Bayby BBM 7000 User manual

EN / Digital Audio Baby Monitor ■User’s manual
CZ / Digitální audio chůvička ■Návod k obsluze
SK / Digitálna audio opatrovateľka ■Návod na obsluhu
HU / Digitális audió babaőrző ■Használati útmutató
BBM 7000

EN .............................................................................................................................................. 3
CZ ............................................................................................................................................. 19
SK ............................................................................................................................................. 35
HU ............................................................................................................................................. 51

3
Digital Audio Baby Monitor EN
Table of Contents
Introduction ......................................................................................................................................................4
Safety instructions and important notes............................................................................................................ 4
Description of the accessories .......................................................................................................................... 6
Description of the baby unit ..............................................................................................................................7
Description of the parent unit............................................................................................................................8
Installation location of the baby unit and parent unit..........................................................................................9
Power source ...................................................................................................................................................9
Using the baby monitor .................................................................................................................................11
General information about using the baby monitor..........................................................................................12
ECO mode .....................................................................................................................................................12
Troubleshooting.............................................................................................................................................. 13
Cleaning and maintenance .............................................................................................................................14
Technical specifications ..................................................................................................................................14
Explanation of symbols used on the product, its accessories and packaging.................................................. 15
Instructions and information about the handling of used packaging ...............................................................16
Warranty conditions........................................................................................................................................ 17

Digital Audio Baby MonitorEN
4
Introduction
■Thank you for selecting the Bayby BBM 7000 Digital Audio Baby Monitor. This digital baby monitor is agreat
child care accessory that enables you to hear your baby when you are not in the same room. Nevertheless, it
is important to understand that it cannot serve as asubstitute for responsible adult supervision.
■The sound detected by the baby unit is transmitted to the parent unit. DECT digital wireless technology is
utilised for transmitting the audio signal. This guarantees very high quality audio transmission up to arange
of 300 metres.
■The encrypted wireless transmission and automatic free channel selection features guarantee privacy and
the peace of mind that you will hear only your child.
■You will be informed about an exceeded signal range, loss of signal or interference by means of an acoustic
alarm and the respective LED indicator light.
■Volume can be set to 5 levels. The parent unit also features aLED volume indicator, which is particularly useful
when the parent unit is set to alow volume.
■The baby monitor automatically switches to ECO mode when no audio is being transmitted. This reduces the
transmission power to ensure power efficient operation and minimisation of radiation.
■The baby unit is powered from the power socket using a power adapter. The parent unit shall be powered
using apower adapter or rechargeable batteries.
Safety instructions and important notes
■Before first use, thoroughly read the user'smanual. Keep this user'smanual for future use.
Attention:
This baby monitor meets all relevant standards and its use is safe when all the instructions contained in
this manual are followed.
■The baby monitor serves to monitor your child when you are not in the same room and cannot supervise it
directly. Nevertheless, it is important to keep in mind that your child'ssafety comes first and therefore this
baby monitor cannot serve as asubstitute for supervision by aresponsible adult.
■This baby monitor is intended for home (private) use only. It is not intended for commercial purposes.
■After unpacking the baby monitor and its accessories from the packaging material, place the plastic bags in
asafe location out of the reach of children. In the presence of children, plastic bags may present asuffocation
hazard.
■Only use the baby monitor with the original adapters that came with it.
■Never use the baby monitor with accessories that are not approved by the manufacturer.

5
Digital Audio Baby Monitor EN
■Before connecting the power adapter to apower socket, make sure the voltage stated on its rating label
corresponds to the voltage in the power socket. Position the power cord of the power adapter so that it
will not be tripped over.
■The baby monitor may only be operated by adults.
■Children must not play with the baby monitor. Keep the baby monitor, power adapters and rechargeable
batteries out of the reach of children.
■Before first using the baby monitor, acquaint yourself with its functions and before every use make sure that
both the baby and parent unit are in working order and that the rechargeable batteries are not flat when
they are used to power the parent unit.
■Ensure that the baby monitor and the power adapter do not come into contact with hot surfaces or sharp
objects.
■Do not place the baby monitor in the vicinity of water containers or appliances that are sources of heat.
■Do not cover the baby monitor and do not place any items on it.
■Do not use the baby monitor in an excessively dusty or humid environment. Do not subject it to extreme
temperature changes and electromagnetic fields.
■Do not submerge the baby monitor and its accessories in water or rinse under running water.
■Always disconnect the baby monitor from the power socket when not using it, after the batteries have been
recharged and before cleaning it.
■Do not disconnect the power adapter from the power socket by pulling on the power cord. This could
damage the power adapter or the power socket. Disconnect the power adapter from the power socket
by pulling on the plug.
■For powering the parent unit from an internal power source, only use type Ni-MH type AAA batteries
(2× 1.2 V/ 550 mAh).
■When not using the baby monitor for an extended period of time, remove the batteries from the parent unit.
■Keep the batteries out of the reach of children as they may present ahazard to achild. In the event that
achild swallows abattery, immediately seek medical help.
■Do not attempt to short circuit or break the battery or throw it into afire. Do not subject the battery to
direct sunlight, fire, etc.
■Do not make any alterations to the baby monitor that would change its electrical or mechanical properties.
■The baby monitor must not be operated with auxiliary amplifiers of high-frequency power or directional
antennas.
■Do not use the baby monitor if it is in any way damaged or if the power adapter is damaged.
■Do not attempt to repair the baby monitor yourself. Have all repairs or adjustments performed at an authorised
service centre. By tampering with the product you risk voiding your legal rights arising from unsatisfactory
performance or quality warranty.
■We recommend saving the original box, packaging material, receipt and responsibility statement of the vendor
or warranty card for the duration of warranty. It is appropriate to transport the baby monitor in its original box.

