which could lead to light
injuries, or damage, malfunction, and/or destruction of the device.
NOTE!
This symbol highlights recommendations and information aimed for effective
and trouble-free device operation.
1.2 Safety instructions
The device is not intended for use by individuals (including
children) with physical or mental disabilities, insufficient
experience, and/or insufficient knowledge unless such persons
are under the care of a person responsible for their safety or
have received instructions regarding appropriate use of the
device.
Children should be observed to ensure that they are not playing
with the device.
Never leave the device unattended when in use.
Only use the device indoors.
The device is not adapted for use with an external timer or
remote control.
This device may only be operated in technically proper and safe
condition.
Prevent access of children to the package materials like plastic
bags and foamed polystyrene elements. Suffocation hazard!

- 22 -
Only a qualified technician and using original spare parts and
accessories should carry out repairs and maintenance of the
device. Do not attempt to repair the device yourself.
Do not use any accessory or spare parts that have not been
recommended by the manufacturer. These can be dangerous
for the user or lead to damages of the device or personal injury,
and further, the warranty expires.
To prevent hazards and to ensure optimum efficiency, no
modifications or alterations to the device that are not explicitly
approved by the manufacturer may be undertaken.
DANGER! Electric shock hazard!
To avoid the hazard results please follow the safety instructions
below.
Never allow the power cable to come into contact with heat
sources or sharp edges. The power cable should not hang over
the side of the working surface. Ensure that no one can step on
or trip over the cable.
The power cable must not be folded, bent or tangled, and must
always remain fully unrolled. Never place the device or other
objects on the power cable.
Do not lay the power cable over carpets or other inflammable
materials. Do not cover the cable. Keep away the cable from
operating range and do not immerse it into water.

- 23 -
Check the power cord regularly for damage. Do not use the
appliance if the power cord is damaged. If this cable is damaged,
it must be replaced by customer service or a qualified electrician
in order to avoid dangers.
The supply cable must be disconnected from the socket
only by pulling the plug.
Never carry or lift the device by the supply cable.
In any case do not open the device housing. In case of
electrical or mechanical modifications the electric shock
hazard will occur.
Do not use any acid agents and make sure no water ingresses
the device.
Never operate the device with moist hands or standing on wet
floor.
Disconnect the device from the electric power supply.
-when the device is not used,
-in case of anomalies during operation,
-before cleaning.
HOT SURFACE! Burn hazard!
Follow the safety instructions listed in order to avoid the hazard:
The housing and the grill plates of the appliance become very
hot. during operation. Do not touch them with bare hands. Use
always the operating handle in order to open the device. Use
appropriate kitchen utensils for laying and taking of food.
Also after switching off, the device remains hot for some time.
Before cleaning or moving it to another place wait until the
device cools down first.

- 24 -
Never move this appliance during operation.
WARNING! Fire or explosion hazard!
Follow the safety instructions listed in order to avoid the hazard:
In order to avoid risk of fire and damage to the device, never
place kitchen utensils, towels, paper and the like on the grill
plate during operation.
Never operate the device near combustible, easily flammable
materials (e.g. petrol, spirit, alcohol etc.). They evaporate
through heating and in case of contact with ignition sources
deflagrations can occur which can lead to serious personal
injuries and property damages.
When a fire arises disconnect it from the power supply before
you initiate appropriate measures for fire-fighting. Provide
sufficient supply of fresh air.
Caution: Never extinguish the fire with water when the power
plug is connected to the socket. Electric shock hazard!

- 25 -
1.3 Proper use
CAUTION!
The device has been designed and built for commercial use and should
be operated only by qualified personnel in kitchen facilities.
The operational safety of the device is assured only in case of proper use, according
to the operation manual.
All technical activities like installation and maintenance must be performed by the
qualified service personnel only.
Contact grill is designed only for grilling appropriate food and heating bread, toasts,
short-baked products and similar food.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the
device is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use
are impossible.
The operator is liable for all damages resulting from inappropriate use.

- 26 -
2. General information
2.1 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology.
CAUTION!
Read this manual carefully and thoroughly before any operation
of the device, and especially before turning it on!
Manufacturer is not liable for any damages or faults caused by:
-violation of advice concerning operation and cleaning;
-use other than designed;
-alterations made by user;
-use of inadequate spare parts.
We reserve the right to make technical changes for purposes of developing and improving
the useful properties.
2.2 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any
form or by any means without permission in writing from the manufacturer. Any person
who commits any unauthorized act in relation to this publication shall be liable to claims
for damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are
copyright and subject to other protection rights. Any person unlawfully
using this publication is liable to criminal prosecution.
2.3 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity. If required we will be
glad to send you the according declaration of conformity.

