Baumatic BFD62W User manual

IMPORTANT!
PLEASE READ THIS MANUAL AND KEEP IT FOR FUTURE REFERENCE!
THIS MANUAL CONTAINS SECTIONS OF SAFETY INSTRUCTIONS, OPERATING
INSTRUCTIONS & TROUBLESHOOTING TIPS, ETC.
BAUMATIC
BFD62W – DISHWASHER
60CM FULL HEIGHT DISHWASHER
INSTRUCTION MANUAL
CAREFULLY READING IT BEFORE USING THE DISHWASHER WILL HELP
YOU USE AND MAINTAIN THE DISHWASHER PROPERLY.
09/01/06

BAUMATIC BFD62W dishwasher user manual 2
BEFORE CALLING
FOR SERVICE
REVIEWING THE SECTION ON
TROUBLESHOOTING TIPS WILL
HELP YOU SOLVE SOME
COMMON PROBLEMS WITHOUT
THE NEED TO ASK FOR HELP
FROM PROFESSIONAL
TECHNICIANS.
PLEASE NOTE:
THE MANUFACTURER
RESERVES THE RIGHT TO MAKE
MODIFICATIONS TO PRODUCTS
WITHOUT GIVING PRIOR
NOTICE.
2
CONTENTS
• SAFETY FIRST!
SAFETY INFORMATION .……………..…………3
*Please read this before using your dishwasher!
• KNOWING YOUR
DISHWASHER
CONTROL PANEL ………………………..……..…4
DISHWASHER FEATURES …………..………….4
• USING YOUR
DISHWASHER
WATER SOFTENER …………………..………...5-6
DETERGENT ………………..............................6
RINSE AID ………………….............................7
LOADING YOUR DISHWASHER…..….......8-11
STARTING A WASH CYCLE ……………….12-14
UNLOADING AT THE END OF A CYCLE…....14
FILTERING SYSTEM ………………..…….…….15
CLEANING AND MAINTAINING
YOUR DISHWASHER …………………….…15-17
• BEFORE YOU CALL FOR
SERVICE…
TROUBLESHOOTING ………………….…18-21
• MISCELLANEOUS
CHARACTERISTICS ………….………….……...22
HOW TO INSTALL ……….…….…..……....23-28
FINAL CHECKLIST BEFORE STARTING…….28
CONDITIONS OF GUARANTEE………………..29
CONTACT DETAILS…………………………..…..30

BAUMATIC BFD62W dishwasher user manual 3
IMPORTANT SAFETY INFORMATION
READ BEFORE USING!
ELECTRICAL SAFETY
• NOTE - This appliance must be grounded. In
the event of a malfunction or breakdown,
grounding will reduce the risk of electric
shock by providing a path of least resistance
of electrical current. You will be able to tell if
it is because a non-grounded appliance will
give off an electrical discharge.
• Manufacturer declines all responsibility for
any damage due to non-grounding of
appliance.
• DURING THE GUARANTEE PERIOD ONLY BAUMATIC
SERVICE ENGINEERS OR AN AUTHORISED AGENT
OF BAUMATIC SHOULD CARRY OUT REPAIRS ON
THIS UNIT.
• DO NOT USE IF THE SUPPLY CORD IS DAMAGED.
• FOR INSTALLATION PROCEDURE PLEASE CONSULT
PAGES 23 – 28.
BEFORE USING
SOME ITEMS ARE UNSUITABLE FOR WASHING
IN YOUR DISHWASHER. PLEASE SEE PAGE 8 FOR A LIST
OF THESE ITEMS.
DO NOT TAMPER WITH THE CONTROLS.
WHEN LOADING ITEMS TO BE WASHED:
1) Keep sharp items like knives away from the door
seal.
2) Load sharp knives with the handles up to prevent
injuries.
ONLY USE AUTOMATIC DISHWASHER
DETERGENT, NOT SOAP OR LAUNDRY DETERGENT.
NEVER USE SOLVENTS AS THIS COULD RESULT IN AN
EXPLOSION!
CHILD SAFETY
• DO NOT ABUSE OR FORCE THE
DISHWASHER. DO NOT SIT ON OR STAND
ON ITS DOOR OR DISH RACKS – TIPPING
HAZARD.
• KEEP CHILDREN AWAY FROM DETERGENT,
RINSE AID AND THE OPEN DOOR OF THE
DISHWASHER AS THERE COULD BE
DETERGENT LEFT INSIDE.
• SUPERVISE YOUNG CHILDREN TO ENSURE
THEY DO NOT PLAY WITH THE APPLIANCE.
• SUPERVISE INFIRM PERSONS IF THEY MUST
USE THE APPLIANCE.
• REMOVE THE DOOR TO WASHING
COMPARTMENT OF YOUR OLD APPLIANCE
BEFORE DISCARDING IT.
DURING USE
• DO NOT TOUCH THE HEATING ELEMENT
DURING OR IMMEDIATELY AFTER USE.
• DO NOT USE YOUR DISHWASHER UNLESS
ALL ENCLOSURE PANELS ARE PROPERLY
IN PLACE. OPEN THE DOOR VERY
CAREFULLY IF THE DISHWASHER IS
OPERATING. THERE IS A RISK OF WATER
SQUIRTING OUT.
AFTER USE
• ALWAYS KEEP THE DOOR CLOSED TO AVOID DANGER
OF TRIPPING.
• CHECK THAT THE DETERGENT DISPENSER IS EMPTY
AFTER COMPLETION OF WASH CYCLE.
• IF LEAVING UNUSED FOR A LONG TIME,
DISCONNECT THE WATER SUPPLY (SEE PP. 17, 25).
3
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY BEFORE
USING YOUR DISHWASHER FOR THE FIRST TIME!