Digital Audio Baby MonitorEN
6
Description of the accessories
A
1
3
2
1Parent unit*
2Baby unit
3Power adapter (2 pcs)
The adapters are identical.
Note*:
The parent unit comes with two type AAA rechargeable batteries (2× 1.2 V/ 550 mAh).

7
Digital Audio Baby Monitor EN
Description of the baby unit
B
1
4
3
2
1Power On LED indicator light
2Button for turning the baby unit on and off
3Microphone
4Socket for connecting the plug on the power
adapter (not shown),
it is located at the rear of the baby unit.

Digital Audio Baby MonitorEN
8
Description of the parent unit
C
1
8
7
2
1Connection/On LED indicator light
2Volume LED indicator light
3Increase volume button
4Button for turning the parent unit on and off
5Decrease volume button
6Socket for connecting the plug on the power
adapter (not shown),
it is located at the bottom of the parent unit.
7Loudspeaker (not shown),
it is located at the rear of the parent unit.
8Battery compartment (not shown),
it is located at the rear of the parent unit.
5
6
3
4

9
Digital Audio Baby Monitor EN
Installation location of the baby unit and parent unit
1. Baby unit
■Locate the baby unit A2within reach of apower socket on an even, dry and stable surface in the room
where you want to monitor your child. We recommend an elevated location (e.g. chest of drawers or ashelf)
at asufficient distance away from equipment and devices that could cause signal interference.
■The baby unit A2should be located at least 1 m away from your child to minimise the effects of electro-
smog.
Attention:
Never locate the baby unit A2or the power adapter A3in the baby'sbed or within the reach of your
child.
2. Parent unit
■Put the parent unit A1in the room where you will be located. When the parent unit A1is to be powered
from the grid, locate it within reach of apower socket.
Power source
1. Baby unit
■External power source and its use
– For powering the baby unit A2, use only the original power adapter A3model number
EP19A-060040WXEZ (input 6V = 400mA).
– Insert the connector of the power adapter A3into the socket B4that is located at the rear of the
baby unit A2. Insert the plug of the power adapter A3into apower socket.
2. Parent unit
■External power source and its use
– For powering the parent unit, use only the original power adapter A3model number
EP19A-060040WXEZ (input 6V = 400mA).
– Insert the connector of the power adapter A3into the socket C6that is located at the bottom of the
parent unit A1. Insert the plug of the power adapter A3into apower socket.

Digital Audio Baby MonitorEN
10
Attention:
For safety reasons, the parent unit A1when powered from an external power source can only be put into
operation with rechargeable batteries inserted inside.
■Internal power source and its use
– For powering the parent unit from an internal power source, use the supplied Ni-MH type AAA
batteries (2× 1.2 V/ 550 mAh).
– From the rear of the parent unit A1, remove the cover of the battery compartment C8. Insert
rechargeable batteries into this compartment C8. When inserting the batteries, make sure that
you maintain the correct polarity, which is marked in the battery compartment C8. Close the cover.
– The rechargeable batteries must be charged for at least 16 hours before the parent unit A1can be
used for the first time independently of the external power source. The batteries will start charging
when the parent unit A1is connected to an external power source. You may use the parent unit
A1while it is charging.
Note:
Subsequent recharging will require only approximately 10 hours.
– When you disconnect the parent unit A1from the power socket after charging it, you may use it
independently of an external power source.
– Fully charged batteries will last for approximately 10 hours of operation. The operating time will
depend on the battery power level and their capacity. The maximum battery capacity is achieved after
they have been fully charged several times. The lifetime of the batteries depends on many factors
such as charging frequency, ambient temperature at which the batteries are charged and stored, etc.
– We recommend that the batteries are charged and kept at room temperature and at least once
every six months to allow them to fully discharge in the parent unit A1and subsequently recharge
them fully.
– Battery operation minimises electro-smog which arises due to the effect of alternating electric and
magnetic fields.
– In the event that the batteries are almost flat and there is aconnection between the units A1and
A2, an acoustic alarm signal will be sounded approximately every 30 seconds, indicating that the
parent unit A1needs to be connected to an external power source in order for the batteries to
recharge. In the event that there is no connection between the units A1and A2, this signal will be
sounded approximately every 10 seconds. If you do not connect the parent unit A1to an external
power source, it will turn itself off automatically after acertain time. The Power On LED indicator light
C1will turn off.

