www.batcafitness.com AXIS Dip/Plyo Platform Owner's Manual
June 2018
Revision 0
Serial Number Here
Date of Purchase
Dip/Plyo Platform
Owner’s Manual

Batca Fitness Systems 2AXIS Dip/Plyo Platform Owner's Manual
Page
Instructions 2
Tools Required/Hardware Sheet 3
AXIS Dip/Plyo Platform Assembly 4-7
Congratulations on the purchase of your new Batca AXIS Dip/Plyo Platform. This gym will
provide you with a lifetime of enjoyment to meet your strength training needs. Batca Fitness
Systems strives to build the best quality gyms and to package these gyms in such a way to
avoid any damage during shipping.
In order to get started with your assembly you should rst familiarize yourself with this
manual. It is recommended that you read through each step thoroughly before you begin.
Begin by opening your boxes and separating all of your parts. Verify that all parts are accounted
for and have no damage. When all parts are accounted for, you may begin your assembly.
Some items may have been pre-assembled for your convenience. Please note that hardware
quantities shown reect total quantities for your gym and may not reect actual quantities in
each bag. Assemble your gym on a solid level surface. This will ensure the best possible
performance, function, and safety for the gym and your workout.
Assemble your gym according to the step by step instructions found in this manual. Failure
to do so will void your warranty and may result in personal injury. After assembly, you should
check each station to ensure correct operation. If a problem arises, recheck your assembly with
these instructions to verify correct assembly. If you are unable to correct a problem or have
questions with your assembly please contact your authorized Batca dealer.
Batca Fitness Systems has built this gym to give you a safe, effective and enjoyable
workout. However, there is a risk assumed by individuals who use this type of equipment. It is
very important that all warnings and instructions are read and followed before beginning any
exercise program.
It is also very important to read and follow the preventative maintenance schedule
described in this manual. If any of the warning labels or stickers are worn, faded, torn,
scratched or missing they should be replaced immediately.
WARNING: There is a risk assumed by individuals who use this type of equipment. To
minimize risk always follow these rules.
1)It is essential that you consult with your physician before beginning any exercise program.
2)Inspect equipment before each use for loose, worn, or frayed parts (including cables, nuts
and bolts). Replace parts at rst signs of wear (use only genuine BATCA replacement parts).
Use of equipment that is damaged, worn, frayed or not completely assembled on a solid,
level surface may result in injury.
3)Make sure all adjustment pins are fully engaged before using equipment.
4)Keep all parts of the body and clothing outside the path of any moving parts of the gym. Be
alert to the possibility of injury. Do not be careless.
5)Minors and children should not be allowed to play on or around this gym.
6)If you have any questions on proper use or maintenance of this gym, do not hesitate to call
your local BATCA FITNESS SYSTEMS distributor or BATCA FITNESS SYSTEMS at (919) 255-
1233. www.batcatness.com
Page
Maintenance 8
Warranty 9
Table of Contents
Instructions
Warning

www.batcafitness.com 3AXIS Dip/Plyo Platform Owner's Manual
Tools Required
 9/16” Wrench/Ratchet
 Metric Allen Wrench Set (M8, M6, M4)
Hardware Blister Pack

