Becker AR6201 Series User manual

Becker Avionics GmbH •Baden-Airpark B108
77836 Rheinmünster •Deutschland
+49 (0) 7229 / 305-0 •Fax [phone] / 305-217
http://www.becker-avionics.com •E-mail: [e-mail]
VHF Transceiver
AR6201, AR6203, RT6201, RCU6201
Software Versions:
upwards from Software Version
SCI1050S305 Version 4.06
SCI1051S305 Version 2.06
Operating Instructions
Article-No.: 0638.420-071
Issue 04 December 2016

Operating Instructions
2 VHF Transceiver 620X 0638.420-071 Issue 04 12/2016
Table of Contents
1. Introduction.................................................................................................4
1.1. General Safety Definitions............................................................................4
1.2. Packaging, Transport, Storage.....................................................................4
1.3. Disposal........................................................................................................5
1.4. Warranty Conditions.....................................................................................5
1.5. Conditions of Utilization................................................................................6
1.5.1. Purpose of Equipment ....................................................................6
1.5.2. Additional Conditions of Utilization..................................................6
1.6. Non Warranty Clause ...................................................................................6
2. Operating Instructions ...............................................................................7
2.1. Device Description........................................................................................7
2.1.1. Device Assignment.........................................................................8
2.1.2. Scope of Delivery............................................................................8
2.1.3. Additional Required Equipment.......................................................8
2.1.4. Type Plate.......................................................................................9
2.1.5. Safety-Conscious Utilization .........................................................10
2.2. Controls and Indicators...............................................................................11
2.3. Start-Up ......................................................................................................13
2.4. Receive and Transmit Mode.......................................................................13
2.4.1. Receive Mode...............................................................................13
2.4.2. Transmit Mode..............................................................................14
2.5. Frequency Selection Modes.......................................................................15
2.5.1. Standard Mode .............................................................................16
2.5.2. Direct Tune Mode .........................................................................17
2.5.3. Channel Mode...............................................................................18
2.5.3.1. Select Channels.........................................................................19
2.5.3.2. Frequency Storage Functions....................................................20
2.5.3.3. Store ..........................................................................................20
2.5.3.4. Automatic Storage Function.......................................................22
2.5.3.5. Delete data:................................................................................22
2.5.4. SCAN Mode..................................................................................23
2.6. SQUELCH ..................................................................................................24
2.7. RX Field Strength Indication.......................................................................24
2.8. Channel Spacing Mode ..............................................................................25
2.9. Auxiliary Audio Input (AUX)........................................................................25
2.10.Intercom Operation.....................................................................................26
2.11.VOX & Speaker Operation..........................................................................27
2.12.Menus.........................................................................................................28
2.12.1. Intercom Menu..............................................................................28
2.12.2. User Menu ....................................................................................30
2.13.Warning and Failure Indications .................................................................32
3. Technical Data ..........................................................................................34
4. Index.......................................................................................................... 36

Operating Instructions
0638.420-071 Issue 04 12/2016 VHF Transceiver 620X 3
Abbreviations
AC
Alternating Current
AF
Audio Frequency
AR
Airborne Radio
ATT
Attenuation
AUX
Auxiliary
CH
Channel
CM
Chassis Module
COM
Communication
DC
Direct Current
IC
Intercom
LCD
Liquid Crystal Display
NAV
Navigation
PBIT
Power-On Built In Test
PTT
Push To Talk
RCU
Remote Control Unit
RSSI
Received Signal Strength Indication
RT
Remote Transceiver
RX
Receive
SQL
Squelch
SW
Software
TX
Transmit
UKW
Ultrakurzwellen
VOX
Voice Operated IC Threshold
VHF
Very High Frequency
VDC
Voltage Direct Current
Units
V
Volt
A
Ampere
mA
Milliampere
W
Watt
mW
Milliwatt
kHz
Kilohertz
MHz
Megahertz
s
Second
dBm
Power ratio in Decibel
dB
Decibel
Ohm (Ω)
Resistor
kg
Kilogram
°C
Degree Celsius
mm
Millimeter
cm
Centimeter

