Beko WMY 91483 LB3 User manual

2820526167_EN/19-03-19.(16:17)
Washing Machine
User’s Manual
WMY 91483 LB3
EN / DE / FR
Document Number=
Waschmaschine
Bedienungsanleitung
Lave-linge
Manuel d‘utilisation

2 / EN Washing Machine / User’s Manual
1 General safety instructions
This section includes security instructions which may help prevent the
injuries and material damage risks. All kinds of warranties shall be invalid if
these instructions are not observed.
1.1 Life and property safety
uNever place the product on a carpet-covered floor. Electrical parts will get
overheated since air cannot circulate from under the device. This will cause
problems with your product.
uUnplug the product if it is not in use.
uAlways have the installation and repairing procedures carried out by the
Authorised Service Agent. The manufacturer shall not be held liable for
damages that may arise from procedures carried out by unauthorised
persons.
uThe water supply and draining hoses must be securely fastened and remain
undamaged. Otherwise, water leak may occur.
uWhile there is still water inside the product, never open the loading door or
remove the filter. Otherwise, risk of flooding and injury from hot water will
occur.
uDo not force open the locked loading door. Door can be opened a few
minutes after the washing cycle ends. In case of forcing the loading door to
open, the door and the lock mechanism may get damaged.
uUse detergents, softeners and supplements suitable for automatic washing
machines only.
uFollow the instructions on the label of textiles and the detergent package.
1.2 Children's safety
uThis product can be used by the children who are at the age of 8 and
over and the people whose physical, sensory or mental skills are not
fully developed or who do not have necessary required experience and
knowledge as long as they are supervised or trained about the safe use of
the product and its risks. Children should not play with the device. Cleaning
and maintenance works should not be performed by children unless they
are supervised by someone. Children of less than 3 years should be kept
This product was manufactured using the latest technology in environmentally friendly conditions.

3 / EN
Washing Machine / User’s Manual
This product was manufactured using the latest technology in environmentally friendly conditions.
away unless continuously supervised.
uPackaging materials may be dangerous for the children. Keep packaging
materials in a safe place away from reach of the children.
uElectrical products are dangerous for the children. Keep the children away
from the product when it is in use.Do not allow them to play with the product.
Use child lock to prevent children from intervening with the product.
uDo not forget to close the loading door when leaving the room where the
product is located.
uStore all detergents and additives in a safe place away from the reach of
the children by closing the cover of the detergent container or sealing the
detergent package.
1.3 Electrical safety
uIf the product has a failure, it should not be operated unless it is repaired by
the Authorised Service Agent. Risk of electric shock!
uThis product is designed to resume operating in the event of powering
on after a power interruption. If you wish to cancel the programme, see
"Cancelling the programme" section.
uPlug the product into a grounded outlet protected by a 16 A fuse. Do not
neglect to have the grounding installation made by a qualified electrician.
Our company shall not be liable for any damages that will arise when the
product is used without grounding in accordance with the local regulations.
uDo not wash the product by spraying or pouring water onto it! Risk of electric
shock!
uNever touch the power cable plug with wet hands! Do not grab the power
cord to unplug the machine, always unplug it by holding the socket with one
hand, and pulling the plug with the other hand.
uProduct should be unplugged during installation, maintenance, cleaning
and repair procedures.
uIf the power cable is damaged, it must be replaced by the manufacturer,
after sales service or a similarly qualified person (preferably an electrician)
or someone designated by the importer in order to avoid possible risks.
1.4 Hot surface safety
While washing the laundry at high temperatures,
the loading door glass will get hot. Considering
this fact, during washing operation keep the
children away from the loading door of the
product to prevent them touching it.

4 / EN Washing Machine / User’s Manual
2 Important instructions for environment
2.1 Compliance with WEEE Directive
This product complies with EU WEEE Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and electronic equipment (WEEE).
This product has been manufactured with high quality parts and materials which can be
reused and are suitable for recycling. Do not dispose of the waste product with normal
domestic and other wastes at the end of its service life. Take it to the collection center for
the recycling of electrical and electronic equipment. Please consult your local authorities to
learn about these collection centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the Directive.
2.2 Package information
Packaging materials of the product are manufactured from recyclable materials in accordance with
our National Environment Regulations. Do not dispose of the packaging materials together with the
domestic or other wastes. Take them to the packaging material collection points designated by the local
authorities.
3 Intended use
• This product has been designed for domestic use. It is not for commercial purposes or it
should not be used out of its intended use.
• The product must only be used for washing and rinsing of laundry that are marked
accordingly.
• The manufacturer waives any responsibility arisen from incorrect usage or
transportation.
• The service life of your product is 10 years. During this period, original spare parts will
be available to operate the appliance properly.