BAUMATIC BFD62W dishwasher user manual 4
CONTROL PANEL
STOP
STOP
STOP
14 5 6 23
87
1 Power On light: Comes on when the ‘ON / OFF’ Button is pressed down.
2 Rinse Aid Warning Light: Comes on when the rinse aid needs refilling.
3 Salt Warning Light: Comes on when the softener needs refilling.
4 ON / OFF Button: Turns the power supply ‘ON / OFF’.
5 Rapid Button: Only used with cycle ‘ ’ .
6 Plus Button: Only used with cycle ‘ ’.
7 Door Handle: Pull it to open the door.
8 Washing Program Selector: Turn the knob clockwise to select wash cycles.
DISHWASHER FEATURES
1 ADJUSTABLE UPPER BASKET
2 SPRAY ARMS
3 LOWER BASKET
4 WATER SOFTENER
5 MAIN FILTER
6 DETERGENT DISPENSER
7 CUP & GLASS SHELF
(ADJUSTABLE)
8 CUTLERY BASKET
9 COARSE FILTER
10 RINSE AID DISPENSER
11 DRAIN PIPE CONNECTOR
4
12 INLET PIPE CONNECTOR

BAUMATIC BFD62W dishwasher user manual 5
Note on chemicals used by the dishwasher
• Your dishwasher is equipped with an adjustable rinse aid and salt container. Using individual detergents,
rinse aid and salt will give the best possible results as this will give the correct dosage of each chemical to
suit your needs. Using Two-in-One or Three-in-One tablets may not give the best results when used in
your appliance, and may not be suitable for the type of water supply in your home, as they contain pre-
determined quantities of salt, rinse aid and detergent and cannot be adjusted to the individual
requirements.
If you are going to use 3-in-1 (or 2-in-1) tablets, we suggest that you contact the manufacturer before use
or if you experience poor results in the wash performance and ask for assistance from them.
WATER
SOFTENING
FEATURE
THE LIME IN HARD WATER MAKES DEPOSITS FORM ON
DISHES AND UTENSILS. YOUR DISHWASHER HAS A
SPECIAL SOFTENING FEATURE THAT USES SALT
SPECIFICALLY DESIGNED TO ELIMINATE LIME AND
MINERALS FROM THE WATER.
WARNING!
ONLY USE DISHWASHER SALT IN YOUR
DISHWASHER.
NOTE:
IF YOU USE 3-IN-1 OR 2-IN-1 TABLETS, BE
SURE NOT TO ADD SALT AND/OR RINSE AID
TO THE APPLIANCE AS THESE TABLET
TYPES ALREADY CONTAIN SALT AND/OR
RINSE AID. ADDING SALT AND RINSE AID
TO YOUR DISHWASHER’S COMPARTMENTS
IN A CYCLE INVOLVING A 3-IN-1 OR 2-IN-1
TABLET WILL RESULT IN OVERDOSING OF
INDIVIDUAL CHEMICALS AND MAY CAUSE
OVERFLOWING OF WATER AND SUDS.
LOADING SALT INTO THE SALT CONTAINER
• REMOVE THE LOWER BASKET & THEN
UNSCREW AND REMOVE THE CAP
FROM THE SALT CONTAINER.
• IF YOU ARE FILLING THE CONTAINER
FOR THE FIRST TIME, FILL WITH
APPROX. 1 LITRE OF WATER.
• PLACE THE END OF THE SUPPLIED
FUNNEL INTO THE HOLE & ADD 1.2 Kg
OF SALT. NOTE: IT IS NORMAL FOR A
SMALL AMOUNT OF WATER TO COME
OUT OF THE CONTAINER.
5

