Bayby BBM 7011 User manual

EN / Digital Audio Baby Monitor ■User's manual
BBM 7011

Digital Audio Baby Monitor
EN
2
Table of Contents
Introduction .....................................................3
Safety instructions and important notes ................................3
Description of the accessories .......................................8
Description of the parent unit ........................................9
Description of the baby unit ........................................10
Description of the LCD Display – same for the parent and the baby unit ......11
Installation location of the baby unit and parent unit......................12
Power source...................................................12
Using the baby monitor ...........................................15
General information about using the baby monitor.......................16
Troubleshooting .................................................17
Cleaning and maintenance.........................................18
Technical specifications ...........................................18
Explanation of symbols used on the product, its accessories and packaging ..19
Instructions and information about the handling of used packaging .........21

Digital Audio Baby Monitor EN
3
Introduction
■Thank you for selecting the Bayby BBM7011 Digital Audio Baby Monitor. This
digital baby monitor is agreat child care accessory that enables you to hear
your baby when you are not in the same room. Nevertheless, it is important to
understand that it cannot serve as asubstitute for responsible adult supervision.
■The sound detected by the baby unit is transmitted to the parent unit. FHSS
digital wireless technology is utilised for transmitting the audio signal. This
guarantees very high quality audio transmission up to arange of 300metres.
■The encrypted wireless transmission and automatic available channel selection
features guarantee privacy and the peace of mind that you will hear only your
child.
■The baby monitor features aVOX function that enables avoice activated trans-
mission mode. The baby monitor will thus always start transmitting when it de-
tects any voice or noise. When no sound is being transmitted, the baby monitor
will automatically switch to the ECO mode. This reduces the transmission power
to ensure power efficient operation.
■If you need to calm the baby down, you can use the two-way communication
function.
■On the LCD display of the parent unit and the baby unit you can monitor the
air temperature in the room, where the baby unit is located, the battery power
level and loss of signal.
■The PAGE function will help you to locate alost parent unit.
■Volume is adjustable.
■The parent unit and the baby unit are powered using the supplied power
adapters or AAA batteries (3×1.5V). The parent unit comes included with
3×rechargeable AAA batteries.
Safety instructions and important notes
■Before first use, thoroughly read the user'smanual.
Keep this user'smanual for future use.

Digital Audio Baby Monitor
EN
4
■This baby monitor meets all relevant standards and
its use is safe when all the instructions contained in
this manual are followed.
■The baby monitor serves to monitor your child when
you are not in the same room and cannot supervise it
directly. Nevertheless, it is important to keep in mind
that your child'ssafety comes first and therefore this
baby monitor cannot serve as asubstitute for super-
vision by aresponsible adult.
■This baby monitor is intended for home (private) use
only. It is not intended for commercial purposes.
■After unpacking the baby monitor and its accessories
from the packaging material, place the plastic bags in
asafe location out of children'sreach. In the presence
of children, plastic bags may present asuffocation
hazard.
■Only use the baby monitor with the original adapters
that came with it.
■Never use the baby monitor with accessories that are
not approved by the manufacturer.
■Before connecting the power adapter to apower
socket, make sure the voltage stated on its rating

Digital Audio Baby Monitor EN
5
label corresponds to the voltage in the power socket.
Position the power cord of the power adapter so that
it will not be tripped over.
■The baby monitor may only be operated by adults.
■Children must not play with the baby monitor. Keep
the baby monitor, power adapters and batteries out
of children'sreach.
■Before first using the baby monitor, acquaint yourself
with its functions and before every use, make sure
that both the baby and parent unit are in working
order.
■Ensure that the baby monitor and the power adapter
do not come into contact with hot surfaces or sharp
objects.
■Do not place the baby monitor in the vicinity of water
containers or appliances that are sources of heat.
■Do not cover the baby monitor and do not place any
items on it.
■Do not use the baby monitor in an excessively dusty
or humid environment. Do not subject it to extreme
temperature changes and electromagnetic fields.
■Do not submerge the baby monitor and its accesso-

Digital Audio Baby Monitor
EN
6
ries in water or rinse it under running water.
■Always disconnect the baby monitor from the power
socket when not using it, after the batteries have been
recharged (on the parent unit) and before cleaning it.
■Do not disconnect the power adapter from the pow-
er socket by pulling on the power cord. This could
damage the power adapter or the power socket. Dis-
connect the power adapter from the power socket
by pulling on the plug.
!
■To power the parent unit from an internal power
source, use the supplied rechargeable batteries type
AAA (3×1.2V600mAh NI-MH) or standard non-re-
chargeable batteries type AAA(1.5V).
■For powering the baby unit from an internal power
source, only use commonly available type AAAbat-
teries (1.5V).
■When not using the baby monitor for an extended
period of time, remove the batteries from the units.
■Keep the batteries out of children'sreach as they may
present ahazard to achild. In the event that achild
swallows abattery, immediately seek medical help.

