Beko HTV 8636 XS0 User manual

Washer-Dryer
User Manual
Lavadora-secadora
Manual del usuario
HTV 8636 XS0
EN / ES
2820527925_EN/ 01-06-20.(10:25)
Document Number:

Please read this user
manual first!
Dear Customer,
Thank you for choosing a Beko product. We
hope that you get the best results from your
product which has been manufactured with
high quality and state-of-the-art technology.
Therefore, please read this entire user manual
and all other accompanying documents
carefully before using the product and keep it
as a reference for future use. If you handover
the product to someone else, give the user
manual as well. Follow all warnings and
information in the user manual.Throughout this
user manual the following symbols are used:
B
DANGER!
• Warning for electric shock.
DANGER!
• Product weight warning
DANGER!
• Fire risk warning.
A
CAUTION!
• Warning for hazardous situations
with regard to life and property.
A
PRECAUTION!
• Precautions that need to be taken.
C
INFORMATION
• Important information or useful hints about
usage.
• Read user manual.
• Packaging materials of the
product are manufactured
from recyclable materials in
accordance with regulations.
• Do not dispose of the
Packaging materials
together with the domestic
or other wastes. Take them
to the packaging material
collection points designated
by the local authorities.
• Allergy UK, is the brand of
British Allergy Association. Their
main endorsement is the ‚Seal
of Approval‘. When you see
a product with this logo on it,
you have the reassurance the
product has been scientifically
tested to prove it is efficient at
reducing/removing allergens
from the environment
of allergy and asthma
sufferers or the products
have significantly reduced
allergen/chemical content.
This product was manufactured using the latest technology in environmentally friendly conditions.

3 / EN Washer-Dryer / User’s Manual
1 Important instructions for safety and environment
This section contains safety instructions
that will help protect from risk of personal
injury or property damage. Failure to follow
these instructions shall void any warranty.
1.1 General safety
A
CAUTION!
• This product can be used by
children at and above 8 years old
and by persons whose physical,
sensory or mental capabilities are
not fully developed or who lack
experience and knowledge provided
that they are supervised or trained
on the safe use of the product and
the risks involved. Children should
not play with the product. Cleaning
and maintenance works should not
be performed by children unless
they are supervised by someone.
Children under the age of 3 must be
kept away from the product unless
they are continuously supervised.
A
WARNING!
• Never place the product on a carpet-
covered floor. Otherwise, lack of
airflow beneath the product will cause
electrical parts to overheat. This will
cause problems with your product.
C
INFORMATION
• Always have the installation
procedures carried out by
authorised persons. The
manufacturer shall not be held
liable for damages that may arise
from procedures carried out by
unauthorised persons.
1.1.1 Electrical safety
B
DANGER!
• If the product has a failure, it should
not be operated unless it is repaired
by the Authorised Service Agent.
There is risk of electric shock!
• Never wash the product by
spreading or pouring water onto it!
There is risk of electric shock!
A
CAUTION!
• If the power cable is damaged, it must
be replaced by the manufacturer, after
sales service or a similarly qualified
person (preferably an electrician) or
someone designated by the importer
in order to avoid possible risks.
A
WARNING!
• Unplug the product when it is not
in use.
• Never touch the plug with wet hands!
Never unplug by pulling on the cable,
always pull out by grabbing the plug.
• Unplug the product during installation,
maintenance, cleaning and repair.
• Do not make connections via
extension cables or multi-plugs.
C
INFORMATION
• This product is designed to resume
operating in the event of powering
on after a power interruption. If you
wish to cancel the programme, see
"Cancelling the programme" section.

4 / EN Washer-Dryer / User’s Manual
1.1.2 Product safety
B
DANGER!
• Never open the loading door or remove
the filter while there is still water in the
drum. Otherwise, risk of flooding and
injury from hot water will occur.
A
CAUTION!
• The water supply and draining
hoses must be securely fastened
and remain undamaged. Otherwise,
there is the risk of water leakage.
C
INFORMATION
• Do not force open the locked loading
door. The door will open immediately
after the washing cycle has ended. If
the machine is not cooled enough at
the end of the programme, the loading
door cannot be opened. Wait for the
product to cool down. If the door still
does not open, apply the solutions
provided for "Loading door cannot
be opened" in the Troubleshooting
section. Do not force the loading door
to open. The loading door and the lock
mechanism may get damaged.
• In the location where this product is
going to be installed, there must be
no doors with a lock, bolt or hinge
that will prevent the loading door
from opening completely.
• Follow the instructions on the textile
tags and on the detergent package.
• Use detergents, softeners and
supplements suitable for washing
machines only.
C
INFORMATION
• Do not install or leave the product in
places where it might be exposed to
outdoor conditions.
• Do not play with control elements of
the product.
• If a non-self-resetting thermal cut-out
is required in order to comply with
the standard then the instructions for
appliances incorporating a non-self-
resetting thermal cutout that is reset
by disconnection of the supply mains
shall contain the substance of the
following:
CAUTION: In order to avoid a hazard
due to inadvertent resetting of the
thermal cut-out, this appliance must
not be supplied through an external
switching device, such as a timer, or
connected to a circuit that is regularly
switched on and off by the utility.

5 / EN Washer-Dryer / User’s Manual
1.1.3 Warnings about drying
DANGER!
• Laundry that has previously been
washed, cleaned, soiled or stained
with petrol/gas, dry cleaning solvents
or other inflammable/combustive
substances must not be dried in the
machine since they emit inflammable/
combustive vapour. Otherwise, there
will be the risk of fire.
• Laundry soiled with vegetable
oil, alcohol, petrol, gas oil, stain
remover, turpentine, wax or wax
remover must be washed with
hot water and a great amount of
detergent before drying. Otherwise,
there will be the risk of fire.
• Rubber (latex) foam, shower caps,
waterproof fabrics, clothes and
rubber-reinforced/rubber-foam
pillows must not be dried with the
drying function. Otherwise, there will
be the risk of fire.
• If you use laundry balls, measuring
scoops or laundry cage in your
machine, these products might melt
during the drying process. If you are
going to select the drying function, do
not use these products. Otherwise,
there will be the risk of fire.
• If you are using industrial chemicals
for cleaning, do not use the drying
function. Otherwise, there will be the
risk of fire.
B
DANGER!
• Do not touch the glass of the
loading door with bare hands after
drying. There is the risk of burning.
• There is a final step, which is
cooling, to keep the laundry at a
certain temperature to ensure that
it is not damaged. You may be
exposed to hot steam if you open
the door before cooling is complete.
There is the risk of scalding.
• If the drying programmes are
interrupted (due to programme
cancellation or power failure), the
laundry in the machine might be
hot. Be careful.
A
CAUTION!
• Do not stop the machine before the
drying programme is completed.
If you have to do so, remove all
laundry, place it at an appropriate
place and wait for it to cool down.
• Your product is designed to work at
temperatures between 0°C and +35°C.
• Ambient temperatures between
15°C and +25°C are suitable for
your product.
• Do not let pets enter the product.
Check inside of the product before
using it.
• Do not overload the machine to dry
laundry. Observe the maximum load
levels stated for drying.

6 / EN Washer-Dryer / User’s Manual
A
WARNING!
• Do not use the machine to dry
leather clothes or clothes that contain
leather (such as leather labels on
jeans). The colour of the leather parts
might affect other fabrics.
• If there is a problem you cannot solve
by using the information given in the
safety instructions section, switch off
and unplug the machine and call the
Authorised Service Agent.
• You can use your washer-dryer to
only wash, only dry or both wash and
dry laundry. The machine must not
be used to dry wet laundry only for a
long time. When using the machine
only for drying purposes, run a
washing programme with the machine
unloaded after every 15 drying cycles.
• Before loading the machine, check
each laundry item and make sure
that there is no lighter, change,
metal objects, needles etc. inside
them or in their pockets.
• Underwear with metal supports
must not be dried in the machine.
Metal supports might come off
during the drying process and
damage the machine. Place them in
a bag or a pillowcase.
• Do not use the machine to dry large
laundry such as tulle, curtains,
sheets/bedding, blanket or rugs.
Your laundry might get damaged.
C
INFORMATION
• Do not dry unwashed laundry in the
machine.
• Do not use softeners or antistatic
agents unless recommended by the
manufacturer.
C
INFORMATION
• Products such as softeners must
be used in accordance with the
manufacturer’s instructions.
• Do not use the machine to dry silk,
wool and similar delicate clothes.
Otherwise, woolen clothes may
shrink, and other delicate clothes
might get damaged.
• Check the symbols on the label of the
clothes before washing and drying.

7 / EN Washer-Dryer / User’s Manual
1.2 Intended use
C
INFORMATION
• This product has been designed for
domestic use. It is not suitable for
commercial use and it must not be
used out of its intended use.
• The product must be used to wash,
rinse and dry only the textile products
that have the relevant marking.
• The manufacturer waives any
responsibility arisen from incorrect
usage or transportation.
• The service life of your product is
10 years. During this period, original
spare parts will be available for the
product to operate properly.
• This appliance is intended to be
used in household and similar
applications such as:
– staff kitchen areas in shops, offices
and other working environments;
– farm houses;
– by clients in hotels, motels and
other residential type environments;
– bed and breakfast type
environments;
– areas for communal use in blocks
of flats or in launderettes.
1.3 Children's safety
A
CAUTION!
• Children under the age of 3 must be
kept away from the product unless
they are continuously supervised.
• Packaging materials are dangerous
to children. Keep packaging
materials in a safe place away from
reach of the children.
• Electrical products are dangerous for
children. Keep children away from
the product when it is in use. Do not
allow them to play with the product.
Use child lock to prevent children
from intervening with the product.
• Do not forget to close the loading
door when leaving the room where
the product is located.
• Store all detergents and additives in
a safe place away from the reach of
the children by closing the cover of
the detergent container or sealing
the detergent package.

