Bayside LAGOON CTC Installation guide

V1.0- EN -WS-(08/2018)
BAYSIDE
LAGOON CTC
CEILING FAN
⚫INSTALLATION
⚫OPERATION
⚫MAINTENANCE
⚫WARRANTY INFORMATION
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION.

Lagoon CTC Fan Installation Instructions
1 | P a g e
THANK YOU FOR PURCHASING
Thank you for purchasing this quality Bayside product. To ensure correct function and safety, please read
and save all instructions before using the product.
SAFETY PRECAUTIONS
1. In Europe: This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use of the appliance in a safe way and
understand the hazards involved. Cleaning and maintenance shall not be undertaken by children
without supervision.
2. In Australia: The appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the appliance by a person responsible for their
safety.
3. Children should be supervised to ensure that they do not play with the appliance.
4. An all-pole disconnection switch must be incorporated into the fixed wiring, in accordance with local
wiring rules.
IN AUSTRALIA
WARNING:
FOR SAFE USE OF THIS FAN AN ALL-POLE DISCONNECTION
MUST BE INCORPORATED INTO THE FIXED WIRING IN
ACCORDANCE WITH THE WIRING RULES.
As outline in clause 7.12.2 of AS/NZS 60335-1 for meeting the
minimum electrical safety of this standard.
Please note warranty will be void if installation is without a means for
an all-pole disconnection incorporated in the fixed wiring in
accordance with the wiring rules.
Example: If a fan is connected to a circuit that can be isolated via an

Lagoon CTC Fan Installation Instructions
2 | P a g e
all-pole safety switch at the switchboard, then this is considered to be
an all-pole disconnection to the ceiling fan electrical circuit, meeting
the requirements of clause 7.12.2 of AS/NZS 60335.1.
A single-pole switch on the active of the receiver input of remote
control must also be included in the wiring, and located the
same room as the ceiling fan.
5. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection
facilities. Contact your local government for information regarding the collection systems available. If
electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the
ground water and get into the food chain, damaging your health and well-being.
6. The structure to which the fan is to be mounted must be capable of supporting a weight of 30kg.
7. The fan should be mounted so that the blades are at least 2.3 m above the floor in Europe or 2.1 m
above the floor in Australia.
8. This fan is suitable for indoor, alfresco and coastal areas where the fan is fully undercover with a
minimum of 1 walls. This fan is not waterproof. When installed in an alfresco or coastal area, the
ceiling fan must be positioned in a location protected from water, wind and dust. Exposure to these
elements will void the warranty. Mounting the fan in a situation where it is subject to water or moisture
is dangerous.
9. Only a licensed electrician should execute the installation.

Lagoon CTC Fan Installation Instructions
3 | P a g e
BEFORE INSTALLATION
Unpack your ceiling fan carefully. Remove all parts and hardware. Examine all parts, you should have
the following:
Fan without light
Fan with light
1
Mounting bracket x 1
1
Mounting bracket x 1
2
Pre-assembled fan motor and canopy x 1
2
Pre-assembled fan motor and canopy x 1
3
Blades x 3
3
Blades x 3
4
Wood screw x 2
4
GX53 lamp x 1
5
Motor screws for blades x 10
5
Wood screw x 2
6
Wall switch x 1 set
6
Motor screws for blades x 10
7
Wall switch x 1 set
Fig. 1

Lagoon CTC Fan Installation Instructions
4 | P a g e
INSTALLING THE MOUNTING BRACKET
•The ceiling fan must be installed in a location so that the blades are spaced 300mm from the tip of the blade
to the nearest objects or walls.
•Secure the hanging bracket to the ceiling joist or structure that is capable of carrying a load of at least 30kg,
with two long screws provided. Ensure at least 30mm of the screw is threaded into the support.
NOTE: The bracket screws provided are for use with wooden structures only. For structures other than
wood, the appropriate screw type MUST be used.
Angled ceiling Installation
This fan hanging system DOES NOT support a degree angled ceiling installation.
INSTALLING THE FAN
Blade attachment
Secure the blade on the motor by using 3 screws to tighten it, ensuring they are tightened simultaneously.
(Take care not to over tighten as this can damage blades)
Once completed, repeat the process on the remaining blades.
Fig. 2
Fig. 3

