Pts 9042 Series User manual

1
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
PTS 9042x Series
Small Cell AC Power Distribution Load Center
INSTALLATION GUIDE
SAP# 33364 T-Mobile PTS90420-3-7777##-P-0
Compact Small Cell Power box
30AMP main, Single SPD (L-G), 4 x 7 AMP load breakers
No External AC Disconnect Switch
SAP# 33365 T-Mobile PTS90422-3-7777##-P-8
Compact Small Cell Power box
30AMP main, Single SPD (L-G), 4 x 7 AMP load breakers
Integrated External AC Disconnect Switch
Scan the QR code above to link to current document or click the link below:
http://www.pactechsol.com/TMOvendor

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
2
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
Table of Contents
1.0 Model Overview ...........................................................................................................................3
Figure 1: Dimensional Drawings. ..............................................................................................5
1.1 Specifications............................................................................................................................7
1.2 Breaker Specifications……..……….…………………………………………………………………..8
1.3 Wiring Diagrams........................................................................................................................ 9
1.4 Application……………………………………………………………………………………………….13
2.0 Features.......................................................................................................................................13
2.1 Main Breakers...........................................................................................................................13
2.2 Distribution Breakers................................................................................................................. 13
2.3 Optional Surge Protection Device……………………………………………………………............13
2.4 Optional External Disconnect Switch ...........................................................................………...13
3.0 Inspecting and Unpacking of PTS9042X Series Load Centers....................................................14
3.1 Steps to Inspect and Remove…………………………………………………………………………14
Figure 3: Packaging..................................................................................................................14
3.2 Hardware Kits............................................................................................................................14
Table 1: PTS9042x Hardware Kit Components.........................................................................14
4.0Mounting. .....................................................................................................................................15
4.1 Mounting Template.............................................................................................................................15
Figure 4: Bottom View Mounting Pattern...................................................................................15
4.2 Mounting to Pole, Stanchion or Round Surfaces.........................................................................16
Figure 5: Mounting Example..................................................................................................... 16
4.3 Mounting to flat surfaces...........................................................................................................17
Figure 6: Mounting Example..................................................................................................... 17
4.4 Removing Dead Front Access Plate………………………………………………………………….18
4.5 Wiring Ground Connections……………………………………………………………………………19
4.6 Wiring Service and Load Connections………………………………………………………………..20
Figure 7: Breaker Wiring Example..............................................................................................20
5.0 Breaker and Modules……………………………………………………………………………………..21
5.0 Main Breaker Replacement or Re-Configuration……………………………………………………21
5.1 Load Breaker Replacement or Re-Configuration……………………………………………………23
5.2SPD Replacement or Re-Configuration………………………………………………………………24
5.3 Re-Installing Dead Front Access Plate......................................................................................26
Figure 8: Dead Front Access Plate Re-installed.......................................................................... 26
6.0 Installation Review........................................................................................................................ 27
7.0 Document and Revision Control…………………………………………………………………..…….28

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
3
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
1.0 Model Overview
The PTS9042x Series of Small Cell AC Power Distribution Load Centers with optional External
Disconnect Switch provides a custom factory fully assembled load center for Small Cell and CRAN
deployments. The PTS9042x Series products conform to UL standards.
PTS90420 –Small Cell AC Power Distribution Load Center

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
4
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
PTS90422 –Small Cell AC Power Distribution Load Center
with External Disconnect

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
5
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
Figure 1: Dimensional Drawings
PTS90420 Outline Drawing
Caution: Installation shall be completed per all NEC and Local Codes. Do not install
PTS9042x Systems before reading and understanding all specifications and installation
guides provided. Installation should be performed by a qualified installer.

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
6
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
PTS90422 Outline Drawing
Bottom view
Caution: Installation shall be completed per all NEC and Local Codes. Do not install
PTS9042x Systems before reading and understanding all specifications and installation
guides provided. Installation should be performed by a qualified installer.