8 / EN Washer-Dryer / User’s Manual
1.4 Compliance with the
WEEE Directive and disposing
of the waste product
This product does not contain the harmful
and prohibited materials described in the
“Directive on the Management of Waste
Electrical and Electronic Equipment”. It
complies with the WEEE Directive.
This product has been
manufactured with high quality parts
and materials which can be reused
and are suitable for recycling.
Therefore, do not dispose of the
product with normal domestic
waste at the end of its service life.
Take it to a collection point for the
recycling of electrical and electronic
equipment. Please consult your
local authorities to learn about
the nearest collection point.
Help protect the environment and natural
resources by recycling used products.
For children’s safety, cut the power
cable and break the lock mechanism of
the loading door to make the product
non-functional before disposal.
Compliance with the RoHS Directive
This product complies with the RoHS Directive
No. 2011/65/EU. It does not contain harmful
or prohibited materials stated in the directive.
1.5 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
together with normal domestic waste. Take
them to the packaging material collection
points designated by local authorities.
2 Your washer-dryer
2.1 Overview
1
2
3
4
5
6
7
8
1- Power cable 5- Loading door
2- Top panel 6- Filter cover
3- Control panel 7- Adjustable feet
4- Water
discharge hose
8- Detergent drawer

9 / EN Washer-Dryer / User’s Manual
2.2 Package contents
Power cable
Water discharge hose
Transit bolts
Mains water inlet hose
Liquid detergent container (*)
User manual
Plastic plug group
C
INFORMATION
• Figures in this manual are schematic and may not match the product exactly.
(*) This may be supplied with the machine depending on the model of your product.

10 / EN Washer-Dryer / User’s Manual
2.3 Technical specifications
A
WARNING!
• Consumption values are applicable for cases where the wireless network connection is off.
Built-in No
Height (cm) 84
Width (cm) 60
Depth (cm) 59
Net weight (±4 kg.) 65
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
Main model code 1420
Complying Commission Delegated Regulation (EU) No.96/60/EC/1996
Supplier name or trademark Beko
Model name HTV 8636 XS0
7166042800
Energy effciency class on a scale of A (more efficient) to G (less efficient) B
Energy consumption for washing, spinning, and drying (kWh) 6,48
Energy consumption for washing, spinning only (kWh) 0,76
Washing performance class on a scale of A (higher) to G (lower) A
Water remaining after spin (as a proportion of dry weight of wash) % 53
Maximum spin speed (rpm) 1200
Washing capacity (cotton) (kg) 8
Drying capacity (cotton) (kg) 5
Water consumption for washing, spinning and drying (l) 92
Water consumption for washing and spinning only (l) 47
Washing and drying time (min) 680
Estimated annual consumption of energy and water for a four-person household, always
using the drier (200 cycles) (kWh / l) 1296 / 18400
Estimated annual consumption of energy and water for a four-person household, never
using the drier (200 cycles) (kWh / l) 152 / 9400
Noise washing / spinning / drying [dB(A) re 1 pW] 57/74/64

11 / EN Washer-Dryer / User’s Manual
3 Installation
To make the product ready for use, review the
information in the user manual and make sure
that the electricity, tap water supply and water
drainage systems are appropriate. If they are
not, call a qualified technician and plumber to
have any necessary arrangements carried out.
B
DANGER!
• Make sure that the installation and
electrical connections of the product
are performed by competent persons.
Manufacturer shall not be held liable for
damages that may arise from procedures
carried out by unauthorised persons.
DANGER!
• Your product is too heavy for
one person to carry.
A
CAUTION!
• Prior to installation, visually check if
the product has any defects on it. If
so, do not have it installed. Damaged
products cause risks for your safety.
A
PRECAUTION!
• Preparation of the location and
electrical, tap water and waste water
installations at the place of installation
is under customer’s responsibility.
• Make sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or crushed
while pushing the product into its place
after installation or cleaning procedures.
3.1 Appropriate
installation location
• Place the product on a solid and level
floor. Do not place it onto a carpet with
high pile or other similar surfaces.
• Do not place the product close to the
edge if the floor contains steps. Do not
also place the product on a platform.
• Do not place the product on the power cable.
• Do not install the product in environments
where the temperature falls below
0 ºC.(See. Warnings for Drying)
• Leaving a gap at the sides of the machine
is suggested to reduce vibration and noise
• In the area where this product is
installed, there must not be a lockable,
sliding or hinged door that will restrict
the full opening of loading door.
• Operate the product in a well ventilated
and dust free environment.
• Do not place heat sources such as Hobs,
Irons, Ovens, etc. on the washing machine
and do not use them on the product.
3.2 Removing packaging
reinforcement
Tilt the machine
backwards to remove
the packaging
reinforcement.
Remove the
packaging
reinforcement
attached to
the ribbon.
DANGER!
• Your product is heavy. Remove packaging
reinforcement as displayed in the figure.
• Be careful not to get your hand caught
under the machine during this procedure.
3.3 Removing the transit bolts
A
PRECAUTION!
• Do not remove the transit bolts before
removing the packaging reinforcement.
• Remove the transit bolts before operating
the washing machine! Otherwise,
the product will get damaged.

