Baumatic BCD70 User manual

BCD70
Condenser Dryer

USER MANUAL FOR YOUR BAUMATIC
BCD70
60 cm 7 kg
Condenser Dryer
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
GS 05/04/11
2

3

4
Contents
Environmentalnote 5
Important safety information 6 – 8
Specifications 9–11
Product dimensions 9
Product specifications 9
Description of the appliance 10
Controlpanel 11
Preparing the drying cycle 12 - 14
Preparing your garments for drying 12 - 13
Program tables 13 - 14
Drying programme guidance 15 – 16
Themoisturesensor 15
Thedrumlight 15
Consumption values 15
Childsafetylock 15-16
Selecting a drying programme 16 - 17
The ANTI-CREASE option 16
TheGENTLEoption 17
Additional drying time adjustment option 17
Thedelaystart 17
Maintenance and cleaning 18 – 20
Control panel and machine cabinet 18
Thelintfilter 18
The container drawer 18
Thedryerdrum 19
Door 19
Cleaning the wash air condenser 19 - 20
Installation 20 – 21
Locating your condenser dryer 20 - 21
Powersupply 21
Before first use maintenance cycle 21 - 22
Error code failure system 22 - 23
General troubleshooting 23
Contactdetails 24

Environmental Concerns
To help look after the environment and save energy, we recommend
that you follow some of the following helpful suggestions:
oOnly dry full loads of washing.
oMake sure you select the correct drying program to ensure that
you are not consuming incorrect levels of energy.
oRegular maintenance of appliance i.e. cleaning filters will
regulate the electricity consumption.
5

Important safety information
Your safety is of the utmost importance to
Baumatic. Please make sure that you read this
instruction booklet before attempting to install or
use the appliance. We recommend that you keep
this instruction book for future reference and pass
it on to any future owners. If you are unsure of any
of the information contained in this booklet, please
contact the Customer Care Department on 1800 444 357.
General Safety
oRepairs to your appliance must only be carried out by an
authorised service agent. Any attempt by an inexperienced
person to repair the appliance, could result in injury or damage
to your condenser dryer.
oIf you notice that the mains cable is damaged. The appliance
must not be used. The same applies if you notice that the
worktop, control panel or base area is damaged. As this could
allow access to the internal components of the machine.
oThe appliance should be turned off and isolated from the mains
supply, before either cleaning or maintenance work is attempted.
oThe mains cable must not be used to pull the plug out of the
electrical socket.
oThe machine should not be sprayed with water.
oThe glass of the porthole door may become hot during a drying
program.
oThe machine should be allowed to cool before removing the lint
filter.
oIt is possible for small animals to chew either the mains cable or
water hoses, which could cause an electric shock hazard.
Installation
oThis appliance is heavy so care should be taken when moving it.
oCare must be taken to make sure that the appliance does not
stand on the electrical supply cable.
6

7
oThe installation instructions contained within this user manual
should be followed.
oIt is obligatory for the completed installation to comply with all
relevant building regulations and local water authority
requirements.
During Use
oIt is recommended that the appliance is unplugged after the
machine is used.
oThis appliance is only designed to dry normal domestic
washloads. If you use your condenser dryer in any other way or
it is incorrectly used, then Baumatic accepts no liability for any
damage that might be caused and any guarantee will be void.
oNo attempt should be made to alter or modify the specifications
of this appliance.
oYou should not dry garments that have been in contact with
flammable materials (e.g. petrol, methylated spirits, dry cleaning
fluid etc…).
oOil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in condenser dryers. Fabrics
that contain vegetable or cooking oil should be washed in hot
water with an extra amount of detergent before being dried in
the condenser dryer.
oYour condenser dryer should not be used for dry cleaning.
oOnly dry fabrics which have been designed to be machine dried.
Follow the instructions on each garment.
oDo not dry unwashed items in the condenser dryer.
oClothes which are soaking wet should not be placed in the dryer.
oFabric softeners or similar products should be used as specified
by the fabric softener instructions.
oIf you use either dyes or bleaching agents inside this machine,
then you should consult with the manufacturer of these products
to make sure they are suitable for use in your machine.
Baumatic cannot be held responsible for any damage that may
result.