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
7
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
1.1 Specifications
Electrical
Operating Voltage
120VAC
Main Breaker
40Amp MAX
Distribution Breakers
Max of (6) UL489 Breakers 0-20Amp
Power Input Wire Size
#14 - #2 awg Cu - Al
Power Output Wire Size
#20 - #2 awg Cu - Al
Neutral and Ground Contacts
#14 - #4 awg Cu - Al
Rated Conditional Short
10kAIC
SPD, Dual MOV (L-G)
20Ka 8/20us Nominal
External Ground Connection
2-hole ¼-20 w/ 5/8” spacing
22 Series External Disconnect Switch Rating
80 Amp Standard
Physical
Housing Material
Powder Coated Aluminum
Breaker Access
Thumb knob and lockable hasp
Wire Access, Internal
¼” hex head or #2 Phillip
Housing Dimensions (H x W x D)
(Excludes hasp and bracket)
PTS90420
10.13 x 6.15 x 6.00
PTS90422
15.14 x 6.15 x 6.00
Unit Weight / Shippping Weight
PTS90420
10lbs / 12lbs
PTS90422
12lbs / 15lbs
Mounting
Supplied Bracket
Environmental
Operating Temperature
(-40°C) to (60°C)
Relative Humidity
95% Non-Condensing

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
8
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
1.2 Breaker Specifications
Breaker Specifications
PTS P/N
Description
PT-KM1N-07A
UL489A DIN rail Breaker, 07 AMP
PT-KM1N-10A
UL489A DIN rail Breaker, 10 AMP
PT-KM1N-12A
UL489A DIN rail Breaker, 12 AMP
PT-KM1N-16A
UL489A DIN rail Breaker, 16 AMP
Torque Recommendations
Main QOU Breaker
42-47 in-lbs
Load Breaker
17-22 in-lbs
Surge Protection
17-22 in-lbs
Neutral Block and Bar
24-27 in-lbs
Ground Bar
24-27 in-lbs
Caution: Installation shall be completed per all NEC and Local Codes. Do not install
PTS9042x Systems before reading and understanding all specifications and installation
guides provided. Installation should be performed by a qualified installer.

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
9
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
1.3 Wiring Diagrams
PTS90420 Wiring Diagram
Caution: Installation shall be completed per all NEC and Local Codes. Do not install
PTS9042x Systems before reading and understanding all specifications and installation
guides provided. Installation should be performed by a qualified installer.

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
10
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
PTS90420 Cabling Diagram
Caution: Installation shall be completed per all NEC and Local Codes. Do not install
PTS9042x Systems before reading and understanding all specifications and installation
guides provided. Installation should be performed by a qualified installer.

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
11
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
PTS90422 Wiring Diagram
Caution: Installation shall be completed per all NEC and Local Codes. Do not install
PTS9042x Systems before reading and understanding all specifications and installation
guides provided. Installation should be performed by a qualified installer.

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
12
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
PTS90422 Cabling Diagram
Caution: Installation shall be completed per all NEC and Local Codes. Do not install
PTS9042x Systems before reading and understanding all specifications and installation
guides provided. Installation should be performed by a qualified installer.

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
13
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
1.4 Application
The PTS90420 and PTS90422 are compact AC Load Centers designed for Small Cell and CRAN
Deployments where distribution of AC power is required.
The PTS9042x Series of compact AC Load Centers can also be used for AC Power Distribution
applications where limited space exists, excluding the ability to use a larger load center.
The PTS9042X Series of compact AC Load Centers can also be used as a subtending branch
panel when modernizing or expanding existing sites.
The PTS90422 Series includes an external rotary disconnect switch, allowing for the utility, fire
safety and first responders to quickly and safely disconnect power.
2.0 Features
The PTS9042x Series of Small Cell AC Load Centers packaged as a custom configuration, ready for
install in new and expansion environments.
2.1 Main Breaker
The PTS9042x Systems can support main breaker ampacity up to 40Amps.
2.2 Distribution Breakers
The PTS9042x Systems support upto (6) UL489 Breakers rated from 0-20 Amps.
2.3 Optional Single-SPD or Dual–SPD Protection
The PTS9042x Systems can support either Single SPD (L-G) or Dual SPD (L-N) & (N-G) modules.
2.4 Optional External Disconnect Switch
The PTS90422 Series includes an external rotary disconnect switch rated up to 80 Amp.

