Belkin NetMaster F8E204 User manual

Ca
Es
Po
En
P73134 F8E204
NetMaster™
Scroll Mouse
User Manual
Guide d’utilisation de la
souris NetMaster™avec
roulette de défilement
Manual de usuario para el
mouse NetMaster™con
rueda de desplazamiento
Mouse de Rolagem
NetMaster™- Manual
do Usuário

Table of Contents
Ca
Es
Po
En
English . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Français (Canada) . . . . . . . . . . . . . . . . . . 15
Español . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Português . . . . . . . . . . . . . . . . . . . . . . . . 43

ABOUT YOUR MOUSE
1.1 An Introduction to your new Belkin
NetMaster™Scroll Mouse
The Belkin NetMaster™Scroll Mouse offers you ease of use
on the Internet, eliminating the need for scroll bars. You can
scroll smoothly through your documents or Web Pages,
browsing them quicker and more efficiently. Imagine, with
the simple movement of the scroll wheel, you can glide
effortlessly through Web Pages and long documents, without
having to remove your pointer from the document itself.
Also, by eliminating this simple task, you can add to the
lifetime of your mouse by reducing natural wear and tear.
Not to mention the reduced tension on your wrist from
excessive, repetitive movement to the scrollbars. Internet
surfing couldn't be easier!
Once the software has been loaded onto your computer, the
center button of your mouse (the wheel) can be programmed
to perform the same tasks as:
"Left Button Double Click"
"F1" through "F12"
"Enter" Key
"Page Up" Key
"Page Down" Key
"Home" Key
"End" Key
These can be used in place of your scrolling options.
1. Introduction
1
En

2
1. Introduction (continued)
1.2 Connecting Your Mouse
Your mouse connects to either a PS/2 (or 6 pin MiniDIN) mouse
port or a 9-pin serial port. To check, look in the back of you
computer for the port that is designated for your mouse. Most
PCs will have the word MOUSE marked next to the PS/2
connector. Older PCs will have either Serial 1 (and up) or COM
1 (and up) for the serial connector. If you are still unsure, please
refer to your hardware manual.
For PS/2 mouse port installation, simply remove the serial
adapter before connecting the mouse cable to the computer.
a. Locate the computer PS/2 mouse port or Serial port on the
back of your computer.
b. Plug your mouse into the appropriate port suggested
above. Check the box in which your mouse was shipped to
verify the ports supported.
c. If applicable, tighten down the connector thumbscrews.
d. Turn your computer on. At this point, your mouse will work
with the built in Microsoft®Operating System. To use the
extra features of your middle button, you must install the
included software.

2. Software Installation
3
A step-by-step guide to getting your mouse set up
WARNING: To avoid damage, turn your computer off before
plugging or unplugging any pointing devices.
Windows®95, Windows®98 and Windows NT®
4.0 Installation
a. Insert the NetMaster™diskette in the A: or B: drive
b. Click on "Start" in the lower left corner of your screen
c. Then click on "Run"
d. Type "A:setup" (or "B:setup") and then click on "OK"
e. Follow the on-screen instructions to complete the
installation of the NetMaster™.
f. To make the process run smoothly:
1. Click on "Next" two times
2. Type in your name and the company's name, then click
on "Next"
3. Click on "Next" two more times
4. Specify if you are using a PS/2 or Serial mouse (refer to
section 1.2) then click on "OK"
5. Select "Yes, I want to restart my computer now" then
click on "Finish"
En

4
3. Troubleshooting
Q: When installing the software, which driver should I
choose? The PS/2 Mouse on COM1 or Serial Mouse
on COM2?
A: If you are using a PS/2 mouse (refer to section 1.2) then
the driver must state that it is using a PS/2 driver. If you
are using a Serial mouse (refer to section 1.2) then the
driver must state that it is using a Serial driver on COM1
or COM2.
Q: I can get into Windows®or into "Safe Mode" but I
cannot use the mouse.
A: If you have more than one driver, this could be causing
your computer to boot in safe mode or not allow your
mouse to work at all. If you are using a PS/2 mouse then
the driver must state that it is using a PS/2 driver. If you
are using a Serial mouse then the driver must state that it
is using a Serial driver on COM1 or COM2. If you have a
Serial Mouse and you are not sure whether you are using
COM1 or COM2 then try moving the mouse to another
serial port on the back of your computer, (most computers
have two, if you have only one then it will more than likely
be COM1). If you have more than one driver then you
must remove the excess drivers.
Q: If I have more than one mouse driver how do I remove
the driver without the mouse control? How do I boot
into normal Windows®mode?
A: Use your "Windows®"Key at the bottom left hand corner
of your keyboard if you have one; if not, press "Alt + S" to
go to the "Start" button in Windows®95. Then use your

