BD ALARIS 8015 Installation and operating instructions

January 2018
DME: 10000318809-00
Part Number: P00000272
BD Alaris™System User Manual Addendum
For BD AlarisTM PC Unit, Model 8015 and BD AlarisTM Pump Module,
Model 8100

BD AlarisTM System User Manual Addendum
The information in this document is subject to change and does not represent a
commitment on the part of CareFusion to provide additional services or
enhancements. The screens illustrated in the document are for reference purposes
only and might be different than the screens displayed on your computer.
Documentation provided with this product might reference product not present in
your facility or not yet available for sale in your area.
If difficulties are encountered while using this software, refer to the user manual,
service manual, or related service bulletin(s) before contacting CareFusion.
Provide a description of the difficulty experienced, any messages that were
displayed at the time of the difficulty, and the software version. Before you return
the software to CareFusion, contact CareFusion to get a return authorization
number. Put the software in its original packaging (if available), write the return
authorization number on the package, and return to the nearest facility.
For countries not listed below, contact your local Alaris System distributor for
technical support.
North America
Customer Advocacy - North America
(Clinical and technical feedback.)
Phone: [phone]
E-mail: [email protected]
Customer Order Management - North America
(Product return, service assistance, and order placement.)
Phone, United States: 800.482.4822
Phone, Canada: 800.387.8309
Technical Support - North America
(Maintenance and service information support; troubleshooting.)
Phone, United States: 888.812.3229
Phone, Canada: 800.387.8309
Note: The BD Alaris PC Unit and Pump Module described in this User Manual
Addendum are available in North America.
© 2018
CareFusion Corporation or
one of its affiliates. All
rights reserved.
BD, the BD Logo and all
other trademarks are
property of Becton,
Dickinson and Company
CareFusion, the
CareFusion logo, and
Alaris are trademarks of
CareFusion Corporation or
one of its affiliates.
All other trademarks are
the property of their
respective owners.
CareFusion
10020 Pacific Mesa Blvd.
San Diego, CA 92121,
United States
888-876-4287
www.carefusion.com

Purpose of Addendum
BD Alaris System User Manual Addendum 3
BD Alaris™ PC Unit, Model 8015
and BD Alaris™ Pump Module,
Model 8100
Purpose of Addendum
This Addendum contains information specific to the BD Alaris™ PC Unit (BD Alaris™ PCU) and BD
Alaris™ Pump Module.
See your Alaris System User Manual for all other information for using your PC unit and Pump module.
NOTE:
The BD Alaris PC unit is also referred to as BD Alaris PCU.
Warning
Product-specific warnings, covered in the applicable sections of this addendum, provide information
needed to safely and effectively use the BD Alaris System.
BD Alaris PC Unit Enhancements
This section provides an overview of the following features of the BD Alaris PC unit:
• High contrast, illuminated keypad provides visibility in low-light environments
• Backlighting the Options key and Silence key make finding the keys easy in low-light environments
• Keys with squared, raised-edges provide large touchpoints
A statement that alerts the user to the possibility of injury, death, or other serious adverse
reactions associated with the use or misuse of the device.

BD Alaris™ PC Unit, Model 8015 and BD Alaris™ Pump Module, Model 8100
4BD Alaris System User Manual Addendum
Enhanced,
high-contrast
keypad
Squared,
raised-edged keys
BD Branding
Silence and
Options key
back-lighting
Updated color
scheme and
design

BD Alaris System User Manual Addendum 5
BD Alaris™ Alaris Pump Module,
Model 8100
This section provides an overview of the Pump module:
Features of the Pump Module
• High contrast, illuminated keypad provides visibility in low-light environments
• Squared, raised-edge keys provide large touchpoints
Inside the Door
• Beveled upper guide
• Set loading guide “Load First” graphic reinforces the placement of the administration set into the
upper fitment as the first step of set loading
• Tubing Guide Arm secures the administration set in place within the Air-in-line detector
NOTE:
Follow set loading instructions found in the Alaris System User Manual.

BD Alaris™ Alaris Pump Module, Model 8100
6BD Alaris System User Manual Addendum
High-contrast,
illuminated keys
Updated color
scheme and design
BD Branding
Squared, raised-edged
keys

BD Alaris System User Manual Addendum 7
NOTE:
There are no changes to set loading, door closure, or latching.
Ensure that the Tubing Guide Arm is not missing and that it opens when the Pump module
door opens. A Tubing Guide Arm failure can result in a nuisance air-in-line alarm. If there is a
failure, send the Pump module to CareFusion for repair
.
Load First text
Reinforces the
placement of the
administration set
into the upper
fitment as the first
step of set
loading.
Enhancement of
upper tubing
fitment
Enhancement of
upper tubing fitment
to support set
loading
Air-in-Line
Detector
Tubing Guide Arm
This feature secures
the administration set
in place within the Air-
in-line detector

BD Alaris™ Alaris Pump Module, Model 8100
8BD Alaris System User Manual Addendum
NOTES:
