Hood
User Manual

Please read this manual first!
Dear Customers!
Thank you for preferring a Beko product. We hope that you get the best results
from your product which has been manufactured with high quality and state-of-
the-art technology. Therefore, please read this entire user manual and all other
accompanying documents carefully before using the product and keep it as a
reference for future use. If you handover the product to someone else, give the user
manual as well. Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models.
Differences between the models are explicitly described in the manual.
Meanings of the Symbols
Following symbols are used in the various section of this manual:
C
Important information and useful hints about
usage.
AWARNING:
Warnings for dangerous situa-
tions concerning the safety of life and proper-
ty.
B
Warning for electric shock.
Ths product has been manufactured n envronmental frendly modern plants wthout gvng any harm to the nature.
Ths applance conforms to
the WEEE regulaton.
It does not contan PCB.

Hood / User Manual 3 / EN
CONTENTS
ENGLISH 04-14
POLSKI 15-26
FRANÇAIS 27-38
DEUTSCH 39-50
ČESKY 51-62

4 / EN Hood / User Manual
This section contains safety in-
structions that will help protect
from risk of personal injury or
property damage. Failure to follow
these instructions invalidates the
granted warranty.
1.1 General safety
•This Operation Manual shall be
maintained, in order to be able to
use it in every further moment.
•The device may be used by the
children in the age of at least 8
years, and by the persons with
limited physical, mental abilities,
or by persons with a lack of expe-
rience in device operation, pro-
vided that the due supervision
or training in terms of the safe
device operation was ensured, in
order to make clear all the related
risks.
•Read this Operation Manual at-
tentively, as it contains the de-
tailed information regarding the
installation, assembly and main-
tenance of the hood.
•The hood appearance may dif-
fer from the hood presented at
drawings in this Manual, however
all recommendations regarding
the operation, maintenance and
assembly of the hood remain un-
changed.
•Do not make any electrical or
mechanical changes in the hood
construction.
•Do not connect the device to
power before finishing the as-
sembly.
•Any assembly or maintenance
operations shall be performed in
the protective gloves.
•Do not use the hood without the
correctly installed filter.
•The assembly non-complying
with this Operation Manual, may
cause the electrical shock danger.
•Do not use the open flame under
the kitchen hood.
•The meals cooked on the fat base
shall be constantly controlled, as
overheated fat may flame out
easily.
1
Important safety and envronmental
nstructons

Hood / User Manual 5 / EN
•The air sucked by the hood may
not be withdrawn into the chim-
ney channel used for extraction
of the combustion gases from
gas or other fuel devices (does
not apply to the closed circuit
hoods).
•If any other non-electric devices
are used in the house besides
the hood (for example, liquid fuel
furnaces, blowthrough heaters,
boilers), the sufficient ventila-
tion of air (air supply) shall be en-
sured.
•Do not disconnect the plug from
the socket drawing the power
cable.
•The power cable may not touch
the hot surface.
•Do not start the device if the
power cable is damaged.
•The replacement of the damaged
power cable may be performed
by the manufacturer; the service
maintenance shall be performed
by the qualified technician.
•The hood shall be cleaned both
inside and outside, at least
monthly, or every 35 hours of
hood operation. Each time, before
the hood cleaning, the hood shall
be disconnected from the power
(disconnect the power cable plug
or turn off the safety levers).
•The children shall not play with
the device.
•The children without the supervi-
sion shall not perform the device
cleaning and maintenance.
•The device is market accord-
ing to European Union Directive
2002/96/EU, about the elec-
tric and electronic equipment
(WEEE). Ensuring the correct dis-
posal of the device, you will help
to limit the risks of a negative
impact over the environment and
health.
•The accessible parts may become
hot in course of the cooking range
operation. The use of screws or
other fastening elements with
violation of the Manual require-
ments, may cause the electrical
shock.
1
Important safety and envronmental
nstructons

6 / EN Hood / User Manual
1
Important safety and envronmental
nstructons
Complance wth the WEEE
Drectve and Dsposng of the
Waste Product:
This product complies with EU WEEE
Directive (2012/19/EU). This product bears
a classication symbol for waste electrical
and electronic equipment (WEEE).
This symbol indicates that this
product shall not be disposed with
other household wastes at the
end of its service life. Used device
must be returned to ocal
collection point for recycling of electrical
and electronic devices. To nd these
collection systems please contact to your
local authorities or retailer where the
product was puchased. Each household
performs important role in recovering and
recycling of old appliance. Appropriate
disposal of used appliance helps prevent
potential negative consequences for the
environment and human health.
Complance wth RoHS
Drectve
The product you have purchased complies
with EU RoHS Directive (2015/863/EU). It
does not contain harmful and prohibited
materials specied in the Directive.
Package nformaton
Packaging materials of the
product are manufactured from
recyclable materials in accordance
with our National Environment
Regulations. Do not dispose of the
packaging materials together with the
domestic or other wastes. Take them to the
packaging material collection points
designated by the local authorities.

Hood / User Manual 7 / EN
2 Technical specifications
Technical data contained in this manual and la-
bels attached to the hood were obtained from
measurements and calculations in accordance
with the requirements of EU Regulation No.
65/2014 and 66/2014.
Chimney
body Power
cabel
Mechanical
control
Lighting
Fig.1 General view of the range hood
Aluminium
grease filter
360
430
O
150
min: 20
300
min:415 max:680
330
405
596
290
198
236
Fig.2

8 / EN Hood / User Manual
3 Operation
3.1 Hood operaton
The hood is intended for sucking in the vapours
during the meals cooking. The device may work
in two modes:
As the extracting hood: the vapours are extract-
ed from the premise through the withdrawal
tube. The withdrawal tube is not supplied with
the device, and should be acquired separately.
C
•The shortest possible vapours
evacuating channel shall be used.
•Use the flue pipe with maximally
smooth internal surface (the use
of Spiro type pipes is not recom-
mended).
•Use the flue channel with as low
number of bends as possible (the
bending angles shall not exceed
90º).
•The changes in flue channel
sections are not advised (from
higher section to lower section,
for example the change from
Ø150 mm to Ø120 mm).
As the absorber: the vapours are cleaned from
fat and odours, before they are returned back to
the premise through the grills in the top part of
the chimney body. To make the hood work in the
absorber mode, install the coal filter
(Fig.10). The coal filter is not included in the
standard equipment, and should be acquired
separately.
3.2 Hood operaton control
The hood is equipped with the mechanical con-
trol system.
•Button “0” – hood fan switched off
•Button “1” - hood fan switched on, with mini-
mum speed
•Button “2” - hood fan switched on with me-
dium speed
•Button “3” - hood fan switched with maximum
speed
The higher speed means the higher air circula-
tion.
•Button switches the light on. To switch the
light off, press the button one more time.w

Hood / User Manual 9 / EN
4 Installation
4.1 Hood nstallaton
B
The use of screws and fasten-
ing elements not specified in the
Operation Manual may cause the
electrical shock.
The minimum distance of hood hanging between
the surface of kitchenware placement over the
cooking range (gas, electric range), and lowest
part of the hood (Fig.3) shall amount at least 65
cm for electric cooking ranges and at least 65 cm
for gas cooking ranges. Should the cooking range
operation manual provide the higher distance for
hood installation, such higher distance require-
ment shall be maintained. The installation of the
hood and chimney body is shown at the figures
(Fig.4 - Fig.9). The hood is equipped with the fix-
ing pins matching to the most part of walls and
ceilings. In course of the assembly, observe the
common rules for air exhaust from the premises.
L
Fig.3 Recommended distances from the cooking
range
Gas cooking ranges L ≥ 65cm
Electrical cooking ranges L ≥ 65cm
•Check if the purchased device dimensions
match to the planned installation place.
•Disassembly and remove (if possible) any fur-
niture remaining in the hood installation area,
in order to ensure the easy access to ceiling or
wall, where the hood shall be mounted. If it is
not possible, protect the furniture elements
remaining in the adjacent area.
•Check, if there is a socket near the mounting
area, and control if the hood may be connected
to the ventilation channel for vapours evacu-
ation.
•Check if there are no cables (electrical, hydrau-
lic, etc.) in places in which the drilling will be
performed.
•Prepare the following tools: tape ruler, pen-
cil, drill / electric screwdriver, drilling tool Ø8,
screwdriver, builder’s level.
Assembly operaton:
1. Defne the axs of cookng range, and project
t onto the wall, where the hood wll be
mounted. Sgn all characterstc ponts of hood
fastenng.Make the openings with the drill.
(Fig. 4)
325mm
4 x O8
2 x O8
325mm
156mm
L+170mm 124mm max:680mm
min:30
Fig.4 Assembly dimensions

