Beko CEB 6020 S User manual

CEB 6020 S
Cooker Hood
User Manual

Complies with the WEEE Directive.
This product was manufactured using the latest technology in environmentally friendly conditions.
Please read this user manual first!
Dear Customer,
Thank you for purchasing this Beko product. We hope that you get the best results from your product
which has been manufactured with high quality and state-of-the-art technology. Therefore, please read
this entire user manual and all other accompanying documents carefully before using the product and
keep it as a reference for future use. If you handover the product to someone else, give the user manual
as well. Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models. Differences between mod-
els will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints about
usage.
AWarning for hazardous situations with regard to
life and property.
BWarning for electric shock.
Does not contain PCB.

3 / 11 EN
Cooker Hood / User Manual
TABLE OF CONTENTS
1 Important instructions for safety and
environment 4-5
1.1 General safety . . . . . . . . . . . . . . . . . . . . . . .4
1.1.1 Electrical safety . . . . . . . . . . . . . . . . . . . . .4
1.1.2 Product safety . . . . . . . . . . . . . . . . . . . . . . 4
1.1.3 Children's safety . . . . . . . . . . . . . . . . . . . .5
1.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . .5
1.3 Compliance with WEEE Directive and
disposing of the waste product . . . . . . . . . . .5
1.4 Package information. . . . . . . . . . . . . . . . . . .5
2 Technical specifıcations of your
appliance 6
3 Installing your appliance 6-8
3.1 Electric connection . . . . . . . . . . . . . . . . . . . .8
3.2 Mounting of the hood between two hanging
cupboards . . . . . . . . . . . . . . . . . . . . . . . . . .8
3.3 Mounting of the hood on the wall . . . . . . . . . 8
3.4 Fixing of front panel . . . . . . . . . . . . . . . . . . .8
3.5 Exhausting version . . . . . . . . . . . . . . . . . . . .8
3.6 Filtering version . . . . . . . . . . . . . . . . . . . . . .9
4 Operating your appliance 10
4.1 Use and maintenance . . . . . . . . . . . . . . . .10
4.2 Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . .10
5 Guarantee and Service 11

Cooker Hood / User Manual
4 / 11 EN
1 Important instructions for safety and environment
This section contains safety instructions that will
help protect from risk of personal injury or proper-
ty damage. All warranties will become void if you
do not follow these instructions.
1.1 General safety
•Always have the installation and repairing pro-
cedures carried out by the Authorised Service
Agent. The manufacturer shall not be held re-
sponsible for damages arising from procedures
carried out by unauthorised persons.
•This appliance is not intended for use by per-
sons (including children) with reduced physi-
cal, sensory or mental capabilities, or lack of
experience and knowledge. Children should be
supervised to ensure that they do not play with
the appliance.
1.1.1 Electrical safety
•Disconnect the product from the mains during
installation, maintenance, cleaning and repair-
ing procedures.
•If the power cable is damaged, it must be re-
placed by the manufacturer, after sales service
or a similarly qualified person (preferably an
electrician) or someone designated by the im-
porter in order to avoid possible risks.
•Operating voltage is 220 to 240 volts.
•If the appliance has a failure, it should not be
operated unless it is repaired by the Author-
ised Service Agent. There is the risk of electric
shock!
•Do not route power cable close to hobs. Other-
wise power cable may cause fire since it melts
down easily.
•Never connect the hood before installation is
completed.
•In order to obtain the best performance, exter-
nal ducting must not be longer than 4 m. It must
not contain more than 2 perpendicular (90°)
angles and its diameter must be min. ø120
mm.
•Disconnect the appliance before any interven-
tion to the internal parts of the appliance.
1.1.2 Product safety
•You can use a pipe with a diameter of 120 mm
or 150 mm on the flue connection of the hood.
•Do not make connections to flues connected
to stoves, exhaust shafts or flues with rising
flames. Observe the rules set by authorities on
the discharge of exhaust air.
•The height between the lower surface of the
hood and upper surface of the cooker top
should not be less than 65 cm.
•Do not operate the hood without aluminum
filters and do not remove the filters while it is
operated.
•Never touch the hood’s lamp after long periods
of operation, wait until it has cooled down. Hot
lamps may burn your skin.
•Avoid big flames beneath the product. Other-
wise, particles on oil filter may ignite and lead
to a fire.
•Turn on the hobs after placing pans or pots on
it. Otherwise, rising temperature may deform
certain parts of your product.
•Turn off the hobs before taking away pans or
pots.
•Avoid inflammable materials under the hood.
•Oil may ignite while frying foods. Therefore, be
careful about cloths and curtains.
•Never leave the cooker unattended when frying
foods; otherwise boiled oil may cause fire.

