Beko SD 8041 K User manual

01M-8816611200-0823-01
SD 8041 K
EN
User Manual
Cordless Stick Vacuum Cleaner

Please read this manual
first!
Dear Customer,
Thank you for selecting a Beko product.
We hope that you get the best results
from your appliance which has been
manufactured with high quality and
state-of-the-art technology. For this
reason, please read this user manual and
all other provided documents carefully
before using the appliance and keep it
as a reference for future use. If you hand
over the appliance to someone else, give
the user manual as well.
Follow the instructions by paying
attention to all the information and
warnings in the user manual.
Meanings of the symbols
Following symbols are used in various
sections of this manual:
Important information and useful
hints about usage.
WARNING: Warnings against
dangerous situations concerning the
security of life and property.
Protection class for electric shock.
1. On/off button
2. Mode button +
3. Mode button -
4. Tube release button
5. Brush release button
6. Electrcal turbo brush
7. Battery pack release button
8. Machne body
9. Dust cup
10. Dust cup release button
11. Chargng staton
12. Power supply plug
13. Crevce
14. Mn turbo brush
15. Soft brush
Techncal data
Rated nput power : 450 W
Input :
100 - 240 V~ 50-60Hz 0.8 A (max)
Output : 36 V 0.6A
Chargng tme : 4-5 hours
Runnng tme max. power: 7 mn.
Runnng tme mn. power to up to:
45 mn.
Techncal and desgn modfcatons reserved.
The values whch are declared n the markngs affxed
on your applance or the other prnted documents
suppled wth t represent the values whch were
obtaned n the laboratores pursuant to the pertnent
standards. These values may vary accordng to the
usage of the applance and ambent condtons.
RECYCLED &
RECYCLABLE
PAPER

3
Parameter of External Power Supply
Manufacturer :
Dongguan Ynl Electroncs Co.,Ltd
Model Identfer : YLS0241A-E360060
Input Voltage : 100-240V~
Input Frequency : 50-60Hz
Input Current : 0.8A
Output Voltage : 36.0V
Output Current : 0.6A
Output Power : 21.6W
Average actve effcency : 87.19%
Effcency at low load(10%) : 79.58%
No-load power consumpton : 0.09W

4
1
2
3
4
5
6
7
8
9
10 11
12 13 14 15

5
EN OPERATION CLEANING AND CARE
RU  
AR  

6
14 15
NEW
13
1 32
4 5 6
7 8 9
1
2
1
1
122
2
24h
1 3
4 5 6
7 8 9
10 11 12
ON/OFF
TURBO
2
102-
104cm

7
14 15
NEW
13
1 32
4 5 6
7 8 9
1
2
1
1
122
2
24h
1 3
4 5 6
7 8 9
10 11 12
ON/OFF
TURBO
2
102-
104cm

8
10
1
2
1
2
24h
12
16
1413 15
1
11
2

Cordless Stick Vacuum Cleaner / User Manual 9 / 14 EN
9 / EN
This section contains safety
instructions that will help protect
from risk of personal injury or
property damage.
Failure to follow these instructions
invalidates the granted warranty.
1.1 General safety
•Ths applance comples wth
nternatonal safety standards.
•Ths applance can be used by
chldren aged from 8 years and
above and persons wth reduced
physcal, sensory or mental
capabltes or lack of experence
and knowledge f they have been
gven supervson or nstructon
concernng use of the applance
n a safe way and understand
the hazards nvolved. Chldren
shall not play wth the applance.
Cleanng and user mantenance
shall not be made by chldren
wthout supervson.
•If the adapter or the applance
tself s damaged, do not use t.
Contact an authorsed servce.
•Your mans power supply should
comply wth the nformaton
suppled on the ratng plate of the
applance.
•Do not use the applance wth an
extenson cable.
•Prevent damage to the power
cable by not squeezng, bendng,
or rubbng t on sharp edges.
•Do not touch the applance or ts
plug when t s plugged f your
hands are damp or wet.
•Do not pull the power cable when
unpluggng the applance.
•Do not vacuum flammable
materals and when vacuumng
cgarette ash, make sure that t
has cooled down.
•Do not vacuum water or other
lquds.
•Protect the applance from ran,
humdty and heat sources.
•Never use the applance n or
near places where combustble or
nflammable ambence or places
are present.
•Unplug the applance before
cleanng and mantenance.
•Do not mmerse the applance
or ts power cable n water for
cleanng.
•Do not attempt to dsmantle the
applance.
1 Important safety and envronmental nstructons

