Becom Argos3D-P230 Instructions for use

Argos3D-P230/P231
Hardware User Manual
Version 5

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
2| 24
BECOM Systems GmbH
Gutheil-Schoder-Gasse 17
1230 Wien
AUSTRIA
[e-mail]
systems.becom-group.com
Argos3D-P230/P231 –Hardware User Manual
Publication date: April 17, 2020
Subject to change without notice. Errors excepted.
This document is protected by copyright. All rights reserved. No part of this document may be reproduced or
transmitted for any purpose in any form or by any means, electronically or mechanically, without expressly
written permission by BECOM Systems.
Windows is a registered trademark of Microsoft.

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
3| 24
Table of Contents
1General Information ...........................................................................................................................................................................................................6
1.1 Symbols Used.....................................................................................................................................................................................................................6
1.2 Certification ...................................................................................................................................................................................................................7
1.2.1 Eye Safety..................................................................................................................................................................................................................7
1.3 Safety instructions ...................................................................................................................................................................................................7
1.4 Electrical connection..............................................................................................................................................................................................7
2Argos3D-P230 Components ....................................................................................................................................................................................... 8
3Mechanical Description...................................................................................................................................................................................................9
3.1 Dimensions .....................................................................................................................................................................................................................9
3.1.1 Top view .....................................................................................................................................................................................................................9
3.1.2 Bottom view............................................................................................................................................................................................................9
3.1.3 Front view ...............................................................................................................................................................................................................10
3.1.4 Back view.................................................................................................................................................................................................................10
3.1.5 Side view...................................................................................................................................................................................................................11
3.1.6 Mount Spacing.....................................................................................................................................................................................................11
4Interface Description .......................................................................................................................................................................................................12
4.1 Signal naming.............................................................................................................................................................................................................12
4.2 Connector Numbering ........................................................................................................................................................................................12
4.2.1 Connector description..................................................................................................................................................................................13
4.2.2 Power supply........................................................................................................................................................................................................13
4.2.3 Power over Ethernet......................................................................................................................................................................................13
4.2.4 DIO...........................................................................................................................................................................................................................14
4.2.5 Trigger In...................................................................................................................................................................................................................14
4.2.6 RS485 Mounting Option .......................................................................................................................................................................14
4.3 Mating Parts ................................................................................................................................................................................................................14
4.3.1 Interconnection cable...................................................................................................................................................................................14
4.3.2 Development Adapter..................................................................................................................................................................................14
5Software.....................................................................................................................................................................................................................................16
5.1 Firmware.........................................................................................................................................................................................................................16

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
4| 24
5.2 Demo Application...................................................................................................................................................................................................16
5.3 Getting Started Software Development Example .....................................................................................................................16
6Appendix....................................................................................................................................................................................................................................17
6.1 Operating Conditions ..........................................................................................................................................................................................17
6.1.1 Input current .........................................................................................................................................................................................................17
6.1.2 Temperature at the case.............................................................................................................................................................................17
6.2 Optical Characteristics........................................................................................................................................................................................18
6.3 Performance ................................................................................................................................................................................................................18
6.3.1 Environmental Conditions.........................................................................................................................................................................18
6.3.2 Precision....................................................................................................................................................................................................................18
6.3.3 Accuracy ...................................................................................................................................................................................................................19
6.4 Sensor Location...................................................................................................................................................................................................... 20
7Support........................................................................................................................................................................................................................................21
7.1.1 General Support.................................................................................................................................................................................................21
7.2 Related Products .....................................................................................................................................................................................................21
8Product History....................................................................................................................................................................................................................22
8.1 Version Information .............................................................................................................................................................................................22
8.1.1 Argos3D-P230......................................................................................................................................................................................................22
8.2 Anomalies.....................................................................................................................................................................................................................22
9Document Revision History.......................................................................................................................................................................................23
AList of Figures and Tables ...........................................................................................................................................................................................24

