Belkin F5D7234-4 v3 User manual

G Wireless Router
User Manual
PM01110-A F5D7234 -4
F5D7234-4 v3

i
G Wireless Router
SECTIONS 12345678910Table of Contents
TABLE OF CONTENTS
SecuringyourWi-FiNetwork................................49
WEPSetup ............................................52
UsingWi-FiProtectedSetup ..............................54
WPASetup.............................................55
SettingWPA/WPA2......................................56
GuestAccess ..........................................56
UsingtheAccessPointMode ...............................59
ConfiguringtheFirewall ....................................60
SettingMACAddressFiltering...............................63
EnablingtheDMZ.........................................64
UtilitiesTab ..............................................65
RestartingtheRouter......................................66
UpdatingtheFirmware.....................................69
7ManuallyConfiguringNetworkSettings ...................75
8RecommendedWebBrowserSettings ....................80
9Troubleshooting........................................82
10Information...........................................99
1Introduction ............................................1
BenefitsofaHomeNetwork..................................1
AdvantagesofaWirelessNetwork ............................1
PlacementofyourRouterforOptimalPerformance...............2
2ProductOverview .......................................5
ProductFeatures...........................................5
3 Knowing your Router ....................................7
Package Contents ..........................................7
SystemRequirements.......................................7
SetupAssistantSoftwareSystemRequirements.................7
4ConnectingandConfiguringyourRouter..................11
5AlternateSetupMethod.................................25
6UsingtheWeb-BasedAdvancedUserInterface ............40
ChangingLANSettings.....................................41
ViewingtheDHCPClientListPage...........................43
ConfiguringtheWirelessNetworkSettings.....................43

1
G Wireless Router
SECTIONSTable of Contents 23456789101
INTRODUCTION
Thank you for purchasing the Belkin G Wireless Router (the Router). The following two short sections discuss the benefits of home
networking and outline best practices for maximizing your wireless home network range and performance. Please be sure to
read through this User Manual completely, and pay special attention to the section entitled “Placement of your Router for Optimal
Performance” on page 2.
Advantages of a Wireless Network
Ř Mobility – you’ll no longer need a dedicated “computer
room”—now you can work on a networked laptop or desktop
computer anywhere within your wireless range
Ř Easy installation – The Belkin Setup Assistant software makes
setup simple
Ř Flexibility – set up and access printers, computers, and other
networking devices from anywhere in your home
Ř Easy expansion – the wide range of Belkin networking products
lets you expand your network to include devices such as printers
and gaming consoles
Ř No cabling required – you can spare the expense and hassle of
retrofitting Ethernet cabling throughout the home or office
Ř Widespread industry acceptance – choose from a wide range of
interoperable networking products
Ř Share one high-speed Internet connection with all the computers
in your home
Ř Share resources, such as files and hard drives among all the
connected computers in your home
Ř Share a single printer with the entire family
Ř Share documents, music, video, and digital pictures
Ř Store, retrieve, and copy files from one computer to another
Ř Simultaneously play games online, check Internet email, and chat
Benefits of a Home Network

2
G Wireless Router
SECTIONSTable of Contents 23456789101
INTRODUCTION
Ř Ensure that your Router’s networking antennas are parallel to each
other, and are positioned vertically (toward the ceiling). If your
Router itself is positioned vertically, point the antennas as much as
possible in an upward direction.
Ř In multistory homes, place the Router on a floor that is as close
to the center of the home as possible. This may mean placing the
Router on an upper floor.
Ř Try not to place the Router near a cordless phone.
2. Avoid Obstacles and Interference
Avoid placing your Router near devices that may emit radio “noise,”
such as microwave ovens. Dense objects that can inhibit wireless
communication include:
Ř Refrigerators
Ř Washers and/or dryers
Ř Metal cabinets
Ř Large aquariums
Ř Metallic-based, UV-tinted windows
If your wireless signal seems weak in some spots, make sure that
objects such as these are not blocking the signal’s path (between your
computers and Router).
Placement of your Router for Optimal Performance
Important Factors for Placement and Setup
Your wireless connection will be stronger the closer your computer is
to your Router. Typical indoor operating range for wireless devices is
between 100 and 200 feet.
In the same way, your wireless connection and performance will degrade
somewhat as the distance between your Router and connected devices
increases. This may or may not be noticeable to you. As you move
farther from your Router, connection speed may decrease. Factors that
can weaken signals simply by getting in the way of your network’s radio
waves are metal appliances or obstructions, and walls.
If you have concerns about your network’s performance that might be
related to range or obstruction factors, try moving the computer to a
position between five and 10 feet away from the Router in order to see if
distance is the problem. If difficulties persist even at close range, please
contact Belkin Technical Support.
Note: While some of the items listed below can affect network
performance, they will not prohibit your wireless network from
functioning; if you are concerned that your network is not operating at
its maximum effectiveness, this checklist may help.
1. Wireless Router Placement
Place your Router, the central connection point of your network, as
close as possible to the center of your wireless network devices.
To achieve the best wireless network coverage for your “wireless clients”
(i.e., computers enabled by Belkin Wireless Notebook Network Cards,
Wireless Desktop Network Cards, and Wireless USB Adapters):

