BEAMEX MC5-IS User manual

User Guide
Fieldbus Option for
PROFIBUS PA

3
User Guide
Fieldbus Option for
PROFIBUS PA
Dear user,
We have made every effort to ensure the accuracy of the contents of
this manual. Should any errors be detected, we would greatly appre-
ciate to receive suggestions to improve the quality of the contents of
this manual.
The above notwithstanding, we can assume no responsibility for any
errors in this manual or their eventual consequences.
We reserve rights to make modifications to this manual without any
further notice.
For more detailed technical data about MC5-IS Intrinsically Safe Cali-
brator, please refer to MC5-IS User Guide or contact the manufactur-
er.
© Copyright 2009
BEAMEX OY AB
Ristisuonraitti 10
68600 Pietarsaari
FINLAND
Tel +358 - 10 - 5505000
Fax +358 - 10 - 5505404
E-mail: [email protected]
Internet: http://www.beamex.com
8822800 / UEMC5-IS-PA / 001139

4
Trademarks
QCAL®is a registered trademark owned by Beamex Oy Ab.
PROFIBUS®is a registered trademark of PROFIBUS International.
FOUNDATION™ Fieldbus is a registered trademark of the Fieldbus Foundation.
HART®is a registered trademark of the HART Communication Foundation.
Other trademarks are property of their respective owners.

5
Contents
General ......................................................................................................... 1
What is Fieldbus................................................................................................. 2
Unpacking and Inspection .................................................................................. 2
Batteries ............................................................................................................. 3
Charging the Batteries ................................................................................. 3
Disposal of Waste Electrical and Electronic Equipment ..................................... 4
Safety ................................................................................................................. 5
Symbols Used.............................................................................................. 5
Ex Information and Approvals ...................................................................... 5
Notes and Warnings .................................................................................... 8
Service ............................................................................................................. 10
Cleaning FI5-IS .......................................................................................... 10
The Battery Charger .................................................................................. 10
Terminology...................................................................................................... 11
MC5-IS, FI5-IS and PROFIBUS PA ................................................................. 12
Calibration Procedure of a Fieldbus Instrument, General .......................... 12
Device Descriptions.......................................................................................... 14
Viewing Device Descriptions in MC5-IS..................................................... 14
Device Description Sender......................................................................... 15
Fieldbus Instruments and Beamex's Calibration Database Software ............... 16
Connecting to a PROFIBUS PA Instrument............................................ 17
Connections ..................................................................................................... 18
Fieldbus and MC5-IS' Basic Mode ........................................................... 19
Connecting to a PROFIBUS PA Instrument ..................................................... 19
Fieldbus Window Setup Menu.......................................................................... 22
Disconnect Device ..................................................................................... 22
Device Information ..................................................................................... 22
Transducer Block Information .................................................................... 23
Target Mode............................................................................................... 24
Select Output ............................................................................................. 24
Trim Fieldbus Device ................................................................................. 24
Add a Fieldbus Device to Database........................................................... 25
Unit ............................................................................................................ 27
Performing a Verifying Calibration.......................................................... 28
Selecting the Instrument................................................................................... 28
Doing the Verifying Calibration......................................................................... 29
Calibrating (Trimming, Adjusting) a Fieldbus Instrument.................................. 30

6 General
Fieldbus Communication Settings .......................................................... 33
Appendix 1, Codes in Profibus PA Profile Version 3.0.......................... 34
Appendix 2, Codes in Profibus PA Profile Version 2.0.......................... 39
Notes........................................................................................................... 41

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
General 1
General
FI5-IS Intrinsically Safe Fieldbus Interface allows you to ca-
librate Intrinsically Safe PROFIBUS PA fieldbus instruments.
All you need is a fieldbus compatible MC5-IS and a FI5-IS
suited for your fieldbus type.
The MC5-IS/FI5-IS for PROFIBUS PA features listed below
are presented in more detail further on in this manual.
Takes the role of PROFIBUS Master when connecting to
PROFIBUS segment.
Capability to read and edit the instrument Tag.
Read and assign the instrument Node Address.
Read and edit the Transducer Block parameters.
Device Descriptions supported.
Note.
MC5-IS/FI5-IS does not support Device Description Me-
thods.
FI5-IS is Intrinsically Safe when used together with
MC5-IS only.

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
2 General
What is Fieldbus
Fieldbus is an industrial digital communications network specif-
ically designed for process automation use. It is meant to re-
place the existing standard 4 … 20 mA analog signal.
Fieldbus technology has been around since late 80's, but de-
veloping an international standard took a long time. There still
are several different types of fieldbus implementations, but
some of them have become more dominant than others. The
two most widely spread types are:
PROFIBUS (www.profibus.com/pb/profibus/process/).
FOUNDATION Fieldbus (www.fieldbus.org/) and
Both are based on IEC fieldbus standard, 61158.
Unpacking and Inspection
At the factory each new FI5-IS passes a careful inspection. It
should be free of scrapes and scratches and in proper opera-
tion order upon receipt. The receiver should, however, inspect
the unit for any damage that may have occurred during transit.
If there are signs of obvious mechanical damage, package
contents are incomplete, or the instrument does not operate
according to specifications, contact the purchasing sales office
as soon as possible. The standard accessories are as follows:
A warranty card,
a Declaration of Conformity,
this User Guide,
a separate multi-lingual booklet entitled
“FI5-IS Safety Information”,
MC5-IS - FI5-IS communication cable,
FI5-IS cable (fieldbus communication test leads),
fieldbus resistor for FI5-IS and
battery charger, type BC09-IS.

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
General 3
Batteries
The rechargeable battery inside FI5-IS provides supply power
to the communication between MC5-IS and FI5-IS.
With fresh, fully charged batteries, FI5-IS may be used for ap-
prox. 10 hours without recharging. To save batteries, discon-
nect the fieldbus cables when FI5-IS is not used. When the
front panel light is not visible, there is a minimal load on the
batteries.
Use the battery charger, BC09-IS for charging the batteries.
Using other chargers may put the safety at risk.
Charging the Batteries
The charger, BC09-IS, for rechargeable batteries operates in
the following environments:
- Voltage: 100 … 240 VAC
- Frequency: 50/60 Hz
The charging time is 16 hours. When taking FI5-IS into use for
the first time, fully charge FI5-IS batteries (16 hours).
Warnings!
USE CHARGER IN SAFE AREA ONLY. The casing of the
charger is not IS-compliant.
USE ONLY THE CHARGER PROVIDED WITH FI5-IS.
The charger should only be used indoors and when charging,
the environment temperature should be between 0 … +35 °C
(32 … 95 °F).
See also General Warnings on page 8.
Front Panel Light
The light on the front panel of FI5-IS is red while charging.
When not charging, fieldbus cables are connected and fieldbus
power for FI5-IS is available, the light is green.
If FI5-IS battery is almost empty, the green light is dimmed. If
battery is completely discharged, the green light is not visible.
Note.
Although the led is lit (green), communication is not in-
itiated until MC5-IS is connected to FI5-IS.

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
4 General
Disposal of Waste Electrical and Electronic Equipment
Beamex is an environmentally conscious company developing
products with a view to ensure that they are easy to recycle
and do not introduce hazardous materials into the environ-
ment.
In the European Union (EU) and other countries with separate
collection systems, waste from electrical and electronic equip-
ment (WEEE) is subject to regulations.
EU WEEE Directive 2002/96/EC (the WEEE Directive) re-
quires that producers of electronic equipment are responsible
for the collection, reuse, recycling and treatment of WEEE
which the Producer places on the EU market after August 13,
2005. The objective of this regulation is to preserve, protect
and improve the quality of the environment, protect human
health, and conserve natural resources.
The symbol on the left is also printed on the prod-
uct's sticker. It indicates that this product should be
handed over to applicable collection point for the re-
cycling of electrical and electronic equipment.
For more detailed information about recycling of this product,
please contact your local representative or your waste disposal
service.

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
General 5
Safety
Symbols Used
The following symbols concerning electrical safety are used in
FI5-IS.
Caution! See manual for further information
Ex Information and Approvals
Please read the separate leaflet shipped with FI5-IS entitled (in
English) Safety Information for Beamex MC5-IS Intrinsically
Safe Multifunction Calibrator. The leaflet includes the same
safety information in several languages.
Ex Approvals:
ATEX IEC
Ex ib [ia] IIC T4
(Tb = -20 … 50°C)
VTT 09 ATEX 005X
Ex ib [ia] IIC T4
(Tb = -20 … 50°C)
IECEx VTT 09.0001X
0537

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
6 General
Special Conditions for Safe Use
Opening FI5-IS voids safety and warranty, if it is valid.
The permissible ambient temperature range is
-20 °C Ta+50 °C..
The battery shall not be charged on a hazardous location.
Use only Beamex charger type BC09-IS for charging. The
charger shall not be used in a hazardous location.
The surface of FI5-IS contains light metal, so the user shall be
aware of possible impact or friction sparks when using this de-
vices.
The connection cables are non-conducting material, so the us-
er shall be aware of dangers of ignition due to hazardous elec-
trostatic charges.
Due to electrostatic discharge hazard, do not affix any stickers
larger than 4 cm2(0.62 in2) to FI5-IS.

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
General 7
Input Parameters
Fieldbus terminals
Ui Ii Pi Ci Li
Maximum values,
Non-FISCO 24 V DC 250 mA 1.2 W 0 0
Maximum values with
FISCO, IEC 60079-27 17.5 V DC
250 mA 1.2 W 0 0
MC5-IS connection
Ui Ii Pi Ci Li
Maximum values 14 V DC 60 mA 0.8 W 0 0
Output Parameters
Fieldbus terminals
Uo Io Po
Maximum values,
Non-FISCO 0 0 0
Maximum values with
FISCO, IEC 60079-27 0 0 0
MC5-IS connection
Uo Io Po Co Lo
Maximum values 5.8 V DC 220 mA 1.3 W 40 µF 0.7 mH

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
8 General
Notes and Warnings
This manual describes the use of MC5-IS and FI5-IS for PRO-
FIBUS PA. For additional fieldbus information, please refer to
your fieldbus control system manuals as well as the manuals
for instruments to be calibrated.
Terms like Function Block Parameters [AUTO, OOS (Out of
Service), MAN], Physical Block, Transducer Block etc.
should be familiar before attempting to calibrate any fieldbus
instruments.
The more instruments a fieldbus segment contains, the slower
the communication is. Be patient.
General Warnings
Do not use FI5-IS in any other way than as described in
this User Guide.
FI5-IS includes a rechargeable Battery Pack. They are
considered as hazardous waste. Dispose used batteries
properly according to local regulations.
Use the FI5-IS' battery charger in a non-hazardous indoor
location only. When charging, the environment tempera-
ture should be between 0 … +35 °C (32 … 95 °F). If the bat-
tery charger is broken, dispose it according to local waste
regulations and order a new charger from Beamex. Do not
connect a broken charger to FI5-IS.
Avoid short circuiting the batteries. The short circuit cur-
rent may cause burns to you, damage to the device or
even fire. The batteries may be replaced by Beamex or a
Beamex authorized service only.
Rechargeable batteries may vent small amounts of gas
during recharge. The vented gas mixture may be highly
explosive, but normally it diffuses rapidly into the atmos-
phere. To avoid danger, use only the original charger and
never recharge in a gas-tight container.

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
General 9
Fieldbus Related Warnings
Do not connect two master devices (e.g. MC5-IS/FI5-IS, a
Field Communicator or a control system) at the same time
to the same fieldbus segment! They clash and make the
fieldbus segment unstable. Only one master device may
be connected to a PROFIBUS PA segment at any time.
When calibrating an instrument that is part of a live seg-
ment (part of a control system), disconnect the instrument
from the segment as instructed in chapter "Calibration
Procedure of a Fieldbus Instrument, General" on page 12.
Failure follow the instructions may result in unexpected
behavior of the control system. The consequences may be
serious damage, injuries or death!
Using MC5-IS and FI5-IS to change the parameters of an
instrument may result in discrepancies: A fieldbus host
control system may mirror all instrument parameters in its
permanent database. In such a case, when returning an
instrument with changed parameters to a live segment,
ensure that the parameters are also available in the con-
trol system's permanent database. Also verify that the
new parameters do not result in an unstable control loop.