5
En
3. Troubleshooting (continued)
"Up" Arrow to select "Settings" then use your "Right"
Arrow to select "Control Panel" and then press "Enter".
These steps have taken you to the "Control Panel"
where you can gain access to your "Device Manager".
The "Device Manager" shows your driver status
and information and it will allow you to modify
their settings.
After entering the "Control Panel" use your "Up" and
"Down" Arrows to select, "System" and then press
"Enter". After entering "System Properties" use your
"Right" Arrow to select "Device Manager". Then press
Tab until you have selected "Computer" and then use
the "Down" Arrow until your "Mouse" is highlighted.
Then use your "Right" Arrow to expand and select your
mouse driver or drivers.
After you have chosen your mouse driver you can now
modify it by removing the driver or changing the driver.
To remove the driver you have selected, use your "Tab"
key until the "Remove" tab is selected. Then press
"Enter". This will remove the driver. Use your "Arrows"
Key to select any other drivers and repeat the process
until all but one driver remains. Even if it is the wrong
driver you can use it and change it to the mouse driver
you want.
After removing or changing the mouse driver, use your
"Tab" key until "Close" is selected and then press
"Enter". Then you will have to reboot your computer.

6
3. Troubleshooting (continued)
Use your "Windows®"Key at the bottom left hand corner
of your keyboard if you have one; if not, press "Alt + S".
Then use the "Up" Arrow to select "Shut Down" and use
your "Enter" key. Use your "Arrow" Key to select
"Restart" and press "Enter".
Q: After installing the mouse driver and rebooting, my
mouse will not work. How do I change the mouse driver
without mouse control?
A: Use your "Windows®"Key at the bottom left hand corner
of your keyboard if you have one; if not, press "Alt + S" to
go to the "Start" button in Windows®95. Then use your
"Up" Arrow to select "Settings" then use your "Right"
Arrow to select "Control Panel" and then press "Enter".
These steps have taken you to the "Control Panel" where
you can gain access to your "Device Manager". The
"Device Manager" shows your driver status and
information and it will allow you to modify their settings.
After entering the "Control Panel" use the "Up" and
"Down" Arrows to select "System" and then press
"Enter". After entering "System Properties" use the
"Right Arrow" to select "Device Manager". Then press
"Tab" to bring your selection to "Computer" and then use
the "Down" Arrow until your "Mouse" is highlighted. Then
use your "Right" Arrow to expand and select your mouse
driver or drivers. After you select the mouse driver, use
your "Tab" key to select "Properties" and then press
"Enter". Use your "Right" Arrow key to choose the
"Driver" tab and then use your "Tab" key to choose

7
En
3. Troubleshooting (continued)
"Update driver" or "Change Driver" and then
press "Enter".
The next options will vary from computer to computer
because there are many types of Windows®95/98 OS
versions. The wording or options will be a little different
but should be somewhat the same.
Windows®will then continue to ask questions and help
guide you through the changes. Use your "Arrow" Keys,
"Enter", and "Tab" keys to continue through the
process. Windows“ may or may not start searching for
Plug-and-Play devices right away and it may or may not
find anything new. If it does not find anything new it will
ask you another line of questions and if it does find
something new choose something similar to "This
Device is not in the list".
Windows®will then ask if you want Windows®to search
for a new device or will ask if you want to select a driver
from a list. You will want to choose a device or driver
from a list. Use your "Arrow", "Tab" and "Enter" keys
to navigate and finish till the end of questioning. After
finishing, Windows®may or may not ask you to reboot
your computer. Yes, you will want to restart your
computer. If it does not ask you to restart your
computer you will have to close "System Properties".
Use the "Tab" key until "Close" is selected and then
press "Enter". Then you will have to reboot your
computer. Use your "Windows®"Key at the bottom left
hand corner of your keyboard if you have one; if not,

8
3. Troubleshooting (continued)
press "Alt + S". Then use the "Up" Arrow to select "Shut
Down" and use your "Enter" key. Use the "Arrow" Key to
select "Restart" and press "Enter".
Q: Why does my external mouse not work with my laptop
computer?
A: You may have to disable the onboard mouse in order to
use an external mouse. Try looking in your CMOS or BIOS
in order to disable the onboard mouse. If you do not have
this option or do not know how to get into your BIOS or
CMOS, please follow the instructions in your computer
manual or call the computer dealer/technical support for
your computer.