3
G Wireless Router
SECTIONSTable of Contents 23456789101
INTRODUCTION
4. Choose the “Quietest” Channel for your Wireless Network
In locations where homes or offices are close together, such as
apartment buildings or office complexes, there may be wireless
networks nearby that can conflict with yours.
Use the Site Survey capabilities found in the wireless utility of your
wireless adapter or card to locate any other wireless networks that
are available (see your wireless adapter’s or card’s user manual), and
move your Router and computers to a channel as far away from other
networks as possible.
Ř Experiment with more than one of the available channels in
order to find the clearest connection and avoid interference from
neighboring cordless phones or other wireless devices.
Ř For Belkin wireless networking products, use the detailed Site
Survey and wireless channel information included with your
Wireless Network Card or Adapter. See your Network Card’s user
guide for more information.
These guidelines should allow you to cover the maximum possible area
with your Router. Should you need to cover an even wider area, we
suggest the Belkin Wireless G Universal Range Extender/Access Point.
3. Cordless Phones
If the performance of your wireless network is impaired after attending
to the above issues, and you have a cordless phone:
Ř Try moving cordless phones away from the Router and your
wireless-enabled computers.
Ř Unplug and remove the battery from any cordless phone
that operates on the 2.4GHz band (check the manufacturer’s
information). If this fixes the problem, your phone may
be interfering.
Ř If your phone supports channel selection, change the channel on
the phone to the farthest channel from your wireless network. For
example, change the phone to channel 1 and move your Router to
channel 11. See your phone’s user manual for detailed instructions.
Ř If necessary, consider switching to a 900MHz cordless phone.

4
G Wireless Router
SECTIONSTable of Contents 23456789101
INTRODUCTION
5. Secure Connections, VPNs, and AOL
Secure connections typically require a user name and password, and
are used where security is important. Secure connections include:
Ř Virtual Private Network (VPN) connections, often used to connect
remotely to an office network
Ř The “Bring Your Own Access” program from America Online (AOL),
which lets you use AOL through broadband provided by another
cable or DSL service
Ř Most online banking websites
Ř Many commercial websites that require a user name and password
to access your account
Secure connections can be interrupted by a computer’s power
management setting, which causes it to “go to sleep.” The easiest
solution to avoid this is to simply reconnect by rerunning the VPN or
AOL software, or by re-logging into the secure website.
A second alternative is to change your computer’s power management
settings so it does not go to sleep; however, this may not be appropriate
for portable computers. To change your power management setting
under Windows, see the “Power Options” item in the Control Panel.
If you continue to have difficulty with secure connections, VPNs, and
AOL, please review the steps above to be sure you have addressed
these issues.
For more information regarding our networking products, visit our
website at www.belkin.com/networking.