5 / EN
Washing Machine / User’s Manual
4Technical specifications
Complying Commission Delegated Regulation (EU) No 1061/2010
Supplier name or trademark Beko
Model name WMY 91483 LB3
Rated capacity (kg) 9
Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++
Annual Energy Consumption (kWh) (1) 195
Energy consumption of the standard 60°C cotton programme at full load (kWh) 0,955
Energy consumption of the standard 60°C cotton programme at partial load (kWh) 0,800
Energy consumption of the standard 40°C cotton programme at partial load (kWh) 0,800
Power consumption in ‘off-mode’ (W) 0,500
Power consumption in ‘left-on mode’ (W) 0,500
Annual Water Consumption (l) (2) 10559
Spin-drying efficiency class / Scale from A (Highest Efficiency) to G (Lowest Efficiency) B
Maximum spin speed (rpm) 1400
Remaining moisture Content (%) 53
Standard cotton programme (3) Cotton Eco 60°C and 40°C
Programme time of the standard 60°C cotton programme at full load (min) 220
Programme time of the standard 60°C cotton programme at partial load (min) 200
Programme time of the standard 40°C cotton programme at partial load (min) 200
Duration of the left-on mode (min) N/A
Airborne acoustical noise emissions washing/spinning (dB) 52/75
Built-in No
Height (cm) 84
Width (cm) 60
Depth (cm) 64
Net weight (±4 kg.) 74
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
Main model code 108
(1) Energy Consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load, and the
consumption of the low-power modes. Actual energy consumption will depend on how the appliance is used.
(2) Water consumption based on 220 standard washing cycles for cotton programmes at 60°C and 40°C at full and partial load. Actual water
consumption will depend on how the appliance is used.
(3) “Standard 60°C cotton programme” and the “standard 40°C cotton programme” are the standard washing programmes to which the information
in the label and the fiche relates and these programmes are suitable to clean normally soiled cotton laundry and that they are the most efficient
programmes in terms of combined energy and water consumption.
Technical specifications may be changed without prior notice to improve the quality of the product.

6 / EN Washing Machine / User’s Manual
4.1 Installation
• Apply to the nearest authorised service agent for the installation of your product.
• Preparation of the location and electrical, tap water and waste water installations at the place of installation
is under customer's responsibility.
• Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or
crushed while pushing the product into its place after installation or cleaning procedures.
• Make sure that the installation and electrical connections of the product are performed by authorised
service. Manufacturer shall not be held liable for damages that may arise from procedures carried out by
unauthorised persons.
• Prior to installation, visually check if the product has any defects on it. If so, do not have it installed.
Damaged products cause risks for your safety.
4.1.1 Appropriate installation location
• Place the product on a hard and level floor. Do not put it onto a carpet with high pile or other similar
surfaces.
• When the washing machine and dryer are placed on top of each other, their total weight –when loaded–
amounts to 180 kilograms. Place the product on a solid and flat floor that has sufficient load carrying
capacity!
• Do not place the product on the power cable.
• Do not install the product in the environments where the temperature falls below 0 ºC.
• Leaving a gap at the sides of the machine is suggested to reduce vibration and noise
• On a graduated floor, do not place the product next to the edge or on a platform.
• Do not place heat sources such as Hobs, Irons, Ovens, etc. on the washing machine and do not use them
on the product.
4.1.2 Removing packaging reinforcement
Tilt the machine backwards to remove the packaging reinforcement.
Remove the packaging reinforcement by pulling the ribbon. Do not make
this operation alone by yourself.
4.1.3 Removing the transportation locks
1 Loosen all bolts with an appropriate wrench until they turn freely.
2 Remove the transport safety bolts by turning them slightly.
3 Insert the plastic covers in the bag containing the user manual to the openings on the rear panel.
ACAUTION: Remove the transportation safety bolts before operating the washing machine! Otherwise, the product will be
damaged.
CKeep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the
future.
Install the transport safety bolts in reverse order of the disassembly procedure.
Never move the product without the transportation safety bolts properly fixed in place!

7 / EN
Washing Machine / User’s Manual
4.1.4 Connecting water supply
C
The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). It is necessary to have
10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly.Attach a pressure
reducing valve if water pressure is higher.
ACAUTION: Models with a single water inlet should not be connected to the hot water tap. In such a case the laundry will
get damaged or the product will switch to protection mode and will not operate.
CAUTION: Do not use old or used water inlet hoses on the new product. It may cause stains on your laundry.
1 Tighten the nuts of the hose by hand. Never use a tool when
tightening the nuts.
2 When hose connection is completed, check whether there is leak
problems at the connection points by opening the taps fully. If any
leaks occur, turn off the tap and remove the nut. Retighten the nut
carefully after checking the seal. In order to prevent the water leaks
and resultant damages, keep the taps closed when you do not use
the product.
4.1.5 Connecting the drain hose to the drain
• Attach the end of the drain hose directly to waste water drain, lavatory or bathtub.
ACAUTION: Your drain house will be flooded if the hose comes out of its housing during water discharge. Moreover, there
is risk of scalding due to high washing temperatures! In order to prevent such situations and make sure that the machine
performs water intake and discharge processes without any problem, fix the drain hose securely.
40 cm
100 cm
• Connect the drain hose to a minimum height of 40 cm
and a maximum height of 100 cm.
• In case the drain hose is elevated after laying it on the
floor level or close to the ground (less than 40 cm above
the ground), water discharge becomes more difficult and
the laundry may come out excessively wet. Therefore,
follow the heights described in the figure.
• To prevent the waste water to go back into the machine again and to ensure easy drainage, do not immerse
the end of the hose into the waste water or do not insert it into the drain for more than 15 cm. If it is too
long, cut it short.
• The end of the hose should not be bent, it should not be stepped on and the hose must not be pinched
between the drain and the machine.
• If the length of the hose is too short, use it by adding an original extension hose. Length of the hose may
not be longer than 3.2 m. To avoid water leak failures, the connection between the extension hose and the
drain hose of the product must be fitted well with an appropriate clamp as not to come off and leak.

