Thank you for purchasing the Belkin Bluetooth Hands-Free HeadSet. The Belkin Hands-Free Headset brings the Bluetooth™ revolution to your mobile phone. It utilises Bluetooth v1.1 technology to give you the advantage of hands- free communication through your mobile phone, with the extra freedom of a wireless connection! Now you can make and receive calls with the simple touch of a button—without ever touching your mobile phone. Simply activate calls with a touch of the answer/end button on your earpiece.
1
INTRODUCTION
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Overview
Important information for safe use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Controls and functions/sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Instuctions
Wearing the headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Preparing the headset for use – pairing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Product information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
TABLE OF CONTENTS
P74481uk_F8T063_manual.qxd 18-12-2003 10:56 Page 2

II. Controls and functions/sounds Keypad • One multifunction push button to switch the headset on/off, to select pairing mode or to
initiate/answer/end a call
• Two push buttons to control volume up/down LED Indicators Green LED
• Continuous – Headset on • Flashing – Headset in Standby
mode (waiting for call)
Red LED
• Continuous – Battery is low, recharge battery
Green and Red LED
• Flashing – Headset in pairing mode. • Waiting for phone to initiate pairing
For pairing instructions please see page 5 3
OVERVIEW
I. Important information for safe use Driving Before using, please check with local authorities, the rules and regulations affecting the use of hands-free devices. Only use the Belkin Bluetooth headset where and when it is safe to do so.
2
OVERVIEW
Multifunction push button
Volume +
Green LED indicator
Ear Hook
Volume –
Red LED indicator
P74481uk_F8T063_manual.qxd 18-12-2003 10:56 Page 2

Preparing the headset for use Before the headset can communicate, it must be paired with your phone. This is to ensure that the headset operated only with your chosen device and not any other Bluetooth device within range. • Pairing information is stored by the headset and can be changed at any time • Pairing need only be done once • A PIN Code is required for pairing. The PIN code for the headset is preset to 1234; The exact process to pair the headset will also depend on the device it is being paired with. The user manual for that device will give instructions on hoe to do this. In all cases, the headset will need to be put into PAIRING mode, which is described here. 1. Ensure the headset is switched OFF 2. Press and hold the Multifunction button for 4 seconds (or until the red & green flash in turn).
A short beep will also be heard
3. The headset is now ready to be paired
5
INSTRUCTIONS
Wearing the headset • The headset can be worn on either ear, by changing the orientation of the ear hook. • To remove the ear hook, carefully align the notches/slots and pull away from the headset • To place on the ear, hold the headset in the hand and push the open end of the hook slightly away
from the headset body
• The headset can also be worn in conjunction with glasses. First fit the headset, then your glasses.
4
INSTRUCTIONS
P74481uk_F8T063_manual.qxd 18-12-2003 10:56 Page 4

Switching the headset on and off • Switching ON – Press the Multifunction button for 2 seconds. A low-high tone and flashing GREEN LED
indicates the headset is switched ON
• Switching OFF – Press the Multifunction button for 2 seconds. A high-low tone indicates the headset is
switched OFF
Answering/Terminating calls • When your phone receives a call, the phone ring tone will be heard in the headset. Pressing the
Multifunction button ONCE will answer the call. Pressing the Multifunction button again terminates the call
Making a call (voice dialling*) • Press the Multifunction button to activate voice dialling • Upon hearing a beep, say the name of the person you wish to call • Your phone will place the call automatically. In the event the phone does not recognise the your voice,
please repeat the steps above.
• Once connected, pressing the Multifunction again will terminate the call • If the desired number has no voice tag**, you will need to use the phone keypad to place the call
manually. Using this method, the call will automatically transfer to the headset. Pressing the Multifunction button will terminate the call
*Check your phone manual to see if this feature is supported **Please refer to your phone manual for information on creating voice tags 7
OPERATING INSTRUCTIONS
4. Follow the instructions for your mobile phone to pair it to the headset 5. When prompted by your phone, enter the PIN code for the headset (1234) 6. Once paired, the headset will automatically switch to STANDBY mode – Green LED will flash
continuously
7. Your headset and phone are now paired and ready for use
6
INSTRUCTIONS
P74481uk_F8T063_manual.qxd 18-12-2003 10:56 Page 6

Specifications • Compliant to Bluetooth 1.1V (Class II) • Operational Distance: Max 10 Metres • Talk time: Up to 3.5 Hours* • Standby time: Up to 100 Hours • Weight: 23g Package Includes • Belkin Hands-Free Headset • Charging Cradle • User Manual • Mains Charger *Talk time can vary depending on make and model of phone.
9
PRODUCT INFORMATION
If the headset stops operating, please try the following: • The battery may be flat. Ensure that it is fully charged by charging it for 5 hours • The headset may no longer be paired to the phone. Please repeat the pairing
process described in pages 5 and 6
LED indicator table
Led Colour Steady ON Alternate Flashing Steady OFF Red Switched OFF
and on charge or battery low OFF Mode
Green In use Off Mode Red&Green Pairing Mode OFF Mode
8
TROUBLESHOOTING
P74481uk_F8T063_manual.qxd 18-12-2003 10:56 Page 8

This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna. • Increase the distance between the equipment and the receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.
