BE PCD1450 User manual

POLY CARPET DRYER
OWNER’S MANUAL
Model: PCD1450
AIR COMPRESSOR
OPERATORS MANUAL
Version 5.1
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
INSTRUCTION MANUAL
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
POLY CARPET DRYER
.0%&-PCD1450

Page 1
POWER EQUIPMENT
POWER EQUIPMENT
PCD1450 OWNER’S MANUAL
READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS
BEFORE USING THIS AIR MOVER
 WARNING!Toreducetheriskofre,electricshock,orinjury:
1. Read the manual carefully and completely before attempting to operate the
unit. This manual has important information for the use and safe operation
of the machine. Following the recommendations outlined in this manual will
assure years of satisfactory service from your unit.
2. Improper connection of the equipment grounding conductor can result in a
risk of re, electrical shock or personal injury. Always use a three-wire elec-
trical system connected to the electrical ground. For maximum protection
against electrical shock, use a circuit that is protected by a ground fault circuit
interrupter. Check with a qualied electrician or service person if you are in
doubt as to whether your outlet is properly grounded. Do not use a unit with a
damaged cord or plug.
3. Machines can cause an explosion when near ammable materials and va-
pors. Do not use or store this machine with or near fuels, grain dust, solvents,
thinners, or other ammable materials. Do not use ammables to clean this
machine.
4. Do not immerse or use this unit in standing water. Such use may cause elec-
trical shock. To avoid electrical shock, do not expose the unit to rain - store it
indoors only. Do not expose the unit to freezing temperatures.
5. Do not move or carry the unit when it is turned on. Do not pull or carry by the
cord, use cord as a handle, close a door on the cord or pull cord around sharp
edges or corners. Keep cord away from heated surfaces. Do not unplug cord
by pulling on it. To unplug, grasp plug, not the cord. Do not handle plug or air
mover with wet hands.
6. Do not put any objects into openings. Do not use with any opening blocked;
keep free of dust, lint, hair and anything that may reduce air ow. Keep hair,
loose clothing, ngers and all parts of the body away from openings and mov-
ing parts.
7. Turn off all controls before unplugging.
8. Operate unit on a level and stable surface to prevent it from falling and possi-
ble cause of injury or damage.
9. Do not drop or throw the unit. Treatment of this type can cause damage to the
components and create hazardous conditions.
OPERATION:
Plug your air mover into a standard grounded outlet with the correct voltage and
amperage. If you are unsure about the outlet, contact your supervisor. Turn on the
switch and check that the unit operates properly before letting it run.
I. Safety Signs and Precautions
Meaning and identification of signs
Please read the safety signs and precautions carefully before using the machine.
Danger
Incorrect use while ignoring the sign may cause casualty
accident, fire, and other property losses.
Warning
Incorrect use while ignoring the sign may cause casualty
accident, fire, and other property losses.
Forbidden
The sign indicates actions that are forbidden.
Constraint
The sign indicates constraint and instruction.
Attention
The sign indicates and urges to notice the contents.

Page 2
POWER EQUIPMENT
POWER EQUIPMENT
PCD1450 OWNER’S MANUAL
MAINTENANCE:
Inspect the electrical cord and wiring for damage or discoloration
Inspect for loose fasteners
Clean screens on the side and front of the unit
Listen for abnormal sounds
Keep unit clean
PERIODIC MAINTENANCE:
Use compressed air or a vacuum to remove lint and other debris from the motor,
screen and blower wheel. Do not use a pressure washer to clean the unit.
READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS
BEFORE USING THIS AIR MOVER!
!
Page 2
VOLTS
POWER
CYCLE
MAX AIR VOLUME
AMPS LOW/MID/HIGH SPEEDS
WEIGHT
SIZE L/W/H
SPEED
CORD LENGTH
240V
3/4HP
50Hz
1200/1300/1400CFM
2.0/2.2/3.0AMPS
13.5KGS
46x42x47cm
3 SPEEDS
4.5M

Page 3
POWER EQUIPMENT
POWER EQUIPMENT
PCD1450 OWNER’S MANUAL
GROUNDING INSTRUCTIONS:
This machine must be grounded. If it should malfunction or break down,
grounding provides a path of least resistance for electric current to reduce the
risk of electric shock. This machine is equipped with a cord having an equipment-
grounding conductor and grounding plug. The plug must be inserted into an
appropriate outlet that is properly installed and grounded in accordance with all
local codes and ordinances.
TROUBLESHOOTING:
Problem Cause Solution
Unit will not run.
1. No power to nuit.
2. Switch not on.
3. Switch is faulty.
4. Faulty/broken cord or
motor wire
1. Plug unit in. Check
circuit breaker.
2. Place in “ON” position.
3. Replace switch.
4. Perform continuity
check, using volt/amp
meter. Repair/replace
faulty broken wire.
Unit runs but air mover
makes loud scraping
noise.
1. Unit has been severely
jolted causing blower
wheel to rub against
housing.
2. Unit has been severely
jolted causing housing to
deform.
1. Remove motor and
replace damaged motor
mounts.
2. Replace blower wheel.
Unit runs but vibrates
excessively.
1. Severe jolt has bent
motor shaft causing unit
to be out of balance.
2. Air mover blade
damaged.
3. Dirt build up on one
side of air mover blade.
1. Remove and replace
motor.
2. Replace blade if
necessary.
3. Clean air mover blade.
Unit runs but blower
wheel does not turn.
1. Motor bearings are
failing or motor has
developed an internal
electrical fault.
2. Intake grill and/or
exhaust grill is obstructed.
3. Excessive duct length.
1. Replace motor.
2. Remove obstruction.
3. Reduce duct length to
recommended maximum

Page 4
POWER EQUIPMENT
POWER EQUIPMENT
PCD1450 OWNER’S MANUAL
Page 4
1
1
1
1
3
3
1
1
2
2
9
9
1
1
1
1
8
8
1
1
6
6
1
1
4
4
1
1
3
3
4
4
5
5
2
2
7
7
1
1
1
1
1
1
0
0
1
1
5
5
ref# ref#
2
3
4
5
1on/off rocker switch,blk
on/off rocker switch,cap
strain relief-lq tight
power cord
screw
qty
12
qty
1
1
1
1
Comet Blower
6
7
8
nut,hex
front guard
AC motor
1
1
1
9
10 housing - blower
rubber foot
1
2
11
12 rivet
blower wheel,cage
8
1
13
14
15
guard,intake
motor control panel
gfci outlet,female plug
1
1
1
descriptiondescription

Distributed in Australia by
CONTACT DETAILS
B.A.R Group P/L
15 Hudson Place,
Mulgrave, NSW, Australia 2756
Phone: [phone]
www.bargroup.com.au
Distributed in New Zealand by
CONTACT DETAILS
BE Pressure Supply
541D Te Rapa Road, Te Rapa,
Hamilton 3200, New Zealand
Phone: [phone]
www.bepressure.co.nz
Errors and omissions excepted.
Specications and performance may change.
Version 5.1; 2021
