Baynhams PeRSo 2.0 User manual

PeRSo 2.0 USER MANUAL
Powered Air-Purifying Respirator
Please read these instructions carefully before using the equipment Incorrect
use can result in risk to life and health
Contents
1. Field of application and conditions for use
2. Description
3. Use
3.1 Prior to use
3.1.1 Usage limitations system
3.1.2 Usage limitations filter element
3.1.3 Charging batteries
3.2 Switching on
3.3 During use
3.4 After use
3.4.1 Cleaning and disinfecting
4.Maintenance and inspection
5. Storage
6. Faults/troubleshooting
6.1 Repairs
7. Technical specifications
7.1 Blower unit
7.2 Filter
7.3 Battery
7.4 Battery charger
7.5 Hose
8. Statutory requirements and regulations
10. Guarantee

1. Application and conditions for use
The PeRSo 2.0 Powered Air-Purifying Respirator (PAPR)
system is intended to be used to provide protection when the user
works in a contaminated environment. It is to be used for dust and
particles only, not for gases or vapors and is used to reduce or
remove resistance to inhalation during respiration – by producing a
constant airflow. There are three levels of flow rate, low, medium
and high. The PeRSo system complies with the requirements of
European Standard EN 12941 class TH1.
2. Description
A complete PeRSo 2.0 PAPR system consists of:
•Blower unit, provided with a dust filter unit, supplied with a
belt and comfort plate, a hose with a bayonet connector
(Blower unit) and an EN thread connector (mask).
•Rechargeable battery, which is placed inside the apparatus.
•Battery charger, fully automatic.
•The complete set is supplied in a carton carrier box.
3. Use
The unit supplies an overcapacity of clean and filtered ambient
air, which is fed into the mask. It allows the user to breathe in
air without having to overcome the resistance of the filter.
Considering that an adult person requires some 50 litres of air
per minute, the overcapacity ensures an overpressure and thus
a high degree of protection.
With a fully charged battery the unit will operate for 8 hours. The
unit contains a warning facility to warn the user against reduced
air supply, due to clogged filter or low battery.
3.1Prior to use
Before using the PeRSo 2.0 PAPR, the user must ensure that
all the conditions for safe use have been satisfied. See section
8 for the applicable statutory regulations and rules.
• Check that the appropriate hose connector is fitted to
the hose
• Check before use that the battery is sufficiently charged
and that the free flow of air is not obstructed by a blocked
hose or other causes.
• Check that a filter is fitted correctly.
• Check that the lids of the battery and filter housing are
closed.
3.1.1 Usage limitations system
The space in which the unit is to be used must contain at least
19.5% oxygen and must not contain any explosive gases or
vapors. In enclosed spaces where there is a risk of oxygen
deficiency, use of the unit should be avoided.
•Air speed in excess of 2m/s can affect the protection
factor.
•The ambient usage temperature should be between -10
and +50.
•Do not use the unit in circumstances where hazardous

gases and/or vapors are present.
Warning
If the user of the respirator feels dizzy or uncomfortable or can
smell/taste anything, he should abandon the contaminated area
immediately and check the unit.
3.1.2 Usage limitations filter element
Used filter elements cannot be cleaned.
Warning
Never attempt to clean a filter element; the filter media may be
damaged, resulting in loss of protection.
3.1.3 Charging batteries
The battery is supplied partially charged. The charging time for
a fully discharged battery is approximately 5 hours. To ensure
maximum working time, it is recommended batteries are fully
charged before use. The automatic setting of the charger
prevents damage to the batteries when the charging time is
exceeded. Under normal circumstances the battery can be
charged and discharged approximately 500 times. After the
battery is completely charged, the charger will switch over to
trickle charging. This will expand the lifetime of the battery
beyond 500 charge cycles.
3.2 Switching on
The unit can be switched on by pushing the ON/OFF button for
three seconds. A sound signal will be heard to indicate that the
electronic control unit is working correctly.
3.3 During use
After turn on, the system runs and self-checks first at full speed
for 3 seconds. After you can set the low-medium-high air flow
speed.
Note: the LED light is on for 5 seconds, if you need to adjust the
air flow later, first press the “ON/OFF/SET” button to turn on the
light, and then set the air flow speed. During usage, if the air
supply drops or fails entirely, leave the work area immediately.
If the sound signal for low battery (two continuous short beeps
repeatedly) is heard or a clogged filter element (a single short
beep repeatedly), leave the workroom immediately, and check
the unit in accordance with section 6.
3.4 After use
Press the button "ON/OFF/SET" for 2 seconds, when you see
the three LED lights flash twice, the device is turned off.
3.4.1 Cleaning and disinfecting
After each session clean the unit, do not use any solvent. During
cleaning ensure that no water is allowed to enter the apparatus.
The unit must not be immersed. Dry the unit with a cloth and/or
leave it to dry in the open air.
Advice
For reasons of hygiene each operator should be equipped with
their own hood or mask.

