BE Ag & Industrial AGRI EASE DIAMOND HARROW HAR60S User manual

DIAMOND HARROW
HAR60S
ASSEMBLY INSTRUCTIONS
FOR MODELS:
• HAR60S
PURCHASE DATE MODEL NO. DEALER

HAR60S ASSEMBLY INSTRUCTIONS 1
PARTS LIST
A. 2x - 2 Hole Beam
B. 2x – 3 Hole Beam
C. 4x – 5 Hole Beam
D. 5x – 5 Hole Beam (Short)
E. 2x – 4 Hole Beam
F. 2x – Hook Bar
G. 2x – Hook Assembly
H. 30x – Tine, Washer, & Nut
G
H
H
Parts
1. 1x Part A
2x Part D
2x Part H
A
ASSEMBLY INSTRUCTIONS
Instructions
Fasten Part A to the ends of Parts D, using H parts as shown.
A
A
B
C
D
D
E
F
H
*Recommended tools: 22 mm & 16 mm spanners
or 7/8” and 5/8” spanners

2 HAR60S ASSEMBLY INSTRUCTIONS
2. 1x Part F
1x Part G
1x Part H
3. 1x Part B
1x Part H
Parts Instructions
Fasten Part F to smaller hole using Part G, then using Part H
hold the other side in place, as shown.
Ensure that Part G and F are assembled correctly, as shown in
close-up photo.
Instructions
Fasten Part B using Part H to assembly, as shown
G
H
H
B
F
H
G
H
B
Parts

HAR60S ASSEMBLY INSTRUCTIONS 3
4. 1x Part C
2x part H
Instructions
Fasten Part C using H parts to assembly, as shown
C
D
H
H
C
H
5. 1x Part D
2x part H
Instructions
Fasten Part D using H parts to assembly, as shown
H
Parts
Parts

4 HAR60S ASSEMBLY INSTRUCTIONS
6. 1x Part C
3x Part H
7. 1x Part C
3x Part H
C
C
H
H
Instructions
Fasten Part C using H parts to assembly, as shown
Instructions
Fasten Part C using H parts to assembly, as shown
C
C
H
H
Parts
Parts

HAR60S ASSEMBLY INSTRUCTIONS 5
D
D
H
H
8. 1x Part D
3x Part H
9. 1x Part D
3x Part H
Instructions
Fasten Part D using H parts to assembly, as shown
Instructions
Fasten Part D using H parts to assembly, as shown
D
H
D
H
Parts
Parts

6 HAR60S ASSEMBLY INSTRUCTIONS
10. 1x Part F
1x Part G
1x Part H
11. 1x Part C
4x Part H
Instructions
Fasten Part C using H parts to assembly, as shown
G
H
F
Instructions
Fasten Part F to smaller hole using Part G, then using Part H
hold the other side in place, as shown.
Ensure that Part G and F are assembled correctly, as shown in
close-up photo.
G
C
H
C
H
Parts
Parts

HAR60S ASSEMBLY INSTRUCTIONS 7
12. 1x Part B
3x Part H
13. 1x Part A
2x Part H
Instructions
Fasten Part B using H parts to assembly, as shown
Instructions
Fasten Part F using H parts to assembly, as shown
B
H
Parts
Parts
H
A
H
H

8 HAR60S ASSEMBLY INSTRUCTIONS
14. 1x Part E
E
E
E
Instructions
Loosen and remove nuts shown, then add part E to assembly
as shown. Tighten nuts to assembly, once part E is added
Instructions
Loosen and remove nuts shown, then add part E to assembly
as shown. Tighten nuts to assembly, once part E is added
15. 1x Part E
E
Parts
Parts

HAR60S ASSEMBLY INSTRUCTIONS 9