oIf you have washed your laundry with stain remover you must
execute an extra rinse before loading your condenser dryer.
Never stop a condenser dryer before the end of
the drying cycle unless all items are quickly
removed and spread out so that the heat is
dissipated.
Child Safety
oYour condenser dryer should only be used by adults. You should
not allow children in the area of the machine unsupervised. You
should not let them touch the controls or play with the appliance.
oIt could be possible for a child or pet to gain access to the
tumble dryer through the porthole door. Therefore please check
the drum before using the appliance.
oAny packaging that is removed from the machine should be kept
away from children.
oKeep all detergents in a safe place out of children’s reach.
8

Specifications
Product dimensions
Height: 855 mm
Width: 595 mm
Depth: 565 mm / 1030 mm (door open)
Product specifications
oEnergy efficiency class: B
o11 drying programmes
o7 kg dry load capacity
o112 litre drum size
o350 mm porthole diameter
o180° door opening
oLED display
oDelay start
oFailure detection system
oMoisture sensor
oSafety lock
oDrying time selector
oRemovable lint filter
oAnti-crease function
oAdjustable feet
9

For future reference please record the following information which can
be found on the rating plate and the date of purchase which can be
found on your sales invoice. The rating plate for your condenser dryer
will be located behind the porthole door.
Model Number ……………………………….
Serial Number ……………………………….
Date of Purchase ……………………………….
Description of the appliance
10

Control panel
1) START / PAUSE button
2) Drying programme selector knob
3) GENTLE programme option button
4) ANTI-CREASE programme option button
5) Empty container indicator
6) Delay start / light control button
7) Programme status indicator
8) Clean filter indicator
9) Time adjustment buttons
10) Delay time or time remaining display
11) Safety lock indicator
11

Preparing the drying cycle
Preparing your garments for drying
oFor optimum drying performance, sort the laundry according to
fabric type, drying programme and the wash care symbol that is
printed on the garment’s wash care label.
oBefore drying, thoroughly spin the laundry in a washing machine
if possible to reduce the drying time and save energy.
oCheck all pockets on a garment to make sure that they are
empty.
oRemove any detachable metal items (badges,
paperclips, safety pins etc).
oZips should be closed, duvet covers and
pillow cases should be buttoned up and any loose straps should
be tied up. This will help to prevent other garments from getting
damaged during the drying cycle.
oDo not dry the clothes for longer than necessary to avoid creases
or shrinkage.
oDO NOT dry items containing rubber or similar elastic materials,
raincoats, bicycle covers or feather products.
oDO NOT dry clothes which have been dry-cleaned.
oIn order to avoid danger of fire caused by excessive drying, DO
NOT use the appliance to dry items such as cushions and quilts
as these items accumulate heat.
oEnsure the lint filter and container are emptied and cleaned after
each use to avoid the extension of drying time and energy use.

oDo not exceed the maximum load capacity or the machine will
fail to dry the clothes efficiently. You should refer to the program
tables for the maximum load size for each program and the
weight references below before starting a cycle. Please note that
all weights are approximate.
Program tables
General clothing:
Programme
MAX
weight
T-
Shirt Shirts
Trousers* Skirts/
dresses
Sports-
wear Work clothes
Anoraks
For cottons and coloured made of cotton or linen.
Light
Standard
Iron
Cotton
Extra
7.0 kg
For non-iron washing made of synthetic and blended fabrics, cotton.
Light
Standard
Synthetics
Extra
3.5 kg
13