5 / 11 EN
Cooker Hood / User Manual
1 Important instructions for safety and environment
•There is the risk of fire if your hood is not
cleaned in the specified periods.
•Be extremely careful and wear gloves when
cleaning the hood.
•We advise you to operate the appliance a few
minutes before starting to cook in order to in-
crease the suction power. Thus, you shall have
a continuous and stable suction power when
the vapors arises.
•Operate your hood for 15 minutes more after
the end of cooking or frying in order to remove
smell cooking vapour in the kitchen.
•When the hood is in use, especially together
with gas cookers, make sure that environment
is ventilated with clean air.
•Pay attention not to connect the appliance to
the flues used by non-electrical devices. (E.g.:
Heater flue).
•When a non-electrical device is concurrently
used in the same room together with the hood,
the negative pressure in the room must be max-
imum 0.4 mbar in order to prevent hood from
sucking other device's exhaust into the room.
1.1.3 Children's safety
•Packaging materials are dangerous to children.
Keep packaging materials in a safe place out of
reach of children.
•Electrical appliances are dangerous to children.
Keep children away from the product. Do not
allow children play with the appliance.
1.2 Intended use
•This appliance is intended for domestic use. It
is not suitable for commercial use and it must
not be used out of its intended use.
•The manufacturer shall not be liable for any
damage caused by improper use or handling.
1.3 Compliance with WEEE regulation
and disposal of the waste product
This product does not contain harmful
and forbidden materials described in the
"Directive on the Restriction of the Use
of Certain Hazardous Substances in
Waste Electrical and Electronic Equip-
ment" (WEEE) issued by the T.R. Ministry of Envi-
ronment and Urbanization.
Complies with the WEEE Directive.
This product has been manufactured with high
quality parts and materials which can be reused
and are suitable for recycling. Therefore, do not
dispose the product with normal domestic waste
at the end of its service life. Take it to a collection
point for the recycling of electrical and electronic
equipment. Please consult your local authorities
to learn the nearest collection point. Help protect
the environment and natural resources by recy-
cling used products.
1.4 Package information
Ni-MH
The product package is made of recy-
clable material as per the National Leg-
islation. Do not dispose of the package
waste together with the household
waste or other waste and deliver them to the
package collection points indicated by the local
authority.

Cooker Hood / User Manual
6 / 11 EN
Values stated on the product labels or in the documentation accompanying it are obtained in laboratory conditions in accordance
with relevant standards. These values may vary depending on operational and environmental conditions of the product.
CEB 6020 S
2 Technical specifıcations of your appliance
Width 600 mm
Depth 400 mm
Height 495 mm
Supply voltage 220 - 240 V, 50 Hz
Control With 3 levels
Lamp power 1 x 28 W
Air outlet pipe 120 - 150 mm
Motor power 110 W
Net weight 9.02 kg
Colour Silver

