Baumatic BFVTD6BL User manual

USER MANUAL FOR YOUR
BAUMATIC
BFVTD6BL
Fully integrated air-
vented tumble dryer
BFVTD6BL
Freestanding air-vented
tumble dryer

BFVTD6BL
Freestanding air-
vented tumble dryer
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will enable
you to get the most out of your appliance. Please keep it in a safe
place so that it is easily available for future reference.
JW 24/04/13
2

3
Contents
Environmental note 3
Important safety information 4 – 6
Specifications 7 – 9
Product dimensions 7
Product specifications 7
Electricaldetails 7
Controlpanel 8
Drying selection knob 9
Appliancefeatures 9
Selecting a drying program 10 - 13
Automatically controlled drying 10
Timecontrolleddrying 10
Optionalfunctions 11
-Delaystart 11
-Quick 11
-Delicate 11
Neonindicatorlights 12
At the end of a drying cycle 12
Cancelling a program 12
Changingaprogram 13
Carelabels 13
Startingadryingprogram 13
Drying program guidance 14-15
Drying program table 15
Laundryweights 15
Maintenanceandcleaning 16-17
Indailyuse 16
Control panel and tumble dryer cabinet 16
Thetumbledryerdrum 16
Door 16
Thefilter 17
Installation 18-21
Positioning 19
Installing the vent hose 19 - 20
Powersupply 20-21
Troubleshooting 21–22
Technical data 23
Contact details 24

Environmental note
Note : Before discarding an old appliance, switch off and
disconnect it from the power supply. Cut off and render any plug
useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person. Disable
the door lock to make sure that children cannot get stuck inside the
appliance.
4
oThe packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
oPlease discard all packaging material with due regard for the
environment.

5
mportant safety informationI
Your safety is of the utmost importance to us. Please make
eneral Safety
oRepairs to your appliance must only be carried out by a Baumatic
oIf you notice that the special mains cable is damaged. The
oThe appliance should be turned off and isolated from the mains
oThe mains cable must not be used to pull the plug out of the
oThe machine should not be sprayed with water.
oThe window of the porthole door may become hot during use.
oThe machine should be allowed to cool before cleaning the filter.
oIt is possible for small animals to chew either mains cables or water
oIf you stop the tumble dryer before the end of a drying cycle ensure
sure that you read this instruction booklet before
attempting to install or use the appliance. If you are unsure
of any of the information contained in this booklet, please
contact the Customer Services Department.
G
engineer or one of its authorised service agents. Any attempt by an
inexperienced person to repair the appliance, could result in injury
or damage to your tumble dryer.
appliance must not be used. The same applies if you notice that
the worktop, control panel or base area is damaged. As this could
allow access to the internal components of the machine.
supply, before either cleaning or maintenance work is attempted.
electrical socket.
hoses, which could cause an electric shock hazard.
all items are quickly spread out so that heat is dissipated. Ideally
you should follow the “cancelling a program” instructions.

6
nstallation
oThe installation instructions contained within this user manual
oIt is obligatory for the completed installation to comply with all
oAdequate venting must be provided to avoid back flow of gases into
oExhaust gas must not be discharged into a flue used for exhausting
oDo not allow the venting hose (where applicable) or filter to become
uring Use
oIt is recommended that the appliance is turned off after the
oThis appliance is only designed to dry normal domestic washloads.
oNo attempt should be made to alter or modify the specifications of
oYou should not dry garments that have been in contact with
oYour tumble dryer should not be used for dry cleaning.
oDo not dry unwashed items in the tumble dryer.
oDo not allow fluff to accumulate around the tumble dryer.
oIf you use either dyes or bleaching agents inside this machine, then
oFabric softeners should be used as specified in the manufacturer’s
I
should be followed.
relevant building regulations.
the room from appliances burning other fuels including open fires.
fumes from appliances burning gas or other fuels.
blocked.
D
machine is used.
If you use your tumble dryer in any other way or it is incorrectly
used, then Baumatic accepts no liability for any damage that might
be caused and any guarantee will be void.
this appliance.
flammable materials.
you should consult with the manufacturer of these products to
make sure they are suitable for use in your tumble dryer. Baumatic
cannot be held responsible for any damage that may result.
instructions.

7
oItems soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax
removers should be washed in hot water with extra detergent
before being dried.
oRemove all objects from pockets of clothes such as lighters and
matches.
oDO NOT place items in the dryer if anything other than a water
solution has been used in the cleaning process.
oDO NOT attempt to dry dripping wet items.
Child Safety
oThe tumble dryer is not intended for use by persons with reduced
mental, physical or sensory capabilities or lack of experience or
knowledge, unless they have been given supervision and
instructions concerning the use of the appliance by a person
responsible for their safety.
oChildren should be supervised to ensure they do not play with the
appliance.
oIt could be possible for a child or pet to gain access to the tumble
dryer through the porthole door. Therefore please check the drum
before using the appliance.
oAny packaging that is removed from the machine should be kept
away from children.

8
Specifications
Appliance dimensions
Height: 850 mm
Width: 595 mm
Depth: 555 mm
Product specifications
oCapacity: 6 kg
o15 drying programs
oElectronic control operation
oTime controlled drying, up to 90 minutes
oDelay start function
oReverse tumble action
o180° door opening
oRemovable fluff filter
oMoisture sensor
oGalvanized drum
oAnti crease function
oDrying phase indicator
oVenting hose
oAdjustable feet
oEnergy efficiency class:C
Electrical details
Rated voltage: 220 - 240 Vac 50 Hz
Electrical connection rating: 2.00 kW
Supply connection: 13 A (double pole switched fused outlet with
3mmcontactgap)
IMPORTANT: For future reference please record the following information
which can be found on the rating plate and the date of purchase which
can be found on your sales invoice. The rating plate of your dishwasher is
located on the right hand side of the drop down door.
Model Number …………………………………….
Serial Number …………………………………….
Date of Purchase …………………………………….

Control panel
1. Program selector dial
2. Sequence indicator lights
oDrying
oCooling
oEnd
oFilter
3. Start / Pause button
4. Delay start button / indicator lights
5. Delicates button
6. Quick cycle button
9

Dryer selection knob
oTurning the selector dial (1) allows you to select the drying
program according to your laundry.
oThe selector dial is divided into four sections:
Cottons
Synthetics
Time
Special
oAfter you have selected your desired program you must press the
start button (3) within 10 minutes or the appliance will return to
standby mode.
Always turn the appliance off after use by turning the dial to “O”.
Appliance features
10
1. Control panel
2. Filter
3. Adjustable feet
4. (Rear/side) vent outlet.