14
ther clothing: O
Programme weight
MAX Toweling
Under-
wear Socks
Bed
linen linen Towels*
Table Terry Tea
bathrobe
Towels/
Hand
towels
For cottons and colo of cotton orured made linen.
Light
Standard
Iron
Cotton 7.0 kg
Extra
For non-iron wa hing ade of synt an rics, c tton.s m hetic d blended fab o
Light
Standard
Synthetics
Extra
3.5 kg
Delicate 3.0 kg For machine-washable woollen textiles. Textiles are fluffier, but not
dried. Remove and hang up textiles when the programme ends.
Quick 3.0 kg For washing which is to be dried quickly e.g. made of acrylic fibres or
for individual small items. Also for subsequent drying.
Wa
(40min/20 n 3.0 kg For the timer programme, delicate textiles made of acrylic fibres orrm / Cool mi ) small items.
* Some jeans and large towels are difficult to dry due to the
absorbent nature of the materials. If you find they are still wet
after a drying programme, you should use the WARM
rogramme to dry them again.p

15
rying programme guidanceD
The moisture sensor
oThis feature senses the moisture content of the clothes and will
automatically adjust the time of the drying programme
g the drying
ight
to help you to see clearly when
me.
Press the button again to turn the light back off.
d under normal conditions. Fluctuations up to 10% are
Programme Weight
(kg) (approx) (mins, with
cooling
time)
consumption
(kWh)
accordingly to ensure optimum performance and energy usage.
oThe moisture sensor will automatically activate durin
cycle except on the WARM and COOL programmes.
The drum light
oFor your convenience, the condenser dryer features a drum l
you open the machine door.
oThe drum light can also be activated by pressing the
light control button (6) during the drying program
Consumption values
oThe values shown in the table below are approximate and
determine
possible.
Residual
humidity Drying time
10min
Energy
50% 135 3.7
60% 155 4.3
Cotton
(standard) 70% 175 5.0
50% 125 3.6
60% 145 3.8
Cotton
(iron)
7.0
1 70% 50 4.2
40% 60 1.2Synthetics 3.5 50% 70 1.6
Child safety lock oThe condenser dryer has a safety lock
feature which can prevent accidental
operation of buttons by children.
oTo activate the safety lock, press the delay start/light
control button and the ANTI-CREASE option button

16
ll light
on the display and all buttons will be inoperable.
ppear from the display and the buttons will be
operable again.
Selecting a drying programme
simultaneously for about 3 seconds. The child lock icon wi
oRepeat this procedure to deactivate the safety lock. The child
lock icon will disa
oLoad the clothes to be dried
into the condenser dryer drum
and close the door.
programme for the clothes you
are drying.
such as GENTLE or ANTI-
CREASE then press the relevant button.
status indicator (7) will show the
drying cycle progress.
plug the appliance before removing your laundry
from the drum.
cleaned and the container drawer emptied
after each programme.
The ANTI-CREASE option
tiles. The drum will
intermittently rotate during the cycle.
ill light above
the ANTI-CREASE programme option button (4).
oRotate the drying programme
selector knob (2) to set the
required program. You should
refer to the Program tables to
select the appropriate
oIf you wish to add a programme option,
oPress the START/PAUSE button (1) to begin the drying
cycle. The programme
oAt the end of the drying programme a buzzer will sound.
You should rotate the programme selector knob (2) to the OFF
position and un
oThe lint filter should be
oThis function can be used to minimize creasing when
drying sensitive tex
oWhen this option is selected, the anti-crease LED w

17
The GENTLE option
ying temperature to protect the items from high
heat.
LED will light above the
GENTLE programme option button (3).
dditional drying time adjustment option
u press
the START/PAUSE button (1) to begin the drying cycle.
is
feature is only available on the WARM and COOL programmes.
he delay start option
e to delay the start of the drying programme by up to
24 hours.
T/PAUSE button (1) press the delay start button
(6).
the display will show the when
the programme is due to begin.
the machine will begin the drying
programme automatically.
oThis function is ideal for sensitive textiles as it lowers
the dr
oWhen this option is selected, the gentle
A
oThis function allows you to set the length
of drying time. The time can be adjusted
from 20 to 40 minutes using the time
adjustment buttons (9) before yo
oAdjusting the drying time is useful for a drying load of a few
small items such as a face cloth or two pairs of socks. Th
T
oIt is possibl
oOnce you have loaded your laundry into the drum and
selected the required drying programme, including any
programme options, instead of pressing the
STAR
oEach press of this button will delay the start of the programme
by 1 hour. When the display shows the correct delay time, press
the START/PAUSE button (1) and
oOnce this time is reached,