12 / EN Washer-Dryer / User’s Manual
3
2
1
1 Use a tool to
loosen all bolts until
they rotate freely.
3
2
1
2 Remove the transit
bolts by turning
them slightly.
3
2
1
3 Attach the plastic
covers supplied in
the user manual
bag into the holes
on the rear panel.
C
INFORMATION
• Keep the transit bolts in a safe place
to reuse when the product needs
to be moved again in the future.
• Never move the product without the
transit bolts properly fixed in place!
3.4 Connecting water supply
C
INFORMATION
• It is necessary to have 10 – 80 liters of
water flowing from the fully open tap in
one minute to have your product run
smoothly. Attach a pressure reducing
valve if water pressure is higher.
A
CAUTION!
• Models with a single water inlet should
not be connected to the hot water
tap. In such a case the laundry will get
damaged or the product will switch to
protection mode and will not operate.
1 2 3
1 Connect the special
hose supplied
with the product
to the water inlet
on the product.
A
CAUTION!
• Ensure that the cold water connection
is made correctly when installing the
product. Otherwise, your laundry
will come out hot at the end of the
washing process and wear out.
1 2 3
2 Tighten the hose
nuts securely
by hand. Never
use a tool when
tightening the nuts.
1 2 3
3 Open the taps
completely after
making the hose
connection to
check for water
leaks at the
connection points.
If any leak occurs, turn off the tap and
remove the nut. Retighten the nut carefully
after checking the seal. In order to prevent
the water leaks, keep the taps closed
when you do not use the product.
3.5 Connecting to the drain
• Attach the end of the drain hose directly
to waste water drain, sink or bathtub.
A
CAUTION!
• Your house will be flooded if the hose
comes out of its housing during water
discharge. Moreover, there is risk of
scalding due to high washing temperatures!
To prevent such situations and to ensure
smooth water intake and discharge of
the machine, fix the end of the discharge
hose tightly so that it cannot displace.

13 / EN Washer-Dryer / User’s Manual
90 cm
90
40
90
40
90 cm
90 cm
min.40
90 cm
90
40
90
40
90 cm
90 cm
min.40
90 cm
90
40
90
40
90 cm
90 cm
min.40
• Connect the hose to a minimum height of
40 cm and a maximum height of 90 cm.
• If the hose is run along the floor (or at less
than 40 cm above it) and raised later on,
water drain becomes difficult and laundry
may come out extremely wet. Therefore,
observe the heights described in the figure.
• To prevent flowing of dirty water back into
the machine and to allow for easy discharge,
do not immerse the hose end into the dirty
water or do not drive it in the drain more
than 15 cm. If it is too long, cut it short.
• The end of the hose should not be
bent, it should not be stepped on
and the hose must not be pinched
between the drain and the machine.
• If the length of the hose is too short, add an
original extension hose. Length of the hose
may not be longer than 3.2 m. To avoid water
leak failures, the connection between the
extension hose and the drain hose of the
product must be fitted well with an appropriate
clamp as not to come off and leak.
3.6 Adjusting the feet
A
CAUTION!
• Adjust feet so that the product will be
balanced in the location it will be used.
• Balance the machine by adjusting the feet.
• Check for any play by pressing the
product from upper diagonal edges.
• Otherwise, the product may move
from its place and cause crushing,
noise and vibration problems.
• Do not use any tools to loosen
the lock nuts. Otherwise, the
lock nuts may get damaged.
a) Loosen the lock nuts on the feet by hand.
b) Adjust the feet until the product stands level
and balanced.
c) Tighten all lock nuts again by hand.
3.7 Electrical connection
Connect the product to a grounded outlet
protected by a 16 A fuse. Our company shall
not be liable for any damages that will arise
when the product is used without grounding
in accordance with the local regulations.
• Connection must comply with
national regulations.
• The wiring for the electrical outlet circuit
must be sufficient to meet the appliance
requirements. Use of a Ground Fault Circuit
Interrupter (GFCI) is recommended.
• Power cable plug must be within
easy reach after installation.
• If the current value of the fuse or breaker
in the house is less than 16 Amps, have a
qualified electrician install a 16 Amp fuse.