BAUMATIC BFD62W dishwasher user manual 6
SETTING THE WATER SOFTENER LEVEL
YOU CAN ADJUST THE AMOUNT OF SALT USED BY THE DISHWASHER TO SOFTEN WATER TO GET
THE BEST WASHING RESULTS, BASED ON THE HARDNESS OF WATER IN YOUR AREA.
1 UNSCREW THE CAP FROM THE SALT
CONTAINER.
2 THERE IS A RING ON THE NECK OF THE
CONTAINER. ROTATE THE RING IN AN
ANTICLOCKWISE DIRECTION FROM THE “-”
SETTING TOWARDS THE “+” SETTING
ACCORDING TO THE HARDNESS OF WATER
IN USE. SEE TABLE BELOW.
NOTE
1. THE SALT CONTAINER MUST BE REFILLED WHEN THE
SALT WARNING LIGHT COMES ON. ALTHOUGH THE
SALT CONTAINER MAY BE FULL, THE INDICATOR LIGHT
MAY NOT GO OUT UNTIL THE SALT HAS DISSOLVED.
2. IF THERE ARE SALT SPILLS, A SOAK PROGRAM CAN
BE RUN TO WASH AWAY SPILLAGE BEFORE USING THE
MACHINE.
3. CLEAR ANY SALT GRANULES AWAY FROM THE
CONTAINER OPENING.
ADJUSTMENTS SHOULD BE MADE ACCORDING TO THE TABLE BELOW:
WATER H ARDNESS
Clarke Degrees dH mmol /l Sel e ct or Po siti o n Salt consum ption
(gra m/cycle)
Au to nomy
(cycles/1.2kgs)
0~14 0~18 0~ 1. 8 /0/
14~36 18~44 1.8~4.4 -20 60
36~71 44~89 4. 4~8.9 MED 40 30
71 89 8. 9 +60 20
Contact your local water board for information on the hardness of your water supply.
DETERGENT “How much do I use?”
To OPEN the DETERGENT DISPENSER DOOR, use the CATCH on its LOWER SIDE.
*NOTE: SEE P.13 – WASH CYCLE TABLE for AMOUNT of DETERGENT to use.
NOTE:
• ALWAYS CHECK THE WASH CYCLE TABLE
FOR DOSAGE ADVICE. NEVER OVERFILL
THE DISPENSER.
• DO NOT OVERDOSE TO PREVENT THE
FORMATION OF DEPOSITS (THE WATER
SOFTENING FEATURE ALREADY TAKES CARE
OF THIS!).
THE HARDER YOUR WATER, THE MORE DETERGENT
YOU MAY NEED. ADJUST THE DOSE JUST BY SMALL
AMOUNTS UNTIL YOU FIND THE CORRECT AMOUNT
OF DETERGENT TO USE.
6

BAUMATIC BFD62W dishwasher user manual 7
RINSE AID
• TO OPEN THE DISPENSER, TURN THE CAP TO
THE ‘OPEN’ (LEFT) ARROW AND LIFT IT OUT.
• POUR THE RINSE AID INTO THE DISPENSER.
BE CAREFUL NOT TO OVERFILL.
• REPLACE CAP BY INSERTING IT ALIGNED WITH
‘OPEN’ ARROW & TURN IT TO THE CLOSED
(RIGHT) ARROW.
• THE RINSE AID IS RELEASED DURING THE
FINAL RINSE TO PREVENT WATER FROM
FORMING DROPLETS ON YOUR DISHES
THAT CAN CAUSE SPOTS AND STREAKS. IT
ALSO IMPROVES DRYING BY ALLOWING
WATER TO FALL OFF THE DISHES.
• YOUR DISHWASHER IS DESIGNED TO USE
LIQUID RINSE AIDS. THE RINSE AID
DISPENSER CAN BE FOUND INSIDE THE
DOOR NEXT TO THE DETERGENT
DISPENSER. TO FILL THE DISPENSER, OPEN
THE CAP AND POUR THE RINSE AID INTO
THE DISPENSER UNTIL THE LEVEL
INDICATOR TURNS COMPLETELY BLACK.
THE DISPENSER HOLDS ABOUT 100ML OF
LIQUID RINSE AID.
• BE CAREFUL NOT TO OVERFILL THE
DISPENSER – THIS COULD CAUSE
FROTHING. WIPE AWAY SPILLS WITH A
DAMP CLOTH. DON’T FORGET TO REPLACE
THE CAP BEFORE YOU CLOSE THE
DISHWASHER DOOR.
NOTE: IF YOU HAVE SOFT WATER, YOU MAY NOT
NEED RINSE AID FOR IT MAY CAUSE A WHITE FILM
TO DEVELOP ON YOUR DISHES.
ADJUSTING THE RINSE AID DISPENSER
•
As with detergent, the amount of rinse
aid needed for your dishes depends on
the hardness of the water in your area.
Too much rinse aid can result in
foaming and cause cloudiness or
streaks on your dishes.If your water
is very soft, you may not need rinse
aid. You can always dilute the rinse
aid with an equal amount of water.
The rinse aid dispenser has six settings. ALWAYS START WITH THE DISPENSER SET ON “1”. IF SPOTS & POOR
DRYING ARE A PROBLEM, INCREASE THE AMOUNT OF RINSE AID DISPENSED BY REMOVING THE DISPENSER
LID AND ROTATING THE DIAL TO “2”. IF THE DISHES ARE STILL NOT DRYING PROPERLY OR ARE SPOTTED,
ADJUST THE DIAL TO THE NEXT HIGHER NUMBER UNTIL YOUR DISHES ARE SPOT-FREE.
***NOTE: Please read the notes for detergent use on p. 13.
WHEN TO REFILL THE RINSE
AID DISPENSER - If the rinse aid
warning light (SEE control panel) is not on, you
can judge the rinse aid level by looking at the
black dot on the rinse aid dispenser. As the
rinse aid level decreases, the black dot shrinks.
Never let the rinse aid get below ¼ full.
7
As the rinse aid diminishes, the size of the black dot on the rinse
aid level indicator changes, as illustrated below.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty

