Beckhoff C6930 User manual

Installation and Operating instructions for
C6930
Control Cabinet PC
Version: 1.6
Date: 2016-10-05

Table of contents
Table of contents
1.
2.
3.
4.
Foreword 3
Notes on the Documentation 3
Liability Conditions 3
Trademarks 3
Patent Pending 3
Copyright 3
State at Delivery 3
Delivery conditions 3
Description of safety symbols 4
Basic safety measures 5
Operator’s obligation to exercise diligence 6
Operator requirements 6
Product Description 7
Appropriate Use 7
Access to the battery and drives 8
Status-LEDs 9
Fan cartridge 9
Extension for PCI and PCIe plug-in cards 10
Access to the plug-in card slots 10
Interfaces 11
Power Supply 11
Network connection 11
USB-Interfaces 11
DVI (Digital Visual Interface) 11
Serial interface 11
Additional plug-in cards (optional) 11
Installation Instructions 12
Transport and Unpacking 12
Transport 12
Unpacking 12
Installation of the PC in the control cabinet 13
Earthing measures 13
Power Supply Connection 14
Beckhoff power supply technology 14
Pin assignment of the connector 15
Fitting the cable 16
Material for assembling the connectors 16
Assembling the connectors 16
Connecting Power Supply 17
Cable Cross Sections 17
Configuration for shutting down the PC 17
PC_ON and Power Status functions 17
UPS output 18
UPS output function 18
Wiring diagram 18
Connecting devices 19
Connecting cables 19
Check voltage rating and connect 19
Operating Instructions 20
Switching the Industrial PC on and off 20
First switching on and driver installation 20
Maintenance 21
Cleaning the Industrial PC 21
Servicing 21
Replacing the battery on the motherboard 21
Emergency procedures 21
1 C6930

Table of contents
Shutting down 21
Disposal 21
5.
6.
7.
8.
UPS Software Components (optional) 22
Installation on the PC 22
Help files 22
Troubleshooting 23
Fault correction 23
Beckhoff Support & Service 24
Beckhoff branches and partner companies 24
Beckhoff Headquarters 24
Beckhoff Support 24
Beckhoff Service 24
Assembly dimensions 25
Industrial-PC C6930 25
Industrial-PC C6930 26
Industrial-PC C6930 with plug-in card slots 27
Industrial-PC C6930 with plug-in card slots 28
Appendix 29
Technical data 29
Approvals 29
FCC: Federal Communications Commission Radio Frequency Interference
Statement 29
FCC: Canadian Notice 29
2C6930

Foreword
Foreword
Notes on the Documentation
This description is only intended for the use of trained specialists in control
and automation engineering who are familiar with the applicable national
standards. It is essential that the following notes and explanations are
followed when installing and commissioning these components.
The responsible staff must ensure that the application or use of the
products described satisfy all the requirements for safety, including all the
relevant laws, regulations, guidelines and standards.
Liability Conditions
The documentation has been prepared with care. The products described
are, however, constantly under development. For that reason the
documentation is not in every case checked for consistency with
performance data, standards or other characteristics. In the event that it
contains technical or editorial errors, we retain the right to make alterations
at any time and without warning. No claims for the modification of products
that have already been supplied may be made on the basis of the data,
diagrams and descriptions in this documentation.
Trademarks
Beckhoff®, TwinCAT®, EtherCAT®, Safety over EtherCAT®, TwinSAFE®
and XFC®are registered trademarks of and licensed by Beckhoff
Automation GmbH.
Other designations used in this publication may be trademarks whose use
by third parties for their own purposes could violate the rights of the
owners.
Patent Pending
The EtherCAT Technology is covered, including but not limited to the
following patent applications and patents:
EP1590927, EP1789857, DE102004044764, DE102007017835
with corresponding applications or registrations in various other countries.
The TwinCAT Technology is covered, including but not limited to the
following patent applications and patents:
EP0851348, US6167425 with corresponding applications or registrations in
various other countries.
Copyright
© Beckhoff Automation GmbH.
The reproduction, distribution and utilization of this document as well as the
communication of its contents to others without express authorization are
prohibited. Offenders will be held liable for the payment of damages. All
rights reserved in the event of the grant of a patent, utility model or design.
State at Delivery
All the components are supplied in particular hardware and software
configurations appropriate for the application. Modifications to hardware or
software configurations other than those described in the documentation
are not permitted, and nullify the liability of Beckhoff Automation GmbH.
Delivery conditions
In addition, the general delivery conditions of the company Beckhoff
Automation GmbH apply.
C6930 3

