BED BATH & Beyond WF307312AAE User manual

Wardrobe
Assembly Instructions - Please keep for future reference
WF307312AAE ,WF307313AAE ,WF307317AAE，WF307318AAE
Dimensions
Width - 21.1inch
Depth - 19.7inch
Height - 80inch
Important – Please read these instructions fully before starting assembly
ZG-058#Issue 1 - 07/07/23

Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
the following pages.
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Handy Hints
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts
• Regularly check and ensure
tightend properly.
• During assembly do not stand
or put weight on the product,
this could cause damage.
• Assemble the item as close
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
• Parts of the assembly will be
easier with 2 people.
• To reduce
the likelihood of
damaging your
product please
ensure that your
power drill is set on a low torque
setting.
WARNING
In order to help prevent overturning –
To help prevent product toppling over please follow the below steps:-
Do not open more than one drawer at a time
Do not place heavy items in the top drawers
Do not place heavy items on top of the furniture, unless the furniture has been
designed for this purpose
You will need to provide wall plugs and screws applicable for your wall type
1
!
• Remove all fittings from the
to its final position (in the same
unit or your floor.
That all bolts and fittings are
please follow these instructions
Do not allow children to climb or hang on the furniture
Use the anti tip stap or wall fixing method provided (if applicable)
please note that only the anti tip strap is provided.

Components - Fittings
Note:
may be supplied than are required.
Male Camlock x 68
A
D
G
Female Camlock x 68
B
E
C
Dowel x 30
F
Please check you have all the panels listed below
The quantitie below are the correcet amount to complete the assembly. In some cases more fittings
6*50mm Screw x 4
I
J K L
M
Handle & Fixings x 4
4*30mm Screw x 12
H
Drawer slider 14" x 4 Ø20 Sticker x 32
Nut x 10
Back Panel Stiffener x 20
Tools required
Phillips screwdriver
(medium & large)
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
The screws length is measured from the head to the point (30mm screw shown).
3*12mm Screw x 32
4*35mm Screw x 6
Shelf Support Pin x 8
Hex Key M4 x 1

Using Camlocks
12
DO NOT OVER TIGHTEN.
NE PAS SERRER EXCESSIVEMENT.
34
4
Step 1
Step 3
Step 2
Step 4
Connect the male
camlock as diected in
the assembly instructions
using a scewdriver.
Push the male camlock
into the entry hole.
Insert the femle
camlock as shown in the
instruction.
Note：ensure that the
arrow on the top of the
camlock points towards
the entry hole for the
male camlock.
Turn the female camlock
clockwise with a
screwdriver.
You should feel a click
when the camlock is
locked in place.
The joint is now secure.

Assembly Instructions
1
2
3
4
5
67
7
8
8
9
9
10
11
12
13
14
15
16
17
18
18
19
20
20
21
21
23
24
25
25
25
26
27
28
29

Assembly Instructions
Step 1
Step 2
J2
J1 J2
J1
X4
J x 4
J
J1 installed on No.7and 8(Step 3，Step 27)
J2 installed on the bottom of the drawer.(Step 34,Step 41)
A x 20
A
1
2
AX10
AX10

Assembly Instructions
Step 3
Step 4
1
2
J1
J1
J1
J1
J1
J1
K x 12
K
K
K
K
K
K
K
K
K
K
K
K
K
3
4
A x 2
A
C x 2
C
A
A
C
C
K
J1

Assembly Instructions
Step 5
Step 6
B x 2
B
1 2 3
4
3
B
B
3
4
6
3
4
2
B x 5
B
1 2 3
B
B
B
B
B

Assembly Instructions
Step 7
Step 8
2
5
7
7
6
3
B x 5
B
1 2 3
B
B
B
B
B
A x 8
A
AA
A
A
9X 2

Assembly Instructions
Step 9
Step 10
5
7
7
6
3
2
8
B x 10
B
1 2 3
2
5
7
7
1
3
6
B
B
B
B
BB
B
B
B
B

Assembly Instructions
Step 11
Step 12
C
C
C
C
5
2
1
C x 4
C
2
1
5
9
B x 4
B
1 2 3
BB
B
B

Assembly Instructions
Step 13
Step 14
8
C x 4
C
C
C
C
C
1
2
A x 16
A
C x 4
C
C
C
C
C
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
10
11

Assembly Instructions
Step 15
Step 16
A x 2
A
C x 8
C
13
12
16
C
C
C
C
C
C
C
C
A
A
13
12
B x 2
B
1 2 3
B
B
12
13

Assembly Instructions
Step 17
Step 18
11
16
12
B x 4
B
1 2 3
B
B
B
B
B x 4
B
1 2 3
16
12
14
15
BB
BB
11

Assembly Instructions
Step 19
Step 20
18
18
17
11
C x 2
C
C
C
14
15
15
14
11
10
B x 8
B
1 2 3
BB
BB
B
B
BB

Assembly Instructions
Step 21
Step 22
B x 4
B
1 2 3
11
10
9
BB
B
B
A
A
19
A x 2
A

Assembly Instructions
Step 23
Step 24
B x 2
B
1 2 3
B
B
19
11
10
D x 4
D
D
D
D
D
19
10

Assembly Instructions
Step 25
Step 26
A x 4
A
19
A
A
A
A
19
10
10
11
1
2
B x 4
B
1 2 3
B
B
B
B

Assembly Instructions
Step 27
Step 28
1
2
K x 4
K
K
K
K
K
J1
J1
J1
K
C
C
C
C
21
21
C x 4
C
10
11

Assembly Instructions
Step 29
Step 30
E x 6
E
21
21
20
20
E
E
E
E
E
E
HH
HH
HH
H H
H
H x 8
H
