BelFone BF-TR85900 User manual

1
Notice to the user
Government law prohibits the operation of unlicensed radio transmitters within
the territories under government control.
Illegal operation is punishable by fine or imprisonment or both.
Acknowledgement
Thank you for choosing BelFone series professional radio communication
products!
Since 1989, BelFone has been dedicating to research and exploration in radio
communication technology, and has developed leading smart technologies in
the industry. Underpinned by research, development and design geared
towards modern complicated and changeable communication environment, it
is capable of tailoring specific communication solutions to your needs based
on features of your industry. Superior products with outstanding performance
may help you control the overall situation, while providing you with the best
choice for smart scheduling dispatching and communicating.
This User Manual is applicable to:
BF-TR8500 Series all frequency band
Fujian BelFone Communications Technology Co.,Ltd
ADD：A-15 Huaqiao Economic Development Zone，Shuangyang，Luojiang，
Quanzhou，Fujian，China

2
Instructions befone Use
Following the safety precautions below may prevent damage to this product
and personal injuries. To avoid potential risks, please read these instructions
carefully before using the product, and operate the product as instructed.
◆The repeater shall be protected from long-time direct exposure to the sun,
kept in a place away from high temperature, high humidity, high dustiness or
water splashes, and put on a stable surface;
◆Where use of the repeater is prohibited or use of intercommunication may
cause interference or danger, the repeater shall have its power turned off as
required by relevant regulations;
◆If you find any fault of the product, please turn off the power directly, and
then contact the local distributor of BelFone; unless otherwise specified in this
Manual, maintenance should only be performed by any person other than a
maintenance worker authorized by BelFone Company;
◆ If this product is needed for further development, please contact BelFone
Company or BelFone's distributor;
◆Keep the product surface clean and dry; for cleaning, use a piece of soft
cloth dipped with mild detergent or clear water (without water dripping) to wipe
the product surface.

3
Contents
UnpackingandDeviceInspection.............................................................................................4
StandardAccessory...............................................................................................................4
OptionalAccessory................................................................................................................4
Features.....................................................................................................................................5
GetFamiliarwiththeDevice.....................................................................................................6
FrontPanelView...................................................................................................................6
IndicatorStatus.....................................................................................................................6
BackPanelview.....................................................................................................................7
BasicOperations........................................................................................................................8
Poweron/off.........................................................................................................................8
ButtonConfiguration.............................................................................................................8
Functionsandoperationinstructions.....................................................................................11
DigitalMode........................................................................................................................11
Back‐to‐BackFunction.........................................................................................................14
SimulcastFunction..............................................................................................................15
TechnicalSpecifications...........................................................................................................15
Statement................................................................................................................................16

4
Unpacking and Device Inspection
Note: The following instructions regarding unpacking are only for BelFone’s distributors,
and service agencies or factories authorized by BelFone.
Please carefully unpacking the box. Strongly recommend to count the
accessories against the following list before discarding the packaging. If you
find any item is missing or damaged, please contact the local distributor of
BelFone or directly contact BelFone Communication immediately.
Standard Accessory
Item Quantity
Main Equipment 1
Power Cable 1
Operation Manual 1
Warranty Card 1
Conformity Certificate 1
Optional Accessory
Item Quantity
Duplexer 1
DC Power Cable 1
Positioning Antenna 1
programming Cable 1

5
Features
Digital Repeater Function
Support customization, work with BelFone Intelligent IP interconnection
system
Support customization, IP Multi-site Connect
Support customization, work as Simulcast Base Station
Over voltage, over temperature alarm and protection
Switching High, Middle and Low TX power.