8 / EN Washing Machine / User’s Manual
4.1.6 Adjusting the feet
ACAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced
on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing
and vibration problems.
CAUTION: Do not use any tools to loosen the lock nuts. Otherwise, they will get damaged.
1 Loosen the lock nuts on the feet by hand.
2 Adjust the feet until the product stands in a stable and balanced way.
3. Tighten all lock nuts by hand again.
4.1.7 Electrical connection
Connect the product to a grounded outlet protected by a 16 A fuse. Our company shall not be liable for any
damages that will arise when the product is used without grounding in accordance with the local regulations.
• Connection must comply with national regulations.
• The wiring for the electrical outlet circuit must be sufficient to meet the appliance requirements. Use of a
Groud Fault Circuit Interrupter (GFCI) is recommended.
• Power cable plug must be within easy reach after installation.
• If the current value of the fuse or breaker in the house is less than 16 Amps, have a qualified electrician
install a 16 Amp fuse.
• The voltage specified in the "Technical specifications" section must be equal to your mains voltage.
• Do not make connections via extension cables or multi-plugs.
BCAUTION: Damaged power cables must be replaced by the Authorised Service Agents.
4.1.8 Initial use
Before starting to use the product make sure that the preparations are
made which are in line with the “Important Safety and Environment
Instructions” and the instructions in the “Installation” section.
To prepare the product for washing laundry, perform first operation
in Drum Cleaning programme. If this program is not available in your
machine, apply the method which is described in the section 4.4.2.
CUse an anti-limescale suitable for the washing machines.
Some water might have remained in the product due to the quality control processes in the production. It is not harmful for
the product.

9 / EN
Washing Machine / User’s Manual
4.2 Preparation
4.2.1 Sorting the laundry
* Sort laundry according to type of fabric, color, and degree of soiling and allowable water temperature.
* Always obey the instructions given on the garment tags.
4.2.2 Preparing laundry for washing
• Laundry items with metal attachments such as, underwired bras, belt buckles or metal buttons will damage
the machine. Remove the metal pieces or wash the clothes by putting them in a laundry bag or pillow case.
• Take out all substances in the pockets such as coins, pens and paper clips, and turn pockets inside out and
brush. Such objects may damage the product or cause noise problem.
• Put small size clothes such as infant's socks and nylon stockings in a laundry bag or pillow case.
• Place curtains in without compressing them. Remove curtain attachment items.
• Fasten zippers, sew loose buttons and mend rips and tears.
• Wash “machine washable” or “hand washable” labeled products only with an appropriate programme.
• Do not wash colours and whites together. New, dark coloured cottons release a lot of dye. Wash them
separately.
• Tough stains must be treated properly before washing. If unsure, check with a dry cleaner.
• Only use the dyes / color changers and descaling agents which are appropriate to machine wash. Always
follow the instructions on the package.
• Wash trousers and delicate laundry turned inside out.
• Keep laundry items made of Angora wool in the freezer for a few hours before washing. This will reduce
pilling.
• Laundry that are subjected to materials such as flour, lime dust, milk powder, etc. intensely must be shaken
off before placing into the machine. Such dusts and powders on the laundry may build up on the inner parts
of the machine in time and can cause damage.
4.2.3 Things to be done for energy saving
Following information will help you use the product in an ecological and energy-efficient manner.
• Operate the product in the highest capacity allowed by the programme you have selected, but do not
overload; see, "Programme and consumption table". See, “Programme and consumption table"
• Always follow the instructions on the detergent packaging.
• Wash slightly soiled laundry at low temperatures.
• Use faster programmes for small quantities of lightly soiled laundry.
• Do not use prewash and high temperatures for laundry that is not heavily soiled or stained.
• If you plan to dry your laundry in a dryer, select the highest spin speed recommended during washing
process.
• Do not use more detergent than the recommended amount specified on its package.
4.2.4 Loading the laundry
1. Open the laundry cover.
2. Put the laundry items into the machine in a loose manner.
3. Push and close the loading cover until you hear the locking sound. Ensure that no items are caught in the
door. The loading door is locked while a programme is running. The door can only be opened a while after
the programme comes to an end.
4.2.5 Correct load capacity
The maximum load capacity depends on the type of laundry, the degree of soiling and the washing
programme desired.
Machine automatically adjusts the water amount according to the weight of the laundry put inside it.
AWARNING: Follow the information in the “Programme and consumption table”. When overloaded, machine's washing
performance will drop. Moreover, noise and vibration problems may occur.