10 / 14 EN Cordless Stick Vacuum Cleaner / User Manual 10 / EN
•Use the orgnal parts or
parts recommended by the
manufacturer only.
•Do not clean the partcles such as
cement, plaster and compressed
paper n order to prevent the flter
from beng clogged and the motor
beng damaged.
•Use the applance only wth the
adapter suppled wth.
•Do not use the applance wthout
flters; otherwse t can get
damaged.
•If you keep the packagng
materals, store them out of the
reach of chldren.
•Ths applance s not ntended for
use by persons (ncludng chldren)
wth reduced physcal, sensory
or mental capabltes, or lack of
experence and knowledge, unless
they have been gven supervson
or nstructon concernng use
of the applance by a person
responsble for ther safety.
•Chldren should be supervsed to
ensure that they do not play wth
the applance.
•The applance s only to be used
wth the power supply unt
provded wth the applance.
•The adapter must be removed
from the socket-outlet and the
battery pack must be removed
from the applance before cleanng
or mantanng the applance
•If the adapter s damaged, t must
be replaced by the manufacturer
or ts agent or smlarly qualfed
person n order to avod hazard.
•Keep fngers, har and loose
clothng from movng parts and
openngs whlst usng the vacuum
cleaner
•The battery must be removed
from the applance before t s
scrapped;
•The applance must be
dsconnected from the supply
mans when removng the battery;
•Please dspose of used batteres
accordng to local laws and
regulatons.
•Ths applance contans batteres
that are only replaceable by sklled
persons.
• WARNING: For the purposes
of rechargng the battery, only
use the detachable supply unt
YLS0241A-E360060 provded
wth ths applance.
•Please remove and nsert the
batteres accordng to UM.
1 Important safety and envronmental nstructons

Cordless Stick Vacuum Cleaner / User Manual 11 / 14 EN
11 / EN
•Rechargeable batteres are to
be removed from the applance
before beng charged;
•Dfferent types of batteres or
new and used batteres are not to
be mxed.
•Batteres are to be nserted wth
the correct polarty.
•Exhausted batteres are to be
removed from the applance and
safely dsposed of.
•If the applance s to be stored
unused for a long perod, the
batteres should be removed.
•The supply termnals are not to be
short-crcuted.
•Only use wth ZB1858 battery.
•The applance s not to be used
by persons (ncludng chldren)
wth reduced physcal, sensory
or mental capabltes, or lack of
experence and knowledge, unless
they have been gven supervson
or nstructon.
•Chldren beng supervsed not to
play wth the applance.
1 Important safety and envronmental nstructons

12 / EN Cordless Stick Vacuum Cleaner / User Manual
2 Part assemblng
2.1 Crevice (13) and soft brush
(15)
Push the round part of the accessory nto the
sucton part untl t clcks. Soft brush cleans your
furnture wthout harmng t (6-7).
2.2 Mini turbo brush (14)
Push the end of the Mn-brush nto the sucton
part untl t clcks.
Remove t by pullng the buttons (6).
3.1 Charging Indicator
Workng Chargng Fully
charged
Lower
power
Persstent
whte lght
Blnkng
whte lght
Persstent
whte lght
Blnkng red
lght
3.2 Charging station (11)
Whle chargng the battery on the chargng dock
the charge ndcator flashes whte.
C
•When you receive this product,
please use the charger provided
by our company to recharge the
battery for 3 hours (no need to
charge it full) and the charging
frequency should be every 3
months.
•Do not place the battery on the
charging base for a very long time.
•When the battery is not in use for a
long time or it is over-discharged,
you may find the working time is
reduced at the first few times.
We recommend you fully charge
the battery (usually 6 hours) and
discharge it. Repeat this action
two times.
3Use