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
14
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
3.0 Inspecting and Unpacking of PTS9042x Series Load Centers
3.0.1 Inspection
3.0.2 Inspect the packaging for obvious signs of rough handling and/or external damage.
3.0.3 Review Installation Guide.
3.0.4 Remove from plastic packaging.
( PTS90422 Shown )
Caution: Installation shall be completed per all NEC and Local Codes. Do not install
PTS9042x Systems before reading and understanding all specifications and installation
guides provided. Installation should be performed by a qualified installer.

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
15
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
4.0 Installation
The PTS9042x Systems are certified for outdoor installations This section provides installations
guidelines to insure the appropriate requirements are met.
4.1 Mounting Bracket
4.1.1 A mounting bracket is included and pre-installed with the enclosure and can be used
as a template, or the mounting details below can be used, if preferred.
4.1.2 If mounting bracket is removed, a lock-tite like adhesive should be applied to the
screws when replacing.
Figure 4: Mounting Bracket Pattern

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
16
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
4.2 Mounting enclosure to Pole, Stanchion or Round Surfaces
4.2.1 Customer is responsible to identify suitable location for mounting
4.2.2 Verify Customer Acceptable mounting requirements by type
4.2.3 Install Pole Straps and tighten per specifications -or -
4.2.4 Mark and drill anchors locations using Fig. 4 or template provided.
4.2.5 Wood Poles should be Lag Bolted or Through Bolted
4.2.6 Fiberglass or Metal pole shall be strap mounted.
4.2.7 Torque to mounting hardware specifications.
Figure 5: Typical Mounting Configuration for enclosure on a Pole,
Stanchion or Round Surface

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
17
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
4.3 Mounting enclosure on flat surfaces
4.3.1Customer is responsible to identify suitable location for mounting.
4.3.2 Mark and drill anchors or clips to secure enclosure to surface.
4.3.3 Torque to mounting hardware specifications.
Figure 6: Mounting Configuration for enclosure on flat surfaces

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
18
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
4.4 Removing Dead Front Access Plate
4.4.1 Locate Dead Front Access Plate set screw and remove
4.4.2 Set aside for reuse.
4.4.3 Review Equipment Ground Connection Points
4.4.4 Review Neutral Connection Points
Figure 7: As from Factory
( Generic PTS90420 Shown )

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
19
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
4.5 Wiring Ground Connections
4.5.1 Ensure enclosure is grounded as per NEC and Local Jurisdictions Code requirements.
4.5.2 Ensure that the neutral buss bar is grounded per NEC and Local Jurisdictions Code
requirements.
4.5.3 Tighten connections as per manufacturers specifications.
Figure 8: Mounting Location of External Enclosure Ground Connection
Caution: Installation shall be completed per all NEC and Local Codes. Do not install
PTS9042x Systems before reading and understanding all specifications and installation
guides provided. Installation should be performed by a qualified installer.

PTS 9042x Series Small Cell
AC Power Distribution Load Centers
Installation Guide
20
All Rights Reserved, 2017 www.pactechsol.com/TMOVendor 888-820-3508
4.6 Wiring Service and Load Connections
4.6.1 Wiring to be done in accordance with NEC and Local Jurisdictions Code.
4.6.2 Ensure connections are properly seated in set screw openings prior to tightening per
specifications.
4.6.3 Re-check all connections are labeled
4.6.4 If completed, re-install Dead Front Plate as per Section 5.3
Figure 9: Standard Wiring Practice Example