Foreword
Description of safety symbols
The following safety symbols are used in this operating manual. They are
intended to alert the reader to the associated safety instructions.
Acute risk of injury!!
DANGER
If you do not adhere the safety advise adjoining this symbol, there is
immediate danger to life and health of individuals!
Risk of injury!
WARNING
If you do not adhere the safety advise adjoining this symbol, there is
danger to life and health of individuals!
Hazard to individuals!
CAUTION
If you do not adhere the safety advise adjoining this symbol, there is
obvious hazard to individuals!
Hazard to devices and environment
Attention
If you do not adhere the notice adjoining this symbol, there is obvious
hazard to materials and environment.
Note or pointer
Note
This symbol indicates information that contributes to better understanding.
4C6930

Foreword
Basic safety measures
Only switch the PC off after
closing the software
Before the Industrial PC is switched off, software that is running must
be properly closed.
Otherwise it is possible that data on the hard disk is lost. Please read the
section on Switching the Industrial PC on and off.
Switch off all parts of the equipment, then uncouple the fieldbus
Attention
Before opening the housing of the PC, and whenever the PC is being
used for purposes other than plant control, such as during functional tests
following repair, all parts of the equipment must first be switched off, after
which the Industrial PC can be uncoupled from the plant.
Pulling out the fieldbus connection plug uncouples the PC (optional).
Items of equipment that have been switched off must be secured against
being switched on again.
The Industrial PC’s power supply unit must be supplied with 24 VDC.
Do not exchange any parts when under power
Attention
When components are being fitted or removed, the supply voltage must
be switched off.
Fitting work on the Industrial PC can result in damage:
• if metal objects such as screws or tools fall onto operating circuit
boards.
• if connecting cables internal to the PC are removed or inserted
during operation.
• if plug-in cards are removed or inserted when the PC is switched
on.
C6930 5

Foreword
Operator’s obligation to exercise diligence
The operator must ensure that
• the Industrial PC is only used for its intended use (see also Product
Description chapter).
• the Industrial PC is in a sound condition and in working order
during operation (see also chapter Maintenance).
• the operation manual is in good condition and complete, and
always available for reference at the location of the Industrial PC.
• the Industrial PC is operated, maintained and repaired only by
sufficiently qualified and authorized personnel.
• the personnel is instructed regularly about relevant occupational
safety and environmental protection aspects, and is familiar with
the operating manual and in particular the safety notes contained
herein.
• none of the safety and warning notes attached to the Industrial PC
are removed, and that all notes remain legible.
National regulations
depending on the machine
type
Depending on the type of machine and plant in which the Industrial PC is
being used, there will be national regulations for the control of such
machines and plant that the operator must observe. These regulations
cover, amongst other things, the intervals between inspections of the
controller.
The operator must initiate such inspections in good time.
Only trained persons may open the Industrial PC housing!
Attention
The operator is responsible for ensuring that only trained electrical staff
opens the housing of the Industrial PC.
Procedure in the event of a
fault
In the event of a fault in the Industrial PC, appropriate measures can be
determined with the aid of the list in the Fault correction section.
Operator requirements
Read the operating
instructions
Every user of the Industrial PC must have read these operating
instructions.
Software knowledge Every user must be familiar with any of the functions of the software
installed on the PC that he can reach.
6C6930

Product Description
Product Description
Appropriate Use
The C6930 Industrial PC is designed for mounting in control cabinets for
machine and plant engineering applications.
Front view of Industrial PC
C6930
Configuration The C6930 Industrial PC is designed for control cabinet installation. The
compact housing is equipped with a 3½-inch motherboard for Intel®
Celeron® or Core™ i3/i5/i7. The C6930 has a SATA RAID controller for
mirroring two hard disks. Cooling fins behind the right-hand side panel
enable operation of the PC at temperatures up to 55 °C.
C6930 7