Operating Instructions
Introduction
4 VHF Transceiver 620X 0638.420-071 Issue 04 12/2016
1. Introduction
Before use of the device it is recommended to study this instruction manual
carefully because it contains safety as well as operating instructions.
Include this manual to the documentation carried on board the aircraft.
1.1. General Safety Definitions
Indicates a hazardous situation which, if not avoided, will result
in death or serious injury.
Indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
Is used to address practices not related to physical injury.
Safety instructions (or equivalent) signs indicate specific
safety-related instructions or procedures.
1.2. Packaging, Transport, Storage
Visually inspect the package contents for signs of transport damage.
The packaging material can be kept and reused in the case of a return shipment.
Improper or faulty packaging may lead to transport damages.
Make sure to transport the device always in a safe manner and with the aid of
suitable lifting equipment if necessary. Do never use the electric connections for
lifting. Before the transport, a clean, level surface should be prepared to place the
device on. The electric connections may not be damaged when placing the device.
First Device Checkup
•Check the device for signs of transport damages.
•Please verify if the indications on the type plate correspond to your
purchase order.
•Check if the equipment is complete ("Scope of Delivery", page 34).
Storage
If you do not wish to mount and install the device immediately, make sure to store it
in a dry and clean environment. Make sure that the device is not stored near strong
heat sources and that no metal chippings can get into the device.

Operating Instructions
Introduction
0638.420-071 Issue 04 12/2016 VHF Transceiver 620X 5
1.3. Disposal
The packaging material is inflammable, if it is disposed of
improperly by burning, toxic fumes may develop.
This product contains materials that fall under the special disposal regulation, which
corresponds to the EC directive for dangerous disposal material. We recommend
disposing of the respective materials in accordance with the respectively valid
environmental laws. The following table states the materials suitable for recycling
and the materials which have to be disposed of separately.
Material
Suitable for recycling
Disposal
Metal yes no
Plastics
yes
no
Circuit boards
no
yes
Dispose of the circuit boards:
•Disposal via a technical waste dump which is allowed to take on e.g.
electrolytic aluminium capacitors. Do under no circumstances dump
the circuit boards with normal waste dump.
1.4. Warranty Conditions
User Conversions and Changes are Not Permitted.
Any change made by the user excludes any liability on our part (excluding the work
described in the manual).
•The device must not be opened.
•Do not make any modifications to the device, except for those
described in the installation manual*.
•Make connections to the inputs, outputs and interfaces only in the
manner described in the installation manual*.
•Fix the devices according to the mounting instructions (installation
manual*). We cannot provide any guarantee for other mounting
methods.
* For details please refer to manual:
http://www.becker-avionics.com/downloads/ →AR620X Family.

Operating Instructions
Introduction
6 VHF Transceiver 620X 0638.420-071 Issue 04 12/2016
1.5. Conditions of Utilization
General introductory notes
With this device you bought a product which was manufactured and tested before
delivery with the utmost care.
Please take your time to read the following notes which you ought to follow closely
during operation.
Unless, all claims under the warranty will become void and a reduced service life or
even damages must be expected.
The user is responsible for protective covers and/or additional
safety measures in order to prevent damages to persons and
electric accidents.
1.5.1. Purpose of Equipment
The VHF transceiver enables voice communication in the very high frequency band
between 118.000 to 136.975 MHz (radio communication part of air-band) with a
selectable channel spacing of 25 or 8.33 kHz.
1.5.2. Additional Conditions of Utilization
Please refer to "Safety-Conscious Utilization", page 10.
1.6. Non Warranty Clause
We checked the contents of this publication for compliance with the associated hard
and software. We can, however, not exclude discrepancies and do therefore not
accept any liability for the exact compliance. The information in this publication is
regularly checked, necessary corrections will be part of the subsequent
publications.

Operating Instructions
Device Description
0638.420-071 Issue 04 12/2016 VHF Transceiver 620X 7
2. Operating Instructions
This chapter contains general information and instructions to ensure safe operation
of the VHF transceivers.
The 620X transceiver family enable voice communication between aircraft or
between aircraft and ground using the very high frequency band between
118.000...136.9750 MHz with a selectable channel spacing of 25 kHz respectively
8.33 kHz.
Several functions and settings are only available via the
password-protected "Configuration Settings*".
* For details please refer to manual:
http://www.becker-avionics.com/downloads/ →AR620X Family.
For further descriptions we are using following terms for VHF transceivers instead
writing their complete model number.
620X in general for the device family
AR620X for: AR6201, AR6203 (Single Block Transceiver).
RT for: RT6201 (Remote Transceiver).
RCU for: RCU6201 (Remote Control Unit).
2.1. Device Description
•The figures for illustrating display show transceivers working in
8.33/25 kHz mixed mode.
•Dedicated pictures for 25 kHz mode are not explicitly shown
(they differ only in number of digits for frequency).
•The HMI actions described in this section can be performed
on primary controller or on optional secondary controller
RCU6201.
•The word "frequency" also used in the sense of "channel
name", as defined in EUROCAE, document ED-23B chapter
1.3.2.
oIn this document the word "memory channel" or "channel"
means a memory place identified by a channel number,
where a frequency may be stored for later use.