Digital Audio Baby Monitor EN
7
■Do not attempt to short circuit or break the battery
or throw it into afire. Do subject the battery to direct
sunlight, fire, etc.
■Do not make any alterations to the baby monitor that
would change its electrical or mechanical properties.
■The baby monitor must not be operated with auxil-
iary amplifiers of high-frequency power or directional
antennas.
■Do not use the baby monitor if it is in any way dam-
aged or if the power adapter is damaged.
■Do not attempt to repair the baby monitor yourself.
Have all repairs or adjustments performed at an au-
thorised service centre.
■By tampering with the product you risk voiding your
legal rights arising from unsatisfactory performance
or quality warranty.
■We recommend saving the original box, packaging
material, receipt and responsibility statement of the
vendor or warranty card for the duration of warranty.
It is appropriate to transport the baby monitor in its
original box.

Digital Audio Baby Monitor
EN
8
Description of the accessories
A
1 2
3
4
1Baby unit
2Parent unit
3Power adapter (2 pcs)
4Power cord (2 pcs)
The adapters are identical.

Digital Audio Baby Monitor EN
9
!
Note: The parent unit comes with two type AAA rechargeable batteries
(3×1.2V600mAh NI-MH)
Description of the parent unit
B
1Two-way communication
button
2Power adapter connection
socket
3Speaker
4On/Off button
5LCD display
6Increase volume button
7Microphone
8Decrease volume button
9Belt clip with hanging hole
0Battery compartment

Digital Audio Baby Monitor
EN
10
Description of the baby unit
C
1
2
3
5
7
4
60
9
qa
8
1"PAGE" function button
2 Power adapter connection
socket
3 Speaker
4On/Off button
5 LCD display
6 Increase volume button
7 Microphone
8 Temperature sensor
9 Belt clip with hanging hole
0 Decrease volume button
qa Battery compartment

Digital Audio Baby Monitor EN
11
Description of the LCD Display – same for
the parent and the baby unit
D
1Loss of signal icon
2 Air temperature value
3 Battery power icon
Fully charged battery
Low battery capacity
Flat battery
4Sleeping baby icon (no sound
at the baby unit, saves power
and batteries)
5 Calling baby icon (constantly
changing)

Digital Audio Baby Monitor
EN
12
Installation location of the baby unit and
parent unit
1. Baby unit
■Locate the baby unit A1within reach of apower socket on an even, dry and
stable surface in the room where you want to monitor your child. We recommend
an elevated location (e.g. chest of drawers or ashelf) at asufficient distance
away from equipment and devices that could cause signal interference.
■The baby unit A1should be located at least 1m away from your child to
minimise the effects of electro-smog.
!
Never locate the baby unit A1or the power adapter A3, A4in the ba-
by'sbed or within your child'sreach.
2. Parent unit
■Put the parent unit A2in the room where you will be located. When the parent
unit A2is to be powered from the grid, locate it within reach of apower socket.
Power source
1. Baby unit
■External power source and its use
– For powering the baby unit A1, use only the original power adapter A3
model number RY050100EU-B including the power cord A4.
– Insert the plug of the power cord A3, incl. cable A4, into the socket
C2that is located on the side of the baby unit A1. Insert the plug of the
power adapter A3into apower socket.

Digital Audio Baby Monitor EN
13
2. Parent unit
■External power source and its use
– For powering the parent unit A2, use only the original power adapter
A3model number RY050100EU-B including the power cord A4.
– Insert the plug of the power cord A3, incl. cable A4, into the socket
B2that is located on the side of the baby unit A2. Insert the plug of the
power cord A3into apower socket.
!
Info:
The supplied power adapters A3and cords A4are identical and inter-
changeable between both units.
!
Attention:
Before connecting the power adapter A3to apower socket, make sure the
voltage stated on its rating label corresponds to the voltage in the power socket.
3. Internal power source and its use
■Battery operation minimises electro-smog which arises due to the effect of
alternating electric and magnetic fields.
Note:
■In the event that you are planning not to use the baby monitor for an extended
period of time, take the batteries out of the units A1and A2and store them
out of children'sreach.
A. Baby unit
■For powering the baby unit A1from an internal power source, only use com-
monly available single-use type AAA batteries (3×1.5V). The baby unit does
not charge batteries.