Product Description
Access to the battery and drives
Access to the hard disk, the
CF-Card/ CFast-Card and
the battery
Opening the front flap (1) allows access to the battery (2), the CF-Card/
CFast-Card (3) and the hard disk (4). Optionally the Industrial PC can be
fitted with a second hard disk (5).
When provided with a CF-Card the ejection of the card occurs by pressing
the eject button below the card slot.
2
1
3
4
5
Danger of Explosion!
WARNING
Replace battery only with the identical type or an alternative type recommended by the
manufacturer. Notice correct polarity!
Polarity of the battery:
-
+
Handling of Lithium Batteries
WARNING
Lithium Batteries should not be recharged, exposed to fire, opened and they should be
protected against sunlight and moisture.
8C6930

Product Description
Status-LEDs
Description of the Status-
LEDs
The Status-LEDs (2) are
located near the power
supply connector (X101):
1 PWR (Power): green
green blinking
Busy
Standby
2 TC (TwinCAT): red
green
blue
Stop Mode
Run Mode
Configuration Mode
3 IDE/ HDD: red Access to a memory
device
4 FAN: green
red
Fans running
Fan Error
5 USR (User): Programmable
6 FB RUN (Fieldbus activ): green
red
Activ
Not activ
7 FB Error (Fieldbus Error): red Error
X101
2
Fan cartridge
For optimal cooling the Industrial PC is equipped with a fan cartridge with two
fans. The fan cartridge can be exchanged.
Replace the fans only with the identical type or an alternative type approved
by Beckhoff.
View from below
2
1
Exchanging the fan
cartridge
For exchanging the fan cartridge (1), first solve the knurled screw (2). The
cartridge can then be folded down and taken out.
C6930 9

Product Description
Extension for PCI and PCIe plug-in cards
Order option When ordered with the following options the Control Cabinet Industrial PCs
C6930-0020 und –0030 can be extended by two additional plug-in card
slots:
Options C6930-0020 and –0030
C9900-B507 2 PCIe plug-in card slots on the passive backplane
integrated inside C6930, to plug-in PCIe x1 cards up to
190 mm (6.3“) length.
C9900-B511 2 PCI plug-in card slots on the passive backplane integrated
inside C6930, to plug-in PCI cards up to 190 mm (6.3“)
length.
C9900-B515 1 PCI and 1 PCIe plug-in card slot on a passive backplane
integrated inside C6930, to plug-in one PCI and one PCIe x1
card up to 190 mm (6.3“) length.
Access to the plug-in card slots
Access to the slots The plug-in card slots are located behind the cover next to the interfaces of
the Industrial PC.
For mounting the plug-in cards first solve the cross-head screw (1). The
cover (2) can now be opened and allows to plug in the cards.
Opening the cover
1
2
10 C6930

Product Description
Interfaces
Interfaces to the
C6930 Industrial PC
Power Supply
Power supply The power supply for the Industrial PC is established via the
socket (X101).
Network connection
Network The RJ-45 connector (X102) allows the PC to be connected to a
10/100/1000BASE-T Local Area Network (LAN). The Ethernet Port is
connected via PCIe, at the C6930-0040/ -0050 the Port is integrated in the
chipset.
The RJ-45 connector (X103) allows the PC to be connected to a
10/100BASE-T Local Area Network (LAN) (till version –0020) and to a
10/100/1000BASE-T Local Area Network (LAN) (version -0020 and
higher). The Ethernet Port is integrated in the chipset, at the C6930-0040/ -
0050 the Port is connected via PCIe.
Cycle times •
•
The Ethernet Port connected via PCIe is normally suitable for cycle
times <= 1 ms and for Distributed-Clock applications with EtherCAT.
The Ethernet Port integrated in the chipset is normally suitable for
Real-Time-Ethernet applications with cycle times > 1 ms (without
Distributed Clocks).
USB-Interfaces
USB1 – USB4 The four USB interfaces (X104 – X107) are used for connecting peripheral
devices with USB connection. USB2.0 standard is supported.
DVI (Digital Visual Interface)
DVI-I The DVI connection (X108) is used for transferring the video signal. DVI-I
standard is supported.
Serial interface
RS 232
COM1
The Industrial PC has one serial interfaces, COM1 (X109), using the type
RS232, which is brought to a 9 pin SUB-D plug connector.
Additional plug-in cards (optional)
Type plate There is a type plate on the top of the Industrial PC which provides
information about the hardware configuration of the Industrial PC at the
time it was supplied.
Ground connection
X104
X
105
X106
X
107 X101
X103 X102
X108
X109
C6930 11