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
10 General
Service
FI5-IS may only be serviced by Beamex or a Beamex author-
ized service. Contact:
BEAMEX OY AB
Ristisuonraitti 10
FIN-68600 Pietarsaari
FINLAND
E-mail: [email protected]
Internet: http://www.beamex.com
Opening of the casing of FI5-IS is not allowed due to ATEX
safety reasons.
There are, however a few things that anyone using FI5-IS may
do.
Cleaning FI5-IS
If FI5-IS needs cleaning, use cloth soaked with a mild solution
of tall oil soap (pine soap). Wait a few minutes and then clean
using a cloth moistened with pure water. Never use any strong
detergents.
The Battery Charger
The charger is not intended to be serviced. When unusable it
can be thrown away according to local waste disposal regula-
tions.

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
General 11
Terminology
There are some inconsistencies between the terminologies
used when calibrating/adjusting/trimming traditional analog in-
struments and new fieldbus instruments.
For both instrument types, the procedure has three phases:
1. Comparing the instrument against a more accurate de-
vice (calibrator). This documents the instrument's state
"As Found". If all is well (instrument is accurate enough),
the 2nd and 3rd phase are not needed.
2. Adjusting/trimming the instrument.
3. Re-comparing to create an "As Left" document of the in-
strument's state after adjustment/trimming.
The leftmost picture below presents the terms used when cali-
brating analog instruments. The rightmost one shows the
terms used in fieldbus instruments and fieldbus control system
software. The numbers of the three phases are shown in the
middle.
For analog instruments the term "Calibration" is used for
comparison phases (1st and 3rd). Phase two is called "Adjust-
ment" or "Trimming".
In the user interfaces and manuals of fieldbus instruments and
fieldbus control system software, the second phase is called
"Calibration", "Adjustment" and/or "Trimming". So, to avoid
confusion Beamex uses the term "Verifying Calibration" for
the comparison phases in fieldbus environment.
S t a r t
C A L I B R A T I O N
A s F o u n d
N e e d o f
A d j u s t m e n t ?
E r r o r
S m a l l
Enough?
C A L I B R A T I O N
A s L e f t
A d j u s t m e n t /
T r i m m i n g
En d
n o y e s
n o y e s
S t a r t
V E R I F Y I N
C a l i b r a t i o n A s F
E r r o r
S m a l l
Enough?
V E R I F Y I N
C a l i b r a t i o n A s L
C A L I B R A T I O N
E n d
n o y e s
n o y e s
1
2
3
N e e d o f
A d j u s t m e n t ?
( C a l i b r a -
t i o n )

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
12 General
MC5-IS, FI5-IS and PROFIBUS PA
Beamex's MC5-IS and FI5-IS together are the master of a
PROFIBUS PA fieldbus segment. Since a PROFIBUS PA
segment supports only one master per segment, MC5-IS and
FI5-IS cannot be connected to a fieldbus segment that already
has a master device. Thus doing a verifying calibrating for a
PROFIBUS PA instrument requires that the instrument is dis-
connected from a control system (live fieldbus segment).
Calibration Procedure of a Fieldbus Instrument, General
This chapter presents the broad outline of a calibration proce-
dure when calibrating a PROFIBUS PA instrument using MC5-
IS and FI5-IS. The focus is on presenting requirements unique
for PROFIBUS PA. Being aware of the details presented here
allows you to perform a safe and fluent calibration procedure.
A more detailed description of connecting MC5-IS and FI5-IS
to a PROFIBUS PA as well as performing the actual calibration
is presented further on in this manual.
1. Preparing for the Calibration Procedure
If the instrument to be calibrated is part of a fieldbus segment
already having a master device, you must disconnect the in-
strument. The following list presents a safe disconnecting pro-
cedure.
If the instrument is part of a control system (live seg-
ment), make sure the control loop the instrument be-
longs to is set to manual
Set the instrument's Transducer Block in Out of Service
(OOS) mode (if applicable). This informs the control sys-
tem that the instrument's input signal is not available
(usable). Note that certain instruments do not have an
Out of Service (OOS) mode at all. Then this phase is not
applicable for that particular instrument.
Make sure any other dependencies are set to manual or
other corresponding state.
If the Control System requires it, set the instrument as a
"Spare Device" in the control system ("Off Line" in
some systems).
See chapter Notes and Warnings on page 8 for possible risks
when working in a live segment.

