BEEK BT-LT1200 User manual

Multi Function LAN Cable Tester
BT-LT1200
User Manual
2

Multi Function LAN Cable Tester
BT-LT1200
User Manual
3
Thank you for purchasing the Cable Tester. Please read the manual before using the Cable Tester and use
properly.
For using the Cable Tester safely, please first read the「Safety Information」carefully in the manual.
The manual should be kept well in case of reference.
Keep the S/N label for after-sale service within warranty period. Product without S/N label will be charged for
repair service.
If there is any question or problem while using the Cable Tester, or damages occurred on the product, please
contact our technical department.

Multi Function LAN Cable Tester
BT-LT1200
User Manual
4
Content
1. Safety information.................................................................................................................................................. 1
2. Production Introduction......................................................................................................................................... 2
2.1 Feature........................................................................................................................................................ 2
2.2 Packing list .................................................................................................................................................. 2
2.3 Interface and Function Introduction ........................................................................................................... 3
3. Operation ............................................................................................................................................................. 6
3.1 Installing the Battery................................................................................................................................... 6
3.2 Auto power off function ............................................................................................................................. 6
3.3 OSD Menu................................................................................................................................................... 6
4. Cable tester ............................................................................................................................................................ 7
4.1 UTP cable test ............................................................................................................................................. 7
4.1.1 Cable tracer .................................................................................................................................... 7
4.1.2 UTP cable test ................................................................................................................................. 8
4.1.3 Short circuit detection .................................................................................................................. 10
4.14 Continuity detection in the state of connected switches .............................................................. 10
4.2 RJ45 cable TDR test................................................................................................................................... 11
4.3 TDR 2.0 Test (Optional) ............................................................................................................................. 12
5. Network test ........................................................................................................................................................ 13
5.1 Port flicker................................................................................................................................................. 13
5.2 PING.......................................................................................................................................................... 14
5.3 IP search.................................................................................................................................................... 15
5.4 NetSpeed .................................................................................................................................................. 15
6. Video level meter test .......................................................................................................................................... 16
7. Other functions .................................................................................................................................................... 16
7.1 Setting....................................................................................................................................................... 16
7.2 PD powered detected ............................................................................................................................... 17
7.3 Telephone status....................................................................................................................................... 17
8. Specification......................................................................................................................................................... 18

Multi Function LAN Cable Tester
BT-LT1200
User Manual
5
1
1. Safety information
◆The cable tester is intended to use in compliance with the local rules of the electrical usage and avoid to apply
at the places which are inapplicable for the use of electrics such as hospital, gas station etc.
◆To prevent the functional decline or failure, the product should not be sprinkled or damped.
◆The exposed part of the cable tester should not be touched by the dust and liquid.
◆During transportation and use, it is highly recommended to avoid the violent collision and vibration of the tester,
lest damaging components and causing failure.
◆Don't leave the tester alone while charging and recharging. If the battery is found severely hot, the tester should
be powered off from the electric source at once. The tester should not be charged over 10 hours.
◆Don't use the tester where the humidity is high. Once the tester is damp, power off immediately and move away
other connected cables.
◆The cable tester should not be used in the environment with the flammable gas.
◆Do not disassemble the instrument since no component inside can be repaired by the user. If the disassembly is
necessary indeed, please contact with the technician of our company.
◆The instrument should not be used under the environment with strong electromagnetic interference
◆Don't touch the tester with wet hands or waterish things.
◆Don't use the detergent to clean and the dry cloth is suggested to use. If the dirt is not easy to remove, the soft
cloth with water or neutral detergent can be used. But the cloth should be tweaked sufficiently.

Multi Function LAN Cable Tester
BT-LT1200
User Manual
6
2
2. Production Introduction
2.1 Feature
●2.4 inch TFT-LCD screen, 320x240 resolution
●Secondary code digital mode, decisively rejects noise and false signals, locate cables quickly and easily.
●Advanced UTP cable test, test UTP cable's sequence, type and remote kit, quickly detect the near-end, mid-end
and far-end fault point of RJ45 cable connector.
●RJ45 cable TDR test, test cable quality, length and attenuation.
●HD Coaxial video level meter, can detect the TVI/CVI/AHD/CVBS signal peak value, SYNC value and burst value.
●Port Flash, can search the switch port which connect the meter.
●PING test, check whether IP camera or other network equipment’s Ethernet port is working normally, the IP
address whether is correct.
●IP Scan, quickly find the IP address of the IP camera or other network equipment which connected to the meter.
●Link status, quickly identify the connected network port (10/100/ 1000M) and duplex mode (full duplex / half
duplex)
●TDR cable test 2.0, can test break point and short-circuit of cat 6e/5e (4 pairs), power line, BNC cable and
Telephone line, etc. the Max. 1.2km length （Optional）
●3.7 V /2000mAh Lithium Ion Battery, after 3 hours charging, working time lasts 18 hours
2.2 Packing list
1) Multi-function cable tester
2) Wire receiver
3) Adaptor DC5V 1A
4) Micro USD charging cable
5) RJ45 cable
6) RJ11 cable
7) TDR alligator clip cable
8) Polymer lithium ion battery (3.7V DC 2000mAh)
9) User Manual