Batca Fitness Systems 4AXIS Dip/Plyo Platform Owner's Manual
PLEASE FOLLOW ALL DIRECTIONS VERY CAREFULLY FOR PROPER INSTALLATION.
THE AXIS DIP/PLYO PLATFORM CAN BE MOUNTED IN BETWEEN ANY COMBINATION OF AT
LEAST TWO MODULAR AXIS UNITS (AXIS FREE TRAINER, AXIS BODY WEIGHT STATION, AXIS
SMITH MACHINE, OR AXIS SQUAT RACK). AT LEAST TWO MODULAR UNITS MUST BE
PURCHASED INORDER TO INSTALL AXIS DIP/PLYO PLATFORM.
Step 1:
Note: Please Position Hardware in the same direction as shown in the figure. This will
make future steps easier to assemble
All Flat Washers and Nylocks are 3/8” unless otherwise noted. Anywhere a washer is against the
round side of a tube there is to be a 3/8” CURVED WASHER instead of a 3/8” FLAT WASHER.
Please Tighten Bolts before moving to next step.
Part # Description Qty
BFM-11118 Dip/Plyo Platform Crossmember A 1
BFM-11122 Dip/Plyo Platform Crossmember B 1
BFP-51753 SHCS 3/8” x 4 3/4” 8
BFH-50204 3/8” Curved Washer 16
BFH-50157 3/8” Nylock 8
Please Note that the
position of the curved
plates where the Selector
Assembly will be mounted
in the next step. If it is
being connected to the
AXIS Smith Machine or the
AXIS Squat Rack, the
Selector Assembly should
always be positioned away
from the Olympic Bar of
those Stations (As shown in
illustration)
4 3/4”
Dip/Plyo Platform
Crossmember B
Dip/Plyo Platform
Crossmember A

www.batcafitness.com 5AXIS Dip/Plyo Platform Owner's Manual
Step 2:
All Flat Washers and Nylocks are 3/8” unless otherwise noted. Anywhere a washer is against the
round side of a tube there is to be a 3/8” CURVED WASHER instead of a 3/8” FLAT WASHER.
DO NOT TIGHTEN BOLTS
Part # Description Qty
BFM-11117 Dip/Plyo Platform Selector Assembly 1
BFP-51748 SHCS 3/8” x 3 1/4” 2
BFP-51799 SHCS 3/8” x 5” 2
BFH-50204 3/8” Curved Washer 4
BFH-50146 3/8” Flat Washer 4
BFH-50157 3/8” Nylock 4
3 1/4”
Dip/Plyo Platform
SHCS 3/8” x 5”
(Qty=2)
3/8” Curved
Washer
(Qty=4)

Batca Fitness Systems 6AXIS Dip/Plyo Platform Owner's Manual
Step 3:
All Flat Washers and Nylocks are 3/8” unless otherwise noted. Anywhere a washer is against the
round side of a tube there is to be a 3/8” CURVED WASHER instead of a 3/8” FLAT WASHER.
DO NOT TIGHTEN BOLTS
Part # Description Qty
BFM-11125 Dip Handle Support 1
BFM-11126 Dip Handle 1
BFM-52711 Dip Handle Storage Assembly 1
BFP-51748 SHCS 3/8” x 3 1/4” 2
BFP-51799 SHCS 3/8” x 5” 3
BFH-50204 3/8” Curved Washer 6
BFH-50146 3/8” Flat Washer 4
BFH-50157 3/8” Nylock 5
5”
5”
3 1/4”

www.batcafitness.com 7AXIS Dip/Plyo Platform Owner's Manual
Step 3:
All Flat Washers and Nylocks are 3/8” unless otherwise noted. Anywhere a washer is against the
round side of a tube there is to be a 3/8” CURVED WASHER instead of a 3/8” FLAT WASHER.
DO NOT TIGHTEN BOLTS
Part # Description Qty
BFM-11121 Plyo Platform 1
Plyo Platform

