Beemoo Maxi 4 Twin User manual

UK ································ 12
SE ································ 17
NO ································ 22
DK ································ 27
FI ································ 32
DE ································ 37

L R
19
20
L R
19
20
FIG 1
1

27
FIG 2
FIG 3
2

FIG 4 FIG 5
FIG 6 FIG 7
FIG 8
3

FIG 9
FIG 10
FIG 11
4

FIG 12
FIG 13.1
FIG 14.1
FIG 13.2
FIG 14.2
5

FIG 17.1 FIG 17.2
A
A
FIG 15
FIG 16
6

FIG 24 FIG 25
FIG 18 FIG 19
FIG 20 FIG 21
FIG 22 FIG 23
7

FIG 29
FIG 26 FIG 27
c
D
FIG 28
8

FIG 31
FIG 30
9

FIG 32
FIG 33
10

2
1
FIG 34
11

WARNING! To avoid injury ensure that your child is kept away when
unfolding and folding this product.
WARNING! Never leave the child unattended.
WARNING! Do not let the child play with this product.
WARNING! Always use the restriant system.
WARNING! Do not allow the child to stand up on the seat.
WARNING! Any additional load, hanging on the handles of the stroller and/or
behind the backrest and/or on the sides of the stroller, causes deterioration of
its stability.
WARNING! Do not use the product on stairs and escalators.
WARNING! Check that the pram body or seat unit or car seat attachment
devices are correctly engaged before use.
WARNING! This product is not suitable for running or skating.
WARNING! Always activate the brakes when stop the stroller, put or take off
any accessories.
WARNING! Ensure that all the locking devices are engaged before use.
WARNING! The maximum basket load is 3 kg.
WARNING! The front carry cot used as bassinet mode is suitable for a child
who cannot sit up unaided, roll over and cannot push itself up on its hands
and knees. Maximum weight of the child :9KG.
WARNING! The rear seat unit is not suitable for children under 6 months,
max weight of the child 15KG.
WARNING! It’s not allowed to reverse using the front and rear seat unit.
WARNING! Do not place the product near open flame or other heat sources.
WARNING! Do not use the stroller if any screws, nuts, bolts, etc. are missing
or any component is damaged.
WARNING! Do not lift the stroller by the bumper bar it may disengage.
WARNING! Use only parts and accessories supplied or recommended by the
manufacturer. Do not use other parts or accessories.
WARNING! Always apply the brakes when the pushchair is stationary,and
when placing and removing children.
WARNING! A statement that the vehicle shall be used only for up to the
number of two children for which it has been designed.
WARNING! Carrying handles shall be left out of the pram body during use.
WARNING! The chassis is suitable for 0 month seat unit, 6 month seat unit,
2in1 seat unit, car seat and carry cot.
WARNING! Not add another mattress on top of the mattress provided or
recommended by the manufacturers.
IMPORTANT – READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
12
This product complies with EN 1888-1:2018+A1:2022.

Stroller frame parts(FIG.1)
1.Handle grip
2.Folding lever button
3.Handle tube
4.Main connector
5.Auto lock
6.Brake and release pedal
7.Rear wheel
8. Wheel cap
9.Rear leg tube
10.Front leg tube
11.Front wheel quick release button
12.Front wheel
13.Directional lock
14.Front wheel socket
15.Folding lever
16.Rear wheel quick release button
17.Stabilizing tube
18.Brake line tube
19.Front adaptor
20.Rear adaptor
Front seat unit parts(FIG.2)
Rear seat unit parts(FIG.3)
21.Seat unit upper
22.Canopy holder
23.Connectors of seat unit
24.Safety unit base
25.Seat unit adjustment button
26.Seat unit release catch
27.Seat unit base
28.Seat unit bottom
29.Safety bar
30.Canopy frame
To open the stroller frame
WARNING! To avoid injury ensure that your child is kept away when unfolding and folding
this product.
1.The status when it's folded(FIG.4).
2.Release the folding hook as the picture shows(FIG.5).
3.Hold the handles and lift upwards until the chassis is fully expanded(FIG.6).
4.The status when it's unfolded(FIG.7).
13