Operating Instructions
Device Description
8 VHF Transceiver 620X 0638.420-071 Issue 04 12/2016
2.1.1. Device Assignment
This manual is valid for the following devices:
•AR6201-(XX2)
•AR6203-(XX2)
•RT6201-(XX0) with RCU6201-(X12)
upwards from Software Version
SCI1050S305 Version 4.06
SCI1051S305 Version 2.06
2.1.2. Scope of Delivery
•Manuals
oOperating Instructions
•Device in accordance with your order
•Device accessories
•Documents of Certifications
2.1.3. Additional Required Equipment
•Mounting kit MK6403-1 (for AR6203)
•Mounting kit MK6201-(10)
(for RT6201, to meet the conditions for certification)
•Connector kits
•Cable
•Antenna
For details please refer to manual:
http://www.becker-avionics.com/downloads/ →AR620X Family.

Operating Instructions
Device Description
0638.420-071 Issue 04 12/2016 VHF Transceiver 620X 9
2.1.4. Type Plate
The device type is defined by the type plate (on the housing):
Figure 2-1: Type plate (example)
Explanation:
PN:
Type designation:
AR6201 = Single Block VHF Transceiver 58 mm (2¼ inch)
AR6203 = Single Block VHF Transceiver 160 mm (6.3 inch)
RT6201 = Remote VHF Transceiver
RCU6201 = Remote Control Unit 58 mm (2¼ inch)
Options:
0XX: 8.33/25 kHz channel spacing capability
1XX: 25 kHz channel spacing capability only
X1X: 10 W @ 28 V
X2X: 6 W @ 12 V
XX2: white illumination colour on black panel
SN:
Unique number of the particular device
AN:
Article number
DoM:
Date of Manufacturing
Software:
Corresponding to the displayed version (see device)
Compliance and Certifications
Corresponding to the displayed text and logos (see device)

Operating Instructions
Device Description
10 VHF Transceiver 620X 0638.420-071 Issue 04 12/2016
2.1.5. Safety-Conscious Utilization
Excessive pulses on the DC bus of the aircraft may cause
damage on electrical circuits of any installed instrument.
Do not switch ON the device during engine start or
shutdown.
A voice communication test shall be performed before
starting the engine.
It should be noted that, if the communication test is carried
out close to a ground station, the results may be positive
even if the antenna cable is broken or short-circuited. In
such a case, at a distance of 5 to 10 km and above,
communication might not be possible.
•Speak always loud, clear and not too fast for optimal voice
communication.
•Keep the microphone always close to the lips otherwise a special
suppressing circuit in the VHF COM will not be capable to suppress
normal cabin noise.
•Use only microphones or headsets which are suitable for use in an
aircraft.
oIn aircraft made of wood, synthetic materials or in gliders or
helicopters, incoming radiation can affect the integrated amplifier of
the microphone (feedback), noticeable in the ground station by
whistling and/or heavy distortion.
If the power supply voltage drops below the "Low Battery Threshold" (default value is
10.5 V), the "LOW BATTERY" message will appear each 3 seconds in the lower part
of the display.
If the power supply voltage drops below 10 V the system
enters power saving mode:
•Speaker output of the transceiver is automatically
switched "OFF"
•Speaker sign will no longer be presented on LCD display
•The pilot must use headphones to continue listening.
Channels store/change:
•The functions "LAST" and Store/Restore are only
available if they are activated in "Configuration Settings*"
- ("MEM OPTIONS").
* For details please refer to manual:
http://www.becker-avionics.com/downloads/ →AR620X Family.

