INSTRUCTION
MANUAL
3-Seat Converting
Outdoor Swing

As shoppers, we’re always trying
to find the perfect balance between
quality & value. At BCP, we believe
we’ve achieved that. Our diverse
catalog of everyday essentials is
tailored especially to our customers
& guaranteed to hit that sweet
spot of high quality & low price.
Always.

| 3
•Please do not exceed the weight limitations of this item.
•Do not stand on or use any part of this item as a step ladder.
•Firmly secure all bolts, screws and knobs before use.
•Reconfirm that all bolts, screws, and knobs are secure every 90 days.
•Fasten screws loosely during initial assembly. Do not firmly tighten the screws until the item is
completely assembled.
•Be aware that some parts are heavy and have sharp edges.
•If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void
the product warranty.
HARDWARE
TOOLS REQUIRED
UP TO 60 MIN.
ASSEMBLY
2 PERSON
ASSEMBLY
750 LBS
CAPACITY
LBS
KNOB
12
2 PCS
SPRING HOOK
10
2 PCS
1
2 PCS
M8 x 100mm
BOLT SET
M8 x 95mm
BOLT SET
2
4 PCS
M6 x 60mm
BOLT SET
4
6 PCS
M6 x 40mm
BOLT SET
5
4 PCS
6
4 PCS
M6 x 35mm
BOLT SET
M6 x 30mm
BOLT SET
2 PCS
8
NUT CAP
9
24 PCS
M6 x 32mm
SCREW
7
6 PCS
M8 x 75mm
BOLT SET
3
2 PCS
11
2 PCS
SPACER
Please retain these instructions for future reference.
NOTICE
WRENCH
(PROVIDED)
ALLEN WRENCH
(PROVIDED)

4|
D
2 PCS
LEG SUPPORT
PARTS
1 PC
TOP BAR
A
2 PCS
FRONT LEG
B
1 PC
MIDDLE SUPPORT
F
E
1 PC
BACK SUPPORT
2 PCS
BACK LEG
C
J
1 PC
RIGHT SEAT FRAME
1 PC
FRONT SWING FRAME
G
1 PC
BACK SWING FRAME
H
1 PC
SEAT
L
K
4 PCS
SWING ARM
1 PC
LEFT SEAT FRAME
I

| 5
P
3 PCS
CUSHION
PARTS
2 PCS
LOWER CANOPY
FRAME
M
2 PCS
UPPER CANOPY
FRAME
N
1 PC
CANOPY
O
PRODUCT ASSEMBLY
1Insert a part B front leg into the part A top bar. Attach a part C back leg with a part 1 bolt set
and two part 2 bolt sets. Repeat on the other side.
Place a part 9 nut cap on every nut.
1
B
BC
C
A
1
2
2
9x6

6|
PRODUCT ASSEMBLY
2Attach a part D leg support and one side of the part E back support to the legs with three part
4 bolt sets. Repeat on the other side.
NOTE: The leg support and back support share a part 4 bolt set.
Attach the part F middle support with two part 8 bolt sets, one on each side.
Place a part 9 nut cap on every nut.
9x8
8
8
x6
D
D
F
E
4
3Attach the part I left seat frame to the part G front swing frame and part H back swing frame
with two part 6 bolt sets. Repeat on the other side to attach the part J right seat frame.
Attach four part K swing arms with four part 5 bolt sets.
Secure the top of the swing arms with two part 10 spring hooks.
x4
G
H
K
I
5x4 J9x8
x2
10
6x4

| 7
4Insert the part L seat into the clamps on the back swing frame. Attach the seat with two part 3
bolt sets and two part 11 spacers.
Place a part 9 nut cap on every nut.
PRODUCT ASSEMBLY
L
x2
x2
x2
11
3
9H
L
5Hang the swing by inserting the spring hooks into the designated holes on the top bar.

8|
6
7
Slide a part M lower canopy frame into the slots on the part O canopy.
Within the canopy, attach a part N upper canopy frame with three part 7 screws. Repeat on the
other side.
Secure the canopy to the swing with two part 12 knobs, one on each side.
Place three part P cushions.
PRODUCT ASSEMBLY
x2
x3
x2
x2
x6
M
N
O
712
P

CONVERTING THE SWING
Pull the seat up from the clamps on the back swing frame. Lay the seat flat while sliding the support arm
into the designated slots on the rear of the swing.