G
Fr
o
①
②
③
④
In
d
A
No
r
et Fa
m
o
nt Pa
n
A Indica
t
state in
d
B Indic
a
state in
d
USB Po
r
d
icator
LED
Indicator
r
mally on
m
iliar
n
el Vie
w
LC
D
t
or: Times
l
d
ication
a
tor: Time
s
d
ication
r
t
Status
Indication
B In
d
with
t
w
D
l
ot 1 worki
n
s
lot 2 wo
r
d
icator
/
t
he D
e
⑤
n
g ⑥
r
king ⑦
⑧
LCD Di
Channel
N
e
vice
P1: Shor
t
channel
n
display I
P
(progra
m
P2: Shor
t
channel
n
display v
(progra
m
P3: Shor
t
frequenc
y
IP intern
e
(progra
m
P4: Shor
t
frequenc
y
IP interc
o
(progra
m
splay
N
umbe
r
T
t
press to
d
n
umbe
r
, l
o
P
address;
m
ming sup
p
t
press to
i
n
umbe
r
, l
o
ersion
m
ming sup
p
t
press to
d
y
, long pr
e
e
t site typ
e
m
ming sup
p
t
press to
d
y
, long pr
e
o
nnection
s
m
ming sup
p
Devi
T
imeslot 1
d
ecrease
t
o
ng press
t
p
orted)
i
ncrease t
h
o
ng press
t
p
orted)
d
isplay T
X
e
ss to disp
l
e
;
p
orted)
d
isplay R
X
e
ss to disp
l
s
tatus.
p
orted)
ce State
emission
6
t
he
t
o
h
e
t
o
X
l
ay
X
l
ay

in
o
Gr
e
flic
k
Or
a
fli
c
Or
a
fli
c
Or
a
flic
k
Or
a
flic
k
B
a
⑨
o
range
e
en light
k
ers (1s)
/
/
a
nge light
c
kers (1s)
a
nge light
c
kers (1s)
a
nge light
k
ers (1s)
a
nge light
k
ers (1s)
/
/
/
a
ck Pan
Power
S
Normall
y
orange
Flashin
g
(1s)
Green li
flashes
(0.5s)
Red lig
h
quickly
(
Red lig
h
slowly (
2
Green li
flickers
s
(2s)
el view
S
witch
/
y
on in
g
in red
ght
quickly
h
t flickers
(
0.5s)
h
t flickers
2
s)
ght
s
lowly
/
/
/
Channel
N
Channel
N
Channel
N
E0
E1
E2
E3
E4
E5
E6
⑭
N
umbe
r
N
umbe
r
T
N
umbe
r
P
a
P
a
E
E
E
t
F
T
u
a
ACC Ac
c
T
imeslot 2
P
LL recei
v
a
bnormalit
P
LL trans
m
a
bnormalit
E
xcessivel
E
xcessivel
E
xcessivel
t
emperatu
r
F
an worki
n
T
he netwo
u
nconnect
e
a
bnormal
c
essory U
n
emission
v
ing
t
y
m
itting
t
y
l
y high vol
t
l
y low volt
a
l
y high
r
e
n
g abnorm
rk is
ed or
n
it Port
7
t
age
a
ge
ality
/
/

8
⑩ AC Power Input Port ⑮ RX RF Input Port
⑫ DC Power Input Port ⑯ TX RF Output Port
⑬ Network Port
Basic Operations
Power on/off
Press the [power switch] on the back of the repeater, the screen will light up
and the LCD will display the channel number; and press the [power switch]
again, the screen will go dark and the device is shut down.
Button Configuration
Use the programming software to configure P1~P4 key, while corresponding
the P1,P2,P3,P4 key to short pressing and holding-down operations.
Programmable buttons include the following functions:
1. Undefined: No function is assigned to the programmable button;
2. Power Switch: Press it to quickly switch the transmitting power: Low, Meddle,
High, user-defined, when switching to high power, the LCD will display icon:
; when switching to meddle power, the LCD will display icon: , when
switching to low power, the LCD will display icon: , when switching to
Self-Defined power, the LCD will display icon: ;