Digital Audio Baby Monitor
EN
14
B. Parent unit
!
■To power the parent unit A2from an internal power source, use the supplied
rechargeable batteries type AAA (3×1.2V600mAh NI-MH) or standard
batteries type AAA (3×1.5V).
■Prior to using the supplied rechargeable batteries from the internal power source,
first charge the supplied batteries for the parent unit A2. You may use the parent
unit A2while it is charging. Full charging of the supplied rechargeable batteries
of the parent unit takes approximately 8hours when the unit is turned off.
■Never charge the supplied rechargeable batteries in an external charger, rather
only in the parent unit. Different types of rechargeable batteries than those
supplied cannot be charged in the parent unit.
C. Battery installation
■From the rear side of the baby and parent unit A1andA2release the top
clip-in middle part of the belt clip B9, C9by pulling it towards yourself, and
release and remove the entire belt clip by pulling it upwards.
■Remove the battery compartment cover B0andCqa.
■Insert 3×AAA batteries into compartment B0of the baby unit and the supplied
3×rechargeable AAA batteries into the compartment Cqa of the parent unit.
When inserting the batteries, make sure that you maintain the correct polarity,
which is marked in the battery compartment B0, Cqa. Close the battery cover
B0, Cqa. Secure the belt clip B9andC9to its initial position by clicking in
the top part of the clip on the rear side of the unit A1,A2.
!
If you decide to power the units A1or A2using power adapters and bat-
teries are still inserted inside, then first remove these batteries from both units.

Digital Audio Baby Monitor EN
15
Using the baby monitor
1. Turning the baby unit and the parent unit on and off
■The baby unit and parent unit A1, A2will automatically turn on when con-
nected to mains power or when batteries are inserted, or the baby unit and
parent unit A1, A2will be turned on by holding down button B4, C4for
two seconds. The turned on state is indicated by the LCD display C5turning
on for 5seconds and if no sound is being transmitted, the LCD display will turn
off and the unit will switch to the stand-by mode.
■To turn off the baby and parent unit A1, A2hold down button B4, C4for
2seconds. The turned off state is indicated by the LCD display C5turning off.
■When you have finished using the baby unit and the parent unit A1, A2, al-
ways turn it off and disconnect the power adapter A3from the power socket.
If batteries are being charged in the parent unit A2, disconnect the power
adapter A3from the power socket only after the charging process is complete.
2. Pairing the units
■The baby unit A1is paired with the parent unit A2in advance. Under normal
circumstances, it is not necessary to pair the units. However, in the event that
the connection is lost, then it is necessary to pair the units again in order for
the baby monitor to function.
■First turn off both units by pressing button B4, C4and turn them on again
by pressing the reduce volume button B8, C0and simultaneously the On/
Off button B4, C4for 2seconds. End of pairing is indicated by asingle beep
and the LCD display being lit.
3. Volume setting
■Increase the volume by pressing button B6, C6.
■Reduce the volume by pressing button B8, C0.
4. Low battery power indicator
■The low battery power icon D3will start flashing when battery capacity falls
below acertain level. At the same time, the low battery level will be indicated
by abeep.

Digital Audio Baby Monitor
EN
16
5. Notification that the unit is outside the signal range (only on the parent
unit).
■In the event that the units are outside the communications range or one of
the units has alow battery power level or is turned off, the parent unit will start
beeping and the icon D1will simultaneously start to flash.
6. Talk back (talk to the child)
■Press and hold down the two-way communication button B1for the time
for which you wish to speak to your child. Your voice will be heard from the
speaker C3of the baby unit.
7. Temperature sensor
■The temperature sensor C8senses the temperature in the room where the
baby unit A1is located.
■The temperature will be shown on both the units 30 – 60seconds after the
baby unit A1is turned on.
8. PAGE function (only on the baby unit)
■The PAGE function will help you locate the parent unit in the event that you have
forgotten where you have placed it.
■Press button PAGE C1on the baby unit.
■The parent unit will beep 3×.
■Press the button PAGE C1again to locate the parent unit A2.
General information about using the baby
monitor
■Before using the baby monitor for monitoring your child, always check that
both the baby and parent unit A1andA2are in working order, that there is
aconnection between the units and that audio is being transmitted.
■To increase the signal range, place the baby unit A1in an elevated location as
close as possible to the door or window.

