Bauer B-TIMER Instruction Manual

Filter cartridge lifetime computer for
BAUER filter systems - P21 P31 P41
Operating Instruction Manual
B-TIMER
11/2012
1
Introduction
Read these operating instructions carefully before using the
B-TIMER. (Valid for devices from version 300.301.811 onwards).
The settings in the setup menu are critically
important in terms of the ability to display the
filter capacity correctly. Without these
settings, the B-TIMER can only be used as an operating
hours counter!
Ensure that the compressor’s pressure
retention valve is set to 150 bar (factory
setting) and that it is functioning correctly,
otherwise the filter capacity may be displayed incorrectly
and the operation may not, under certain circumstances,
be detected correctly.
Before delivery, ensure that all the
maintenance counters (a+b+c) have been
reset. (Otherwise, the B-TIMER signalises
incorrect maintenance intervals, since the storage times
are not taken into consideration.) If the items in question
have not been reset, it must be done without delay. Refer
to the ‘Reset’ sectiononpage4.
DESCRIPTION
The B-TIMER (Figure 1) is a self-activating mini-computer that
keeps track of the compressor’s operating hours and calculates
the filter cartridges’ lifetime with the help of the time, the
temperature, the type of cartridge and the delivery quantity of
the compressor. It displays the operating hours, the cartridge’s
service life and the compressor’s upcoming
maintenance-related tasks. The B-TIMER needs neither an
external power supply nor a connection to the compressed air
system. It is mounted on the enclosure of the filter to be
monitored with the help of a fastener and is thus the ideal
monitoring device for all mobile BAUER compressors. It is
particularly well-suited for sport-diving devices that are
powered by either gasoline or diesel fuel. Every system of
BAUER-KOMPRESSOREN can easily be retrofitted with the
B-TIMER.
Intended usage
This device serves solely as an appliance that can be used to
display the operational status and does not release the user from
the additional responsibility to monitor and measure the
breathing air quality of the filter system in accordance with
national norms (e.g. EN 12021). This cannot be done with the
B-TIMER.
The B-TIMER may only be used with BAUER compressors,
BAUER processing plants and original BAUER filter cartridges. It
has only been designed and approved for the aforementioned
BAUER filter systems, not for the Verticus and Mini-Verticus
plants. The respective cartridge numbers are contained in the
software. Every other type of utilisation counts as utilisation that
is not in accordance with the regulations. Damages resulting
from such utilisation are subject to the manufacturer’s/supplier’s
risk exclusion, warranty exclusion and liability exclusion policies.
In case of external filter cartridges, even those of similar
dimensions, the service life can deviate significantly from the
intended service life on account of, e.g. different filling materials
and fill quantities. Secure and correct functionality cannot be
guaranteed for compressors and filter systems produced by
other manufacturers, as the compressed air in these items may
be at different temperatures and the efficiency of the upstream
final interceptor may be different. The B-TIMER has only been
tailored to the interaction between BAUER compressors, BAUER
filter systems and original filter cartridges.
Be mindful of the application limits of the device:
Working temperature: 0 C to +50 C
Storage temperature: -20 C to +70 C
Protection class: IP65 (protection against contact, dust-proof,
protection against hose water)
Vibration, ±3 g when in operation
Max. humidity: 95%; non-condensing
Figure 1 B-TIMER
Installation
Use the enclosed fastener to mount the B-TIMER at the centre
of the gold-coloured filter’s enclosure. In case of the P41, mount
it on the grey micro-filter’s enclosure. Both its legs must lie on
the container. Ensure that it does not come into contact with
the filter’s fastening clamps. If the B-TIMER needs to be
remounted, e.g. during the replacement of the filter’s
enclosure, ensure that the underside of the heat conduction pad
has not been damaged.