Operating Instructions
Controls and Indicators
0638.420-071 Issue 04 12/2016 VHF Transceiver 620X 11
2.2. Controls and Indicators
5 3 4 8
6
7
912
AR620X, RCU6201
AR6203
Figure 2-2: Controls and Indicators
Symbol
Description
Function
1
IC/SQL
(Intercom/
Squelch)
•"Short press" during normal operation
toggles the RX -SQL ON/OFF.
•"Long press" during normal operation
activates Intercom Menu.
2
MDE
(Mode)
•"Short press" during normal operation
changes the frequency selection mode.
•"Long press" during normal operation
activates the user menu.
3
STO
(Store)
•"Short press" during normal operation
activates storage procedure.
4
↨/SCN
(Exchange/SCAN)
•"Short press" during standard mode, or scan
mode toggles between preset and active
frequency.
•"Long press" activates scan mode.
5
Power ON/OFF +
Volume
•Switches the transceiver ON/OFF and
adjusts volume level of received signal.
6
Rotary encoder
•Turning "ROTARY ENCODER" changes the
settings of several parameters (frequency,
IC-volume, VOX, …).
•Pushing the "ROTARY ENCODER" toggles
between the digits and acts as an enter key.
-8/25-
Change of
Channel Spacing
•Keeping the MDE and STO button pressed
simultaneously longer than 2 seconds
changes 8.33 to 25 kHz channel spacing
and vice versa.
7
Display
LCD: Liquid Crystal Display

Operating Instructions
Controls and Indicators
12 VHF Transceiver 620X 0638.420-071 Issue 04 12/2016
8
Active frequency
Only on the active frequency, transmitting is
possible and receiving has priority, even in scan
mode. Frequency tuning is not possible in
standard mode.
9
Preset frequency
Frequency tuning is possible in standard mode.
In scan mode both frequencies, active and
preset are in listening watch. If no receive signal
is detected on the active frequency, receiving
signals on the preset frequency will be audible,
but will be muted as soon as a signal on the
active frequency is detected.
The device detects a:
"Long press": when pressing and holding down a key for at least 2 seconds (≥2s).
"Short press": any pressing below 2 seconds (< 2 s).
If any action by the user is invalid, the whole display inverting for a short time.
Symbols shown on the display
Symbol
Function
IC
Intercom operation is active (triggered by VOX or external IC key).
Intercom operation via VOX is disabled.
TX
Transceiver is in transmit operation.
SQL
Squelch function is active, weak RX signals suppressed.
SCAN
Transceiver operates in scan mode.
STO
Transceiver performs a storage operation.
LOW BATT
Battery below predefined low threshold.
128 .000
Inverted figures or letters on display ready to edit
Speaker on

Operating Instructions
Start-Up
0638.420-071 Issue 04 12/2016 VHF Transceiver 620X 13
2.3. Start-Up
Excessive pulses on the DC bus of the aircraft may cause damage
on electrical circuits of any installed instrument.
Do not switch ON the device during engine start or shutdown.
•Turn "ON" the device by turning the volume knob clockwise.
oPower-On Built In Test is started.
•During PBIT (Power-On Built In Test) the display indicate the
messages:
o"WAIT".
oThe software version of "Control Head" (CH).
oThe software version of "Core Module" (CM).
•If the PBIT has detected error(s),"FAILURE" appears on the display.
Details see "Warning and Failure Indications", page 32.
2.4. Receive and Transmit Mode
2.4.1. Receive Mode
If PTT (Push To Talk) inputs are inactive, the transceiver remains in receive mode.
In receive mode the headphone(s) outputs (if enabled) provide a mixed signal
consisting of:
•Received signal from antenna.
•Intercom signal from intercom circuit 1 and 2.
•Signal from auxiliary input.
In receive mode the speaker output (if enabled) provides a mixed signal
consisting of:
•Received signal from antenna.
•Signal from auxiliary input.
The signal from the auxiliary input been muted under certain conditions, for details
refer to "Auxiliary Audio Input (AUX)", page 25.
The signal from intercom can be attenuated or muted, under certain conditions, for
details refer to "Intercom Operation", page 26.

Operating Instructions
Receive and Transmit Mode
14 VHF Transceiver 620X 0638.420-071 Issue 04 12/2016
2.4.2. Transmit Mode
118.005
127.000
TX
•If PTT input is active (PTT=Push To Talk key is pressed)
the transceiver switches to transmit mode.
oMicrophone(s) signals can modulate the transmitter.
oPTT 1 input activates transmission from microphone
path 1.
oPTT 2 input activates transmission from microphone
path 2.
oIf "BOTH MIKES" are active/enabled in the
"Configuration Settings*", each input (PTT 1 or 2)
activates the transmission from both microphone
paths simultaneously.
•The "TX" symbol indicates the device is in transmit mode.
•The sidetone (demodulated audio of the emitted signal) is
available on the headphone output.
•The transmit mode automatically deactivates the speaker.
* For details please refer to manual:
http://www.becker-avionics.com/downloads/ →AR620X Family.
•In transmit mode several user actions such as changing
frequency selection mode or channel spacing mode, which
are normally allowed in receive mode, are blocked.
(As an exception in standard mode the "Preset" frequency
may still be changeable, even during transmission).
•In transmit mode no intercom operation is possible.
•Transmit mode is automatically terminated (return to
receive mode) after 120 s of continuous transmitting.
"STUCK PTT" is indicated, see "Warning and Failure
Indications", page 32.