Batca Fitness Systems 8AXIS Dip/Plyo Platform Owner's Manual
Batca Fitness Systems strives to give you the very best in quality, performance and safety through carefully engineered
designs and excellent workmanship. In order to maintain this high level of quality the preventative maintenance schedule
below should be followed.
Clean upholstery, grips, and roller pads with mild soap and water generally after every use. The guide rods, chrome slides and
frame should be cleaned with a cotton cloth. Upon cleaning the guide rods, a thin layer of Silicone or Teon gel should be
applied to each rod to ensure a glass smooth performance.
An overall inspection should be done before each workout. If the warning and safety decals are worn or have been removed
they should be replaced immediately. The cables and cable systems should be inspected for signs of wear and proper
tension. In order to check cables properly you should carefully run the cable through your ngertips, checking for signs of
wear, cracks, burs and thinning spots. Replace any part at rst signs of wear. Cables should be adjusted for proper tension.
See assembly instructions for this detail. All hardware, stops, and adjustments should be checked and tightened as required.
The guide rods on your machine should be cleaned and lubricated regularly. This will ensure a glass smooth performance
from your weight stack. A thin layer of either Silicone or Teon gel should applied to each rod. Each pillow block bearing and
ange bearing has a grease ttings that must be lubricated regularly. Use general purpose bearing grease and follow the
schedule below.
Although cables should be inspected daily, it is important that ALL cables be replaced as directed in the schedule below.
Please note that at any rst sign of wear the cable should be replaced immediately.
If there are any questions concerning maintenance, please contact your local Batca dealer or contact Batca Fitness Systems
directly at:
Batca Fitness Systems
[phone]
www.batcatness.com
Preventive Maintenance
Daily Weekly Monthly Quarterly Years
Commercial Home Commercial Home Commercial Home Commerci Home Commercial Home
Clean
Frame XX
Inspect
Overall XX
Hardware XX
Frame XX
Lubricate

www.batcafitness.com 9AXIS Dip/Plyo Platform Owner's Manual
What is covered
For Residential Use:
Batca Fitness Systems warrants all of its products against defects in manufacturing, materials and workmanship
under normal use and service for one year from date of purchase including paint, chrome, upholstery and grips.
Batca Fitness Systems also warrants all cables, belts, bolts, nuts, caps, plugs, bumpers, washers, levelers, decals,
gas springs and other hardware for three years after date of purchase; all moving parts, including pulleys, bushings,
bearings and pull pins for ve years after date of purchase and warrants the frame and all welded parts for the
lifetime of the original purchaser.
For Commercial Use:
Batca Fitness Systems warrants all of its products against defects in manufacturing, materials and workmanship
under normal use and service for six months from date of purchase including paint, chrome, upholstery and grips.
Batca Fitness Systems also warrants all cables, belts, bolts, nuts, caps, plugs, bumpers, washers, levelers, decals,
gas springs and other hardware for one year after date of purchase; all moving parts, including pulleys, bushings,
bearings and pull pins for three years after date of purchase and warrants the frame and all welded parts for ten
years after date of purchase.
What is not covered
This warranty does not cover damage, which results from shipping, misuse, abuse, neglect, carelessness,
modication or alteration, accident, re, ood, “acts of God” or other contingencies beyond the control of Batca
Fitness Systems. This warranty also does not cover deterioration from wear and tear or exposure or any defect,
which would not have happened if instructions in the owner’s manual had been followed. Improper installation,
improper assembly or follow-up maintenance along with installation of parts or accessories not originally intended
for products of Batca Fitness Systems are also not covered by this warranty. Only genuine Batca parts should be
used for replacement, repair, and maintenance for this warranty to apply.
Defective parts will be repaired or replaced at Batca Fitness Systems option, without parts charge to the purchaser.
All returns require a return authorization prior to acceptance of repair work. Batca Fitness Systems reserves the right
to make design changes without any prior notication and shall not be responsible for incidental or consequential
damages.
The purchaser is responsible for shipping the defective part back to the factory. Repair or replacement is the
exclusive and sole remedy of the purchaser. Labor charges associated with parts changeovers are not covered by
this warranty. Proof of purchase, serial number, model number and date of purchase will be required along with all
pertinent information of the alleged damage.
This warranty applies only to the original purchaser and is not transferable. Claims under this warranty must be
made directly to Batca Fitness Systems.
Batca Fitness Systems
1207 N. New Hope Road
Raleigh, NC 27610
[phone]
www.batcatness.com
Please keep this for your records.
Limited Lifetime Warranty
Scan the QR Code to
register your new
BATCA Product online!
