Wi-Fi Power Point Controller
Warranty Details
The product is guaranteed to be free from defects in workmanship and
parts for a period of 12 months from the date of purchase. Defects that
occur within this warranty period, under normal use and care, will be
repaired, replaced or refunded at our discretion. The benets conferred
by this warranty are in addition to all rights and remedies in respect of the
product that the consumer has under the Competition and Consumer Act
2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.

3
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Contents
Warranty 2
Contents 3
Welcome 4
General Safety Instructions 5
Product Features 6
Parts List / Technical Specications 7
Product Setup 8
Product Operation 17
Timers & Schedules 19
Troubleshooting Guide 27
FAQ’S 28
Repair and Refurbished Goods or Parts Notice 31

4After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Congratulations on choosing to buy a BAUHN® product. By doing so you
now have the assurance and peace of mind that comes with purchasing a
product made by one of the leading manufacturers. All products brought to
you by BAUHN® are manufactured to the highest standards of performance
and safety and, as part of our philosophy of customer service and
satisfaction, are backed by our comprehensive 1 Year Warranty. We hope
you will enjoy using your purchase for many years to come.
Welcome

5
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Read this manual thoroughly before rst use and keep it in a safe place for
future reference, along with the warranty card, purchase receipt and carton.
The safety precautions enclosed herein reduce the risk of re, electric shock
and injury when correctly adhered to. Follow all instructions and take notice
of all warnings to reduce the risk of re or electric shock.
• Indoor use only
• Do not exceed the maximum power rating 10A or 2400W
• Do not expose to water, dust, chemicals and moisture
• Keep away from heat sources and direct sunlight
• Children and inrm persons should use this device only under the
supervision of a responsible adult to control appliances safely
• Young children must be supervised to ensure they do not play with
this device.
• Do not operate or control heat producing devices connected to the
Wi-Fi Power Point Controller when unattended.
• Do not drop or subject the device to undue shock
• Do not attempt to service or disassemble. Attempting to open
or service the unit voids all warranties, express or implied. If you
experience problems with the device, discontinue use, unplug the
device from the wall outlet and contact Winplus After Sales Support
for assistance.
• Unplug this device during lightning storms or when unused for long
periods of time
General Safety Instructions

6After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Product Features
• Control the Wi-Fi Power Point Controller from anywhere, using your iOS
/ Android device*
• Check the current status of your Wi-Fi Power Point Controller from
anywhere, using your iOS / Android device*
• Easy to setup on your existing wireless network
• Set timers to activate your according to a schedule
• Control up to 150 Wi-Fi Power Point Controllers using one iOS / Android
device
• Gives you extra control to conserve energy
* Power Point Controller requires a Wi-Fi network. Mobile remote control
requires an iOS or Android device with Wi-Fi, 3G or 4G connection.
RATING: AC 240V 10A
TOTAL LOAD MUST NOT EXCEED 2400W
LED indicator
Socket
Operating button

7
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Technical Specications
Voltage: 240V AC 50HZ
Max load current: 10A
Total load must not exceed 2400W
Working temperature: 0-50°C
Network: 802.11, b/g/n
Security: WPA-PSK / WPA2-PSK / WPA / WPA2 / WEP / WPS2 / WAPI
Encryption Type: WEP / TKIP / AES
Parts List
• Wi-Fi Power Point Controller
• Getting Started Guide
• Warranty Card
• Warranty Stickers
• Instruction Manual

8After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Product Setup
Before you can use your Wi-Fi Power Point Controller, it must be set
up using your Android/iOS device. Initial setup must be performed
using your home Wi-Fi network. Once it has been set up you can
control your power outlet via Wi-Fi/3G/4G.
Important: A current mobile service plan is required for correct
operation over 3G & 4G. Mobile data may be required for some
features. The supplier is not responsible for any charges incurred.
Please contact your network service provider for further information
about your current data plan and any associated charges.
Note: Consult your device’s instruction manual if you are unsure
how to download apps, connect to Wi-Fi or any other functions of
your Android or iOS device.
Software
The free SmartPoint App is available for Android and iPhone, and is required
to operate your Wi-Fi Power Point Controller.
1. Ensure your iOS / Android device is connected to the internet using your
home Wi-Fi network.
2. Open the App store on your phone.
3. Search for “SmartPoint” in the App store.
4. Download the SmartPoint controller App to your phone.