Installation Instructions
Installation Instructions
Please also refer to chapter Foreword.
Transport and Unpacking
The specified storage conditions must be observed (see chapter Technical
data).
Transport
Despite the robust design of the unit, the components are sensitive to
strong vibrations and impacts. During transport, your Industrial PC should
therefore be protected from excessive mechanical stress. Therefore,
please use the original packaging.
Danger of damage to the unit
Attention
If the device is transported in cold weather or is exposed to extreme
variations in temperature, make sure that moisture (condensation) does
not form on or inside the device.
Prior to operation, the unit must be allowed to slowly adjust to room
temperature. Should condensation occur, a delay time of approximately
12 hours must be allowed before the unit is switched on.
Unpacking
Proceed as follows to unpack the unit:
1.Remove packaging.
2.Do not discard the original packaging. Keep it for future relocation.
3.Check the delivery for completeness by comparing it with your order.
4.Please keep the associated paperwork. It contains important
information for handling the unit.
5.Check the contents for visible shipping damage.
6.If you notice any shipping damage or inconsistencies between the
contents and your order, you should notify Beckhoff Service.
12 C6930

Installation Instructions
Installation of the PC in the control cabinet
The C6930 Industrial PC is designed for mounting in control cabinets for
machine and plant engineering applications.
The ambient conditions specified for operation must be observed (see
chapter Technical data).
Preparation of the control
cabinet
Four holes for the fixing bolts have to be provided in the control cabinet
according to the dimensions of the PC (see chapter Assembly dimensions).
Circulation of air
Note
When the unit is installed in an enclosure, adequate space for ventilation
and for opening the PC must be provided.
The clearance above and below the housing must be at least 5 cm in
order to ensure adequate ventilation of the PC.
Avoid extreme environmental conditions
Attention
Extreme environmental conditions should be avoided as far as possible.
Protect the PC from dust, moisture and heat.
The ventilation slots of the PC must not be covered.
Earthing measures
Earthing measures
Earthing connections dissipate interference from external power supply
cables, signal cables or cables to peripheral equipment.
Establish a low-impedance connection from the earthing point on the PC
housing to the central earthing point on the control cabinet wall, in which
the computer is being installed. The earthing connection is located at the
mounting plate of the Industrial PC (see photograph on the left).
C6930 13

Installation Instructions
Power Supply Connection
Supplied mains power unit The Industrial PC is fitted with a 24 VDC power supply unit .
Uninterruptible power supply (UPS)
Note
When the Industrial PC is provided with a power supply unit with
integrated UPS (order option) you can realize an uninterruptible power
supply (UPS) using the battery pack C9900-U330.
Danger of Explosion!
WARNING
Danger of Explosion if using other battery packs!
Beckhoff power supply technology
Schematic diagram of
power supply unit wirings
Innovative solution for
shutting down Industrial
PCs
Industrial PCs equipped with a UPS are in actual use frequently switched
off by simply turning off the supply voltage. In this case the PC shuts down
via the battery. However, over time this reduces the service life of the
battery.
The new Beckhoff power supply technology approach addresses this
problem and now offers the user the option of switching the PC off without
the need for using the battery, thereby reducing the load on the battery.
In addition to the main switch this innovative solution uses an ON/OFF
switch for the machine. Basically, the main switch remains switched on and
provides the power supply for the PC during shutdown. Via the PC ON-
input of the power supply the PC gets the command to shut down the
operating system.
Once the PC has shut down, the PC power supply unit sets the Power
Status-output (P-S) to 0, what indicates that the process is complete and
14 C6930

