BEAUTME BM1B User manual

WALL-MOUNTED LED
BATHROOM MIRROR
BM1B User Manual
400mm / 15.7"
1016mm / 40"
610mm / 24"
146mm / 5.7"
45mm
/ 1.8"
Notice
For warranty , please kindly contact us for return policy if any issues happen.
(1) Please read the instructions carefully before using.
(2) Make sure that your charging device is adequate for the mirror voltage rating before
using.
(3)Turn o󽗈 the power and avoid direct sunlight if not used or stored for a long time. Far
away from children's access.
(4) Please do not disassemble or remodel mirror, and keep it away from sharp things.
(5) Please do not use corrosive liquids to clean the mirror.
(6) Please do not violently throw, hit and rub mirror.
(7) Do not approach or put the product into the 󽗉re in case of 󽗉re or explosion.
(8) Please stop using it immediately if an abnormality occurs.
Step 4. Two Ways Of Connection
Operating Instruction
Turn on or o󽗈 the anti-fog
function
Touch to switch White Light /
Natural Light / Warm Light
Long press to adjust light
brightness
Turn on or o󽗈 the LED lights
OFF OFFON ON
1. connect to power source
directly by using the plug
installed
2. Through the connector provided, here is how:
a. remove the plug by pull up the buttons of
the connector
b. connect the wire from your home power
source to one end of the connect
c. make sure all wires settled 󽗉rmly

Product Information
Name Wall-Mounted LED Bathroom Mirror
Model BM1B
Voltage 12V 4A
Lighting Power Max 48W
Anti-fog Power Max 30W
Input UL110V
Product Size 1016×610×45mm (40×24×1.8 inches)
Frame Color Black + Gold
Color Temperature White Light 6500K, Natural Light 4800K, Warm Light 3200K
Material Aluminium + Glass
Step 1. Tray installation
Product Installation
c. take o󽗈 the sticker
before installation
a. Horizontal
Screw holes
located at the
bottom left
1. This mirror supports two wall-mounted methods, Horizontal or Vertical
2. Fix the tray to the mirror according to your actual situation
b. Vertical
Screw holes
located at the
bottom right
d. Put the tray on
and tighten with
screws
4. Hang up the
mirror as above
demonstration
and make sure
the hook goes
into the slot of
the mirror frame
4. Hang up the
mirror as above
demonstration
and make sure
the hook goes
into the slot of
the mirror frame
Step 3. Wall-Mounted Ways and
Step 2. Foam pads installation
Situation1 Hole-free installation (Only suitable for smooth glass or tiled walls)
1. Apply nail-free
glue to the back
of the hook
2. Stick the level
vial closely on
the hook
3. Align the position
and fix the hook
to the wall, then
wait at least 48
hours to dry the
nail-free glue
(better 72hrs)
1. Use the level
vial to choose a
suitable location
on the wall and
mark it
1. Paste the foam pad to
the back of the mirror
2. Drill holes
and insert the
expansion tube
into the hole
2. Horizontal paste position
3. Fix the hook with
screws
3. Vertical paste position
Situation2 Drilling installation
Hook
screw*4
Expansion
pipe*4
Level
vial*1
Nail-free
glue*1
Hook*1Tray*1 Tray
screw and
washer*4
Foam
pads*2
12345678
Accessories included