10 / EN Hood / User Manual
2. Into the openngs, nsert the screw plugs. In
two openngs marked wth A screw also the
screws (leaving 7 mm of screw length outside
the screw plug, Fig.5).
2 x O5 x 45mm
4 x O8 x 40mm
7mm
2 x O8 x 40mm
A
Fig.5 Screw plugs assembly
3. Screw the chmney body fastenng element,
hang the hood on two untghtened screws
(Fg. 6).
Fig.6 Hood hanging
4Installation
4. Open the hood cover and remove the fat flter
(Fg.7).
1
2
Fig.7 Aluminium fat filter removing
5. Place the level on the hood body. Rotatng
the element marked wth A, adjust the hood
level accordng the level’s ndcatons, and
then tghten two screws prevously screwed
partally and screw n two remanng screws
(Fg. 8).
2 x O5 x 45mm
A
Fig.8 Range hood positioning

Hood / User Manual 11 / EN
4 Installation
Place the chmney body on the hood body.
Then, draw delcately the hood part sgned
wth B upwards, untl t becomes possble to
screw t to the fastenng element prevously
attached to the wall (Fg. 9).
A
B
A
B
2 x O3,9x9,5
Fig.9 Chimney body assembly
Be especialy attentive while sliding the
chimney body
C
This assembly operation shall be
performed very carefully, in order
to avoid the scratching of chimney
body and hood itself.
4.2 Electrcal connectons
The network voltage shall correspond to the
voltage indicated at the plate placed inside the
hood. If the hood is equipped with a plug, insert
it into the socket complying with the applicable
requirements, and located in the easily accessi-
ble place. If the hood is not equipped with a plug,
the hood installations shall be performed by a
person having the required authorizations (such
as electrician).

12 / EN Hood / User Manual
5 Cleaning and maintenance
5.1 Cleanng
•Particularly do not neglect to clean your hood
immediately after you have made frying.
•Use a soft cloth soaked with liquid detergent to
clean the outer surface of your hood.
•Never use abrasive or scratching materials for
cleaning.
•You may use the cleaning agents commercially
available for persistent grease etc. by follow-
ing the warnings on the product. In order not
the scratch the brushed steel body, wipe in the
same direction with the bush trace.
•Do not use cleaning agents containing hy-
drochloric acid, bleach or abrasive powders in
order to maintain the surface quality of your
product. Use a cloth dampened in soapy water
or special stainless steel cleaning spray for
stainless steel steel surfaces. Remove the pro-
tective foil on the appliance.
A
Caution! You may cause a fire if you
do not follow the instructions on
the cleaning and replacement of
the filters of your hood.
5.2 Fat flter
The hood is equipped with aluminium filter stop-
ping the particles of fat emitted in course of
cooking. To remove the filter, move the clamps in
the direction of arrows (Fig.7). The filter shall be
cleaned manually by its immersion into the water
with dish washing liquid for approx. 15 minutes,
under the temperature equal to 40-50ºC. After
15 minutes, wash and accurately rinse the filter.
The filter must be dry before its installation in
the hood. It is also possible to wash the filter in
the dish washing machines. In course of wash-
ing, the filter colour may change, which does not
influence its filtering characteristics. The failure
to clean the filter regularly reduces the hood
performance, and may cause the fire. The filter
shall be cleaned at least every 35 hours of hood
operation.
5.3 Coal flter
The hood may be equipped with the coal filter.
The coal filter is used when the hood is not con-
nected to ventilation duct only. The filter shall be
installed on the fan body, like it is shown in the
drawing (Fig.10). The coal filter shall be replaced
every 6 months.
C
Do not wash or regenerate the
coal filter.
1
2
1
2
Fig.10 Coal filter replacement
filter installationMark
Mark filter removal

