BCP SKY3992 User manual

SKY3992
Ver. 2
INSTRUCTION
MANUAL
Utility Kitchen Cart with Storage

Pg. 2
Thank you for choosing us! Since 2002, Best
Choice Products has been bringing customers
high-quality products at the absolute lowest
price. With everything ranging from instruments
and toys to furniture and outdoor, we’ve got
your everyday living essentials covered. We’re
centered around a customer-first philosophy –
with free shipping, exceptional customer
service, and a catalog sourced with you in mind.

Pg. 3
HARDWARE
A
30 PCS
M6 x 35mm
CAM BOLT
M10 x 15mm
CAM LOCK
M6 x 30mm
DOWEL
B
30 PCS
C
12 PCS
TOOLS REQUIRED
APPROXIMATELY
60 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
PHILLIPS
SCREWDRIVER 300 LBS
CAPACITY
LBS
M3 x 12mm
SCREW
D
52 PCS
•Please do not exceed the weight limitations of this item.
•Do not stand on or use any part of this item as a step ladder.
•Firmly secure all bolts, screws and knobs before use.
•Reconfirm that all bolts, screws, and knobs are secure every 90 days.
•Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
•If any parts are missing, broken, damaged, or worn, stop using this item until repairs are made and/or
factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
•To wipe down the furniture, use a damp cloth. Then, wipe it down once more with a dry cloth.
NOTICE Please retain these instructions for future reference.
F
2 SETS
SLIDER (L/R) HANDLE M4 x 20mm
SCREW
G
6 PCS
H
12 PCS
4 x 35mm
SCREW
I
6 PCS
K
16 PCS
M4 x 12mm
SCREW
M4 x 35mm
SCREW
HINGE
L
4 PCS
M
8 PCS
METAL PLATE
N
4 PCS
P
2 PCS
MAGNET M3 x 14mm
SCREW
Q
4 PCS
M4 x 30mm
SCREW
E
8 PCS
LOCKING CASTER
J
4 PCS
PEG
O
8 PCS
F1
F2

Pg. 4
1 PC
TABLETOP
1 PC
LEFT SIDE
2 PCS
MIDDLE DIVIDER
5
1 PC
BOTTOM
PARTS
12
7
6
2 PCS
DRAWER SUPPORT
CENTER
3
2 PCS
BACK
2 PCS
DRAWER BOTTOM
2 PCS
LEFT DOOR
13
2 PCS
RIGHT PANEL
910
15
14
2 PCS
BACK PANEL
FRONT PANEL
11
2 PCS
SHELF
8
RIGHT SIDE
4
2 PCS
RIGHT DOOR
16
LEFT PANEL
12
17
2 PCS
TOWEL RACK
1 PC 1 PC
2 PCS 2 PCS

PRODUCT ASSEMBLY
2
F1
D
x2
3
F1
D
x4
x2
4
F1
D
x2
3Attach a F1 railing from a slider set to the
part 4 right side with two part D screws.
2
1Attach a F1 railing from a part F slider set to the part 2 left side with two part D screws.
Attach two F1 railings from the slider
sets to the part 3 center piece with
four part D screws. Attach one railing
on each side.
Pg. 5

5
Repeat to attach a part 6 drawer support and
part 7 middle divider to the other side of the
part 3 center piece and the part 4 right side.
4
Attach a part 6 drawer support to
the part 2 left side and part 3
center piece with four part A cam
bolts and four part B cam locks.
Attach a part 7 middle divider with
four part A cam bolts and four part
B cam locks.
2
6
A
x8
x8
B
7
3
6
x8
B
7
A
x8
4
3
PRODUCT ASSEMBLY
8
Pg. 6

7Attach the part 5 bottom piece with six part I screws and six part C dowels.
6Attach two part P magnets to the drawer supports with four part Q screws.
5
Ix6
C
x6
P
Q
x4 x2
PRODUCT ASSEMBLY
Pg. 7

9x2
9Stand the cart upright and slide in two part 9 back pieces.
8Attach four part J casters with sixteen part K screws, four screws per caster.
x4
K
x16
J
PRODUCT ASSEMBLY
Pg. 8

11 Attach a part G handle to a
part 15 left door with two
part H screws. Attach a
part N metal plate with a
part D screw. Repeat to
attach handles/metal plates
to another part 15 left door
and two part 16 right doors.
10 Attach the part 1 tabletop with
six part A cam bolts, six part C
dowels, and six part B cam
locks. Turn the cam locks to
secure the tabletop.
x6
x6
x6
1
B
A
C
D
x4
G
x4
15
N
x4
H
x8
x2
16 x2
PRODUCT ASSEMBLY
Pg. 9

Attach a part 15 left door and part 16 right door
with eight part D screws, two screws per hinge.
Repeat to attach the other set of doors.
Attach two part 17 towel racks with four part L
screws, two screws per rack.
13
14 Insert eight part O pegs into
the interior of the cart, then
slide in two part 8 shelves.
8
x2
O
x8
L
x4
17
x2
Dx16 16
15
x2
x2
Attach eight part M hinges
to left/right doors with
sixteen part D screws, two
screws per hinge.
12
PRODUCT ASSEMBLY
Pg. 10
D
x16
Mx8