14 / EN Washer-Dryer / User’s Manual
• The voltage specified in the “Technical
specifications” section must be
equal to your mains voltage.
B
DANGER!
• Damaged power cables must be replaced
by the Authorised Service Agent.
3.8 Transportation of the product
1 Unplug the product before transporting it.
2 Remove water drain and water
supply connections.
3 Drain all water that has remained
in the product. See 6.5
4 Install the transit bolts in reverse order of
the disassembly procedure. See 3.3
DANGER!
• Your product is too heavy for
one person to carry.
• Your product is heavy; two persons
must carry it and extra precaution
taken on stairs. If your product falls
on you, it may cause injuries.
A
CAUTION!
• Packaging materials are dangerous to
children. Keep packaging materials in a
safe place away from reach of the children.
C
INFORMATION
• Never move the product without the
transit bolts properly fixed in place!
4 Preparation
4.1 Sorting the laundry
* Sort laundry according to type of
fabric, colour, degree of soiling and
the suitable water temperature.
* Always obey the instructions
given on the garment tags.
4.2 Preparing the laundry for washing
• Underwire bras and clothes with metal pieces
such as buckles or buttons damage the
machine. Remove the metal pieces or wash
such clothes after putting them in a cotton
laundry bag or cotton pillow case. Moreover,
this type of clothes may overheat during the
drying process and damage other clothes.
Do not use the machine to dry such clothes.
• Put small size clothes such as infant's
socks and nylon stockings in cotton a
laundry bag or cotton pillow case.
• Place curtains in without compressing
them. Remove curtain attachment items.
Do not dry tulle curtains in your machine.
• Fasten zippers, sew loose buttons
and mend rips and tears.
• Wash “Machine washable” or “Hand
washable” labeled products only with an
appropriate programme. Dry them by
hanging them or laying them flat. Do not
use the machine to dry such clothes.
• Do not wash colours and whites together.
New, dark coloured cottons release a
lot of dye. Wash them separately.
• Only use the dyes / color changers and
descaling agents which are appropriate
to machine wash. Always follow the
instructions on the package.

15 / EN Washer-Dryer / User’s Manual
C
INFORMATION
• Laundry that are subjected to materials
such as flour, lime dust, milk powder,
etc. intensely must be shaken off before
being placed into the machine. Such
dusts and powders on the laundry may
build up on the inner parts of the product
in time and can cause damage.
• Keep laundry items made of Angora
wool in the freezer for a few hours before
washing. This way, pilling will be reduced.
• Wash trousers and delicate
laundry turned inside out.
• Tough stains must be treated
properly before washing. If unsure,
check with a dry cleaner.
• Take out all substances in the pockets
such as coins, pens and paper clips,
and turn pockets inside out and brush
if possible. Such objects may damage
the product or cause noise problem.
4.3 Recommendations
for energy saving
Energy efficiency can be improved
with low-temperature programmes
and suitable detergents.
• Operate the product in the highest
capacity allowed by the programme you
have selected, but do not overload; see
"Programme and consumption table".
• Follow the instructions on the detergent packaging.
• Wash slightly soiled laundry at low temperatures.
• Use faster programmes for small
quantities of lightly soiled laundry.
• Do not use prewash setting or high
temperatures for laundry that is
not heavily soiled or stained.
• If you plan to dry your laundry in a
dryer, select the highest spin speed
recommended during washing process.
• Do not use more detergent than the amount
recommended on the detergent package.
4.4 First use
Before starting to use
the product make sure
that all preparations are
made in accordance
with the “Important
safety and environment
instructions” and the
instructions in the
“Installation” section.
To prepare the product for washing
laundry, perform first operation in Drum
Cleaning programme. If this programme
is not available on your machine, apply
the method described in section 6.2.
C
INFORMATION
• Use an anti-limescale agent
suitable for washing machines.
• Some water has remained in the product
due to the quality control processes in the
production. It is not harmful for the product.
4.5 Correct load capacity
The maximum load capacity depends on
the type of laundry, the degree of soiling
and the selected washing programme.
The product automatically adjusts
the water amount according to the
weight of the laundry put inside it.
A
CAUTION!
• Follow the information in the “Programme
and consumption table”. When overloaded,
machine's washing performance will
drop. Moreover, noise and vibration
problems may occur. For a good drying
performance, do not load the machine
with more laundry than recommended.
Laundry
type
Weight
(g)
Laundry
type
Weight
(g)
Bathrobe 1200 Hand towel 100
Fabric napkin 100 Nightgown 200
Bed sheet 700 Underclothing 100
Bed sheet 500 Men’s work shirts 600
Pillowcase 200 Men’s shirt 200
Tablecloth 250 Men’s pyjamas 500
Towel 200 Blouses 100