BAUMATIC BFD62W dishwasher user manual
8
8
LOADING
YOUR
DISHWASHER
NOTE:
FOR BEST PERFORMANCE, FOLLOW THESE
LOADING GUIDELINES. FEATURES AND
APPEARANCE OF RACKS & CUTLERY
BASKETS MAY VARY FROM YOUR MODEL.
BEFORE LOADING!
• REMOVE ALL SCRAPS OF FOOD.
• EMPTY DRINKS & LIQUIDS FROM CUPS.
• SOFTEN BURNT-ON FOOD IN PANS BY SOAKING.
DO NOT PUT THESE ITEMS IN YOUR DISHWASHER:
• BRONZE
CUTLERY
• SAUCEPANS
WITH
WOODEN
HANDLES
• CUTLERY
WITH
WOODEN,
HORN, CHINA
OR MOTHER
OF PEARL
HANDLES
• PLASTIC
ITEMS THAT
ARE NOT HEAT
RESISTANT
• OLDER
CUTLERY
WITH GLUED
PARTS
• BONDED
CUTLERY
ITEMS OR
DISHES
• PEWTER OR
COPPER ITEMS
• LEAD CRYSTAL
GLASS
• STEEL ITEMS
SUBJECT TO
RUSTING
• WOODEN
PLATTERS
• ITEMS MADE
FROM
SYNTHETIC
FIBRES (eg.
SPONGES)
• DELICATE,
REPAIRED OR
PAINT /
PATTERN
OVERLAID
CHINA

BAUMATIC BFD62W dishwasher user manual 9
Note:
Do not wash stainless steel and silver cutlery together. Iron objects can rust
and stain other items. Aluminium tends to go black. Copper, pewter & brass
stain.
HOW TO USE THE UPPER RACK
THE UPPER RACK IS FOR MORE DELICATE
AND LIGHTER DISHWARE SUCH AS
GLASSES, COFFEE & TEA CUPS, SAUCERS,
PLATES, BOWLS, AND SHALLOW PANS
(PROVIDED THESE ARE NOT TOO DIRTY).
POSITION THE DISHES AND
COOKWARE SO THAT THEY DO NOT
GET MOVED BY THE SPRAY OF
WATER. ALWAYS PLACE GLASSES,
CUPS & BOWLS UPSIDE DOWN.
NOTE:
YOUR DISHWASHER COMES WITH AN
ADJUSTABLE TOP RACK (BASKET) –
PICTURED AT RIGHT. ITS HEIGHT CAN
BE ADJUSTED BY UNDOING THE FRONT
RAIL CLIPS, REMOVING THE RACK
COMPLETELY AND LATCHING THE
WHEELS OF THE LOWER LEVEL
(POSITION ‘1’ IN THE FIGURE ON THE RIGHT)
OR THE HIGHER LEVEL (POSITION ‘2’ IN
THE FIGURE ON THE RIGHT) IN THE GROOVE
OF THE RAIL.
1
LOADING GUIDE (UPPER RACK):
9
2