18
aintenance and cleaningM
IMPORTANT: The appliance should be disconnected from the
power supply and allowed to cool before commencing any
either the
new damp cloth with warm
water.
. Therefore the lint filter should be
f the porthole opening. Pull the filter
off the scrap threads and fluff
ated on it.
erate the condenser dryer without
dryer, some water will be
e
res of water can be held in the container drawer.
cleaning process.
Control panel and machine cabinet.
IMPORTANT: Do not use any abrasive
cleaner or household polish on
control panel or operating parts.
oWipe over the control panel and the
external surface of the machine using a
brand
The lint filter
oThe fluff and debris which accumulates on the filter will block the
air circulation which will cause the drying time and energy
consumption to increase
cleaned after each use.
oTo remove the filter, open the condenser dryer door and locate
the filter at the base o
upwards to take it out.
oClean the lint filter by wiping
which have accumul
oReinstall the filter.
oIMPORTANT: NEVER op
the lint filter in place.
The container drawer
oAs this appliance is a condenser
utilised during the drying process.
oThis water will be collected in the container drawer next to the
control panel. It should be emptied and cleaned after each use.
oTo remove the container drawer pull it gently away from the
machine. Extra care should be taken to avoid any water spillag
as up to 5 lit

19
he dryer drum
ed inside the drum, then
n/steel wool or
couring agents to clean the drum of your appliance.
the drum with an appropriate
stainless steel cleaning agent.
oor
er
door gasket. This sits inside the opening of the porthole door.
leaning the wash air condenser
loth under the maintenance flap as residual
opened completely for easy
access.
to release the air
condenser.
. You should also
clean the seals.
bottom.
Unscrew both the locking levers away from each other.
T
The drum of your condenser dryer is constructed from stainless steel.
However if there are objects that can rust plac
it is possible for the drum to become stained.
IMPORTANT: Do not use a descaling agent, iro
s
oRemove any rust stains on
D
oYou should regularly check to see if any deposits have formed,
or there are any foreign bodies inside or underneath the rubb
C
oBefore carrying out this cleaning process, it is recommended to
place an absorbent c
water may escape. oOpen the maintenance flap by
carefully pulling it downwards. Make
sure it is
oScrew both the locking levers towards
each other
oFlush out the air condenser, clean and
drain thoroughly
oReinsert the air condenser with the handle at the

oClose the maintenance flap until it
locks into position.
oThe air condenser should be cleaned
frequently if the appliance is used
regularly.
oIMPORTANT: DO NOT clean the air condenser with hard or
sharp-edged objects. Only warm water should be used to
clean it.
oIMPORTANT: DO NOT operate the condenser dryer
without the air condenser in place.
oIMPORTANT: During the drying programme water may
collect between the door window and the seal but this
does not affect the performance of the dryer and does not
indicate a fault.
Installation
IMPORTANT: THIS INSTALLATION MUST BE
COMPLETED BY A SUITABLY QUALIFIED PERSON.
BAUMATIC ONLY SANCTION THE INSTALLATION
GIVEN IN THIS INSTRUCTION MANUAL. YOU
SHOULD KEEP THE TRANSIT PACKAGING, IN CASE
YOU NEED TO TRANSPORT THE MACHINE IN THE
FUTURE.
Locating your condenser dryer
oBefore commencing installation, check the location where you
intend to install the appliance. You should make sure that you
have everything in place that is necessary for the correct
installation.
oDo not place or store your condenser dryer in a location where
the ambient temperature could fall below 0°C, otherwise the
water used in it could freeze up.
oNever place or store laundry products on top of the appliance.
oInstall the dryer on a flat, solid floor. If the appliance is installed
on an uneven or suspended floor, it could cause excessive noise
and severe vibration, which may result in the malfunction of the
appliance.
oYou should also level off the condenser dryer, using the
adjustable feet on the base of the appliance.
20