16 / EN Washer-Dryer / User’s Manual
4.6 Loading the laundry
1. Open the loading door.
2. Place the laundry loosely in the product.
3. Push the loading door to close it until
you hear a locking sound. Ensure that
no items are caught in the door.
C
INFORMATION
• The loading door is locked while a
programme is running. The door lock
will open immediately after the washing
programme has ended. If the inner part of
the machine is too hot at the end of the
programme, the loading door will not open
until the temperature drops. If the door
does not open, apply the solutions provided
for "Loading Door Cannot be Opened."
error in the Troubleshooting section.
A
CAUTION!
• If the laundry is misplaced,
noise and vibration problems
may occur in the machine.
4.7 Using detergent and softener
C
INFORMATION
• When using detergent, softener, starch,
fabric dye, bleach or limescale remover,
read the manufacturer's instructions on the
package carefully and follow the suggested
dosage values. Use measuring cup if any.
4.7.1 Detergent drawer
The detergent drawer is composed
of three compartments:
1
3
2
– (1) for prewash
– (2) for main wash
– (3) for softener
–( ) in addition, there
is a siphon part in the
softener compartment.
4.7.2 Detergent, softener
and other cleaning agents
• Add detergent and softener before
starting the washing programme.
• Never leave the detergent drawer open
while the washing programme is running!
• When using a programme without prewash,
do not put liquid detergent into the prewash
compartment (compartment no. "1").
• In a programme with prewash, put
liquid detergent into the prewash
compartment (compartment no. “1”).
• Do not select a programme with prewash if
you are using a detergent bag or dispensing
ball. Place the detergent bag or the
dispensing ball directly among the laundry
in the machine. Remove them after drying.
• If you are using liquid detergent, do not forget
to place the liquid detergent container into the
main wash compartment (compartment no. 2).
• When the machine is in Drying step,
do not add any washing chemicals
(Liquid detergent, Softener, etc.).
4.7.3 Choosing the detergent
Detergent type to be used depends
on the fabric type and colour.
• Use different detergents for
coloured and white laundry.
• Wash your delicate clothes only with special
detergents (liquid detergent, wool shampoo,
etc.) used solely for delicate clothes.
• When washing dark coloured clothes
and duvets, it is recommended
to use liquid detergent.
• Wash woolens with a special detergent
made specifically for woolens.
A
CAUTION!
• Use only detergents manufactured
specifically for washing machines.
• Do not use soap powder.
4.7.4 Adjusting the
amount of detergent
The amount of washing detergent to be
used depends on the amount of laundry,
the degree of soiling and water hardness.

17 / EN Washer-Dryer / User’s Manual
• Do not use amounts exceeding the dosage
quantities recommended on the detergent
package to avoid problems of excessive
foam, poor rinsing, financial savings
and finally, environmental protection.
• Use lesser detergent for small
amounts or lightly soiled clothes.
4.7.5 Using softeners
Pour the softener into the softener
compartment of the detergent drawer.
• Do not exceed the (>max<) level marking
in the softener compartment.
• If the softener has lost its fluidity or if it is
concentrated, dilute it with water before
putting it in the detergent drawer.
4.7.6 Using liquid detergents
4.7.6.1 If the product contains
a liquid detergent container
• Place the liquid detergent container
in compartment no. “2”.
• If the liquid detergent has lost its fluidity, dilute it
with water before putting in the compartment.
2
4.7.6.2 If the product is equipped
with a liquid detergent apparatus:
• If you want to use liquid detergent,
pull the apparatus towards yourself.
The part that falls off will function as
a barrier for liquid detergent.
• If required, clean the apparatus with water
when it is in place or by removing it.
• If you will use powder detergent, the
apparatus must be secured at top position.
4.7.6.3 If the product does not
contain a liquid detergent container
• Do not use liquid detergent for the
prewash in a programme with prewash.
• Liquid detergent stains your clothes
when used with Delayed Start function.
If you are going to use the Delayed Start
function, do not use liquid detergent.
4.7.7 Using gel and
tablet detergent
• If the gel detergent thickness is fluidal and
your machine does not contain a special
liquid detergent container, put the gel
detergent into the main wash detergent
compartment during first water intake. If
your machine contains a liquid detergent
container, fill the detergent into this
container before starting the programme.
• If the gel detergent thickness is not fluidal
or in the shape of capsule liquid tablet, put
it directly into the drum before washing.
• Put tablet detergents into the main wash
compartment (compartment no. "2") or
directly into the drum before washing.
C
INFORMATION
• Tablet detergents may leave residues in the
detergent compartment. If you encounter
such residues, place the tablet detergent
between the laundry, close to the lower
part of the drum in future washings.
• Use the tablet or gel detergent without
selecting the prewash function.
C
INFORMATION
• Before drying, remember to remove
objects such as the plastic detergent
container from the drum.
4.7.8 Using laundry starch
• Add liquid starch, powder starch or the
fabric dye into the softener compartment.
• Do not use softener and starch
together in a washing cycle.
• Wipe the inside of the machine with a
damp and clean cloth after using starch.

