Beghelli Zone Sensing Panel User manual

INSTRUCTIONS
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed including the following:
1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS
2. Disconnect power before performing work on electrical equipment.
3. Do not use outdoors.
4. Do not let power cords touch hot surfaces and do not mount near gas or electric heaters.
5. Equipment should be mounted in locations and at heights where unauthorized personnel will not readily
subject it to tampering.
6. The use of accessory equipment not recommended by Beluce Canada Inc., may cause an unsafe condition,
and will void the unit’s warranty.
7. Do not use this equipment for other than its intended purpose.
8. Servicing of this equipment should be performed by qualified service personnel.
9. SAVE THESE INSTRUCTIONS!
INSTALLATION
1. Secure the zone sensing panel to your wall or mounting surface.
2. Open the unit by pulling on the cabinet door (Figure 1). The hinged front cover can then be swung open and pulled
back, out of the way.
3. The cabinet supplied will be similar to that shown in (Figure 1) and may change slightly depending on the voltage of
the unit purchased.
4. Route wires into the cabinet utilizing the appropriate conduit and hub (supplied by others) to the terminal blocks.
Refer to (Figure 3) for typical connection or (Figure 4) for user-assigned DC Zones.
5. All connections are made within the ZSP utilizing heavy duty large gauge terminal blocks.
6. Make proper wiring connections within the cabinet as per diagram supplied (Figure 2)
7. Route wires and secure in place.
8. The cabinet purchased should not have AC power turned ON until on-site regulatory approval has been completed.
Zone Sensing Panel (ZSP)
926000145
Beluce Canada Inc., 3900 14th Avenue, Markham, ON L3R 4R3 Tel: [phone] Fax: [phone]
09/23/2020

Figure 1 Figure 2
Zone Sensing Panel
Terminal Block Inputs and Outputs Layout
Zone 1 (+)
Zone 2 (+)
Zone 3 (+)
Zone 4 (+)
Zone 1 (-)
Zone 2 (-)
Zone 3 (-)
Zone 4 (-)
Zoned DC Outputs
TO DC Loads
CAUTION: Disconnect Main Power and Zoned AC Before Servicing Unit!
Main AC
Power Input
Line
Neutra
l
Load(+)
Load(-)
AC To:
&
DC From:
Emergency
Unit
Line
Neutra
l
GND
Zone 1 Zone 2 Zone 3 Zone 4
Line
Neutral
Line
Neutral
Line
Neutral
Line
Neutral
Zoned Inputs
FROM Unswitched AC Feed
GND
Input: 120VAC, 0.8A, 60Hz
DC Load Current: 16A max. per Zone
DC Load Voltage: 6, 12, or 24VDC
AC Fuse: 1A max.
DC Load Fuse:
Instructions:
Press TEST BUTTON (Zone1-4) once to start DC output
timer for each Zone. Set Time is 5-20 minutes.
Press TEST BUTTON (Zone1-4) the second time to end
testing before the timer is up.
In order for this ZSP unit to function properly, any unused
AC Zone input must receive power from Main AC input.
AC to Emergency Unit is 120VAC.
Designed to work with Beghelli Emergency Unit, which the
peak AC power consumption is less than 85VA.
Side Terminal 1 Top Terminal
Side Terminal 2
10A or 20A max. per Zone








$ $
% %
& &
' '