9
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Connecting the Wi-Fi Power Point Controller to your Wi-Fi network
Initial setup must be performed using your home Wi-Fi network.
1. Ensure your iOS / Android device is connected to your home Wi-Fi
network. Refer to your device manual for further details on connecting
your device to Wi-Fi.
2. Open the SmartPoint controller App on your iOS / Android device
3. Click the settings icon at the bottom of the screen, then select Smart
Setup

10 After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
4. Your wireless network name (SSID) is shown in the smart setup screen
below is an empty eld to enter your Wi-Fi network password. Enter
your password into this box
SSID

11
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
5. Insert the Wi-Fi Power Point Controller into the power socket. Turn
on the power outlet. The Power Point Controller will begin to ash red
rapidly to indicate it has enter pairing mode.

12 After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
6. While the light is ashing rapidly, select the Setup New Socket button in
the SmartPoint App to begin the pairing process.
7. Once paired, you will see a ‘Cong successful’ message. If you do not
see this message repeat step 7 or refer to the FAQ at the back of the
manual for more information.
Note: The conguration process should take about 1 minute
SSID

13
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
8. Once conguration is complete, press Back, then press Devices. Press
the on-screen power button to check that your Wi-Fi Power Point
Controller is now operating.
9. Connect the appliance you wish to control to the socket of the Wi-Fi
Power Point Controller.
SSID

14 After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Customise your Wi-Fi Power Point Controller
The Bauhn Wi-Fi Power Point Controller can be customised to allow you
to easily tell the difference between multiple controllers connected to your
network.
1. Open the SmartPoint App, and select Customise from the main screen.
2. Select the Wi-Fi Power Point Controller you wish to modify, and you will
see the current name and current graphic icon displayed.

15
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
3. To change the name of the Wi-Fi Power Point Controller, click the name
eld, and modify the text. When you have nished, press done.
4. Select the graphic you wish to be displayed for this Wi-Fi Power Point
Controller by clicking on the icons.
5. Press Conrm to save your changes, and return to the Customise menu.

16 After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Locking your Wi-Fi Power Point
You can lock the Wi-Fi Power Point to prevent new users from discovering
the Power Point over your local network.
1. Open the SmartPoint App, and select Customise from the main screen.
2. Select the Wi-Fi Power Point Controller you wish to modify, and you will
see the current name and current graphic icon displayed.
3. Press the lock icon to lock the Wi-Fi Power Point controller from being
discovered by new users
Changing your password
Once you have set up your WiFi Power Point Controller, you can add a
password to prevent other users accessing the device remotely.
1. Open the SmartPoint App, and select Customise from the main screen.
2. Select the Wi-Fi Power Point Controller you wish to modify, and you will
see the current name and current graphic icon displayed.
3. Select Modify Remote Password to set a password for the Wi-Fi Power
Point Controller.
4. Enter the old password, and your new password, then press OK.
Note: The default password is 888888.
5. Press Conrm to save your changes, and return to the Customise menu.

17
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Switching On and Off
To control your Wi-Fi Power Point Controller simply follow the below
instructions.
1. Open the SmartPoint App, and select Devices from the main screen.
2. Select the device you wish to control, then press the power button to
toggle between on and off state.
Tip: The indicator light on the front of your Wi-Fi Power Point
Controller will be solid red when in off status, and solid blue
when in on status
Product Operation

18 After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Check the Current Status of Your Appliance
1. Open the SmartPoint App, and select Devices from the main screen.
2. Select the device you wish to control, refer below.
On/Off/Ofine status
for selected device
On status shown with
coloured icon
All Wi-Fi Power Point Controllers which have been
programmed with this iOS / Android device are shown at the
bottom of the screen
Ofine
(unreachable)
status shown with
broken chain
Off status shown with
grey icon

19
After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
Timers and Schedules
Your Wi-Fi Power Point Controller can be used to manage your device power
using automatic timers and schedules.
Setting the Automatic Timer
1. Connect your iOS Android device to the Wi-Fi network.
2. Open the SmartPoint App, and select Rules from the main screen.
3. Select Timing from the menu at the top of the screen, then select the
rule you wish to modify or create a new rule by pressing Add.
4. Repeat – Select the days you wish your rule to activate. For a single
time only rule, you should select single from the list.

20 After Sales Support - Help Desk
Telephone: [phone]
Internet: www.winplus.com.au
5. Time – Select the time you wish the action to be performed.
6. Devices – Select the on/off status you wish for each of your connected
Wi-Fi Power Point Controllers at this time.
7. Once you have nished making changes, click Save to return to the
Rules menu.
Tip: To return to the Rules menu without saving the timer,
select Back