Front wheel assembly(FIG.8)
Insert the front wheels into the front legs until you hear a click sound.
The front wheel orientation(FIG.9)
Push in the upper part of the direction lock to lock the front wheel (as A shows),
push up the button to achieve 360 degree rotation (as B shows).
Front wheel release(FIG.10)
If you press the quick release button on both sides of the front wheels, it can automatically
remove the wheel.
Rear wheel assembly(FIG.11)
Insert the rear axle into the hole, until you hear a click sound. Ensure that it is
engaged before use.
Rear wheel release(FIG.12)
Press the rear wheel quick release button to unlock the rear wheels (as the pictures shows).
To use the brake
1.Step down the brake pedal until you hear a click sound to engage brake
mechanism(A)(FIG.13.1).
2.Step up the brake pedal to unlock the brakes(B)(FIG.13.2).
To use safety bar
WARNING: Install the safety bar before using.
Installing the bar: Slide the bar tips into the relative opening till hearing click sound(FIG.14.1).
Releasing the safety bar: Push two buttons of each side of the bar while pulling it out(FIG.11.2).
Canopy attachment(FIG.15)
Fix the attachment brackets of the canopy to the metal construction (Point A).
WARNING: must install the canopy before using the stroller.
Canopy release(FIG.16)
Pull the brackets of the canopy off the metal construction to realize the release.
To use safety belts
Lock(FIG.17.1) Open(FIG.17.2)
Assembling the carrycot
Remove the apron(A) by undoing the press studs(FIG.18).
14

Remove the mattress (B)(FIG.19).
Unfasten all press studs(C) on both sides of the carrycot and remove the liner(FIG.20).
Lift up the rim of the carrycot(D)(FIG.21).
Holding straps (E), pull the bars in the direction shown until the bars locate in slots (F).
Replace the liner and reattach press studs (C). Insert the mattress(FIG.22).
Fasten the hood press studs on both sides of the carrycot (G).Pull the carrycot
hood/handle into the vertical position until it clicks into place (H)(FIG.23).
Folding the carrycot
Remove the apron (A) and mattress (B)(FIG.24).Close the canopy(FIG.25).Unfasten all press
studs (C) on both sides of the carrycot and remove the liner(FIG.26).Holding the straps (D),
pull the bars into the centre of the carrycot and allow the body of the carrycot to collapse
down(FIG.27).Replace the liner and mattress.
Carrycot assembly(FIG.28)
WARNING: This stroller is suitable for child from 6 months to 15kg used as seat unit and
suitable for child from birth to 9kg used as carrycot. Please use the safety belts when the
child can sit unaided.
1.Insert the front adaptor(A) into both sides of sockets on frame(B), until hear a click sound
to make sure the front adaptors are installed correctly.
2.Match the connector[c] of both sides and sockets on front adaptor(d),until hear a click
sound to make sure the seat unit is installed correctly.
IMPORTANT: The carrycot can only be fittedparent facing as shown.
Carrycot release(FIG.29)
Push the release button on both sides of the seat unit and pull up the seat unit to release it.
Adjustment of the canopy(FIG.30)
Three or two sections are available by using the zipper.
Rear seat unit assembly(FIG.31-FIG.32)
WARNING: 1. This stroller is not suitable for children under 6 months, max weight of the
child 15KG. Please use the safety belts when the child can sit unaided.
2.The rear wheels should be assembled before putting the rear adaptors.
1.Install the rear adaptors on the frame, move the rear adaptors according to the graphic
direction until touch the rear wheel plastic, and then press the fixed button.
2.Match the connector[c] of both sides and sockets on rear adaptor(d), until hear a click
sound to make sure the rear seat unit is installed correctly.
WARNING: 1. Rear seat unit is not reversible. It can't be parent-facing.
15

Rear seat unit release(FIG.33)
Push the release button on both sides of the seat unit and pull up the seat unit to release it.
To fold the stroller(FIG.34)
1.The rear seat unit and rear adaptors should be removed before folding, and change into front
seat unit mode and the direction for the seat unit must be forward and adjust it into minimum
angle when be folded.
2.Fold the canopy.
3.Press the button on the right handle, pull up the folding lever at the same time, fold it down
until it is completely folded, attach the auto lock.
Care and maintenance:
1.Fabric: sponge clean only with a mixture of water and mild detergent. Do not iron. Do not
bleach.
2.Periodically check for loose and broken parts.
3.Exposing the stroller to direct sunlight for long periods may cause fading.
4.If the stroller becomes wet, dry the metal parts and store it at cool and ventilate.
5.Check if the air pressure of the wheels is normal or not before using (the standards air
pressure is 20 Psi or 137.9Kpa)
16