Lagoon CTC Fan Installation Instructions
5 | P a g e
Light kit installation (For fan with light)
Install the globe (included, Max. 23W, GX53) in the lamp holder.
HANGING THE FAN
•Lift the fan assembly to the mounting bracket (1) and let the J-hook (2) of the mounting bracket go through
the hole of the hanging canopy (3) and hang up the fan assembly. Fig. 5
•Connect the male and female connector together (4). Fig. 5
•Complete the electrical wiring using the diagram below (Fig.6).
Fig. 4
Fig. 5

Lagoon CTC Fan Installation Instructions
6 | P a g e
ELECTRICAL WIRING DIAGRAM
WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST BE UNDERTAKEN BY A
LICENSED ELECTRICIAN.
NOTE: AN ADDITIONAL ALL POLE DISCONNECTION SWITCH MUST BE INCLUDED IN THE FIXED
WIRING.
NOTE: Wiring diagram includes the light kit wiring. The light wiring diagram and switch is omitted
when no light kit is used with the ceiling fan.
USE WITH WALL SWITCH WIRING DIAGRAM:
USE WITH REMOTE WIRING DIAGRAM: (REMOTE sold separately)
1/ Remote without plugs
Fig. 6
Fig. 7

Lagoon CTC Fan Installation Instructions
7 | P a g e
2/ Remote with plugs
FINISHING THE INSTALLATION
•Loosen two screws (1) from the mounting bracket (5).
•Loosen two screws (2) by half thread from the mounting
bracket (5).
•Lift the hanging canopy (3) of the fan assembly up to
the mounting bracket and let the L-shape slot on the
hanging canopy go through the screws (2) on the
mounting bracket. Turn the hanging canopy until it locks
in place at the end section of the L-shape slot and
secure it by tightening the two screws (1). Avoid
damaging the electrical wiring prepared previously.
•Finally attach the canopy cover (4) to the mounting
bracket, secure it by pushing the hooks of the canopy
cover into the slot holes of the hanging canopy and turn
it anti clockwise.
Fig. 8
Fig. 9

Lagoon CTC Fan Installation Instructions
8 | P a g e
USING YOUR CEILING FAN
FAN WALL CONTROL
Turn on the power and check the operation of the fan.
• OFF Position – Fan off
• 3rd Position – Low fan speed
• 2nd Position – Medium fan speed
• 1st Position – High fan speed
Light Control
• Toggle Switch – On/off
REVERSING SWITCH
Your ceiling fan can operate in either summer or winter mode.
SUMMER Mode: The reverse switch shall be in the “Left” (SUMMER) position to make the fan rotate in an
anticlockwise direction. The airflow will be directed downwards, for cooling in summer.
WINTER Mode: The reverse switch shall be in the “Right” (WINTER) position to make the fan rotate in a clockwise
direction. The airflow will be directed upwards assisting in the circulation of warm air, for energy conservation in
winter.
Fig. 11
Fig. 10