Digital Audio Baby Monitor EN
17
■Other radio waves may interfere with the signal transmission. For this reason, do
not place the baby monitor in the vicinity of appliances such as e.g. amicrowave
oven or WLAN devices, etc.
■The following factors may interfere with the signal or reduce its range:
– one of the units is covered,
– obstacles in the signal transmission direction such as furniture, walls,
trees, etc.
– weather events such as fog, rain, etc.
Troubleshooting
■No connection
– The unit or both units are turned off. Press the On/Off button B4, C4
on both the units.
– Check whether the batteries are inserted, e.g. if the unit or both the units
are powered from the mains.
– The batteries may have alow capacity, replace them, or recharge them
(on the parent unit).
■Sound is not being transmitted.
– Check that you do not have the sound on the baby unit set too low or
turned off. Increase the volume to ahigher level by pressing button C6
on the baby unit.
– Check that you do not have the sound on the parent unit set too low or
turned off. Increase the volume to ahigher level by pressing button B6
on the parent unit.
– The units are outside the signal range or have lost their connection. Try
bringing the units closer together or pairing them if necessary. Remove
any obstacles preventing signal transmission such as microwave ovens,
furniture, etc.
■Signal interference
– The units are located too close to each other. Keep the units at least
1metre apart.
– The volume on the parent unit is set too high. Turn down the volume on
the parent unit.

Digital Audio Baby Monitor
EN
18
Cleaning and maintenance
■Before cleaning the baby monitor, disconnect it from the power socket.
■To clean the parent unit and the baby unit and the power adapters, use aclean,
dry cloth.
■For cleaning, do not use abrasive cleaning products, solvents, thinners, etc.
Never submerge the baby monitor or its power adapters in water or rinse
under running water.
Technical specifications
Model number........................................................................................BBM7011
Frequency broadcast band ......................................................... 2.40-2.4835GHz
Transmission power ................................................................................< 20dBm
Maximum power ....................................................................................... 100mW
Range in open space ...........................................................................up to 300m
Audio transmission.......................................................... two- way communication
Voltage and amperage draw ............................................................ 5.0V 1.0A
Operating temperature.............................................................................0 – 40°C
Power source........................................................power adapter, RY050100EU-B
input:..........................................................................100–240V~ 50/60Hz, 0.2A
output: ...................................................................................... 5.0V, 1.0A, 5.0W
or
Rechargeable batteries Ni-MH type AAA, 3×1.2V 600mAh (only for the parent unit)
and3×1.5V type AAA (only for the baby unit)
Value and accuracy...........................................................................................Unit
Name of manufacturer or trademark, business registration number and address ...
Dong Guan Reyi Power Electronics Co., Ltd.
The five floor No.A Building Huixing Industrial park Yangwu Village, Dalingshan
Town Dongguan City, Guangdong CHINA
Model identification ........................................................................RY050100EU-B
Input voltage ..........................................................................................100–240V
Frequency for alternating current.............................................................. 50/60Hz

Digital Audio Baby Monitor EN
19
Output voltage ................................................................................................5.0V
Output current.................................................................................................1.0A
Output power.................................................................................................5.0W
Average efficiency ......................................................................................75.46%
Power consumption in stand-by condition................................................ 0.082W
Electrical shock protection class (power adapter).................................................. II
Explanation of symbols used on the
product, its accessories and packaging
This symbol indicates that this appliance meets all the basic
requirements of EU directives related to it.
This symbol indicates that the product has protection class II.
This symbol indicates the polarity of the power cord connectors.
LOT This symbol serves to designate the production lot number.
This symbol indicates that the requirements of directive
2011/65/EU (RoHS II) have been met for limiting the use of
certain hazardous substances in electrical and electronic
equipment.
This symbol informs the consumer about how to handle the
packaging.

Digital Audio Baby Monitor
EN
20
This symbol on products or original documents means that
used electric or electronic products must not be added to or-
dinary municipal waste. For proper disposal, renewal and re-
cycling, hand over these appliances to determined collection
points. Alternatively, in some European Union states or other
European countries you may return your appliances to the local
retailer when buying an equivalent new appliance. Correct dis-
posal of this product helps save valuable natural resources and
prevents potential negative effects on the environment and hu-
man health, which could result from improper waste disposal.
Ask your local authorities or collection facility for more details. In
accordance with national regulations penalties may be imposed
for the incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask
your retailer or supplier for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dis-
pose of this product, request the necessary information about
the correct disposal method from the local council or from
your retailer.
