Basalte Eve Plus 0130-01 User manual

Installation Manual
© 2022 basalte v1.0
Eve Plus wall base 24 V
Safety instructions
Before installing the unit, read this manual thoroughly and retain it for future reference.
The device should be installed in compliance with ocial regulations valid in country of use.
The device may only be installed and connected by qualified electricians.
Ensure that electricity is switched o when installing or unmounting the device.
Do not open, dismantle, alter or modify the device.
Components
Wall base
0130-01
A
AB
B
B
B
C
F
E
D
Eve Plus cover
(not included)
Model No. 0131-CC
Wall boxes
The wall base should be installed in European wall boxes with screws.
The distance between the screws needs to be 60 mm, and a minimal
depth of 45 mm is required.
Square wall boxes size 60 x 60 mm are compatible with the sockets.
Round wall boxes should have an inner diameter of 64mm or more.
The following round wall boxes are compatible with the Basalte sockets:
• Helia round with cut hole 68 mm (type 247, 261).
• Kaiser round with cut hole 68 mm (type 9063-xx, 9064-xx, 9062-xx).
• Legrand batibox round (ref 080051, 080061, 080052, 080053).
• ABB round Hafobox MD4050 and hollow wall boxes HW-50,
HW50-G, HW52-F (Except HW52-F IGD and HW52-F BW).
When using other round boxes,
please verify the compatibility upfront.
Do not use following wall boxes:
• Helia O-range
• Kaiser (1055-xx – 1056-xx)
• ABB 3040
• ABB HW52-F IGD and HW52-F BW
AOpening to fix the outlet to the wall box
BClips to mount the cover plate
CCharging connector for Eve Plus sleeve
DThis sign up
EAligning magnets
F24 V DC power connector

Installation Manual
© 2022 basalte v1.0
Installation instructions
1. Use a standard European back box with screws. The distance between the screws needs to be 60mm. The
required depth is 45mm, although additional depth should be reserved for connecting the cables.
2. Connect the 24 V DC power lines using the terminals.
3. Fix the wall base to the wall box with 2 screws using the holes on vertical axis.
4. Mount the cover using the clips (see drawing below).
Cabling
The cable between the DC power supply and wall base must have a cable section of at least 0. 8mm2and
maximum 1.5 mm2. To limit power loss in the cable, we recommend using a star wiring from the power supply to
each single wall base.
Maximum cable length between DC power supply and wall base
Cable type
0.8 mm2(AWG 19)
1.0 mm2(AWG 18)
1.5 mm2(AWG 17)
How to remove the socket front cover (see drawing below)
Eve Plus wall base 24 V
Technical data
Power supply: 20 - 30 V DC
Consumption: Input power 15 W
Operating temperature: 0°C - +35°C
APlace the frame over the lower clips
BPush the frame upwards and tilt towards the wall
CAttach the frame over the top clips
Pushing the frame straight
into the clips without
pushing upwards and
lifting, might damage the
wall base.
EPush the frame upwards
FTilt the frame away from the wall
a
b
c
e
f
basalte bv | fraterstraat 37b | 9820 merelbeke | belgium
t [phone] | www.basalte.be | [e-mail]
24 V DC
300 m (984ft)
400 m (1312ft)
500 m (1640ft)
Eve Plus does not support always-on display configuration.