10 / EN Washing Machine / User’s Manual
4.2.6 Using detergent and softener
C
When using detergent, softener, starch, fabric dye, bleacher and decolorant, descaling agents; read the manufacturer's
instructions written on the package and follow the dosages specified. Use measuring cup if available.
1
3
2
The detergent drawer is composed of three compartments:
– (1) for prewash
– (2) for main wash
– (3) for softener
– ( ) in addition, there is a siphon piece in the softener
compartment.
Detergent, softener and other cleaning agents
• Add detergent and softener before starting the washing programme.
• While the washing cycle is in progress, do not leave the detergent dispenser open!
• When using a programme without prewash, do not put any detergent into the prewash compartment
(compartment nr. "1").
• In a programme with prewash, do not put liquid detergent into the prewash compartment (compartment nr.
"1").
• Do not select a programme with prewash if you are using a detergent bag or dispensing ball. Place the
detergent bag or the dispensing ball directly among the laundry in the machine.
If you are using liquid detergent, do not forget to place the liquid detergent container into the main wash
compartment (compartment number “2”).
Choosing the detergent type
Detergent type to be used depends on the fabric type and color.
• Use different detergents for coloured and white laundry.
• Wash your delicate clothes only with special detergents (liquid detergent, wool shampoo, etc.) used solely
for delicate clothes.
• When washing dark coloured clothes and quilts, it is recommended to use liquid detergent.
• Wash woolens with special detergent made specifically for woolens.
ACAUTION: Use only detergents manufactured specifically for washing machines.
CAUTION: Do not use soap powder.
Adjusting detergent amount
The amount of washing detergent to be used depends on the amount of laundry, the degree of soiling and
water hardness.
• Do not use amounts exceeding the dosage quantities recommended on the detergent package to avoid
problems of excessive foam, poor rinsing, financial savings and finally, environmental protection.
• Use lesser detergent for small amounts or lightly soiled clothes.
Using softeners
Pour the softener into the softener compartment of the detergent drawer.
• Do not exceed the (>max<) level sign on the softener compartment.
• If the softener has lost its fluidity, dilute it with water before putting it in the detergent drawer.

11 / EN
Washing Machine / User’s Manual
Using liquid detergents
If the product contains a liquid detergent cup:
2
2
• Put the liquid detergent container into the
compartment no “2”.
• If the liquid detergent lost its fluidity, dilute it
with water before putting it into the detergent
container.
If the product is equipped with a liquid detergent part:
• When you want to use liquid detergent, pull
the apparatus towards yourself. The part that
falls down will serve as a barrier for the liquid
detergent.
• If required, clean the apparatus with water
when it is in place or by removing it.
• If you will use powder detergent, the apparatus
must be secured at top position.
If the product does not contain a liquid detergent cup:
• Do not use liquid detergent for the prewash in a programme with prewash.
• Liquid detergent stains your clothes when used with Delayed Start function. If you are going to use the
Delayed Start function, do not use liquid detergent.
Using gel and tablet detergent
• If the gel detergent thickness is fluidal and your machine does not contain a special liquid detergent cup,
put the gel detergent into the main wash detergent compartment during first water intake. If your machine
contains a liquid detergent cup, fill the detergent into this cup before starting the programme.
• If the gel detergent thickness is not fluidal or in the shape of capsule liquid tablet, put it directly into the
drum before washing.
• Put tablet detergents into the main wash compartment (compartment nr. "2") or directly into the drum
before washing.
Using starch
• Put the liquid soda, powder soda or the fabric dye into the softener compartment.
Do not use softener and starch together in a washing cycle.
Wipe the inside of the machine with a damp and clean cloth after using starch.
Using limescale remover
• When required, use limescale removers manufactured specifically for washing machines only.
Using bleaches
• Add the bleach at the beginning of the washing cycle by selecting a prewash program. Do not put detergent
in the prewash compartment. As an alternative application, select a programme with extra rinse and add
the bleaching agent while the machine is taking water from the detergent compartment during first rinsing
step.
• Do not use bleaching agent and detergent by mixing them.
• Use just a little amount (approx. 50 ml) of bleaching agent and rinse the clothes very well as it causes skin irritation. Do not
pour the bleach onto the laundry and do not use it with the colored items.
• When using oxygen-based decolorant, select a program which washes the laundry at a low temperature.
• Oxygen-based decolorant can be used with the detergent; however, if it is not at the same consistence, first
put detergent in the compartment number “2” in the detergent dispenser and wait for the machine to flush
the detergent when taking in water. While the machine continues taking in water, add decolorant in the
same compartment.