11
Digital Audio Baby Monitor EN
Note:
The interval after which the parent unit A1automatically turns off depends on the mode in which the
parent unit A1is, the battery capacity, battery age, etc.
– In the event that you are planning not to use the baby monitor for an extended period of time, take the
batteries out of the parent unit A1and store them out of the reach of children.
Using the baby monitor
1. Turning the baby unit on and off
■The baby unit A2will turn on automatically when it is connected to a working power socket. This is
signalled by the LED indicator light B1being lit.
■To turn off the baby unit A2, press the On/Off button B2and hold it down for approximately 2 seconds.
The turned off state of the baby unit A2is signalled by the LED indicator light B1turning off.
■To turn the baby unit A2that is connected to apower socket on again, it is necessary to press the On/Off
button B2and hold it down for approximately 2 seconds.
■When you have finished using it, always turn off the baby unit A2and disconnect the power adapter A3
from the power socket.
2. Turning the parent unit on and off
■The parent unit A1automatically turns on when it is connected to a working power socket or after
the batteries are inserted, unless they are completely flat. When the parent unit A1is turned on, the
Connection/On indicator light C1will start flashing. As soon as aconnection is made with the baby unit
A2, the LED indicator light C1will remain permanently lit.
Attention:
For safety reasons, the parent unit A1when powered from an external power source can only be put into
operation with rechargeable batteries inserted inside.
■In the event that the parent unit A1was turned off manually after the batteries were inserted or after
being connected to apower socket, it is necessary to press the On/Off button C4and hold it down for
approximately 2 seconds to turn it on again.
■Turn off the parent unit A1by again pressing the On/Off button C4and holding it down for approximately
2 seconds. The turned off state of the parent unit A1is signalled by the LED indicator light B1turning off.

Digital Audio Baby MonitorEN
12
3. Setting the volume intensity
■Buttons C3and C5can be used to increase and decrease the volume on the parent unit A1. The
volume setting is confirmed by the volume LED indicator C2turning on for ashort time, and an acoustic
signal will be sounded. Volume can be set to 5 levels. The maximum volume setting is indicated by both
volume LED indicator lights C2being lit shortly. If the setting is outside the possible volume range, an
acoustic warning will be made when button C3or C5is pressed.
General information about using the baby monitor
■Before using the baby monitor for monitoring your child, always check that both the baby and parent unit
A2andA1are in working order, that there is aconnection between the units and that audio is being
transmitted. The connection between the units is indicated by the Connection/On LED indicator light C1.
■The sound detected by the baby unit A2is transmitted to the parent unit A1. LED indicator lights C2
will inform you about audio transmission. This will be particularly useful when the parent unit A1is set to
alow volume.
■In the event that there is no connection between the baby and parent unit A2andA1(the baby unit
A2is turned off or out of signal range), the connection/On LED indicator light C1will flash and sound an
acoustic alarm signal (beeping).
■To increase the signal range, place the baby unit A2in an elevated location as close as possible to the
door or window.
■Other radio waves may interfere with the signal transmission. For this reason, do not place the baby monitor
in the vicinity of appliances such as e.g. amicrowave oven or WLAN devices, etc.
■The following factors may interfere with the signal or reduce its range:
– one of the units is covered,
– obstacles in the signal transmission direction such as furniture, walls, trees, etc.
– weather events such as fog, rain, etc.
ECO mode
■The baby monitor automatically switches to ECO mode when no audio is being transmitted. This reduces
the transmission power to minimum to ensure power efficient operation and limits unnecessarily exposing
your child to radiation.