Lagoon CTC Fan Installation Instructions
9 | P a g e
AFTER INSTALLATION
WOBBLE:
NOTE: Ceiling fans tend to move during operation due to the fact that they are mounted on a rubber grommet. If
the fan was mounted rigidly to the ceiling it would cause excessive vibration. Movement of a few centimetres is quite
acceptable and DOES NOT suggest any problem.
TO REDUCE THE FAN WOBBLE: Please check that all screws which fix the mounting bracket and down rod are
secure.
NOTE: This fan has been precision balanced at the factory and will not need to be balanced again.
NOISE:
When it is quiet (especially at night) you may hear occasional small noises. Slight power fluctuations and frequency
signals superimposed in the electricity for off-peak hot water control, may cause a change in fan motor noise. This
is normal. Please allow a 24-hour “breaking-in” period, most noises associated with a new fan disappear during this
time. Please note that this is not a product fault and as such is not covered under warranty –All electric motors are
audible to some extent.
CARE AND CLEANING:
•Periodic cleaning of your ceiling fan is the onlymaintenance required. Use a soft brush or lint free cloth to avoid
scratching the paint finish. Please turn off electricity power when you do so.
•Do not immerse your ceiling fan in the water. It could damage the motor or the blades and create the
possibility of an electrical shock.
•Ensure that the fitting does not come in contact with any organic solvents or cleaners.
•To clean the fan blade, wipe with only a damp clean cloth with NO organic solvents or cleaners.
•The motor has a permanently lubricated ball bearing so there is no need to oil.
NOTE: Always turn OFF the power at the mains switch before attempting to clean your fan.
TECHNICAL INFORMATION
Aria fan models
Rated Voltage
Rated power (motor)
Rated power lamp
52 inch blade fan only
220-240 VAC
55W
N/A
52 inch blade fan with light
220-240 VAC
55W
Max. 23W, GX53

Lagoon CTC Fan Installation Instructions
10 | P a g e
BAYSIDE CEILING FAN WARRANTY DETAIL
BAYSIDE WARRANTY HOTLINE - 1300 289 808
THIS WARRANTY IS VALID IN AUSTRALIA ONLY
In the event of service being required, please call the Bayside Fan Warranty Hotline on 1300 289 808
between 9am & 5pm (EST) Monday to Friday. Please make sure you have all the ceiling fan details filled
out at the end of the manual before making the call.
Every Bayside ceiling fan is thoroughly inspected and tested before being released for sale. In addition
to any warranty rights or conditions under statutory regulations, Bayside warrants all of its ceiling fans
against defective workmanship and faulty materials with an in-home warranty period of twenty four (24)
months from the date of purchase. Following this, an additional fourty eight months (48) part replacement
warranty applies.
Bayside undertakes, at its option, to repair or replace, free of charge, each product or part thereof on
condition that;
1. The fan or relevant part has not been subjected to misuse, neglect, or been involved in an accident.
2. The repairs are not required as a result of normal wear and tear.
3. The product was installed by a licensed electrical contractor.
4. A copy of the original receipt of purchase is presented.
5. 12 month warranty applies when used in any non-domestic applications.
6. This warranty does not cover stains, scratch and scuff marks, or dents if the product is purchased
through a factory outlet or to refurbished items.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail
to be of acceptable quality and the failure does not amount to a major failure.
Bayside design cannot be held responsible for any repair other than those carried out by it or one of its
Authorised Service Agents. Please keep this warranty information in a safe place. This information must
be produced in the event of service being required.
Distributed by:
Bayside Fans and Lighting
140 Fulton Drive, Derrimut 3026, Victoria, Australia
Ph: 1300 289 808
Email: [e-mail]

Lagoon CTC Fan Installation Instructions
11 | P a g e
CEILING FAN WARRANTY INFORMATION
BAYSIDE WARRANTY HOTLINE - 1300 289 808
Complete and retain this form for your personal records and warranty purposes.
NAME…………………………………………………………………………………
ADDRESS……………………………………………………………………………
……………………………………………………POSTCODE……………………
MODEL NUMBER……………………………………………………………………
(PO# + DATECODE Sticker here)
PO NUMBER or DATECODE ………………………………………………………
DATE OF PURCHASE………………………………………………………………
INSTALLING LICENSED ELECTRICAN……………………………………………
…………………………………………………………………………………………
LICENCE No…………………………………………………………………………
ATTACH PROOF OF PURCHASE HERE