12 / EN Washing Machine / User’s Manual
4.2.7 Tips for efficient washing
Clothes
Light Colours and
Whites Colours Black/Dark Colours
Delicates/
Woolens/Silks
(Recommended temperature
range based on soiling level:
40-90 oC)
(Recommended temperature
range based on soiling level:
cold -40 oC)
(Recommended
temperature range
based on soiling
level: cold -40 oC)
(Recommended
temperature range
based on soiling
level: cold -30 oC)
Soiling Level
Heavily
Soiled
(difficult stains
such as grass,
coffee, fruits and
blood.)
It may be necessary to pre-treat
the stains or perform prewash.
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and soil
stains and the stains that are
sensitive to bleaches.
Powder and liquid
detergents recommended
for colors can be used at
dosages recommended
for heavily soiled clothes.
It is recommended to use
powder detergents to clean
clay and soil stains and the
stains that are sensitive to
bleaches. Use detergents
without bleach.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended
for heavily soiled
clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woolen and silk
clothes must be
washed with special
woolen detergents.
Normally
Soiled
(For example,
stains caused by
body on collars
and cuffs)
Powder and liquid
detergents recommended
for whites can be used at
dosages recommended for
normally soiled clothes.
Powder and liquid detergents
recommended for colors can be
used at dosages recommended
for normally soiled clothes.
Detergents which do not contain
bleach should be used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
normally soiled
clothes.
Prefer liquid detergents
produced for delicate
clothes. Woolen and silk
clothes must be washed
with special woolen
detergents.
Lightly Soiled
(No visible stains
exist.)
Powder and liquid
detergents recommended
for whites can be used at
dosages recommended for
lightly soiled clothes.
Powder and liquid
detergents recommended
for colors can be used at
dosages recommended
for lightly soiled clothes.
Detergents which do not
contain bleach should be
used.
Liquid detergents
suitable for colors
and dark colors can
be used at dosages
recommended for
lightly soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woolen and silk
clothes must be washed
with special woolen
detergents.
4.2.8 Displayed Program Time
You can see the programme duration on the display of your machine while selecting a programme. Depending on the amount of
laundry you have loaded into your machine, foaming, unbalanced load conditions, fluctuations in power supply, water pressure and
program settings, the programme duration is automatically adjusted while the programme is running.
SPECIAL CASE: At programme start of Cottons and Cotton Eco programmes, display shows the duration
of half load, which is the most common use case. After programme starts, in 20-25 minutes actual load is
detected by the machine. And if the detected load is higher than half load; washing program will be adjusted
accordingly and program duration increased automatically. You may follow this change on the display.

13 / EN
Washing Machine / User’s Manual
4.3 Operating the product
4.3.1 Control panel
1 - Programme selection knob
2 - Temperature level lights
3 - Spin level indicator lights
4 - Duration information display
5 - Child lock enabled light
6 - End Time Setting button
7 - Door lock enabled light
8 - Programme Follow-up indicator lights
9 - On / Off button
10 - Start / Pause button
11 - Auxiliary function buttons 3
12 - Auxiliary function buttons 2
13 - Auxiliary function buttons 1
14 - Spin speed adjustment button
15 - Temperature adjustment button
16 - Programme selection indicator lights
WMY 91483 LB3
Mix
Manchas PRO
Delicados
Sintéticos
Camisas
Algodón
Algodão
Algodón
Algodão
Rápido 28’
Rápido 14’
Lana
Lã
R. oscura
R. escura
Lencería
Lingerie
Sport
Edredón
20°
1400
1200
800
600
123 4 5 6 7 8
9
10
11121314
15
16
SpinPre-wash Night
mode
Fast+ Rinse
Plus
TemperatureAnti
creasing
No
spin
Cold Rinse
hold
Time
delay
Pet hair
removal
Drain
(Pump)
Cottons Cottons
Eco
Synthetics Wool /
Hand Wash
Wool /
Hand Wash
Shirts Down
Wear
Daily Xpress /
Xpress Super
Short
Drum
Cleaning
Mix Delicate Sports /
Outdoor
DarkCare /
Jeans
Lingerie
On/Off Rinse Stain
Expert
Hygiene+ Duvet /
Down Wear
Cool
Clean
Automatic
Programme
Auto
Dosing
Air Refresh
(Clean&Wear)
Hygiene Steam