Operating instruction manual - B-TIMER
2
Method of functioning
The B-TIMER display displays the following functions:
Operating hours of the compressor plant. A blinking ‘h’
indicates that the compressor-operation has been detected.
Cartridge life in % via 4 segments in the filter-cartridge
symbol.
When the remaining capacity reaches or falls below 20% of
the total lifetime, the final segment starts blinking and the
figure displayed for the operating hours switches over to the
cartridge’s order number.
The compressor plant displays the upcoming
maintenance-related tasks with the help of alphabets and
figures displaying the operating hours.
A = 500 hours or 1 year
B = 1000 hours or 2 years
C = 2000 hours or 4 years
A battery symbol is used to indicate that the lithium battery
is weak and must be replaced. The data is saved and is not
lost when the battery is changed.
The B-TIMER is operated with the help of the entry and
selection keys.
Error display
If the temperature sensor in the device malfunctions, ‘Error 1’ or
‘Error 2’ comes up at the display (Figure 3).
In such a case, use of the B-TIMER should be discontinued. Send
the device to the factory for repairs, or send it to the next
agency.
Battery replacement
The battery (1, Figure 4) is placed in the battery compartment.
To replace the order, withdraw plug (2) and pull the battery out
of the battery compartment. Make sure you use a battery of the
same type (BAUER order number 82743).
Figure 2 Display
12
3
4
5
6 7
1 Key symbol (maintenance due)
2 Alphabet (type of maintenance)
3 Battery symbol
4 Cartridge saturation display
5 Operating hours or cartridge no.
6 Selection keys
7 Entry keys
Figure 3
1
2
Figure 4 Battery replacement

Operating instruction manual - B-TIMER
3
Operation
The B-TIMER switches itself on when the
compressor is activated. The fact that the
compressor is in operation is indicated by the
blinking ‘h’ symbol.
To switch on the B-TIMER without putting the compressor into
operation, press one of the buttons on the display: the main
menu is displayed (Figure 5).
If no button is actuated for 1 minute, the
display reverts to the main menu. The
B-TIMER switches itself off if the
compressor-operation is not detected in 2 minutes.
Functional display
Press the selection button to display the
desired function ().
Press the button. The remaining filter-capacity is displayed
(Figure 6).
Press the button. The number of operating hours lying
between the point in question and service interval A (500 hours
or yearly) is displayed (Figure 7).
Press the button. The number of hours remaining before
service interval B (1000 hours or every two years) is displayed
(Figure 8).
Press the button. The number of hours remaining before
service interval C (2000 hours or every four years) is displayed
(Figure 9).
Press the button. The filter-cartridge number is displayed
(Figure 10). The filter icon blinks.
Press the button. The display reverts to the main menu.
Figure 5
Figure 6
Figure 7
Figure 8
Figure 9

Operating instruction manual - B-TIMER
4
Reset
The filter capacity may only be reset after the
cartridge has been replaced!
To reset the filter capacity or the A, B and C service intervals,
hold the  button down for more than 5 seconds when the
respective display has been activated (Figure 11).
Setup
To navigate to the setup menu of the various functions of the
B-TIMER, hold down the and  buttons simultaneously for
more than 5 seconds when the cartridge number is being
displayed (Figure 10). The filter icon starts blinking (Figure 12),
which indicates the setup mode.
The applicable filter-cartridge no. is set under setup A.To
change the article number, hold down the  button for
3 seconds, after which the number starts blinking. Use the
button to set the desired number. Use the  button to accept
the number in question.
Article numbers beginning with 999 must be
set in a special manner.
Hold down the button for 3 seconds, and then enter 999000
with . The last 0 starts blinking. Appoint the corresponding
digit with and accept it with . When the 2nd zero starts
blinking, appoint the digit as described above, and carry out the
same procedure for the 3rd digit.
When the button is pressed, the display switches over to
setup B (setting of the delivery quantity). The filter icon starts
blinking (Figure 13). The delivery quantity (in l/min.) can be
found in the compressor’s instruction manual. To change the
configuration, hold down the  button for 3 seconds, after
which the 1st digit starts blinking. Use the button to set the
desired number. Use the  button to accept the number in
question and repeat the same procedure until all three digits
have been set correctly.
When the button is pressed again, the display switches over
to setup C (setting of operating pressure). The filter icon starts
blinking (Figure 14).
To change the operating pressure, hold down the  button for
more than 3 seconds. Press the button to enter the new
operating pressure. (Options: 200 bar, 300 bar or 200/300 bar).
Press the button to confirm the new setup.
The filter capacity must be reset after the
setup preferences have been entered and a
new filter cartridge has been inserted. Refer
to the ‘Reset’ section.
When the button is pressed again, the display switches over
to the setup menu for the operating hours. Press the 
button for 2 seconds, after which the last digit starts blinking.
Use the button to appoint the desired digit and press the
button. Repeat this procedure until all the digits have been
entered. Repeated actuation of the button leads the system
back to the main menu. Pressing the and buttons (for
2 seconds) makes it possible to repeat the setup procedure.
Figure 10
Figure 11
Figure 12
Figure 13
Figure 14