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
5| 24
© BECOM Systems GmbH 2020
All Rights Reserved.
The information herein is given to describe certain components and shall not be considered as a guarantee of
characteristics.
Terms of delivery and rights of technical change reserved.
We hereby disclaim any warranties, including but not limited to warranties of non-infringement, regarding
circuits, descriptions and charts stated herein.
BECOM Systems makes and you receive no warranties or conditions, express, implied, statutory or in any
communication with you. BECOM Systems specifically disclaims any implied warranty of merchantability or fitness
for a particular purpose.
BECOM Systems takes no liability for any damages and errors causing of the usage of this board. The user of this
board is responsible by himself for the functionality of his application. He is allowed to use the board only if he
has the qualification. More information is found in the General Terms and Conditions (AGB).
Information
For further information on technology, delivery terms and conditions and prices please contact BECOM Systems
www.becom-group.com

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
6| 24
1General Information
This guide applies to the Argos3D-P230/P231 from BECOM Systems. Follow this guide chapter by chapter to set up
and understand your product. If a section of this document only applies to certain camera parts, this is indicated
at the beginning of the respective section.
The document applies to product V1.0.x
1.1 Symbols Used
This guide makes use of a few symbols and conventions:
Warning
Indicates a situation which, if not avoided, could result in minor or moderate injury and/or
property damage or damage to the device.
Caution
Indicates a situation which, if not avoided, may result in minor damage to the device, in
malfunction of the device or in data loss.
Note
Notes provide information on special issues related to the device or provide information that will
make operation of the device easier.
Procedures
A procedure always starts with a headline
1. The number indicates the step number of a certain procedure you are expected to
follow.
Steps are numbered sequentially.
This sign indicates an expected result of your action.
References
This symbol indicates a cross reference to a different chapter of this manual or
to an external document.

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
7| 24
1.2 Certification
The product is in X-grade state.
1.2.1 Eye Safety
Illumination:
Laserdiodes
Wavelength
850nm (typ.)
Laser classification according to
EN 60825-1 pending
Output power
24 W peak
Caution
This device emits Laser radiation.
1.3 Safety instructions
Important
This manual is part of the device and contains information and illustrations about the correct
handling of the device and must be read before installation or use. Observe the operating
instructions. Non-observance of the instructions, operation which is not in accordance with use as
prescribed below, wrong installation or handling can affect the safety of people and machinery.
The installation and connection must comply with the applicable national and international
standards. Responsibility lies with the person installing the unit.
1.4 Electrical connection
Note
The unit must be connected by a qualified electrician.
Device of protection class III (PC III).
The electric supply must only be made via PELV circuits.
The device must only be powered by a limited energy source (≤ 30 V; ≤ 8 A; ≤ 100 VA).
Disconnect power before connecting the unit.

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
8| 24
2Argos3D-P230 Components
c
a
b
c
Figure 2-1: Argos3D-P230 components
a. Case
b. Viewing window for 3D sensor
c. Viewing window for illumination module
d. IP67 compliant connector

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
9| 24
3Mechanical Description
3.1 Dimensions
All dimensions are in mm, tolerance +/-0,2mm.
3.1.1 Top view
Top mounting hole size: M3
162
173
57
65
Figure 3-1: Top view dimensions without cover panel
3.1.2 Bottom view
Bottom mounting hole size: M3
162
173
65
Figure 3-2: Bottom view dimensions

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
10 | 24
3.1.3 Front view
Front mounting hole size: M3
46
65
19
21
13
66
Figure 3-3: Front view without cover panel
3.1.4 Back view
Back view mounting hole size: M3
46
65
13
66
Figure 3-4: Back view without cover panel

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
11 | 24
3.1.5 Side view
173
45
Figure 3-5: Side view without cover panel
3.1.6 Mount Spacing
Caution
Case may become hot!
The user is responsible to take care for an appropriate cooling.
To prevent the Argos3D-P230/P231 from overheating, it is strongly recommended, to keep away nearby objects.
This guarantees a constant airflow for proper cooling. This bounding box may be violated, when other cooling
techniques are provided.
b
a
30,0
15,050,0
c
d
Figure 3-6: Bounding box
a. Argos3D-P230 Case
b. Argos3D-P230 Cover plate (optional)
c. Mating IP67 connector
d. Wall or mounting panel