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
General 13
2. Verifying Calibration, As Found
Connect the instrument to MC5-IS/FI5-IS using one of the me-
thod presented in chapter Connecting to a PROFIBUS PA
Instrument, starting from page 17. Perform the Verifying Cali-
bration using MC5-IS/FI5-IS for PROFIBUS PA as presented
in chapters further on. Verifying Calibration of fieldbus instru-
ments is basically done as the calibration of analog and
HART® instruments. The minor differences that exist are due
to the instrument's fully digital output.
3. Calibration (Trimming, Adjusting)
Calibrate (Trim, Adjust) the fieldbus instrument using MC5-
IS/FI5-IS as presented in chapters further on.
Note.
MC5-IS and FI5-IS affect the instrument's Transducer
Block only. It is there the instrument's calibration parame-
ters are located.
4. Verifying Calibration, As Left
Again, perform the Verifying Calibration using MC5-IS/FI5-IS
as presented in chapters further on.
5. Returning the Instrument to a Live Fieldbus Segment
Returning an instrument to a live fieldbus segment requires
opposite tasks than those done in step 1.
Again, see chapter Notes and Warnings on page 8 for possi-
ble problems when returning instruments to a live segment.

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
14 General
Device Descriptions
Each fieldbus instrument type is unique in what kind of para-
meters it has in its memory. A few common parameters are
similar in all devices, but to fully communicate with a fieldbus
instrument, you need to have a device description file that de-
fines all the parameters in the instrument.
Device description files are done by the instrument manufac-
turers and made available via manufacturer's and certain field-
bus sites.
MC5-IS accesses only the instrument's Transducer Block.
Therefore Beamex publishes special device descriptions for
MC5-IS and the instruments connected to it. Please contact
Beamex if you need device descriptions for new instruments.
For contact info, see the first pages of this manual.
The following chapters describe how available device descrip-
tions can be viewed in MC5-IS and also how to add new de-
vice descriptions to MC5-IS.
Viewing Device Descriptions in MC5-IS
To view device descrip-
tions saved in MC5-IS'
memory, press:
D/Menu
C/Others and
4/Device Description
Information.
Each row in the list is a
device description.
The lower window dis-
plays detailed data for
the highlighted device
and the version number
of the Device Description
File in MC5-IS.
If the same device name is shown twice in the list, there is
some difference in the Device Type, Device Revision and/or
DD Revision detail data.
3 0 . 0 3 . 2 0 0 7 1 3 : 5 7
M a n u f a c t u r e r = P R E l e c t r o n i c s
M a n u f a c t u r e r = 0 0 6 D
B l o c k _ O b j e c t = 0 3
P a r e n t _ C l a s s = 0
D D i l e V e r s i o n 6 . 5 ( P A )
C l o s e
D E V I C E D E S C R I P T I O N S
P R e t o p 5 3 5 0
W I K A T 5 3
I n v e n s y s R T T 1 5
R o s e m o u n t 3 2 4 4 M V
F l e x B a r 3 4 3 1
S I T R A N S P 3 0 0
S I T R A N S T 3 K
V E A B A R 5 0 / 6 0
A B B T F 1 2
A B B 2 6 0 0 T - 2 6 3 / 2 6 5
K a m s t r u p F l e x T o p

User Guide – MC5-IS Fieldbus Option for PROFIBUS PA
General 15
Device Description Sender
Beamex offers a tool for sending device descriptions to MC5-
IS. This can however be done in safe are only.
Running the Device Description Sender software opens a win-
dow with a list of device description data it contains.
Hint.
If the highlight is as shown in the picture above, both
FOUNDATION Fieldbus and PROFIBUS PA device de-
scriptions are sent to MC5-IS. If you, e.g. have PROFIBUS
PA instruments only, highlight corresponding row and send
only PROFIBUS PA instrument device descriptions to
MC5-IS.
Click the secondary mouse button to view details of the se-
lected set of device data (the secondary mouse button is the
rightmost button, if you use the mouse with your right hand).
Details window:
Please contact Beamex if you need Device Descriptions for
new instruments. For contact info, see the first pages of this
manual.