7 / 11 EN
Cooker Hood / User Manual
2 Technical specifıcations of your appliance

Cooker Hood / User Manual
8 / 11 EN
3 Installing your appliance
side hanging cupboards.
Fix the hood to the hanging cupboards through
4 screws, which are appropriate to that kind of
cupboard.
Close the room, which eventually remains be-
tween the hood and the wall adjusting the spacer
(L) by acting on the appropriate screws (P) fig. 1.
3.3 Mounting of the hood on the
wall
Drill 6 holes on the wall as showed in fig. 2.
Fix the spacer (L) on the wall at the right height,
according to the depth of the hanging cupboards
fig. 2.
Adjust the position of the superior clamps (M) fig.
2, according to the depth of the side hanging cup-
boards.
Fix the hood on the wall through 4 screws and
dowels with expanding plug , which are appropri-
ate to that kind of wall (ex. concrete, plasterboard,
etc.).
Fix the hood to the spacer through the screws (P)
fig. 1.
3.4 Fixing of front panel
Take off the door (E) by removing the grill (G) and
pulling at the same time the special spring locking
knobs (H) fig. 3.
Fix the door on the front panel through the screws
at the level indicated in fig. 3.
Replace the door by inserting it in the upper and
lower slides until the spring locking knobs (H) are
released.
3.5 Exhausting version
Insert the coupling flange (B) in the hole (A) and
connect the discharge pipe to the same fig. 1.
3.1 Electric connection
The appliance has been manufactured as a class
II, therefore no earth cable is necessary.
The connection to the mains is carried out as fol-
lows:
BROWN = L line
BLUE = N neutral
•The cooker hood must be installed in order that
the electrical connection point is easily acces-
sible.
•An omnipolar switch with a minimum aperture
of 3mm between contacts, in line with the elec-
trical load and local standards, must be placed
between the appliance and the mains supply
network in the case of direct connection to the
electrical network.
•This device must be hardwired to the mains
supply network by connecting to a single phase
spur protected by a 3A fuse.
•The appliance must be installed at a minimum
height of 650 mm above the cooker top.
•If a connection tube composed of two parts is
used, the upper part must be placed outside
the lower part.
•Do not connect the cooker hood exhaust to the
same conductor used to circulate hot air or for
evacuating fumes from other appliances gener-
ated by other than an electrical source.
ACaution!
Should the lamps not work, make
sure they are well tightened.
3.2 Mounting of the hood between
two hanging cupboards
Drill 2 holes of 2,5 mm diameter on the side of
the hanging cupboards as showed in the fig. 1
considering also the thickness of the front panel,
so that the hood remains at the same level of the

9 / 11 EN
Cooker Hood / User Manual
3 Installing your appliance
3.6 Filtering version
Active carbon filters are necessary to purify the
air, that will be released in the room. Filters are
not washable; they cannot be regenerated and
have to be replaced at most every 4 months. The
saturation of the activated charcoal depends on
the more or less prolonged use of the hood, on the
type of cooking and on the regularity of cleaning
the grease filter. The filter has to be applied to the
aspirating group, which is inside the hood hiting
the centre of the group with it and turning it of
90° degrees until the stop click is heard to lock
it fig. 4.

Cooker Hood / User Manual
10 / 11 EN
4 Operating your appliance
4.1 Use and maintenance
•It is recommended to operate the appliance
prior to cooking. It is recommended to leave
the appliance in operation for 15 minutes after
cooking is terminated in order to completely
eliminate cooking vapours and odours. The
proper function of the cooker hood is condi-
tioned by the regularity of the maintenance
operations, in particular, the active carbon filter.
•The anti-grease filters capture the grease par-
ticles suspended in the air, and are therefore
subject to clogging according to the frequency
of the use of the appliance. In order to prevent
fire hazard, it is recommendable to clean the
filter at a maximum of 2 months by carrying out
the following instructions:
- Remove the filters from the cooker hood and
wash them in a solution of water and neutral
liquid detergent, leaving to soak.
- Rinse thoroughly with warm water and leave
to dry.
- The filters may also be washed in the dish-
washer. The aluminium panels may alter in
colour after several washes. This is not cause
for customer complaint nor replacement of
panels.
•The active carbon filters purify the air that is
replaced in the environment. The filters are not
washable nor re-useable and must be replaced
at maximum every four months. The saturation
of the active carbon filter depends on the fre-
quency of use of the appliance, by the type of
cooking and the regularity of cleaning the an-
ti-grease filters.
•Clean the fan and other surfaces of the cooker
hood regularly using a cloth moistened with
denatured alcohol or non abrasive liquid deter-
gent.
4.2 Lighting
Light Replacement
28W light
• Removethemetalgreasefilters.
• Unscrewthebulbsandreplacethemwithnewones
having the same characteristics.
• Replacethemetalgreasefilters.

