BCP SKY3993 User manual

SKY3993Ver. 2
Mobile Kitchen Island Cart
INSTRUCTION
MANUAL

As shoppers, we’re always trying
to find the perfect balance between
quality & value. At BCP, we believe
we’ve achieved that. Our diverse
catalog of everyday essentials is
tailored especially to our customers
& guaranteed to hit that sweet
spot of high quality & low price.
Always.

I
Please retain these instructions for future reference.
HARDWARE
A
15 PCS
CAM BOLT CAM LOCK DOWEL
B
15 PCS 18 PCS 12 PCS
CM6 X 60MM
BOLT
D
E
12 PCS
ANCHOR NUT MAGNETIC
CATCH
M4 X 8MM
SCREW
F
1 PC
G
4 PCS
HANDLE
H
2 PCS
2 PCS 2 PCS
LOCKING
CASTER
CASTER M4 X 35MM
SCREW
J K
2 PCS
M4 X 30MM
SCREW
L
4 PCS
TOOLS REQUIRED
UP TO 60 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
PHILLIPS
SCREWDRIVER
300 LBS
CAPACITY
LBS
NOTICE
• Please do not exceed the weight limitations of this item.
• Do not stand on or use any part of this item as a step ladder.
• Firmly secure all bolts, screws, and knobs before use.
• Reconfirm that all bolts, screws, and knobs are secure every 90 days.
• Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
• If any parts are missing, broken, damaged, or worn, stop using this item until repairs are made and/or
factory replacement parts are installed.
• Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
M
19 PCS 1 PC
M3 X 12MM
SCREW
METAL PLATE
NHINGE O
2 PCS
SHELF PEG
P
4 PCS
I
FLAT HEAD
SCREWDRIVER

4|
PARTS
Q
1 PC 1 PC
OUTER
RAILING (L)
INNER
RAILING (R)
ROUTER
RAILING (R)
S
1 PC
INNER
RAILING (L)
T
1 PC
HARDWARE
4
1 PC
DIVIDER
1 PC
TABLETOP
1
1 PC
LEFT SIDE
2
1 PC
SHELF I
6
5
1 PC
BOTTOM PANEL
7
1 PC
SLOTTED SHELF
1 PC
BACK SUPPORT
9
8
1 PC
SHELF II
1 PC
RIGHT SIDE
3

PARTS
13
1 PC
TOWEL RACK
1 PC
FRONT SUPPORT
10
1 PC
LEFT ARM
11
1 PC
DRAWER FRONT
15
14
1 PC
DOOR
16
1 PC
DRAWER LEFT
1 PC
DRAWER BACK
18
17
1 PC
DRAWER RIGHT
19
1 PC
DRAWER BOTTOM 20
1 PC
BACK PANEL
1 PC
RIGHT ARM
12
| 5

PRODUCT ASSEMBLY
1
2Attach two part O hinges to part 14 door with four part M screws. Attach part N metal
plate with a part M screw.
Screw six part A cam bolts into the part 1 tabletop. Screw a cam bolt into the part 10
front support.
TIGHTENING CAMLOCKS
1. Screw cam bolt
in completely.
2. Insert cam bolt and cam lock into
designated holes.
3. Screw cam lock
clockwise to secure
cam bolt.
6|
x5
M
x7
A
x2
O
N
1
10
14

PRODUCT ASSEMBLY
Screw two part A cam bolts into the part 4 divider. Attach part S outer railing (right) with two
part M screws.
3
PRODUCT ASSEMBLY
4Place the part 13 towel rack between the part 11 and 12 arms. Attach the arms to the part 2
left side with two part C dowels, two part D bolts, and two part E anchor nuts.
4
USE THESE HOLES
S
x2
A
x2
D
4
13
11
12
2
x2
M
x2
E
x2
C
| 7

PRODUCT ASSEMBLY
Flip the part 2 left side over. Screw two part A cam bolts into the left side. Attach part Q outer
railing (left) with two part M screws.
5
6Attach the part 16 and part 17 drawer sides to part 18 drawer back with four part L screws. Slide
in part 19 drawer bottom.
USE THESE HOLES
16
18
19
17
x2
M
Q
2
x4
L
x2
A
8|

PRODUCT ASSEMBLY
Screw four part A cam bolts into part 15 drawer front. Attach the drawer front with four part B
cam locks.
7
8Attach a part H handle with two part G screws. Attach part R and part T inner railings with four
part M screws.
H
R
T
15
Ax4
x2
B
x2
G
15
M
x4 Flip drawer over
to attach railings.
| 9

PRODUCT ASSEMBLY
Attach part 9 back support and part 10 front support with three part B cam locks.
Attach part 5 bottom panel with two part C dowels and two part K screws.
9
10 Attach part 6 shelf with two part D bolts and two part E anchor nuts. Attach part 7 slotted shelf
with two part C dowels.
x3
B
x2
K
x2
C
x2
C
x2
E
6
7
10
9
5
x2
D