Operating Instructions
Frequency Selection Modes
0638.420-071 Issue 04 12/2016 VHF Transceiver 620X 15
2.5. Frequency Selection Modes
Following frequency selection modes are available on AR620X and RCU6201:
•Standard Mode
•Direct Tune Mode
•Channel Mode
•SCAN Mode
The availability of the modes depends on enabling or disabling in
the "Configuration Settings*".
* For details please refer to manual:
http://www.becker-avionics.com/downloads/ →AR620X Family.
The modes "Standard Mode", "Direct Tune Mode" and "Channel Mode" provide
different user interfaces for the selection of the operating frequency.
•The modes are selectable by consecutive short pressing of "MDE" key.
•One by one appear: "Standard Mode", "Direct Tune Mode" "Channel
Mode" and again "Standard Mode", etc.
•When toggling between the three modes the active frequency always
remains the same and active.
The mode SCAN is a sub-mode of standard mode and is used for monitoring two
frequencies at the same time.
•Press "↕/SCN" key (2 seconds) to activate/deactivate the scan function.

Operating Instructions
Frequency Selection Modes
16 VHF Transceiver 620X 0638.420-071 Issue 04 12/2016
2.5.1. Standard Mode
118.005
127.000
IC
SQL
•Press the "MDE" key until the standard mode page appears.
oThe active frequency is displayed in the top line and
preset frequency in the bottom line.
•Changing the active frequency is not possible in standard
mode (only available in direct tune mode).
•Changing the preset frequency is possible.
Changing the preset frequency in standard mode:
118.005
128.000
SQL
•Make a "short press" on the "ROTARY ENCODER" for
modification of the MHz digits.
oThe editable digts are shown inverted.
•Rotate the "ROTARY ENCODER" clockwise/counter
clockwise to change the frequency in 1 MHz steps.
118.005
128.000
SQL
•Make another "short press" on the "ROTARY ENCODER" for
modification of the 100 kHz digits.
oThe editable digts are shown inverted.
•Rotate the "ROTARY ENCODER" clockwise/counter
clockwise to change the frequency in 1 kHz steps.
128.000
SQL
118.005
•Make another "short press" on the "ROTARY ENCODER" for
modification of the 25/8.33 kHz digits.
oThe editable digts are shown inverted.
•Rotate the "ROTARY ENCODER" clockwise/counter
clockwise to change the frequency in 25/8.33 kHz steps.
•A short press of the "↨/SCN" key, exchanges active frequency
to preset frequency and vice versa.
oWhile the transceiver operates in transmit mode, the
toggle function is disabled.
•Press the "STO" key to store the active frequency into the
next vacant memory place of the user channel database (see
"Frequency Storage Functions", page 20).

Operating Instructions
Frequency Selection Modes
0638.420-071 Issue 04 12/2016 VHF Transceiver 620X 17
2.5.2. Direct Tune Mode
IC
SQL
118.005
BAT 13.5V
•Press the "MDE" key until the direct tune mode page
appears.
oThe active frequency is displayed in the top line.
•The battery information is displayed.
The battery information is only displayed if BATTERY VOLTAGE
in the "Configuration Settings*" is selected.
* For details please refer to manual:
http://www.becker-avionics.com/downloads/ →AR620X Family.
Changing the active frequency in direct tune mode:
IC
SQL
118.005
•Make a "short press" on the "ROTARY ENCODER" for
modification of the MHz digits.
•The editable digts are shown inverted.
•Rotate the "ROTARY ENCODER" clockwise/counter
clockwise to change the frequency in 1 MHz steps.
IC
SQL
118.005
•Make another "short press" on the "ROTARY ENCODER" for
modification of the 100 kHz digits.
•The editable digts are shown inverted.
•Rotate the "ROTARY ENCODER" clockwise/counter
clockwise to change the frequency in 1 kHz steps.
IC
SQL
118.005
•Make another "short press" on the "ROTARY ENCODER" for
modification of the 25/8.33 kHz digits.
•The editable digts are shown inverted.
•Rotate the "ROTARY ENCODER" clockwise/counter
clockwise to change the frequency in 25/8.33 kHz steps.
•The changes become active immediately.
•Changing the active frequency is possible only when the
transceiver is not transmitting.
•Press the "STO" key to store the active frequency into the
next vacant memory place of the user channel database (see
"Frequency Storage Functions", page 20).