18 / EN Washer-Dryer / User’s Manual
4.7.9 Using bleach
• Select a programme with prewash and
add the bleach at the beginning of the
prewash. Do not put detergent in the
prewash compartment. Alternatively, select
a programme with an extra drying step,
add the bleach to the empty detergent
compartment and once you see the rinsing
step on the display for the first time, add 1
glass of water into the same compartment.
• Do not use bleach and detergent
by mixing them.
• Use just a little amount (approximately
50 ml) of bleach and rinse the clothes
very well as it causes skin irritation. Do
not pour the bleach onto the laundry and
do not use it with the colored items.
• When using oxygen-based bleaches,
select a programme that washes the
laundry at a low temperature.
• You can use oxygen-based bleaches
together with the detergent. However, if it
has a different consistency, first add the
detergent into the detergent compartment
no “2” and wait for the machine to take in
the detergent together with water. While
the product continues taking in water,
add bleach in the same compartment.
4.7.10 Using limescale remover
• When required, use limescale
removers manufactured specifically
for washing machines only.
4.8 Tips for efficient washing
Clothes
Light Colours and
Whites Colours Black/Dark Colours
Delicates/
Woolens/Silks
(Recommended temperature
range based on soiling level:
40-90˚C)
(Recommended temperature
range based on soiling level:
cold -40˚C)
(Recommended
temperature range
based on soiling level:
cold -40˚C)
(Recommended
temperature range based
on soiling level: cold
-30˚C)
Soiling Level
Heavily Soiled
(difficult stains such as grass, coffee,
fruits and blood.)
It may be necessary to pre-treat
the stains or perform prewash.
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and soil
stains and the stains that are
sensitive to bleaches.
Powder and liquid detergents
recommended for coloured
laundry can be used at dosages
recommended for heavily soiled
clothes. It is recommended
to use powder detergents to
clean clay and soil stains and
the stains that are sensitive to
bleaches. Detergents which
do not contain bleach should
be used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
heavily soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woolen and silk
clothes must be washed
with special woolen
detergents.
Normally
Soiled
(For example, stains
caused by body on
collars and cuffs)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for normally soiled clothes.
Powder and liquid detergents
recommended for colors can be
used at dosages recommended
for normally soiled clothes.
Detergents which do not contain
bleach should be used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
normally soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woolen and silk
clothes must be washed
with special woolen
detergents.
Lightly
Soiled
(No visible stains
exist.)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for lightly soiled clothes.
Powder and liquid detergents
recommended for colors can be
used at dosages recommended
for lightly soiled clothes.
Detergents which do not contain
bleach should be used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for lightly
soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woolen and silk
clothes must be washed
with special woolen
detergents.