Installation Instructions
that the main voltage can be switched off. This can be done manually via a
signal lamp connection or via a contactor. With this solution the main
switch generally only has to be switched off if the control cabinet has to be
opened. The battery will only be used in the event of a power failure.
In order to maintain a screen display for the Industrial PC in the event of a
power failure, the power supply unit is equipped with a UPS output 27 V /
1.4 A (max. 2.5 A from 2016 and later) for connecting a Control Panel with
a display dimension up to 19 inches. This enables a power failure to be
visualized and displayed to the user. Once the PC has shut down, the UPS
output is switched off.
For a detailed functional description please refer to section Connecting
Power Supply.
Pin assignment of the connector
The power supply and the external circuit for switching the Industrial PC on
and off are connected via the 8-pole plug connector .
Pin assignment for
connecting the switch, the
power supply and the
battery pack (optional)
Pin Function
1 -
2 +
Battery Pack
(with UPS only)
3 UPS+ (Output)
4
5 -
6 +
24 V DC
Power Supply
7 PC_ON
8 Power-Status
1 2 3 4 5 6 7 8
C6930 15

Installation Instructions
Fitting the cable
Wiring in accordance with
wiring diagram
Fit the cables for the power supply of the Industrial PC, the connection of
the battery pack as well as the connection of the power-switch in
accordance with the wiring diagram, using the included material for
assembling the connectors.
Material for assembling the connectors
Material for assembling the
connectors
Plug connector 8-pole, Strain
relief housing with lacing cord
Assembling the connectors
Conductive cross-section The connector is specified for 16 A and can lift conductive cross-sections
until 1.5 mm2.
Fitting the connector to the
cable
So the connector is fitted to the cable:
1. Strip insulation from the cable ends (Length of stripped conductor
is 8 – 9 mm).
2. Screw together the cable ends in the 8-pole plug connector in
accordance with wiring diagram.
Applying the strain relief
Thread the lacing cord into that
lower part of the strain relief
housing.
Putting in the plug
connector
Put the plug connector into that
lower part of the strain relief
housing.
Tighten the lacing cord and pinch off
the plastic strap.
Fixing the upper part of the
strain relief housing
Fix the upper part of the strain relief
housing by snapping it onto the
lower part.
16 C6930

Installation Instructions
Connecting Power Supply
The external wiring consists of the connection of the power supply, the
battery pack (optional) and the connection of customized components for
shutting down the PC.
Cable Cross Sections
Note cable cross sections,
avoid voltage drop!
For the connection of the power supply, wiring with a cable-cross-section
of 1.5 mm2 must be used.
With bigger distances between voltage source and PC, you take the
voltage drop as a function of the cable-cross-section as well as voltage
fluctuations of your distribution voltage into account, so that is secured that
the voltage doesn't fall under 22 V at the power supply.
Insert fuse
Attention
The power supply must be protected with maximum 16 A.
Configuration for shutting down the PC
The connections for shutting down the Industrial PCs are established via
the PC_ON input and the Power Status output.
PC_ON and Power Status functions
• If the PC_ON input is connected to 24 V via a switch, the PC shuts
down according to the rules. The PC_ON signal is inverted, i.e. the
PC shuts down if the 24 V connection is live.
• If the PC_ON input is NOT connected by the user, the PC can be
booted in the familiar way by connecting the supply voltage and shut
down via the battery by switching off the supply voltage.
Service life of the rechargeable battery
Attention
This procedure significantly reduces the service life of the rechargeable
battery and should therefore not be used.
• Once the PC has shut down, the Power Status output is switched
from 24 V to 0 V. Via this output a signal lamp can be connected or a
contactor for de-energizing the whole system. The maximum load for
the Power Status output is 0.5 A and a suitable fuse should be
provided.
C6930 17

Installation Instructions
UPS output
In order to maintain a screen display for the PC in the event of a power
failure, the power supply unit is equipped with a UPS output for connecting
a Control Panel. The maximum load for the output is 1.4 A (max. 2.5 A
from 2016 and later).
UPS output function
• The 27 V DC connection at the UPS output is live even after a power
failure. The maximum load is 1.4 A (max. 2.5 A from 2016 and later).
• Once the PC has been de-energized via the UPS software, the UPS
output is switched to 0 V. Any connected panel is thus switched off,
and total discharge of the rechargeable battery is prevented.
Wiring diagram
Wiring according to the wiring diagram (the circuit of PC_ON and Power-
Status is symbolical):
Wiring diagram external
switch and power supply
Connection of the Battery Pack and UPS Output
Note
Connection of the Battery Pack and UPS Output only in combination with
integrated UPS (order option).
18 C6930