Operating Instructions
Frequency Selection Modes
18 VHF Transceiver 620X 0638.420-071 Issue 04 12/2016
2.5.3. Channel Mode
The channel mode shows data from "User channel database" (indicated by "CH"), or
"Last Channel Database" (indicated by "LAST") and shows if applied a customized
label (identifier) for the frequency (max. 10 characters).
IC
SQL
125.875
CH
TWR EDSB
01
IC
SQL
125.875
LAST
TWR EDSB
1
The channel database provides storage of:
•CH01…CH99 and
•LAST 1…LAST 9.
•The functions "LAST" and Store/Restore are only available if
they are activated in "Configuration Settings*" -
("MEM OPTIONS").
* For details please refer to manual:
http://www.becker-avionics.com/downloads/ →AR620X Family.
•If the device is operating in the 25 kHz mode a selection of
stored 8.33 kHz channels is not possible.
For selection of 8.33 kHz channels, the device must operate
in 8.33 + 25 kHz mixed mode.
IC
SQL
125.875
CH
TWR EDSB
01
•Press the "MDE" key until the channel mode page appears.
•By means of channel number stored frequencies can be
selected.
oThe top line shows the corresponding frequency and
the bottom line the customized label (identifier)
assigned to the frequency number.
oIf the active frequency has no assigned channel number
the indication is "CH--".

Operating Instructions
Frequency Selection Modes
0638.420-071 Issue 04 12/2016 VHF Transceiver 620X 19
2.5.3.1. Select Channels
Example: With CH01 user channel shown on display:
In order to select the channel number:
IC
SQL
125.875
CH
TWR EDSB
01
…

STO CH
FREE
09
125.875
•The first turn clockwise in channel mode provides
navigation up to the user channels CH01…CH99.
oMake a short press of the "ROTARY ENCODER", or:
oMake one clockwise turn of the "ROTARY
ENCODER".
•The channel number is now highlighted and the channel
can be changed turning the "ROTARY ENCODER".
At each step the receiver tunes immediately to the
displayed frequency.
IC
SQL
125.875
LAST
TWR EDSB
1
•The first turn counter-clockwise will enter to the channel
"LAST 1".
oThe channel number is now highlighted and one of the
nine last used channels is selectable by turning the
"ROTARY ENCODER" either counter clockwise or
clockwise.
•The "LAST" mode is left automatically after a 5 second
timeout or can be deselected by a press of the "ROTARY
ENCODER".
•When leaving the "LAST" channel database and the last
shown frequency is not stored in the u
ser channel database,
"CH__" appear on the display.
•Press the "STO" key to store the frequency into the next free
memory place of the user channel database.
Leave Channel Mode:
•Press the "MDE" key.
oThe channel mode will be closed.
o
The standard mode page appears.

Operating Instructions
Frequency Selection Modes
20 VHF Transceiver 620X 0638.420-071 Issue 04 12/2016
2.5.3.2. Frequency Storage Functions
Start store function:
STO CH
FREE
09
125.875
•Press "STO" key.
(in "Standard", Direct Tune" or "SCAN Mode").
oThe symbol "STO” appears.
2.5.3.3. Store
Note The functions "LAST" and Store/Restore are only available if
they are activated in "Configuration Settings*"
("MEM OPTIONS").
* For details please refer to manual:
http://www.becker-avionics.com/downloads/ →AR620X Family.
Two databases are provided:
•User channel database - provides 99 channels CH01…CH99
to store frequencies with the possibility to apply a customized
label (identifier) with max. 10 alphanumeric characters.
•Last channel database - automatically stores last used
frequencies.
Named and callable as LAST 1…LAST 9, the customized
identifier will be displayed (if applied).
•Any frequency (within the range 118.000...136.9916 MHz)
can be assigned to any channel by simply pressing the
"STO" button.
•All 99 channels are editable.