BAUMATIC BFD62W dishwasher user manual 10
***NOTE***: THE UPPER RACK HAS
SIDE FLAPS (PICTURED AT LEFT ABOVE BASKET).
THERE ARE 4 (2 ON EACH SIDE).
THESE CAN BE ADJUSTED INTO 2
POSITIONS = POSITION 1 (HIGH)
AND POSITION 2 (LOW).
TO MOVE THE FLAPS BETWEEN THESE
POSITIONS, FIND THE LARGE HINGES
CLASPING EACH FLAP TO THE UPPER
RACK. THERE ARE TWO OF THESE AT
EITHER END OF EACH FLAP. GENTLY PULL
BOTH CLASPS OFF THE WIRE RACK AND
MOVE THE FLAP TO THE DESIRED
POSITION. BE CAREFUL IF YOU HAVE
LONG FINGERNAILS!
POSITION 1
THE UPPER POSITION WILL ACCOMMODATE ITEMS SUCH AS GLASS TUMBLERS
(PLACED BENEATH FLAP) AND WINE GLASSES. WINE GLASSES CAN BE PLACED
UPSIDE DOWN SO THAT THE NECK NESTLES SNUGLY IN THE GROOVES AT SIDE OF
FLAP WITH THE BASE OF THE GLASS FACING UPWARD.
POSITION 2
WHEN THE FLAPS ARE MOVED TO THE LOWER POSITION, THEY CAN BE USED TO
HOLD ADDITIONAL TUMBLERS, CUPS AND MUGS. ALWAYS CHECK THAT YOU ARE
ONLY PLACING ITEMS ON THE FLAPS THAT WILL CLEAR THE CEILING HEIGHT OF
YOUR DISHWASHER WHEN YOU PUSH THE RACK BACK IN. BE PARTICULARLY
CAREFUL WITH LONG-STEMMED GLASSWARE SUCH AS CHAMPAGNE GLASSES –
BREAKAGE HAZARD!
HOW TO LOAD THE LOWER RACK:
PLACE LARGE ITEMS THAT ARE HARD TO CLEAN IN THE LOWER RACK: eg. POTS, PANS,
LIDS, SERVING DISHES, BOWLS.
• POTS, SERVING BOWLS, ETC. MUST ALWAYS BE PLACED UPSIDE DOWN.
• DEEP POTS SHOULD BE SLANTED TO LET WATER FLOW OUT.
10
• THE BOTTOM RACK FEATURES FOLD DOWN BASKETS SO THAT LARGER OR MORE POTS
& PANS CAN BE LOADED.

BAUMATIC BFD62W dishwasher user manual 11
CUTLERY BASKET
CUTLERY SHOULD BE PLACED IN THE CUTLERY BASKET WITH HANDLES ALWAYS POINTING
DOWNWARD (AT THE BOTTOM). VERY LONG UTENSILS (LADLES, etc.) SHOULD BE PLACED
HORIZONTALLY AT THE FRONT OF THE UPPER RACK.
NOTE:
• WHEN YOU ARE SATISFIED YOU HAVE LOADED ALL THE UTENSILS
AND DISHES YOU WANT TO WASH AND HAVE ADDED THE PROPER
AMOUNT OF DETERGENT TO THE DISPENSER (REMEMBER TO CHECK THE
TABLE ON PAGE 13 FOR THE DOSE THAT’S RIGHT FOR THE WASHING CYCLE YOU
WANT), ENSURE THE RACKS ARE PUSHED ALL THE WAY BACK INTO
YOUR DISHWASHER AND CLOSE THE DOOR.
• YOU ARE NOW READY TO START A WASH CYCLE (SEE NEXT PAGE).
11
1
Forks
2
Soup Spoons
3
Dessert Spoons
4
Teaspoons
5
Knives
6 Serving Spoons
7 Gravy Ladle
8 Serving Fork

BAUMATIC BFD62W dishwasher user manual
12
12
STARTING A WASH CYCLE
STOP
STOP
STOP
14 5 6 23
87
1) MAKE SURE THAT THE PLUG OF THE APPLIANCE IS INSERTED INTO THE WALL
SOCKET.
2) MAKE SURE THAT THE WATER SUPPLY IS TURNED ON TO FULL PRESSURE.
3) LOAD THE DISHWASHER (SEE THE SECTION ENTITLED ‘LOADING YOUR
DISHWASHER’).
4) POUR IN DETERGENT (SEE THE SECTION ENTITLED ‘SALT, DETERGENT & RINSE
AID’).
5) ENSURE THE DOOR IS CLOSED (IT WILL MAKE A ‘CLICKING’ SOUND).
6) TURN THE KNOB LOCATED ON THE RIGHT OF THE CONTROL PANEL CLOCKWISE
UNTIL IT POINTS TO THE SYMBOL FOR THE CYCLE SETTING YOU WANT (SEE
THE ‘WASH CYCLE TABLE’ ON PAGE 13).
7) PRESS THE ON/OFF BUTTON – THE ON/OFF LIGHT WILL TURN ON. AT THIS
POINT, THE WASH CYCLE WILL BEGIN.
Approximate Timing of Wash Cycles
Intensive
(strong) 120
mins.
Normal
114
mins.
Economy
93
mins.
Rinse
80
mins.
Glass
53
mins.
Rapid
30
mins.
Soap
7
mins.