Hood / User Manual 13 / EN
5 Cleaning and maintenance
5.4 Lght replacement
Before starting any works related to the light re-
placement, switch off the power. If the hood was
previously turned on, wait previously until the
lams become cold, and then start their replace-
ment. The lamp replacement is illustrated in Fig.
11.
C
•Before the replacement of lamps,
switch the hood power off.
•Do not touch the lamps when
they are hot.
•Be attentive not to touch the
lamp installed with hands.
GU10 12
1
2
Fig.11 Lights replacement
lamp installationMark
Mark lamp removal
5.5 How to reduce the cookng
mpact to the envronment
•In order to reduce the energy consumption,
cook in the kitchenware under the cover.
•The hood aluminium filters shall be kept clean
(the recommended time of work of aluminium
filter between its cleaning: max. 35h of hood
operation).
•The ventilation ducts shall not be blocked.
•The fan operation speed during the cooking
shall be always set on minimum level which al-
lows to withdraw the vapours considering the
actual cooking intensiveness.
If you need to transport the appliance:
•Keep the original packaging of the appliance.
Transport the appliance with its original pack-
age, and follow the transport markings on the
original package.
If you do not have the original package:
•Do not place any objects on the hood.
•Protect the outer surface from impacts.
•Pack the appliance so that it would not be dam-
aged during transport.

14 / EN Hood / User Manual
6 Troubleshooting
Symptoms Cause Reparng method
Durng hood operaton, the pulsatng
letter „F” s dsplayed.
After 35 hours of operaton the hood
ndcates the need for cleanng or
replacng the grease flter.
Press and hold for about 8 sec. “-” on
the touch control. The flter should be
washed n the dshwasher or replace
wth a new one.
The dsplay shows only the symbol
“-.” (mnus and dot n the rght bottom
corner), the hood does not respond
to dsablng.
The touch control has been locked
– ths feature facltates the hood
cleanng.
To dsable the lock, press and hold for
about 10 sec the feld wth the symbol
of swtchng on.
No symbol s shown on the dsplay,
the hood does not respond to pres-
sng the control felds.
The touch control s probably sus-
pended.
Dsconnect the hood from the power
supply for about 15 sec. and swtch t
on agan.
The dsplay shows the symbol of one
of the gears; the hood does not res-
pond to pressng the control felds.
The touch control s probably
suspended
Dsconnect the hood from the power
supply for about 15 sec. and swtch t
on agan.
The hood turbne dsconnects after
15 mn of operaton, the dsplay
shows a pulsatng dgt .e. “1.” (cur-
rent gear number and dot n the rght
bottom corner).
The automatc tme swtch of the
touch control has been actvated.
To deactvate the tme swtch, press
and hold for about 10 sec the symbol
„+”or dsable the hood.
On fourth gear the dgt “4” s pulsa-
tng on the dsplay, after 5mn the
gear s changed nto thrd.
The hood s equpped wth a turbo
mode, whch automatcally swtches
over nto thrd gear after 5 mn of
operaton to save energy.
The turbo gear shall be used only wth
ntensve cookng.
The hood can be operated only wth
use of the control panel, t does not
respond to the remote control.
The battery of the remote control s
empty or the dstance s too long.
Replace the battery wth a new one.
The hood has very poor vapor
sucton.
Probably cause s drty flters. The grease flter must be cleaned n the
dshwasher or replace wth a new one.
The carbon flter (f present) must be
replaced wth a new one.
One or more lght ponts do not
operate.
Defectve halogen/ LED bulb. The lght bulb needs to be replaced
wth a new, compatble wth the symbol
specfed n the nstructon manual for
the cooker hood.
The hood generated excessve nose
and vbraton.
Ths may be caused by an ncorrect
nstallaton of the hood to the wall
or ktchen cabnets. Not all provded
screws have been used or screws are
loosely ftted leavng clearance.
The hood must be mounted to a wall or
cabnet by usng all the ponts provded
for by the manufacturer. After adjustng
the poston of the hood horzontally
and vertcally, tghten all mountng
screws.
* apples to hoods wth touch control.
If the recommendatons above do not solve the problem, contact an authorzed home applances servce enttled to
repar. Under no crcumstances s the hood user enttled to ndependent repar. A lst of servce ponts s ncluded n the
warranty card and the webste.