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
12 | 24
4Interface Description
4.1 Signal naming
Signal names are usually written in capital letters. They are noted in positive logic (positive asserted). If the signal
is negative asserted an “n” will be added as prefix to the signal name.
Type:
The type describes the electrical characteristics of the signal. The following types are available:
•I Input
•O Output
•DN Negative Differential I/O
•DP Positive Differential I/O
•P Power supply
•LCVMOS33 Low voltage CMOS compatible signal with 3.3 V high level and 0 V low level.
•50 V tolerant Accepts input voltage levels up to 50 V (2.5 V logic high threshold)
4.2 Connector Numbering
Figure 4-1: Connector Pin Numbering

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
13 | 24
4.2.1 Connector description
No.
Signal
Type
Description
1
ETH-B_N
DN
Ethernet Lane B
2
ETH-B_P
DP
Ethernet Lane B
3
GND
P
DIO Reference Ground
4
DO
O (50V tolerant)
Digital Output Signal
5
V+
P
Positive Power Supply
6
ETH-C_N
DN
Ethernet Lane C
7
ETH-C_P
DP
Ethernet Lane C
8
ETH-D_N
DN
Ethernet Lane D
9
ETH-D_P
DP
Ethernet Lane D
10
nTRIGGER
I (LCVMOS33)
Trigger Input
11
ETH-A_N
DN
Ethernet Lane A
12
ETH-A_P
DP
Ethernet Lane A
13
GND
P
DI Reference Ground
14
DI
I (50V tolerant)
Digital Input Signal
15
V-
P
Power Ground
Table 4-1: Connector Description
4.2.2 Power supply
The power supply pins are protected against wrong polarity.
Although the operating input voltage range is between 18 V and 33 V, using a stable 24 V power supply unit is
suggested for best performance.
Note
Use inherently limited power sources only!
4.2.3 Power over Ethernet
The Argos3D-P231 has the possibility to be powered via Power over Ethernet (PoE). The IEEE 802.3bt specification
allows a maximum power consumption of 75 W.
Note
For the Argos3D-P230 an external Power over Ethernet adapter is available. This can be used to
operate the Argos3D-P23x cameras on a PoE Plus (IEEE 802.3at) PSE. Please refer to 7.2 for
related products.

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
14 | 24
4.2.4 DIO
The digital Input-Output interface has an optical isolated input and output stage. Driven by the GPIOs 1 (output)
and GPIO 2 (input). See the Software User Manual specifications for GPIO functionality.
The output stage is a solid state relais, and gives the possibility to use the output as a simple switcher. The current
is limited to 200 mA.
If this interface is used as input, the corresponding output must be set to logically 0. Otherwise the input is
constantly shorted. The maximum LOW input detection voltage is 2 V, the minimum HIGH input detection volte is
5 V.
4.2.5 Trigger In
The trigger Input is not optically isolated to minimize the propagation delay. But the input is protected against
50V clamp voltages. A standard 3.3 V LVCMOS signal should be used. The corresponding ground reference is the
negative supply voltage (V-).
4.2.6 RS485 Mounting Option
For some Applications a RS485 communication could be needed. Therefore, the internal hardware could be
modified to route the RS485-A and –B signals to the connector in state of DI (RS485-A) and DIGND (RS485-B).
Ask BECOM Systems for custom modifications.
4.3 Mating Parts
The mating IP67 connector is an A-HDS15-HOOD-WP from ASSMANN WSW components GmbH and available for
purchase e.g. at Digi-Key.
An adjusted adapter cable is available from BECOM Systems.
4.3.1 Interconnection cable
A customized 5 m IP67 compliant cable is available from BECOM Systems. Please refer to 7.2 for related products.
4.3.2 Development Adapter
For development purposes there is an adapter available with standard Ethernet RJ45 interface and a 2.1 mm DC
power supply socket and for digital input, digital output and trigger input a two-pole header each.