14 / EN Washing Machine / User’s Manual
4.3.2 Programme and consumption table
• : Selectable.
* : Automatically selected, no canceling.
** : Energy Label programme (EN 60456 Ed.3 )
*** : If maximum spin speed of the product is lower then this value, you can only select up to the maximum spin speed.
- : See the programme description for maximum load.
** “Cotton Economic 40°C" and "Cotton Economic 60°C" are standard programmes. These programmes are known as "40°C cotton
standard programme" and "60°C cotton standard programme" and indicated with the symbols on the panel.
CThe auxiliary functions in the table may vary according to the model of your product.
Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient
temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.
You can see the washing duration on the display of your machine while selecting a programme. Depending on the amount of laundry
you have loaded into your machine, there may be a difference of 1-1.5 hours between the duration shown on the display and the
actual duration of the wash cycle. Duration will be automatically updated soon after the washing starts.
Auxiliary function selection modes can be changed by the manufacturing company. Existing selection modes can be removed or new
selection modes can be added.
"The manufacturer reserves the right to make modifications in the programmes and auxiliary functions given in the table. While these
modifications will not change the product performance, programme steps and durations can change."
EN 2Auxiliary functions
Programme
Max. Load (kg) Water Consumption (l) Energy Consumption (kWh) Max. Speed*** Prewash Fast+ Pet hair removal Anticrease+
Selectable
temperature range
°C
Algodón
90 9 96,0 2,50 1400 • • • • Cold-90
60 9 96,0 1,85 1400 • • • • Cold-90
40 9 94,0 1,10 1400 • • • • Cold-90
Algodón Eco
60** 9 55,0 0,955 1400 Cold-60
60** 4,5 42,7 0,800 1400 Cold-60
40** 4,5 42,7 0,800 1400 Cold-60
Sintéticos 60 4 70 1,37 1200 • • • • Cold-60
40 4 68 0,90 1200 • • • • Cold-60
Rápido 28’ / Rápido 14
90 9 75 2,15 1400 • • Cold-90
60 9 75 1,12 1400 • • Cold-90
30 9 75 0,17 1400 • • Cold-90
Rápido 28’ / Rápido 14 + Fast+ 90 2 42 0,15 1400 • • Cold-30
Mix 40 4 81 0,96 800 • • • Cold-40
Lana 40 2 60 0,50 1200 Cold-40
Delicados 40 4 52 0,71 800 Cold-40
Edredón 60 - 102 1,67 1000 Cold-60
Sport 40 4 57 0,58 1200 • Cold-40
R. oscura 40 4 102 0,98 1200 • • • • Cold-40
Manchas PRO 60 4,5 85 1,79 1400 • • 30-60
Camisas 60 4 60 1,34 800 • • • • Cold-60
Hygiene+ 90 9 122 2,75 1400 20-90
Lencería 30 1 70 0,26 600 Cold-30
Drum Cleaning 90 - 85 2,55 600 90

15 / EN
Washing Machine / User’s Manual
4.3.3 Programme selection
1 Determine the programme suitable for the type, quantity and soiling level of the laundry in accordance with
the "Programme and consumption table".
CProgrammes are limited with the highest spin speed appropriate for that particular type of fabric.
When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature.
Always select the relevant lowest required temperature. Higher temperature means higher electricity consumption.
2 Select the desired programme with the Programme Selection knob.
4.3.4 Programmes
• Algodón Eco (Cottons Eco)
Use to wash your normally soiled, durable cotton and linen laundry. Although it washes longer than all other
programmes, it provides high energy and water savings. Actual water temperature may be different from the
stated wash temperature. When you load the machine with less laundry (e.g. ½ capacity or less), periods in
programme stages may automatically get shorter. In this case, energy and water consumption will decrease
more, providing a more economic wash.
• Algodón (Cottons)
You can wash your durable cotton laundry (sheets, bedlinen, towels, bathrobes, underwear etc.) in this
programme. When the fast+ wash function key is pressed, programme duration becomes notably shorter but
effective washing performance is ensured with intense washing movements. If the fast+ wash function is not
selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.
• Sintéticos (Synthetics)
You can wash your laundry (such as shirts, blouses, synthetic/cotton blended fabrics etc.) in this programme.
The programme duration gets notable shorter and washing with high performance is ensured. If the fast+
wash function is not selected, superior washing and rinsing performance is ensured for your heavily soiled
laundry.
• Lana (Woollens / Hand Wash)
Use to wash your woolen/delicate laundry. Select the appropriate temperature complying with the tag of your
clothes. Your laundry will be washed with a very gentle washing action in order not to damage the clothes.
Indicative values for Synthetics programmes (EN)
Load (kg) Water Consumption (l) Energy Consumption (kWh) Programme Duration (min) *
Remaining Moisture Content
(%) **
Remaining Moisture Content
(%) **
≤ 1000 rpm > 1000 rpm
Synthetics 60 4 70 1,37 115/150 45 40
Synthetics 40 4 68 0,90 115/150 45 40
* You can see the washing time of the programme you have selected on the display of the machine. It is normal that small differences may occur
between the time shown on the display and the real washing time.
** Remaining moisture content values may differ according to the selected spin speed.