Viktigt: Spara dessa instruktioner för framtida bruk.
VARNING: Säkerställ att ditt barn befinner sig på säkert avstånd när du fäller upp eller
ned produkten för att förhindra att ditt barn kommer till skada.
VARNING: Lämna aldrig ditt barn utan uppsikt.
VARNING: Låt inte ditt barn leka med produkten.
VARNING: Använd alltid fempunktsselen.
VARNING: Låt inte barnet stå upp i sitsen.
VARNING: Häng inte väskor eller påsar på handtaget då detta påverkar vagnens
stabilitet.
VARNING: Använd inte i rulltrappor eller trappor. Fäll ihop barnvagnen och bär den
istället.
VARNING: Säkerställ att barnvagnen, sittdelen, liggdelen och/eller adaptern för
babyskyddet är korrekt monterade före användning.
VARNING: Produkten är inte avsedd för löpning och liknande.
VARNING: Tryck alltid ner bromsen när du stannar barnvagnen eller justerar eventuella
vagnleksaker.
VARNING: Säkerställ att barnvagnen är korrekt monterad före användning.
VARNING: Belastningen i varukorgen får inte överstiga 3 kg.
VARNING: Överbelasta inte barnvagnen då den kan bli instabil. Sittdelens maxvikt på
15 kg får inte överstigas.
VARNING: barn som inte kan sitta upp själva, rulla Den främre liggdelen är lämplig för
runt eller resa sig på händer och knän. Maxbelastning för liggdelen är 9 kg.
VARNING: Det bakre sätet är lämpligt för barn från 6 till 36 månader, med en maxvikt
på 15 kg.
VARNING: Använd inte barnvagnen nära öppen eld, grillar eller värmeelement.
VARNING: Använd inte barnvagnen om skruvar, muttrar etc. saknas eller om någon del
är skadad.
VARNING: Lyft inte barnvagnen i bygeln, då den kan lossna.
VARNING: Använd endast reservdelar som säljs eller rekommenderas av tillverkaren
eller återförsäljaren.
VARNING: Aktivera alltid bromsen när du ska lyfta ett barn i eller ur vagnen.
VARNING: Barnvagnen lämpar sig för upp till två barn åt gången.
VARNING: Liggdelens bärhandtag ska vara utvikt utanför liggdelen vid användning i
barnvagnen.
17
Produkten uppfyller säkerhetskraven för EN 1888-1:2018+A1:2022.

Chassits delar(FIG.1)
1.Handtag
2.Knapp för hopvikning
3.Handtagsram
4.Fäste för sitt- eller liggdel
5.Autolås
6.Bromspedal
7.Bakhjul
8. Navkapsel
9.Bakaxel
10.Främre ram
11.Knapp för att lossa framhjul
12.Framhjul
13.Svänglås
14.Fäste för framhjul
15.Spak för hopvikning
16. Knapp för att lossa bakhjul
17.Stabiliseringsaxel
18.Bromsaxel
19.Adapter för främre positionen
20.Adapter för bakre positionen
Delar för främre sätet(FIG.2)
Delar för bakre sätet(FIG.3)
21.Överdel
22.Fäste för sufflett
23.Fästen för sätet
24.Fäste för bygel
25.Justeringsknapp
26.Knapp för att avlägsna sitsen
27.Fäste för sittdelen
28.Underdel
29.Bygel
30.Sufflettens ram
Fälla upp chassit
VARNING! Säkerställ att ditt barn befinner sig en bit bort när du fäller ihop eller fäller upp
produkten för att förhindra att ditt barn kommer till skada.
1.Chassit i hopfällt läge(FIG.4).
2.Lyft spärren enligt bilden(FIG.5).
3.Greppa handtaget och lyft uppåt tills chassit är helt uppfällt(FIG.6).
4.Chassit i uppfällt läge(FIG.7).
18
