Cooper Lighting Shaper 417SERIES User manual

PENDANTS
960
SHAPER™
COOPER LIGHTING
MATERIAL
Solid aluminum
materials. Matte
white acrylic, one piece.
Single stem is standard
suspension. Minimum
18” (OA).
BALLAST
Integral electronic HPF,
multi-volt 120/277V (347V
Canada), thermally
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage.
LAMP/SOCKET
One (1) 26W, 32W
(GX24q-3) or 42W
(GX24q-4) 4-pin triple
CFL lamp or one (1) 100W
A-19 or 50PAR20H lamp.
CFL socket injection
molded plastic. INC
socket fired ceramic
rated for 660W-250V.
Lamps furnished by
others.
INSTALLATION
Supplied with either a
circle strap mounting
canopy or bar strap that
mounts to a 4" J-box or
plaster ring. Integral
safety cable provided.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
417 Direct/Indirect Luminous
Pendant.
417 SERIES
4" ø
14" ø
9-1/2"
24"
4-1/2" ø
1/2"
3-1/2"
417 CFL
4" ø
14" ø
9-1/2"
24"
417 INC
6-1/4" ø
2-1/8"
3-1/2"
MATERIAL
Solid aluminum or solid
copper materials. Matte
white acrylic diffuser.
Supplied with an SJ cord
assembly. Single stem is
standard suspension.
Minimum 18” (OA).
Notes:
1 Available with CFL only.
2 Consult the factory for available options.
3 Supplied by others.
4 For Stem mounting only. Specify up to 45°.
BALLAST
Integral electronic HPF,
multi-volt 120/277V (347V
Canada), thermally
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage.
LAMP/SOCKET
One (1) 26W, 32W
(GX24q-3) or 42W
(GX24q-4) 4-pin triple CFL
lamps or one (1) 100W
A-19 lamps. CFL socket
injection molded plastic.
INC socket fired ceramic
rated for 660W-250V.
Lamps furnished by
others.
INSTALLATION
Supplied with either a
circle strap mounting
canopy or bar strap that
mounts to a 4" J-box or
plaster ring. Integral
safety cable provided
with option stem.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
416 Luminous Shade Pendant.
416 SERIES
Sample Number: 416-CFL/1/26-347V-SAL-__
Series
416 =Luminous
Shade
Lamp
CFL/1/26
CFL/1/32
CFL/1/42
INC/1/100
Voltage
120V
277V1
347V1
Finish
NA (standard),
CC, MW, PCP,
SAL, SCP
Options
1S
CSJ
PSS2SD
PSS3SD
PSS4SD
DL
DM2
REM3
SCA4
MATERIAL
Solid aluminum
materials. Matte white
acrylic bowl and optional
Cone Diffuser (CD).
Single stem is standard
suspension. Minimum
18” (OA).
BALLAST
Integral electronic HPF,
multi-volt 120/277V (347V
Canada), thermally
protected with end-of-life
circuitry to accommodate
the specified lamp
wattage.
LAMP/SOCKET
One (1) 26W or 32W
(GX24q-3) 4-pin triple CFL
lamp or one (1)100W A-19
lamp. CFL socket
injection molded plastic.
INC socket fired ceramic
rated for 660W-250V.
Lamps furnished by
others.
INSTALLATION
Supplied with either a
circle strap mounting
canopy or bar strap that
mounts to a 4" J-box or
plaster ring. Integral
safety cable provided.
FINISH AND OPTIONS
See page 1020 for finish
details and options.
418 Direct/Indirect Luminous Bowl
Pendant.
418 SERIES
18" ø
3" ø
5"
24"
6-1/4" ø
2-1/8"
18" ø CFL
24"
3-1/2"
3" ø
14-1/2" ø
6-1/4" ø
2-1/8"
14" ø CFL
Sample Number: 418-18-CFL/1/26-347V-SAL-__
Series
418=
Direct/Indirect
Luminous Bowl
Size
14"
18"
Lamp
CFL/1/26
CFL/1/32
INC/1/100
Voltage
120V
277V1
347V1
Finish
NA
(standard),
CC, MW,
PCP, SAL,
SCP
Options
1S
CSJ
SSS2SD
SSS3SD
SSS4SD
DL
DM2
REM3
SCA4
CD
INC
CFL
24"
12-1/2"
9" ø
6-1/4" ø
2-1/8"
9" ø
24"
12-1/2"
9" ø
4-1/2" ø
1/2"
Suspension
Height
24"
Or Specify
Notes:
1 Available with CFL only.
2 Consult the factory for available options.
3 Supplied by others.
4 For Stem mounting only. Specify up to 45°.
Sample Number: 417-HAL/1/50-120V-SAL-__
Series
417=Direct/Indirect
Luminous Bowl
Lamp
CFL/1/26
CFL/1/32
CFL/1/42
INC/1/100
HAL/1/50
Voltage
120V
277V1
347V1
Finish
NA (standard),
CC, MW, PCP,
SAL, SCP
Options
1S
CSJ
SSS2SD
SSS3SD
SSS4SD
DL
DM2
REM3
SCA4
Suspension
Height
24"
Or Specify
Suspension
Height
24"
Or Specify
Notes:
1. Available with CFL only. Notes:
2. Consult the factory for available options.
3. Supplied by others.
4. For Stem mounting only. Specify up to 45°.