BAUMATIC BFD62W dishwasher user manual 13
For normally soiled loads,
such as , plates,glasses
and lightly soiled pans.
standard daily cycle.
pots
Pre-rinse
-rinse
Wash (52 ℃)
Rinse (70 ℃)
Drying
Pre
For the heaviest soiled loads,
such as pots,pans,casserole
dishes and dishes that have
been sitting with dried food
on them for a while.
For lightly soiled loads,such
as plates,glasses,bowls and
lightly soiled pans.
For dishes that need to be
rinsed and dried only.
For lightly soiled loads,
such as glasses, crystal and
fine china.
To rinse dishes that you
plan to wash later that day.
15 gr.
15 gr.
A shorter wash for lightly
soiled loads that do not
need drying.
Intensive
Rapid
Soak
5/22 gr.
5/22 gr.
22 gr.
Pre-rinse
-rinse( 2℃
Wash (60 ℃)
Rinse
Rinse (70 ℃)
Drying
Pre 5 )
Wash (52 ℃)
Rinse (70 ℃)
Drying
Rinse (70 ℃)
Drying
Wash (52 ℃)
Rinse (62 ℃)
Drying
Wash (52 ℃)
Rinse
Pre-rinse
Normal Wash
(IEC-EN 50242)
Normal Wash
Light Wash
Rinse
Glassware
Glassware
Soak
• PLUS BUTTON
Press this button to give a ‘SUPER’ Wash (on table as ‘INTENSIVE’ Wash) when you have to wash pots and
pans with dry, caked-on food (always soak extreme cases of burnt-on food, etc. first). Turn the knob to
‘NORMAL’ to begin this cycle. A SUPER CYCLE will start.
You should not use the PLUS BUTTON when washing delicate items. The high temperature used in this wash
could damage delicate items over time.
• RAPID BUTTON
Press this button to give a ‘QUICK’ Wash (on table as ‘RAPID’ Wash) when you want to wash items quickly.
This cycle uses a lower temperature (50°C) and has no drying phase.
OVERFLOW PROTECTION
YOUR BAUMATIC DISHWASHER HAS AN OVERFILL PROTECTION DEVICE WHICH AUTOMATICALLY SHUTS OFF
THE INLET VALVE AND STARTS THE DRAIN PUMP IF THE WATER OVERFLOWS. IF THIS OCCURS THEN TURN OFF
THE MAINS WATER SUPPLY BEFORE CALLING THE SERVICE DEPARTMENT. IF THERE IS WATER IN THE BASE
PAN BECAUSE OF AN OVERFILL OR SMALL LEAK, THE WATER SHOULD BE REMOVED BEFORE RESTARTING THE
DISHWASHER.
5 grams (pre)
/ 22 grams
(main)
22 grams
15 grams
15 grams
13
5 grams (pre)
/ 22 grams
(main)

BAUMATIC BFD62W dishwasher user manual 14
FORGET TO ADD A DISH?
A FORGOTTEN DISH CAN BE ADDED AT ANY TIME BEFORE THE DETERGENT
DISPENSER OPENS.
• OPEN THE DOOR A LITTLE TO STOP THE WASHING.
• WAIT ABOUT TEN SECONDS. AFTER THE SPRAY ARMS STOP WORKING,
YOU CAN OPEN THE DOOR COMPLETELY.
• ADD FORGOTTEN DISHES.
• CLOSE THE DOOR, THEN THE DISHWASHER WILL WORK.
14
NEED TO INTERRUPT A CYCLE?
If an emergency arises, you can stop the machine at any time by pressing the
ON/OFF button. Remember to wait approx. 10 seconds before you open the door
fully, as the spray arms continue to turn after the power has been cut and could spray
hot water up at you. DO NOT TURN THE KNOB AHEAD AS THIS WILL AFFECT
THE WASHING RESULT! YOU ALSO COULD JUST PULL THE DOOR OPEN – DO
NOT TOUCH ANY BUTTONS!
NOTE:
If you need to change a cycle, you can as long as the dishwasher has only been
running for a short time. Just press the ON/OFF button so the ON light goes out, turn
the knob to the setting you want then turn the dishwasher back on with the ON/OFF
button.
However, if it’s been a long time since the old cycle began, the detergent may have
already been released and the wash water drained out. You’ll need to start a new
cycle altogether so press the ‘ON/OFF’ button to switch the dishwasher off, wait until
the inside cools before you refill the detergent dispenser, close the door and then turn
the knob to the cycle setting you want before you turn your dishwasher back on.
TAKE CARE WHEN OPENING THE DOOR DURING
WASHING. THE HOT WATER MAY SCALD YOU!
AT THE END OF THE WASH CYCLE
When the knob stops turning and lines up with the STOP mark (see
figure), the cycle has finished. Turn the dishwasher off using the ON/OFF button
and open the door of the dishwasher. Wait a few minutes before unloading the
dishwasher so the dishes can cool down. This will make them less breakable and
allow them to dry better.