WEEE. 


Drodzy Klienci,



            


            



C
     -

A
-
-
niu.
B


16 / PL
-
  
    -
  -
dami w mieniu. Nieprzestrzeganie
   -


Zasady ogólne
•
-

•    -
kowany przez dzieci w wieku co
najmniej 8 lat i przez osoby o obni-

-


-



•-
   
-
-
serwacji okapu.
•-
-
wionego na rysunkach w niniejszej

   

•-
trycznych czy mechanicznych w
okapie.
• 
-

•


•-

•-

-
nym.
•

•
-


1




Okap / Instrukcja obsługi
17 / PL
•Zasysane powietrze przez okap



    


•

   -
trycznym (np. piece na paliwa cie-

   

powietrza).
•    


•-

•
-
dzony.
•Wymiana uszkodzonego prze-
-

serwis lub wykwalifikowanego

•-


-
zowo przed czyszczeniem okapu,
    -
-

•-
tem.
•-
-
cji.
•
w czasie pracy kuchenki.
•   -
    -


1




18 / PL
1
Ważne instrukcje dotyczące
bezpieczeńs twa i ochrony
środowiska naturalnego
Zgodność z dyrektywą WEEE i
usuwanie odpadów:
Niniejszy wyrób jest zgodny z dyrektywą Par-
.)EW/91/2102( ydaR i ogeiksjeporuE utnemal
Wyrób ten oznaczony jest symbolem klasyfikacji
zużytych urządzeń elektrycznych i elektronicznych
(WEEE).
Zgodność z dyrektywą RoHS:
Niniejszy wyrób jest zgodny z dyrektywą Parla-
mentu Europejskiego i Rady RoHS (Ograniczenie
użycia substancji niebezpiecznych) (2011/65/
WE). Nie zawiera szkodliwych i zakazanych ma-
teriałów, podanych w tej dyrektywie.
Informacje o opakowaniu
Opakowanie tego wyrobu wykonano z
materiałów nadających się do recy-
klingu, zgodnie z naszym ustawodaw-
stwem krajowym. Nie wyrzucaj materia-
łów opakowaniowych do śmieci wraz z innymi
odpadkami domowymi. Oddaj je w jednym z wy-
znaczonych przez władze lokalne punktów zbiórki
materiałów opakowaniowych.
Ten symbol oznacza, że sprzęt nie
może być umieszczany łącznie z
innymi odpadami gospodarstwa
domowego po okresie jego użytkowan-
ia. Zużyte urządzenie należy oddać do
specjalnego punktu zbiórki
zużytego sprzętu elektrycznego i elektronicznego
w celu utylizacji. Aby uzyskać informacje o
punktach zbiórki w swojej okolicy należy
skontaktować się z lokalnymi władzami lub
punktem sprzedaży tego produktu. Gospodarstwo
domowe spełnia ważną rolę w przyczynianiu się
do ponownego użycia i odzysku zużytego
sprzętu. Odpowiednie postępowanie ze zużytym
sprzętem zapobiega potencjalnym negatywnym
konsekwencjom dla środowiska naturalnego i
ludzkiego zdrowia.

Okap / Instrukcja obsługi
19 / PL
2 
Dane techniczne zawarte w niniejszej instrukcji



nr 65/2014 oraz 66/2014.

kominowa 
zasilajacy
Sterowanie
mechan-
iczne

Rys.1 Rysunek pogldowy okapu kuchennego
Klapa
uchylna
Filtr

aluminiowy
Rys.2 Rysunek gabarytowy
360
430
O
150
min: 20
300
min:415 max:680
330
405
596
290
198
236

20 / PL
3 

-


       -
     
      -

C
•   
 
opary.
•-
   
-

•-
    
     
stopni).
•
  
na mniejszy np. wylot powietrza
Ø150 mm na wylot powietrza
Ø120mm).

-
 
-


u sprzedawcy

 -
ne.
•„0” 
turbiny okapu
•„1” 

•„2” 

•„3” 

•-
trza.
Button switches the light on. To switch the life off,
press the button one more time.
• 
-

Okap / Instrukcja obsługi