Cordless Stick Vacuum Cleaner / User Manual 13 / EN
4.1 Cleaning and care
Switch off and unplug the appliance ,before cleaning it.
AWARNING:
Never use gasoline,
solvent, abrasive cleaning agents,
metal objects or hard brushes to
clean the appliance.
4.2 Hepa filter
•In order to ensure the performance of the
product, we recommend you clean regularly,
and replace one after 3-6 months. (Depending
on usage)
A
WARNING: Long-term no use,
please keep the battery intact,
stored in a cool dry place, and let the
battery in the semi-state of charge.
Not full or empty. Please enclose
the battery with non-conductive
material to avoid the metal touching
the battery directly, causing the
battery to be damaged.
4.3 Storage
•If you do not intend to use the appliance for a
long time, store it carefully.
•Pull the appliance’s plug out.
•Keep the appliance out of the reach of children.
•Long-term no use, please keep the battery
intact, stored in a cool dry place, and let the
battery in the semi-state of charge. Not full or
empty.
•Please enclose the battery with non-conductive
material to avoid the metal touching the battery
directly, causing the battery to be damaged.
4.4 Handling and
transportation
•During handling and transportation, carry
the appliance in its original packaging. The
packaging of the appliance protects it against
physical damages.
•Do not place heavy loads on the appliance or on
the packaging. The appliance may get damaged.
•Dropping the appliance may render it non-
operational or cause permanent damage.
4.5 Compliance with the WEEE
Directive and disposal of the
waste product
This product complies with EU WEEE
Directive (2012/19/EU). This product
bears a classification symbol for waste
electrical and electronic equipment
(WEEE).
This symbol indicates that this product shall not be
disposed with other household wastes at the end
of its service life. Used device must be returned to
offical collection point for recycling of electrical
and electronic devices. To find these collection
systems please contact to your local authorities
or retailer where the product was puchased. Each
household performs important role in recovering
and recycling of old appliance. Appropriate
disposal of used appliance helps prevent potential
negative consequences for the environment and
human health.
4 Informaton

14 / EN Cordless Stick Vacuum Cleaner / User Manual
For commssonng, general use
and cleanng, please observe the
nstructons on pages 5-6-7 of ths
operatng manual.
4.6 Information on waste
batteries
This symbol on rechargeable batteries/
batteries or on the packaging indicates
that the rechargeable battery/battery
may not be disposed of with regular
house hold rubbish. For certain rechargeable
batteries/batteries, this symbol may be
supplemented by a chemical symbol. Symbols for
mercury (Hg) or lead (Pb) are provided if the
rechargeable batteries/batteries contain more
than 0,0005 % mercury or more than 0,004 %
lead.
Rechargeable batteries/batteries, including those
which do not contain heavy metal, may not be dis-
posed of with household waste. Always dispose of
used batteries in accordance with local environ-
mental regulations. Make enquiries about the ap-
plicable disposal regulations where you live.
4.7 Compliance with RoHS
Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
4.8 Package information
Packaging materials of the product are
manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials together
with the domestic or other wastes. Take them to
the packaging material collection points
designated by the local authorities.
5 Informaton

Cordless Stick Vacuum Cleaner / User Manual 15 / EN
Common falure Possble cause Solutons
The vacuum doesn’t work Product s power off or battery s low Please charge the product before
use
Product sucton port s blocked. Cleanng product sucton mouth
Sucton s too weak
Dust barrel & flter assembly s dusty Clean the dustbn and flter materal
Rollng brush s wrapped around the
har and other objects Clean roller brush
Stuaton stll remans Please contact wth our after sales
team
Dfferent motor operaton sound
The alumnum tube s blocked Clean up the obstacles
Stuaton stll remans Please contact wth our after sales
team
Vacuum cleaner n trouble at work
Too many obstacles n the cleanng
area Manually remove obstacles
Product sucton port s blocked Clean product sucton mouth
Stuaton stll remans Please contact wth our after sales
team
Product can not be charged
Battery pack and charger nterface
not connected well Please check and contact well
Charger or receptacle s not fully
charged or loose Check t and put away
Stuaton stll remans Please contact wth us
Common LED falure Possble cause Solutons
The red lght flcker Product s power off or battery s low Please charge the product before
use
The red lght flash
Brush pluggng and the man brush
motor s workng Clean roller brush
Overchargng current s too lager Change the correct adapter
The red and whte lght tradng flash
when the dscharge process The battery pack has a problem Please contact wth our after sales team
The red and whte lght tradng flash
when the charge process The battery pack s not nstalled well
1- Remove adapter
2- Installed the battery pack agan
3- Insert adapter
4- Strctly follow the above steps
6 Troubleshooting

Arçelik A.Ş. Karaağaç Caddesi No:2-6, 34445, Süt-
lüce / İSTANBUL/ TÜRKİYE
www.beko.com