16 / EN Washing Machine / User’s Manual
The wool wash cycle of this machine has been approved by The Woolmark Company
for the washing of machine washable wool products provided that the products are
washed according to the instructions on the garment label and those issued by the
manufacturer of this washing machine. M13985
“In UK, Eire, Hong Kong and India the Woolmark trade mark is a Certification trade
mark.”
• Hygiene+
Use this programme for your laundry for which you require an anti-allergic and hygienic washing at high
temperature with intensive and long washing cycle. The high level of hygiene is ensured thanks to long heating
duration and additional rinsing step.
• Programme was tested by the “VDE” institute with the 20°C temperature option selected and it was
certified in terms of its efficacy in eliminating bacteria and mould.
• Programme was tested by “The British Allergy Foundation” (Allergy UK) with the 60°C temperature
option selected and it was certified in terms of its efficacy in eliminating allergens in addition to bacteria and
mould.
Allergy UK is the operational name of The British Allergy Foundation. The Seal of Approval
endorsement, which indicates that the product bearing it specifically restricts / reduces /
removes allergens from the environment of the allergy sufferer or has significantly reduced
allergen content, was created in order to provide guidance for people seeking advice in this
issue. It is aimed to assure poeple that products had been scientifically tested or reviewed
with measurable results.
• R. oscura (Dark Care)
Use this programme to protect the colour of your dark-coloured garments or jeans. It performs high
performance washing with special drum movement even if the temperature is low. It is recommended to use
liquid detergent or woolen shampoo for dark coloured laundry. Do not wash your delicate clothes containing
wool or etc.
• Spin / Drain
You can use this function to remove the water on the garment of drain the water in the machine.
• Rinse
Use when you want to rinse or starch separately.
• Camisas (Shirts)
This programme is used to wash the shirts made from cotton, synthetic and synthetic blended fabrics
altogether. It reduces wrinkles. When the fast+ wash function is selected, the Pre-treatment algorithm is
executed.
• Apply the pre-treatment chemical on your garments directly or add it together with detergent when
the machine starts to take water from the main washing compartment. Thus, you can obtain the same
performance as you obtain with normal washing in a much shorter period of time. Usage life of your shirts
increases.
• Mix
Use to wash your cotton and synthetic clothes together without sorting them.
• Delicados (Delicates)
You can wash your delicate clothes such as cotton/synthetic blended knitwear or hosiery in this programme. It
washes with more delicate washing action. Wash your clothes whose colour you want to preserve either at 20
degrees or by selecting the cold wash option.
• Rápido 28’ / Rápido 14’ (Daily Xpress / Xpress Super Short)
Use this programme to wash your lightly soiled or unspotted cotton clothes in a short time. The programme
duration can be reduced up to 14 minutes when the fast+ wash function is selected. When the fast+ wash
function is selected, maximum 2 (two) kg of laundry must be washed.

17 / EN
Washing Machine / User’s Manual
• Edredón (Duvet / Down Wear)
Use this programme to wash your fiber duvets that bear "machine washable" tag. Check that you have loaded
the duvet correctly in order not to damage the machine and the duvet. Remove the duvet cover before loading
the duvet into the machine. Fold the duvet into two and load it into the machine. Load the duvet into the
machine paying attention to place it in a way that it will not contact the bellow or the glass.
CDo not load more than 1 double fiber duvet (200 x 200 cm).
Do not wash your duvets, pillows and etc. that contain cotton in the machine.
ACAUTION: Do not wash the items apart from duvets such as carpets, rugs and etc. in the machine. Permanent damage
occurs in the machine.
• Lencería (Lingerie)
You can use this programme to wash delicate garments that are suitable for hand wash and delicate women's
underwear. Small amount of garments must be washed in a washing net. Hooks, buttons etc. must be done up
and zips must be zipped up.
• Sport
You can use this programme to wash sports and outdoors garments that contain cotton/synthetics mix and
water repellent covers such as gore-tex etc. It makes sure your garments are washed gently thanks to special
rotating movements.
• Manchas PRO (StainExpert)
The machine has a special stain programme which enables the removal of different types of stains in the
most effective way. Use this programme only for durable colourfast cotton laundry. Do not wash delicate
and pigmenting clothes and laundry in this programme. Before washing, garment tags should be checked
(recommended for cotton shirts, trousers, shorts, t-shirts, baby clothes, pyjamas, aprons, table clothes,
beddings, duvet cover, bed sheet, pillowcase, bath-beach towel, towel, socks, cotton underwear that are
suitable for washing at high temperature and long time). In the automatic stain programme, you can wash
24 types of stains divided into two different groups according to fast+ function selection. You can see stain
groups based on the selection of the fast+ function.
You can find stain groups based on fast+ function below:
When Fast+ function is selected:
Blood Tea Red Wine
Chocolate Coffee Curry
Pudding Fruit juice Jam
Egg Ketchup Coal
When Fast+ function is not selected:
Butter Sweat Salad Dressing
Grass Collar Soil Make-up
Mud Food Machine Oil
Coke Mayonnaise Baby Food
• Select the stain programme.
• Select the stain you want to clean by locating it in the groups above and selecting the related group with the
fast+ auxiliary function key.
• Read the garment tag carefully and ensure that correct temperature and spin speed are selected.

18 / EN Washing Machine / User’s Manual
4.3.5 Temperature selection
Whenever a new programme is selected, the recommended temperature for the selected programme appears
on the temperature indicator.
To decrease the temperature, press the Temperature Adjustment button. Temperature will decrease gradually.
Temperature level lights will not turn on when the cold level is selected.
CIf the programme has not reached the heating step, you can change the temperature without switching the product to Pause
mode.
4.3.6 Spin speed selection
Whenever a new programme is selected, the recommended spin speed of the selected programme is
displayed on the spin speed indicator.
To decrease the spin speed, press the Spin Speed Adjustment button. Spin speed decreases gradually.
Then, depending on the model of the product, "Rinse Hold" and "No Spin" options appear on the display.
When "No Spin" is selected, the rinse level indicator lights will not turn on.
CIf the programme has not reached the spinning step, you can change the spinning speed without switching the product to
Pause mode.
Rinse hold
If you are not going to unload your clothes immediately after the programme completes, you can use rinse
hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled
when there is no water in the product. Press Start/Pause button after this process if you want to drain the
water without spinning your laundry. Programme will resume and complete after draining the water.
If you want to spin the laundry held in water, adjust the spin speed and press Start / Pause button. The
programme will resume. Water is drained, laundry is spun and the programme is completed.
4.3.7 Auxiliary function selection
Select the desired auxiliary functions before starting the programme.
Chosen auxiliary function indicator lights up.