13
Digital Audio Baby Monitor EN
Troubleshooting
Problem Solution
LED indicator light B1
does not light up when the
baby unit A2is turned on.
Check that the power adapter A3is connected to aworking power socket and
that the plug on the power cord is properly inserted into socket B4.
LED indicator light C1
does not start flashing/light
up when the parent unit
A1is turned on.
Check that the power adapter A3is connected to aworking power socket and
that the plug on the power cord is properly inserted into socket C6.
Check whether the rechargeable batteries need to be recharged and check them
for damage.
The parent unit A1is
sounding an alarm signal.
Check that the signal range has not been exceeded.
Check that the baby unit A2is plugged into apower socket.
Check that the baby unit A2is turned on.
The rechargeable batteries inside the parent unit A1may be flat or damaged. In
the event that the batteries are flat, recharge them. Damaged batteries must be
replaced with new ones of the same type.
Ahigh tone is coming out
of the parent unit A1.
The units are located too close to each other. Move the parent unit A1farther
away from the baby unit A2. The parent unit A1should be located at least
1 metre away from the baby unit A2.
Transmitted audio cannot
be heard.
On the parent unit A1, set ahigher volume using button C3.
The parent unit A1turns
off automatically.
The rechargeable batteries are weak. Recharge them.
Weak signal, signal
interference or the
connection is repeatedly
interrupted.
If there is any equipment located in the signal transmission direction, e.g.
amicrowave oven, move it elsewhere or turn it off.
Check whether there are any obstacles in the signal transmission direction, e.g.
trees. Move the units so that apermanent connection is made.
Check that the units are within the signal range.

Digital Audio Baby MonitorEN
14
Cleaning and maintenance
■Before cleaning the baby monitor, disconnect it from the power socket. If it becomes soiled, wipe the
external parts of the baby and parent units A2andA1using acloth lightly dampened in lukewarm water.
Then wipe everything so that it is thoroughly dry.
■To clean the adapters A3, use aclean, dry cloth.
■For cleaning, do not use abrasive cleaning products, solvents, thinners, etc. Never submerge the baby
monitor or its power adapters A3in water or rinse under running water.
Technical specifications
Model number ................................................................... BBM 7000
Frequency broadcast band................................................ 1 880–1 900 MHz
Transmission power........................................................... 20 dBm (100 mW)
Range in open space......................................................... up to 300 m
Audio transmission ............................................................ one way communication
Voltage and amperage draw.............................................. 6 V , 400 mA
Power source .................................................................... power adapter, EP19A-060040WXEZ
input: 100–240 V~, 50/60 Hz, 200 mA,
output: 6 V , 400 mA
or
rechargeable batteries Ni-MH type AAA,
2× 1.2 V/ 550 mAh (only the parent unit)

15
Digital Audio Baby Monitor EN
Value and precision............................................................ Unit
Manufacturer’s name or trade mark,
commercial registration number and address .................... Dongguan everest industrial Co, Ltd, No. 2 Xingyi
road, Shangjiao community, ChangAn Town,
523878 Donguang Guangdong, Peopleś republic of
China
Model identifier .................................................................. EP19A-060040WXEZ
Input voltage...................................................................... 100-240 V
Input AC frequency............................................................ 50/60 Hz
Output voltage................................................................... 6 V
Output current................................................................... 0,4 A
Output power .................................................................... 2,4 W
Average active efficiency.................................................... 73,93 %
No-load power consumption ............................................. 0,042 W
Electrical shock protection
class (power adapter) ........................................................ II
Battery operating time ....................................................... approximately 10 hours with fully charged batteries
(parent unit)

Digital Audio Baby MonitorEN
16
Explanation of symbols used on the product, its accessories and packaging
This symbol indicates that this appliance meets all the basic requirements of EU directives
related to it.
This symbol indicates that the product has protection class II.
This symbol indicates the polarity of the power cord connectors.
This symbol indicates that it is aproduct that may be used indoors.
LOT. This abbreviation serves to designate the production lot number.
This symbol indicates that the requirements of directive 2011/65/EU (RoHS II) have been met
for limiting the use of certain hazardous substances in electrical and electronic equipment.
This symbol on products or original documents means that used electric or electronic products
must not be added to ordinary municipal waste. For proper disposal, renewal and recycling
hand over these appliances to determined collection points. Alternatively, in some European
Union states or other European countries you may return your appliances to the local retailer
when buying an equivalent new appliance. Correct disposal of this product helps save valuable
natural resources and prevents potential negative effects on the environment and human health,
which could result from improper waste disposal. Ask your local authorities or collection facility
for more details. In accordance with national regulations penalties may be imposed for the incor-
rect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier for the
necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this product, request the nec-
essary information about the correct disposal method from the local council or from your retailer.
Batteries contain environmentally damaging substances and therefore do not belong in standard
household waste. Take the batteries to an appropriate collection point, which will take care of
their ecological disposal. You can obtain the contact for the nearest collection point from you
town council or from your retailer.

17
Digital Audio Baby Monitor EN
Instructions and information about the handling of used packaging
Dispose of used packaging material at asite designated for waste in your municipality.
BAYBY hereby declares that radio device model number BBM 7000 is in compliance with directive 2019/1782/EU.
A valid declaration of conformity can be found at www.bayby.com.
The Czech language is the original version of the user'smanual. Changes to text and technical parameters are
reserved.

Digital Audio Baby MonitorEN
18
Authorized service centres
Please visit our website www.bayby.com for detailed information about authorised service centres.