4. Maintenance and inspection
Prior to use: Check unit is fully functional.
After use: Clean and disinfect check functionality of the complete
system.
Every 6 months: Clean and disinfect the blower unit;
Clean and check functionality of the complete system. Check the
hose for leakage’s and inspect the connector for damage.
5. Storage
Before storing the unit it should be thoroughly dry.
Do not keep soiled filter canisters together with the unit and the
mask in the same enclosed storage space.
Remove the filters from the unit and seal them.
6. Faults/troubleshooting
Blower unit fails to supply air:
•Battery is empty
•ON/OFF button is in “OFF” position
•ON/OFF button defective
•Plug connection defective
•Motor bearings defective
•Printed circuit-board defective
Blower supplies insufficient air:
•Filter unit blocked
•Hose blocked or leaking
•Blockage or leakage in mask
•Suction opening clogged
Battery fails to charge:
•Power lead or plug connection defective
•Charger defective
•Battery defective or worn out
Battery is losing charge too quickly:
•Charger defect
•Battery defect or worn out
•Battery not charged sufficiently
6.1Repairs
Note
All other repairs should only be carried out by the manufacturer
7. Technical specifications
7.1Blower unit
Airflow：150 L/min,180L/min,220L/min adjustable
Motor Speed：Electronically controlled
Alarms：Electronically controlled, for low flow and
Low battery
Material：Impact proof ABS
Color：Black/blue
Weight (incl.filter.
battery and hose)：1280 grams
Dimensions LxWxH：235x145x85mm

7.2Filter
Filter class： P3
Material filter medium: Glass fibre paper
Material support disks: ABS
Color： Black
Weight： 135 grams
Dimension(DxH)： ø120x35mm
7.3Battery
Type： Lithium,rechargeable
Voltage：12 Volt
Capacity：4300 mAh
Operating time：﹥8hrs
Charging time：3hrs typically, upon 5hrs recommend.
Charging cycles：﹥500
Material case：Impact proof ABS
Color：Black
Weight：315 grams
Dimensions：87x43x63 mm
7.4Battery charger
Type：Fully automatic, overcharge protection
Primary voltage：100-240 v, 50/60 Hz
Secondary voltage：12.6 Volt
Material case：Noryl
Color：Black
Weight：200 g
Dimensions：110x48x30 mm
7.5Hose
Length：1000 mm
Diameter(int)：32 mm
Connection：Bayonet couplings
Material：HDPE
8. Statutory requirements and regulations
89/686/EC: European directive for Personal protective devices
(89/686/EC).
Norm EN 12941 ：Powered filtering devices incorporating a
helmet or a hood
Norm EN 12942：Power assisted filtering devices incorporating
fill face masks, half masks or quarter masks.
Marks：CE
10.Guarantee
The supplier will repair or, if necessary, replace this product free
of charge in the event of a material or manufacturing defect
within 12 months of the purchase date, provided that the product
has only been subjected to normal usage in accordance with the
user manual. The guarantee is invalidated if the type or serial
number marking is modified, removed or made illegible.
The guarantee is subject to the PeRSo 2.0 unit being used solely
for the purpose for which is it intended. Has not been subject to
misuse, accident, modification or repair.
The guarantee does not cover normal wear and tear.