19 / EN
Washing Machine / User’s Manual
CWhen you try to change an auxiliary function that is not allowed to be selected with the current programme, indicator light
of the relevant auxiliary function will flash and an audio warning is given.
Furthermore, you may also select or cancel auxiliary functions that are suitable to the running programme after the washing cycle
starts. If the wash cycle has reached a point where no auxiliary function can be selected, an audio warning will be given and the
related auxiliary function's light will flash.
CSome functions cannot be selected together. If a second auxiliary function conflicting with the first one is selected before
starting the product, the function selected first will be canceled and the second auxiliary function selection will remain active.
An auxiliary function that is not compatible with the programme cannot be selected. (See, "Programme and consumption
table".)
Some programmes have auxiliary functions that must be operated simultaneously. Those functions cannot be cancelled. The
frame of the auxiliary function will not be illuminated, only inner area will be illuminated.
4.3.7.1 Auxiliary functions
• Prewash
A Prewash is only worthwhile for heavily soiled laundry. Not using the Prewash will save energy, water,
detergent and time.
• Fast+
When this function is selected, the durations of the relevant programmes get shorter by 50%.
Thanks to the optimised washing steps, high mechanic activity and optimum water consumption,
high washing performance is achieved in spite of the reduced duration.
• Pet Hair Removal
This function helps to remove pet hair that remain on your garments more effectively.
When you select this function, Prewash and Extra Rinse steps are added to the normal programme. Thus,
washing is performed with more water and the pet hair is removed more effectively.
4.3.7.2 Functions/Programs selected by pressing the key for 3”
• Drum Cleaning
Press and hold the 1st auxiliary function key for 3 seconds to select the programme.
Use regularly (once in every 1-2 months) to clean the drum and provide the required hygiene. Operate the
programme while the machine is completely empty. To obtain better results, put powder lime-scale remover
for washing machines into the detergent compartment no. “2”. When the programme is over, leave the loading
door ajar so that the inside of the machine gets dry.
CThis is not a washing programme. It is a maintenance programme.
Do not run the programme when there is something in the machine. If you try to do so, the machine detects that there is
load inside and aborts the programme.
• Child Lock
Use Child Lock function to prevent children from tampering with the product. Thus you can avoid any changes
in a running programme.

20 / EN Washing Machine / User’s Manual
CYou can switch on and off the product with On / Off button when the Child Lock is active. When you switch on the product
again, programme will resume from where it has stopped.
To activate the Child Lock:
Press and hold 2nd auxiliary function button for 3 seconds. In the programme selection display on the
panel, „CL 3-2-1 On“ light will turn on. When this light is on you can stop pressing on 2nd when this warning
is displayed.
To deactivate the Child Lock:
Press and hold 2nd Auxiliary Function button for 3 seconds. In the programme selection display on the
panel, „CL 3-2-1 Off“ light will turn on.
• AntiCrease+
This function is selected when the 3rd auxiliary function is pressed and held for 3 seconds and the
programme follow-up light for the relevant step turns on. When the function is selected, the drum rotates
for up to 8 hours for preventing the laundry from creasing at the end of the programme. You can cancel the
programme and take your laundry out at any time during the 8-hour duration. Press the function selection
key or the machine on/off key to cancel the function. The programme follow-up light will remain on until the
function is canceled or the step is complete. If the function is not cancelled, it will be active in the subsequent
washing cycles as well.
4.3.8 End Time
With the End Time function, the startup of the programme may be delayed up to 24 hours. After pressing
End Time button, the programme's estimated ending time is displayed. If the End Time is adjusted, End Time
indicator is illuminated.
1 Open the loading door, place the laundry and put detergent, etc.
2 Select the washing programme, temperature, spin speed and, if required, the auxiliary functions.
3 Set the end time of your choice by pressing the End Time button. End Time indicator illuminates.
4 Press Start / Pause button. Time countdown starts. “:” symbol in the middle of the end time on the display
starts flashing.
Adjusting the end time
If you want to cancel End Time function, press On / Off button to turn off and on the product.
CDo not use liquid detergents when you activate End Time function! There is the risk of staining of the clothes.
CYou must press Start/Pause and wait for the door to open to add laundry into the machine during the End Time countdown.
Press Start/Pause once again after adding the laundry to resume the countdown. At the end of the countdown, End Time
indicator turns off, washing cycle starts and the time of the selected programme appears on the display.
When the End Time selection is completed, the time appears on the screen is the total of the end time chosen with the
duration of the selected programme.
4.3.9 Starting the programme
1. Press Start / Pause button to start the programme.
2. Programme follow-up light showing the startup of the programme will turn on.
CIf no programme is started or no key is pressed within 10 minute during programme selection process, the product will turn
off automatically. Display and all indicators will turn off.
If you press on the On / Off button, the programme information set as default will be displayed.