BAUMATIC BFD62W dishwasher user manual 15
FILTERING SYSTEM
FOR YOUR CONVENIENCE, WE HAVE PLACED THE FILTERING SYSTEM WITHIN EASY REACH INSIDE THE
TUB. THE FILTER REMOVES BITS OF FOOD TRAPPED IN THE FILTER FROM THE WASH WATER SO IT CAN BE
RECIRCULATED DURING THE CYCLE. THERE ARE THREE PARTS TO THE FILTERING SYSTEM: 1) The Main Filter,
2) The Coarse Filter & 3) The Fine Filter.
1MAIN FILTER
Food and soil particles trapped by this filter are
pulverized by a special jet on the lower spray arm and
washed down the drain.
2COARSE FILTER
Larger items, such as pieces of bone or glass that could
clog the drain are trapped in the coarse filter. To
remove an item caught in this filter, gently squeeze
the tabs on top of this filter and lift it out.
3FINE FILTER
This filter holds soil and food residue in the sump area
and prevents it from being re-deposited on the dishes
during a cycle.
Caring for your Dishwasher
CLEANING THE OUTSIDE SURFACES OF YOUR APPLIANCE
• TO CLEAN THE EXTERIOR OF YOUR DISHWASHER (INCLUDING THE CONTROL PANEL), USE A LIGHTLY
DAMPENED CLOTH THEN DRY THOROUGHLY. NEVER USE SHARP OBJECTS, SCOURING PADS OR
HARSH CLEANERS ON ANY PART OF THE APPLIANCE. SOME PAPER TOWELS CAN SCRATCH.
• TO CLEAN THE EDGE AROUND THE DOOR,
ONLY EVER USE A SOFT WARM, DAMP RAG.
DO NOT USE A SPRAY CLEANER HERE OR
WHEN CLEANING THE DOOR PANEL AS THIS
MAY HARM THE DOOR LOCK AND
ELECTRICAL PARTS.
15
CLEANING THE SPRAY ARMS
THE SPRAY ARMS NEED REGULAR CLEANING AS HARD WATER RESIDUES WILL CLOG THEIR
JETS & BEARINGS. TO REMOVE THE SPRAY ARM, SCREW OFF THE NUT TO TAKE OUT THE
WASHER ON TOP OF THE SPRAY ARM AND REMOVE THE ARM. WASH THE ARMS IN SOAPY
WARM WATER & USE A SOFT BRUSH TO CLEAN THE JETS. REPLACE THE SPRAY ARM AFTER
RINSING IT THOROUGHLY.

BAUMATIC BFD62W dishwasher user manual 16
CLEANING THE FILTERS
• THE FILTER ASSEMBLY MUST BE KEPT CLEAN FOR BEST PERFORMANCE. You should remove the
larger bits of food trapped in the filter after each wash cycle by rinsing the semicircular filter and
cup under running water. To remove the filter assembly, pull up on the cup handle.
• The entire filter assembly should be cleaned at least once a month.
• To clear the coarse filter and the fine filter, use a cleaning brush. Then, reassemble the filter parts
as shown in the figure above and reinsert the entire assembly in the dishwasher in its seat & press
downward to secure it.
• Improper replacement of the filter may impair appliance performance and damage dishes and
utensils.
• Warning - never run the dishwasher without the filters
in place!
• Warning - Before cleaning the inner cavity of the appliance
always allow 30 minutes for the Element to cool down to
avoid injury!
16

BAUMATIC BFD62W dishwasher user manual 17
HOW TO KEEP YOUR DISHWASHER IN SHAPE
AFTER EVERY WASH,leave the door slightly ajar so that moisture and odours are not trapped
inside.
REMOVE THE PLUG before cleaning or performing maintenance. Never run the risk of electric
shocks.
DO NOT USE SOLVENTS OR ABRASIVE CLEANING AGENTS to clean the exterior and the rubber
parts of the dishwasher. Only use a cloth and warm soapy water. To remove spots or stains
from the surface of the interior, use a cloth dampened with water and a little white vinegar,
or a cleaning product made specifically for dishwashers.
WHEN YOU GO ON HOLIDAY, run a wash cycle with the dishwasher empty. Then unplug it, turn
off the water supply and leave the door slightly ajar to prevent odours and mould from
developing.
MOVING THE APPLIANCE is possible but KEEP IT UPRIGHT.
SEALS can trap food, which in turn will cause odours. Periodic cleaning with a damp cloth or
sponge will prevent this from becoming a problem.
PROTECTING YOUR DISHWASHER AGAINST FREEZING
If your dishwasher is left in an unheated place during the winter, ask a
service technician to:
1) Cut off electrical power to the dishwasher. Remove fuses or trip circuit
breaker.
2) Turn off the water supply and disconnect the water inlet pipe from the water
valve & discharge hoses.
3) Drain water from the inlet pipe and water valve (Use a pan to catch the
water).
4) Reconnect the water inlet pipe to the water valve.
5) Remove the plastic sump cover in the tub bottom and use a sponge to soak
up water in the rubber boot.
17

