Bauhn ASPP4C-1021-B User manual

Product Overview
Troubleshooting
Have you got everything?
Unpack the box and make sure
all of these items are there:
Note: only one powerboard
(white/black) is supplied.
User Guide
Model: ASPP4C-1021-B / ASPP4C-1021-W
4-Way Surge Powerboard
with USB-C Charging
A. 4-Way Surge Powerboard
B. User Guide
C. Warranty Certicate
AC Sockets
All 4 sockets are the same protected
sockets.
USB Charging Ports
For charging phones, tablets or other
mobile devices.
USB-C Charging Ports
For charging devices that support USB-C
connection.
Overload Circuit Breaker (Resettable)
Protects against current overload at 10 amps.
Give us a call
What? You mean this User Guide didn’t have ALL the answers? Speak to us!
We’d love to help you get up and running as quickly as possible.
Call our After Sales Support on 1300 002 534.
Operating hours: Monday-Friday, 8:30am-6pm; Saturday, 9am-6pm AEST
No power
output from
one of the
sockets
• Try other sockets. If the other sockets have power output, it’s
probably the contact of one faulty socket that is loose or not
connected; avoid using that socket.
No power
output from
any of the
sockets
• Check that the surge protected LED indicator is lit green.
• Check the overload circuit breaker button to see whether it’s
tripping, push it down to reset the circuit breaker.
• Make sure the input socket for the powerboard has power output.
No output
from the
USB/USB-C
ports
• Check that the USB/USB-C cable is connected securely to the
USB/USB-C port and/or try a different USB port.
• The total output current for the USB ports are 6.2A (USB supports
2.4A and USB-C supports 3A). Remove devices using the other
USB ports.
• Check that your device supports 5V charging for the USB-C port.
• Use another USB/USB-C cable.
Powerboard
is not turning
on
• Check that there is no visible damage to the plug or cord.
• Ensure that the devices connected do not exceed the total
maximum load (2400W, 10A). If exceeded, unplug the devices and
press the overload reset button.
Well done, you made it.
Now sit back and relax... your powerboard is automatically
covered by a 1-year warranty.
How nice!
1
1
2
2
3
4
4
5
Enjoy using your powerboard!
Surge Protected LED Indicator
When lit, the green light indicates that all
connected devices are surge protected.
ADSL/Phone Line Port
Protect your home phone or modem
against electrical surges
3

Specications
Input AC 230-240V, 50Hz, 10A
Total Loading Max 10A 2400W
Surge Protection 190J
USB Output DC 5V, 2.4A Max.
USB-C Output DC 5V, 3A Max.
Power Cable 1.8m
Mass 580g
Dimensions (W x H x D) 330 x 33 x 55 mm
GENERAL SAFETY WARNINGS
General Safety Warnings
For the safety of yourself and others, follow all instructions and take notice of all the warnings.
When adhered to, these safety precautions can reduce the risk of fire, electric shock and injury.
This product complies with Australian Safety standard AS/NZS 3105, AS/NZS 62368.1 to ensure
the safety of the product.
The RCM is a visible indication of a product’s compliance with all applicable ACMA
regulatory arrangements, including all technical and record-keeping requirements.
IMPORTANT
• Damage: If the powerboard or cord
is damaged, contact the After Sales
Support line for advice. Do not
attempt to open the board or replace
the cord. The cord must be replaced
by appropriately qualied personnel.
• Repair: If the powerboard requires
repair, contact the After Sales
Support line; never disassemble or
modify the powerboard or attempt to
service it yourself.
• Run the power supply cord in such
a way that there will be no risk of
anyone pulling it inadvertently or
tripping over it.
• The powerboard is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision or
instruction by a person responsible
for their safety.
• Young children should be supervised
to ensure they do not play with the
powerboard. Close supervision is
always necessary when any appliance
is used by or near children.
• The surge powerboard is designed
for indoor use in dry places only.
• Do not exceed a maximum loading of
2400 watts.
• For safety reasons, always use earth
connections.
• Only use the powerboard with the
power supply cord fully unwound.
• Before installing the powerboard,
make sure to place it away from: heat
sources, radiators or other products
that produce heat; areas with high
temperatures, high humidity or direct
sunlight; excess dirt and dust; open
windows and any place where water
may get to the unit.
• Do not immerse the cord, plug or
the surge powerboard in water or
other liquid, or expose the electrical
connections to water or other liquid.
• Unpack the powerboard and keep
the original packaging carton and
materials in a safe place. It will
help prevent any damage if the
powerboard needs to be transported
in the future, and you can use it to
store the powerboard when it is not
in use.
• The powerboard should always be
repacked in its original packaging
whenever transporting to prevent any
possible damage to the product.
• When not in use: Disconnect from
the power source and store in a cool,
dry and well ventilated location out
of direct sunlight, and not subject to
humidity.
• Warning: Discard this powerboard if
the supply cord is damaged.
• Warning: The socket outlet should
be located near the equipment and
should be easily accessible.
Responsible disposal of the product
At the end of its working life, do not throw
this product out with your household
rubbish. An environmentally friendly
method of disposal will ensure that
valuable raw materials can be recycled.
Contact your local authority for your
nearest recycling centre. Electrical and
electronic items contain materials and
substances which, if handled or disposed
of incorrectly, could potentially be
hazardous to the environment and human
health.
Responsible disposal of the packaging
The packaging of the product has been
selected from environmentally friendly
materials and can usually be recycled.
Please ensure these are disposed of
correctly. Plastic wrapping can be a
suffocation hazard for babies and young
children, please ensure all packaging
materials are out of reach and are safely
disposed of. Please ensure they are
offered for recycling rather than throwing
these materials away.
Cleaning the product
Only use a soft, dry cloth for cleaning the
product; do not use a damp cloth. Never
clean with industrial strength polish, wax,
benzene, paint thinner, air freshener,
lubricant, detergent or other chemicals.
Wipe off any moisture, dirt or dust on the
power sockets and plug pins with a clean,
dry cloth.