- 27 -
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in
your country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
-do not store outdoors,
-keep it dry and dust-free,
-do not expose it to aggressive media,
-do not expose it to direct sunlight,
-avoid mechanical shocks and vibration,
-in case of longer storage (> 3 months) make sure you check the state
of the packaging and the parts regularly, if required refresh or renew.

- 28 -
4. Technical data
4.1 Technical data
Name
Contact grill 2500 1R
Code-no.:
A150691
Material:
housing: stainless steel
grill plates: cast iron
Realization:
Number of grill units: 1
Grill surface type: grooved
Digital display for programming and storing the time
Timer
ON / OFF switch with indicator
Heating indicator
Fat collection container
Degree of protection:
IP23
Power supply:
2.5 kW / 220-230 V~ 50/60 Hz
Temperature range:
100 °C to 300 °C
Dimensions:
W 400 x D 485 x H 285/600 mm
Grill surface size:
360 x 270 mm
Weight:
25.4 kg
Includes:
1 scraper for cleaning the grooved surface
We reserve the right to make technical changes!

- 29 -
4.2 Overview of parts
1
Thermal insulator handle
2
Upper grill plate
3
Handle for setting the upper
grill plate
4
Lower grill plate
5
Ventilation holes
6
Control panel
7
Feet
8
Body
9
Fat collection container
10
Cleaning scraper
4
2
6
9
8
5
3
1
7
10

- 30 -
Control panel
11
Digital display
12
Time setting button:
13
Start/Stop button
14
Heating indicator (green)
15
Temperature controller knob
16
Indicator light (red)
17
ON/OFF switch
5. Installation and operation
5.1 Installation
CAUTION!
All installation, connection, and maintenance works must be realized only by
the qualified and authorized professionals, according to the international,
national, and local regulations valid in the country of installation.
Positioning
Unpack the device and discard the entire packaging material according to the
regulations valid in the country of installation.
Place the device in a well ventilated room or under the ventilating hood to efficiently
remove vapours produced when cooking dishes.
Place the device on an even, stable, dry and waterproof and heat-resistent surface.
14
16
17
11
15
13
12

- 31 -
Never place the device on an inflammable surface.
Never place the device in wet or damp locations.
Place the device so that it is easily accessible, leaving enough space to freely
service the device and ensure appropriate air circulation.
Never place the device directly against walls, low walls, furniture or other objects
which are made of flammable material. Keep a distance of at least 10 cm at the
sides and at the rear from walls and other objects. Take into account the applicable
fire protection regulations.
If keeping the above mentioned distance is impossible, apply appropriate safety
measures (e.g. heat-resistant foil), which will ensure keeping the wall’s temperature
within the safe range.
Before the first use, remove the protective foil from the device. Remove the foil slowly
not to leave glue residues. Remove possible glue residues with appropriate solvent.
CAUTION!
Never remove the type plate and warning signs from the device.
Place the unit so that the plug is easily accessible and can be quickly removed from
its socket in case of necessity.
Connection
DANGER! Electric shock hazard!
The device can cause injuries due to improper installation!
Before installation and connecting the local power grid
specification should be compared with that of the device
(see rating plate). Connect the device only in case of
compliance!
The electrical circuit in the socket must be secured to at least 16A. Only connect the
unit directly to the wall socket; do not use any extension cords or power strips.

- 32 -
5.2 Operation
Prepare the device
The device should be thoroughly cleaned before the first use. Follow instructions in
section 6 “Cleaning and maintenance”.
WARNING
Never use the device without the properly attached drip tray.
Mount the fat collection container in front of the device, under the edge of lower grill
plate. That container is used for collecting the grilling residuals dripping during the
process.
Grilling juices and fat drip during the
grilling process on the edge of lower grill
plate to the fat collection container (9)
(fig. on the left).
Regularly check and empty the fat
collection container (9).
Before cleaning, always leave the device
and the fat collecting pan to completely
cool down.
Remove the fat collection container (9)
from the device, clean and thoroughly
dry before reinstalling.
Device start-up
Connect the device to the single grounded socket.
Switch on the device with ON/OFF switch, setting it in position “I”. The red indicator
light (16) (fig. on page 30) will come on signalling that the device is turned on.
Heat the device for at least 20 minutes without food inside, setting it at 200°C (see
section “Settings”), to remove any production residuals. Due to use of industrial
greases smoke may be emitted from the device. That smoke will not occur during the
next use. When heating up the device, make sure there is appropriate air circulation
in the room.
9