19 / EN Washer-Dryer / User’s Manual
4.9 Tips for correct drying
Programmes
Cottons Drying Synthetics Drying Babyprotect + Washing and Drying Wash&Wear
Types of Clothes
Durable Clothes with Cotton-Content
Sheet, bedding, baby
clothes, t-shirts,
sweatshirts, durable knit
clothing, jeans, canvas
trousers, shirts, cotton
socks etc.
Not recommended!
Washes and dries
respectively! Sheet,
bedding, baby clothes,
t-shirts, sweatshirts,
durable knit clothing,
jeans, canvas
trousers, shirts, cotton
socks etc.
Washes and dries
respectively! Sheet,
bedding, baby clothes,
t-shirts, sweatshirts,
durable knit clothing, jeans,
canvas trousers, shirts,
cotton socks etc.
Stainless clothes
that has been worn
for a short time such
as shirts, t-shirts,
sweatshirts A very small
amount of laundry must
be loaded.
Synthetics Clothes (Polyester, nylon, etc.)
Not recommended!
It is recommended for the
polyester, nylon, polyacetate,
acrylic-content clothes.
Drying is not recommended
for the viscose-content
clothes. Drying explanations
in the maintenance label
should be taken into account.
It is recommended
for polyester, nylon,
polyacetate, acrylic
content clothes at low
temperatures, taking
into account the
washing and drying
warnings on the care
label.
It is recommended
for polyester, nylon,
polyacetate, acrylic
content clothes at low
temperatures, taking into
account the washing and
drying warnings on the
care label.
Lightly soiled and
stainless shirts, t-shirts
and synthetic-content
clothes. A very small
amount of laundry
should be loaded.
Delicate (Silk, Woolens, Cashmere, Angora wool, etc. content) Clothes
Not recommended! Not recommended! Not recommended! Not recommended! Not recommended!
Bulky laundry such as blankets, coats, curtains etc.
Not recommended!
It is not appropriate to
dry bulky laundry in the
washer. Dry them by
hanging them or laying
them flat.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
Not recommended! It
is not appropriate to
dry bulky laundry in
the washer. Dry them
by hanging them or
laying them flat.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
Not recommended!
It is not appropriate to
dry bulky laundry in the
washer. Dry them by
hanging them or laying
them flat.
SpinPre-wash Night
mode
Fast+ Rinse
Plus
TemperatureAnti
creasing
No
spin
Cold Rinse
hold
Rinse
hold
Time
delay
Pet hair
removal
Auto
Dosing
Rinse Spin+Pump Fast+ Steam Pet hair
removal
Cold Drying Auto
Dosing
Softener
Selection
4.10 Displayed Program Time
You can see the programme duration
on the display of your machine while
selecting a programme. Depending on the
amount of laundry you have loaded into
your machine, foaming, unbalanced load
conditions, fluctuations in power supply,
water pressure and program settings,
the programme duration is automatically
adjusted while the programme is running.
SPECIAL CASE: At programme start of
Cottons and Cotton Eco programmes,
display shows the duration of half load,
which is the most common use case. After
programme starts, in 20-25 minutes actual
load is detected by the machine. And if the
detected load is higher than half load; washing
program will be adjusted accordingly and
program duration increased automatically.
You may follow this change on the display.

20 / EN Washer-Dryer / User’s Manual
5 Operating the product
5.1 Control panel
1200
1000
800
600
90
˚
60
˚
40
˚
30
˚
20
˚
Cottons
CottonsEco
Synthetics
Woollens
HandWash
DailyExpress
XpressSuperShort
DownWear
Rinse
Shirts
Cotton
Dry
Synthetic
Dry
Hygiene+
Wash & Dry
Wash & Wear
Spin+Drain
Downloaded
Program
5 5 5 Kg
Wash & Dry
1 2 3 4
79 8101112 6 5
1 - Programme selection knob
2 - Temperature level lights
3 - Spin speed level lights
4 - Display
5 - Start/Pause button
6 - Remote Control button
7 - End Time Adjustment button
8 - Drying Level Adjustment Button
9 - Auxiliary function button 2
10 - Auxiliary function button 1
11 - Spin speed adjustment button
12 - Temperature adjustment button
5.2 Display Symbols
1400
1000
800
600
90˚
60˚
40˚
30˚
20˚
a b c d e
f
h
g
ikl jno mpr
a - Temperature indicator
b - Spin speed indicator
c - Duration information
d - Door lock engaged symbol
e - Programme follow-up indicator
f - No water indicator
g - Add laundry indicator
h - Bluetooth connection indicator
i - Remote Control indicator
j - Delayed Start enabled indicator
k - Drying level indicator
l - Child lock enabled symbol
m - Auxiliary function indicators 2
n - Auxiliary function indicators 1
o - No spin indicator
p - Rinse hold indicator
r - Cold water indicator
5.3 Preparing the Machine
1. Check if the hoses are connected tightly.
2. Plug in your machine.
3. Turn the tap on completely.
4. Place the laundry in the machine.
5. Add detergent and fabric softener.
5.4 Selecting a washing
programme
1. In accordance with the “Programme
and consumption table”, select a
suitable programme for the amount
and soiling level of the laundry.
2. Select the desired programme with
the Programme Selection knob.
C
INFORMATION
• Programmes are limited to the
highest spin speed appropriate for
that particular type of fabric.
• When selecting a programme, always
consider the type of fabric, colour, soiling
level and permissible water temperature.
• Always select the lowest appropriate
temperature. Higher temperature means
higher electricity consumption.
5.5 Washing programmes
Depending on the type of fabric, use
the following main programmes.
C
INFORMATION
• After selecting a washing programme suitable
for your laundry, you can press the Drying
button to set the machine to perform drying
after the washing programme. Each time you
press the button, info line shows at which
step the drying process will take place and
the relevant symbol will turn on. If you want,
you can keep pressing the button to perform
drying for the maximum period allowed.
• The symbols shown on the display
are schematic and may not
match the product exactly.
• When you will perform washing and
drying by using the Drying function of your
machine, load maximum 5 kg of laundry
into the machine. If you exceed the capacity
of the machine, your laundry will not dry
and the machine will work longer, which
will result in more energy consumption.