BAUMATIC BFD62W dishwasher user manual 18
BEFORE YOU CALL FOR SERVICE …
CHECKING AGAINST THE CHARTS BELOW MAY FIX YOUR PROBLEM.
18
PROBLEM POSSIBLE CAUSES WHAT TO DO
• Fuse blown, or the
circuit breaker acted
• Replace fuse or reset circuit
breaker.
• Remove any other appliances
feeding from the same socket as
the dishwasher.
• Power supply is not
turned on • Make sure the dishwasher is turned on and the door is closed securely.
Dishwasher
doesn’t run!
• Water pressure is low • Check that the water supply is connected properly and the water is
turned on.
Drain Pump
doesn’t stop! • Overflow
• The system is designed to detect an
overflow. When it does, it shuts off
the circulation pump and turns on
the drain pump. Call a Baumatic
Ltd approved technician.
• Some audible sounds
are normal
• Sound from soft food shredding
action and detergent cup opening.
This is not a problem.
• Utensils are not secure
in the baskets or
something small has
dropped into the
basket and is loose
• Ensure everything is placed
securely in the dishwasher.
Noise!
• Motor Hums
• Dishwasher has not been used
regularly. If you do not use it
often, remember to set it to fill and
pump out every week. (See Wash
Cycle table). This will help keep the
seal moist.

BAUMATIC BFD62W dishwasher user manual 19
19
PROBLEM POSSIBLE CAUSES WHAT TO DO
Suds in the Tub! • Improper detergent • Use only special dishwasher
detergent to avoid suds.
• Spilled rinse agent • Always wipe up rinse agent spills
immediately.
Stained tub
Interior!
• Detergent with
colorant was used • Make sure you use detergent without colorant.
Dishes are not
dried! • Rinse agent dispenser
is empty • Make sure that the rinse agent dispenser is filled.
Dishes and
Flatware not
Clean!
• Improper program • Select stronger program.
• Improper rack loading • Make sure there are no large dishes blocking the action of the detergent
dispenser and the spray arms.
Spots and Filming
on Glasses and
Flatware!
• Extremely hard water
• Low inlet temperature
• Overloading the
dishwasher
• Improper loading
• Old or damp powder
detergent
• Empty rinse agent
dispenser
• Incorrect dosage of
detergent
To remove spots from glassware:
1. Take all metal utensils out of the
dishwasher.
2. Do not add detergent.
3. Choose the longest cycle.
4. Start the dishwasher and let it to run for
18 - 22 minutes, then it will be in the main
wash.
5. Open the door and pour 2 cups of white
vinegar into the bottom of the dishwasher.
6. Close the door and let the dishwasher
complete the cycle.
7. If the vinegar does not work, repeat as
above, only use ¼ cup (60ml) of citric acid
crystals instead of vinegar.

BAUMATIC BFD62W dishwasher user manual 20
20
PROBLEM POSSIBLE CAUSES WHAT TO DO
Cloudiness on
glass!
• Combination of soft
water and too much
detergent
• Use less detergent if you have soft
water and select a shorter cycle to
clean the glassware.
Yellow or brown
film on inside
surfaces!
• Tea or coffee stains
• Use a solution of ½ cup of bleach
and 3 cups warm water to remove
the stains by hand. Rinse
thoroughly.
White film on
inside surface!
• Iron deposits in water
can cause an overall
film
• You have to call a water softener
company for a special filter.
• Hard water minerals
• To clean the interior, use a damp
sponge with dishwasher detergent
and wear rubber gloves. Never use
any other cleaner than dishwasher
detergent for the risk of foaming or
suds.
Detergent cup lid
won’t latch!
• Button is not in the
‘OFF’ position • Turn the Button to ‘OFF’ position and slide the door latch to the left.
Detergent left in
dispenser cups! • Dishes block detergent
cups • Reload the dishes properly.
Steam! • Normal phenomenon • There is some steam coming
through the vent by the door latch
during drying and water draining.