- 33 -
Settings
Temperature
Heat the device to required temperature before
placing food inside. Set temperature with use
of temperature control knob (15) (fig. on the
left). Temperature may be set in range from
100 °C to 300 °C, the optimum grilling
temperature is 250 °C - 280 °C.
Green heating indicator (14) is on during heating
and goes off after reaching the preset temperature.
Time
It is possible to set time of final cooking of selected
food when required.
To do this, use the time setting button (12). The
digital display (11) shows „SET“.
Use Start/Stop button (13), the digital display (11)
shows set number.
Press the time setting button (12) until the digital
display shows the selected value. After 2 seconds
the setting will be accepted automatically. Set other
values and confirm them with Start/Stop button (13).
When the preset time passes the acoustic signal
is emitted.
Instructions for preparation of food
The contact grill is designed for gentle preparation of food with a very low
amount of fat.
Use oil of high smoke point, such as rapeseed or sunflower seed oil.
Meat and fat require smaller amounts of oil, because they already contain grease;
when grilling fish and vegetables more oil can be applied on the lower grill plate.
The addition of oil reduces sticking or burning of food on the grilling surface.
To avoid transmission of smell and taste of one food to another, remove their
remains from the grilling surface between subsequent grilling stages.
14
15
13
11
12

- 34 -
Grilling/heating
Set temperature (up to 300°C) suitable for selected food and turn the device on.
The heating time is approx. 25 - 30 minutes.
In the meantime prepare food products for grilling or heating.
Open the pre-heated device by lifting the upper grill plate using the handle until it
stops.
Use heat-resistant brush to spread the vegetable oil on the lower grill plate or
spray the plate with baking oil three or four times. It allows for closing the large
pores and creation of coating. It is also possible to use the cooking paper during
preparation of food.
Hints: When preparing bakery products it is not required to apply oil
on the grill plates.
Put selected food on the plates.
Close the device by lowering the upper grill plate using the handle. When required,
adjust the upper grill plate with use of knob in front of that plate.
Never leave the device unattended during grilling.
HOT SURFACE! Risk of burns!
During the operation the external surface of the contact
grill is very hot. Never touch the device during operation
or shortly after. Use the appropriate handle when
opening and closing the device.
After grilling is finished, open the device with the handle and remove the grilled
food.
Avoid using hard or sharp objects to prevent grill plates from damaging. You may use
wooden spatula, heat resistant tongs or heat resistant plastic forks.
Turn the device off
To turn the device off set the temperature control knob to position “0” and ON/OFF
switch to position “OFF”.

- 35 -
6. Cleaning and maintenance
WARNING!
Before cleaning switch the device off with use of ON/OFF
switch and disconnect it from the power supply (pull the
plug!). Let the device to cool down.
Never clean the device with use of pressurized water jet!
Make sure that no water gets into the device.
Cleaning
oClean the device after each working day or also between the grilling processes,
when required.
oUse soft cloth only and never use any kind of abrasive cleaning agents which may
scratch the surface of the device.
oNever use any aggressive agents or sprays.
oOpen the device and remove the grilling
residuals from the upper and lower grill plate
using appropriate scrapper by depositing the
remains to the fat collection container (fig. on
the right) or wipe it with the paper towel.
oClean the upper and lower grill plate with a soft cloth soaked in warm water.
Dry the grill plates and apply a small amount of vegetable oil on them.
oIn case of the hardest dirt, lubricate the still warm grill plates with vegetable oil and
leave to soak for a few minutes and then clean off the dirt with a paper towel.
oPull out the fat collecting pan from the device. Empty and clean it with a mild
cleaning agent and a soft cloth or sponge. Wipe additionally with clear water.
Dry the fat collection container thoroughly before reinstalling in the device.
oHousing and handle should be wiped with cloth moistened with warm water and
gentle cleaning agent. All cleaned surfaces should be dried thoroughly.

- 36 -
Maintenance
oWe recommend to order the maintenance of the device in the professional service
company at least once a year. Works interfering in the device must be realized by
the professional and qualified personnel.
Storage
oIf the device is not used for any lengthy period, clean it according to the aforemen-
tioned description and store it in dry, clean place protected against cold, sun and
children. Do not place any heavy objects on the device.
7. Waste disposal
Discarding old devices
At the end of its service life the discarded device has to be disposed in accordance with
the national regulations. It is advisable to contact a company which is specialized in
waste disposal, or just contact the local disposal service in your community.
WARNING!
To exclude any abuse and the dangers involved make
the waste device unfit for use before disposal.
For that purpose disconnect device from mains supply
and remove mains connection cable from the device.
CAUTION!
For the disposal of the device please consider and
act according to the national and local rules and
regulations.
Bartscher GmbH
Franz-Kleine-Str. 28
33154 Salzkotten phone: [phone]
Germany fax: [phone]