9
3. Low Power: Press this button to switch to lower power, the LCD will display
icon: ;
4. Middle Power: Press this button to switch to medium power, the LCD will
display icon:
5. High Power: Press this button to switch to high power, the LCD will display
icon:
6. Self-Define Power: Press this button to switch to a Self-Defined power, the
LCD will display icon: ;
7. Tone Alerts: Press this button to turn on or off the prompt tone, when turn on
the prompt tone, the LCD will show the following icon: , when turn off
the prompt tone, the LCD will show the following icon: ;
8. Channel+：Press this button to switch the channel - the channel number will
progressively increase
9. Channel-：Press this button to switch the channel - the channel number will
progressively decrease
10. Back-to-Back Switch：Press this button to turn on/off the back-to-back
switch, when turn on the Back-to-Back, the LCD will show the following icon:
, when turn off the Back-to-Back, the LCD will show the following icon:
;
11. Satellite Positioning Switch: Press this button to turn on/off the position
switch, when turn on the satellite positioning, the LCD will show the following
icon: , when turn off the satellite positioning, the LCD will show the

10
following icon: ;
12. Display Version: Press this button to view the version, the LCD will scroll
show the version number;
13. Display IP Address: Press this button to view IP address, the LCD will
scroll show the IP address;
14. Display IP internet site type: Press this button to view the IP internet site
type, if the connection type is None, the LCD show the icon: - ; if the
connection type is: Peer, the LCD show the icon: - ; if the connection type is:
Backup Main Site, the LCD show the icon: - ; if the connection type is: Home
Station, the LCD show the icon: - .
15. Display IP interconnection status: Press this button to view the IP
interconnection status, if the interconnection function disable, the LCD show
the icon: - , if the connection type is Home Station, the LCD show the
number of connected slave repeater; if the connection type is Backup main site,
the LCD show the icon:- .
16. Display TX Frequency: Press this button to view TX Frequency of current
channel;
17. Display RX Frequency: Press this button to view RX Frequency of current
channel;
18. Squelch Adjustment -: Press this button to adjust squelch level, the LCD
show the squelch level of current channel, and then press again the value
progressively increase;

11
19. Squelch Adjustment +: Press this button to adjust squelch level, the LCD
show the squelch level of current channel, and then press again the value
progressively decrease.
Note: While the LCD scroll shows the values and last digit will show repeatedly.
Functions and operation instructions
Digital Mode
1. Digital Repeater Mode
In the repeater mode, if the repeater is transmitting in timeslot 1, indicator A
will glow orange, and if the repeater is transmitting in timeslot 2, indicator B will
glow orange.
2. IP Interconnection Mode
Digital mode supports IP multi-site connection, and may realize
interconnection between IP sites of multiple repeaters. When programming
software is used to configure network services with one master repeater and
multiple slave repeaters, it is required to configure a timeslot to the IP
interconnection mode, so that after the network is connected, services may be
transmitted from one repeater to the other repeaters.
Network Setting
Connection Type
Connection type Function

12
None IP interconnection function is disabled
Peer Set to slave (registration of the master repeater
required)
Master Station Set to master (waiting for slave repeater registration)
Master Repeater
Backup
A type of slave repeater that will automatically become a
master repeater when the master repeater fails.
Master Station:
In IP multi-site connect system, it is permitted to configure only one master
repeater, while other repeaters shall be configured as slave repeater, with IP
addresses registered with the master repeater for IP interconnection.
Backup Master Repeater:
The backup master repeater is a slave repeater. In a system, it is permitted to
configure a backup master repeater, which in normal operating conditions is
the same with other slave repeaters. Only when the master repeater fails and
cannot be connected, the backup master repeater will act to play the role of a
master repeater in lieu of the original master repeater for registration of other
slave repeaters.
Peer:
The peer is a slave repeater, in a system, it is permitted to configure multiple
slave repeaters. Upon programming software, it is required to configure slave
repeaters, the backup master repeater and the current repeater’s IP address
for successful registration with the master repeater.