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
15 | 24
Figure 4-2: Adapter for Argos3D-P2xx
Please refer to 7.2 for related products.

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
16 | 24
5Software
5.1 Firmware
For a description of the firmware related interfaces, protocol descriptions, register settings, etc. please refer to
the Software User Manual.
5.2 Demo Application
For the first evaluation of the camera and to evaluate different settings and configurations a .NET demo
application for Microsoft Windows is provided: BLT-ToF-Suite. The demo application can be downloaded from our
support web site support.systems.becom-group.com.
5.3 Getting Started Software Development Example
To facilitate the integration of the Argos module in your own application a getting started example will be
available on our download site. Please refer to our support site support.systems.becom-group.com.

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
17 | 24
6Appendix
6.1 Operating Conditions
Symbol
Parameter
Min
Typical
Max
Unit
VIN
Input supply voltage1)
18
24
33
V
IAVG
Average input current
TBD
TBD
A
IPK
Peak input current
TBD
TBD
A
T
Operating temperature 2)
-20
502)
°C
T
Storage temperature
-40
+85
°C
FITP
Frame-rate Integration Time Product
TBD
Table 6-1: Operating Conditions
1) Note
The connector is used as section point.
2) Note
The maximum operating temperature depends on the frame-rate and integration time.
6.1.1 Input current
The average input current depends on the selected frame-rate (fps) and the integration time (tINT). The following
figure shows typical values. The values on the x axis shows the FITP which has been calculated with the following
equation:
  󰇟󰇠

TBD
Figure 6-1: Input current @24V depending on frame-rate integration time product
6.1.2 Temperature at the case
The following figure shows the expected case temperature @ 25 °C ambient temperature depending on the
frame-rate integration time product (FITP). The FITP has been calculated as follow:
  󰇟󰇠

TBD
Figure 6-2: Expected cooling plate temperature depending on frame-rate integration time product

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
18 | 24
The temperature on the casing can be reduced by mounting an additional heat sink on the cooling plate.
Caution
The user is responsible to take care for an appropriate cooling if the Argos camera is mounted
into a case.
Caution
Be careful to not stress the device beyond the limits, otherwise you may damage the device.
6.2 Optical Characteristics
Symbol
Parameter
Min
Typical
Max
Unit
#LEDs
Nr. of laser diodes
8
ΛCENTROID
Centroid-wavelength of illumination
850
nm
Δλ
Spectral bandwidth
5
nm
POPT
Average optical output power during
integration
W
FoVH
Horizontal field of view
80
Deg
FoVV
Vertical field of view
60
Deg
Table 6-2: Operating Parameters
6.3 Performance
6.3.1 Environmental Conditions
All the following measurements have been acquired at the following constant environmental conditions.
Parameter
Value
Temperature
23 °C
Humidity
35 %
Ambient light
500 Lux
Modulation Frequency
40 MHz
Frame-rate
30 fps
Table 6-3: Environmental Specification
6.3.2 Precision
The following graph shows the standard deviation over 100 samples on an integration time of 0,3ms and a
reflectivity of 90%

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
19 | 24
Figure 6-3: Precision
6.3.3 Accuracy
The following figures has been determined by an integration time of 0,3ms with a reflectivity of 90%.
Figure 6-4: Accuracy
0
2
4
6
8
10
12
14
16
750 1250 1750 2250 2750 3250 3750 4250
Precision [mm]
Distance [mm]
Precision
-15
-10
-5
0
5
10
15
750 1250 1750 2250 2750 3250 3750 4250
Relative Error [mm]
Distance [mm]
Accuracy

© BECOM Systems 2020
Hardware User Manual - Argos3D-P230/P231
Last change: 17 April 2020/Version 5
20 | 24
6.4 Sensor Location
44
Figure 6-5: Location of optical center of sensor