11 / 11 EN
Cooker Hood / User Manual
5 Guarantee and Service
Your Beko product is guaranteed against the cost of breakdown re-
pairs for 2 years from the date of the original purchase.
What is covered?
 • Allrepairsnecessaryasaresultoffaultymaterials,defective
components or manufacturing defect.
 • Thecostoffunctionalreplacementparts.
 • ThelaborcostsofaBekoapprovedrepairertocarryoutthe
repair.
What is note covered?
 • Transitordeliverydamage
 • Accidentaldamage
 • Misuse,orabuse
 • Cabinetorappearanceparts,includingknobsandaps
 • Accessory items, including ice trays, scrapers, cutlery bas-
kets
 • Repairsrequiredasaresultofunauthorizedrepairsorinex-
pertinstallationthatfailstomeettherequirementscontained
in the user instruction book.
 • Repairstoproductsused oncommercialornon-residential
household premises
Important notes
 • Theproductisguaranteedfordomestichouseholduseonly.
 • Theguaranteewillbevoidiftheproductisinstalledorusedin
commercial or non-residential domestic household premises.
 • Theproductmustbecorrectlyinstalled,locatedandoperat-
ed in accordance with the instructions contained in the User
InstructionsBookletprovided.
 • Professionalinstallationbyaqualiedplumber/electricalap-
pliance installer is recommended for all Washing & Dishwash-
ingMachinesandElectricCookers.
 • GasCookersmustonlybeinstalledbyaGasSafe(orBORD
GAIS)registeredGasInstaller.
 • TheguaranteeisgivenonlywithintheboundariesoftheUnit-
ed Kingdom.
 • Theguaranteeisnottransferableiftheproductisresold.
 • Bekoplc.disclaimsanyliabilityforincidentalorconsequential
damages.
 • Theguaranteedoesnotinanywaydiminishyourstatutoryor
legal rights.
HOW TO OBTAIN SERVICE UNDER THE MANUFACTURERS GUARANTEE
Pleasekeepyourpurchasereceiptorotherproofofpurchaseinasafeplace;youwillneedtohaveitshouldtheproductrequireattentionin
the guarantee period
Youshouldalsocompletethedetailsbelow;itwillhelpusassistyouquickerwhenrequestingservice.(Themodelnumberisprintedonthe
InstructionBooklet)
Model Number : Purchased From : Date of purchase :
Forserviceunderguaranteesimplytelephonetheappropriatenumberbelow
LOCATION TELEPHONE
UKMainland&NorthernIreland
Fridges&Freezers          08456004903/03456004903
ElectricCookers          08456004902/03456004902  
Gas&DualFuelCookers         08456004905/03456004905
WashingMachines&Dishwashers       08456004906/03456004906
RepublicofIreland
AllRefrigeration,Cooking,Washing&DishwashingMachines  018623411
Beforerequestingservicepleasecheckthetroubleshootingguidein
theOperatingInstructionsasachargemaybeleviedwherenofault
isfoundeventhoughyourproductmaystillbeunderguarantee.
Serviceoncethemanufacturesguaranteehasexpired.
Ifyouhavepurchasedanextendedguaranteeagreementdocument.
Otherwisepleasecalltheabovenumberswhereservicecanbeob-
tained at a charge.
Shouldyouexperienceanydifcultyinobtainingservicepleasecallthe
Beko Customer Help-Line on 0845 600 4911/0345 600 4911
Beko Plc, Beko House, 1 Greenhill Crescent, Watford Herts, WD18 8QU, Tel: [phone]

www.beko.co.uk