13
Authorization Code: Peers should have consistent authorization codes with the
master repeater for successful registration. For an authorization code, it is
allowed to enter a maximum of 16 digits and letters from 0~9 and A~F; it can
be null if nothing is entered.
DHCP: When a peer is set to DHCP, the router will act as the DHCP server
and automatically assign one IP address to the peer.
(The router shall support DHCP, and the IP address assigned should be within
the same network segment of the master repeater’s IP).
● When the current repeater is connected as a master repeater, it is required
to configure its IP, UDP port, gateway IP, network mask, NDS server IP, UDP
port;
● When the current repeater is connected as a backup master repeater, it is
required to configure its IP, UDP port, gateway IP, network mask, DNS server
IP, UDP port and master repeater IP, master repeater UDP port;
● When the current repeater is connected as an peer, it is required to
configure its IP, UDP port, gateway IP, network mask, DNS server IP, UDP
port and master repeater IP, master repeater UDP port, backup master
repeater IP, backup master repeater UDP port.
Note: In one system, only one “master repeater” and one “backup master repeater” are
permitted; other repeaters shall be configured as “peers”.
The function is optional.
3. System Networking Function

14
The repeater can be connected to BelFone intelligent interconnection system
(SDC), and supports access to the system network for repeating DMR digital
voice and data services, so as to realize interconnected communication in the
networked mode.
Note: System networking is optional.
Back-to-Back Function
The repeater supports the back-to-back function to realize back-to-back
connection between a single repeater and other device for repeating voice.
The current device supports back-to-back connection of digital channels.
The back-to-back function can be set via the programming software or the
preprogrammed [Back to back Switch] key.

15
Simulcast Function
The repeater supports Simulcast function. When the Simulcast function is
enabled, the repeater can be registered as a peer with the base station
controller of BelFone intelligent interconnection system to realize Simulcast
networking.
Note: Simulcast function is optional.
Technical Specifications
General
Frequency Range 400-480MHz
Channel Spacing 12.5KHz
Antenna Impedance 50Ω
Master Power Supply 85~264VAC， 47-63Hz
3A/115VAC,1.7A/230VAC
Backup Power Supply 11-13.8VDC，9A
Current Consumption < 9A
Operating Environment -30℃～+70℃
Storage Temperature -40℃～+85℃
Sizes 441mm(L)*327.5 mm(W)* 88(H)
Weight
3.5dBi
Emission
RF Power 5-20W（Continuous Emission）
Frequency Stability ≤±0.5ppm（Without Positioning）
Maximum antenna gain
11.8Kg

16
≤±0.02ppm（With Positioning）
4FSK Digital Modulation 12.5KHz only data：7K60F1D
12.5KHz data and voice：7K60F1E
Power of Adjacent Channel ≤60dB
Spurious Emission -36dBm<1GHz
-30dBm>1GHz
Receiving
Sensitivity 3%BER≤0.35µV
Frequency Stability ≤±0.5ppm（Without Positioning）
≤±0.02ppm（With Positioning）
Adjacent Channel Selectivity ≥60dB
Intermodulation Immunity ≥70dB
Spurious Response ≥70dB
Blocking ≥95dB
Statement
To the best of our knowledge, this Manual has been prepared in an accurate
and complete manner. For any doubt, please contact us timely for specific
explanation. Considering the fast development of wireless communication
technology, BelFone reserves the right to modify the product design and
specification without any further notification. Your understanding in this respect
will be much appreciated!

FCC Caution:
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
IMPORTANT NOTE:
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Operational Instruction and Training Guidelines:
To ensure optimal performance and compliance with the occupational/controlled environment
RF energy exposure limits in the above standards and guidelines, users should transmit not
more than 50% of the time and always adhere to the following procedures:
Antenna gain must not exceed 3.5dBi.
The antenna must be installed complying with the requirements of manufacturer or supplier,
and it must be at least 55cm away from human body.