5
G Wireless Router
SECTIONSTable of Contents 1 345678910
PRODUCT OVERVIEW
2
Product Features
In minutes you will be able to share your Internet connection and
network your computers. The following is a list of features that make
your new Belkin G Wireless Router an ideal solution for your home or
small office network.
Works with Both PCs and Mac®Computers
The Router supports a variety of networking environments including
Mac OS®, 9.x, X v10.x, AppleTalk®, Linux®, Windows®98, Me, NT®,
2000, XP, Vista®, and others. All that is needed is an Internet browser
and a network adapter that supports TCP/IP (the standard language of
the Internet).
Front-Panel LED Display
Lighted LEDs on the front of the Router indicate which functions are in
operation. You’ll know at-a-glance whether your Router is connected to
the Internet. This feature eliminates the need for advanced software and
status-monitoring procedures.
Web-Based Advanced User Interface
You can set up the Router’s advanced functions easily through your web
browser, without having to install additional software onto the computer.
There are no disks to install or keep track of and, best of all, you can
make changes and perform setup functions from any computer on the
network quickly and easily.
NAT IP Address Sharing
Your Router employs Network Address Translation (NAT) to share the
single IP address assigned to you by your Internet Service Provider while
saving the cost of adding IP addresses to your Internet service account.
SPI Firewall
Your Router is equipped with a firewall that will protect your network
from a wide array of common hacker attacks including IP Spoofing, Land
Attack, Ping of Death (PoD), Denial of Service (DoS), IP with zero length,
Smurf Attack, TCP Null Scan, SYN flood, UDP flooding, Tear Drop
Attack, ICMP defect, RIP defect, and fragment flooding.
Integrated 10/100 4-Port Switch
The Router has a built-in, 4-port network switch to allow your wired
computers to share printers, data and MP3 files, digital photos, and
much more. The switch features automatic detection so it will adjust to
the speed of connected devices. The switch will transfer data between
computers and the Internet simultaneously without interrupting or
consuming resources.
Universal Plug-and-Play (UPnP) Compatibility
UPnP (Universal Plug-and-Play) is a technology that offers seamless
operation of voice messaging, video messaging, games, and other
applications that are UPnP-compliant.

6
G Wireless Router
SECTIONSTable of Contents 1 3456789102
PRODUCT OVERVIEW
Support for VPN Pass-Through
If you connect to your office network from home using a VPN
connection, your Router will allow your VPN-equipped computer to pass
through the Router and to your office network.
Built-In Dynamic Host Configuration Protocol (DHCP)
Built-In Dynamic Host Configuration Protocol (DHCP) on-board makes
for the easiest possible connection of a network. The DHCP server will
assign IP addresses to each computer automatically so there is no need
for a complicated networking setup.
Setup Assistant Software
The Setup Assistant Software takes the guesswork out of setting up
your Router. This automatic software determines your network settings
for you and sets up the Router for connection to your Internet Service
Provider (ISP). In a matter of minutes, your Wireless Router will be up
and running on the Internet.
NOTE: Setup Assistant Software is compatible with Windows 2000,
XP, Vista, and Mac OS X. If you are using another operating system,
the Wireless Router can be set up using the Alternate Setup Method
described in this User Manual (see page 25).
Integrated 802.11g Wireless Access Point
802.11g is an exciting new wireless technology that achieves data rates
up to 54Mbps, nearly five times faster than 802.11b.
MAC Address Filtering
For added security, you can set up a list of MAC addresses (unique
client identifiers) that are allowed access to your network. Every
computer has its own MAC address. Simply enter these MAC addresses
into a list using the Web-Based Advanced User Interface and you can
control access to your network.

7
G Wireless Router
SECTIONSTable of Contents 12 45678910
KNOWING YOUR ROUTER
3
Package Contents
Ř Belkin G Wireless Router
Ř Quick Installation Guide
Ř Belkin Setup Assistant Software CD with User Manual
Ř Belkin RJ45 Ethernet Networking Cable
Ř Power Supply
System Requirements
Ř Broadband Internet connection such as a cable or DSL modem
with RJ45 (Ethernet) connection
Ř At least one computer with an installed network interface adapter
Ř TCP/IP networking protocol installed on each computer
Ř RJ45 Ethernet networking cable
Ř Internet browser
Setup Assistant Software System Requirements
Ř A PC running Windows 2000, XP, or Vista, or a Mac computer
running Mac OS X v10.4 or v10.5
Ř Minimum 64MB RAM
Ř Internet browser
The Router has been designed to be placed on a desktop. All of the
cables exit from the rear of the Router for better organization and utility.
The LED indicators are easily visible on the front of the Router to provide
you with information about network activity and status.
(6)
(1)
(2)
(3)
(4)
(5)

8
G Wireless Router
SECTIONSTable of Contents 12 456789103
KNOWING YOUR ROUTER
3. Security/WPS LED
OFF Wireless security is OFF
Solid Green Wireless security is ON
Blinking Green WPS sync in progress
4. Wireless Network LED
OFF Wireless is OFF
Solid Green Wireless is ON
Blinking Green Indicates wireless activity
1. Modem LED
This LED lights in GREEN to indicate that your modem is connected
properly to the Router. It blinks rapidly when information is being sent
over the port between the Router and the modem.
OFF Not connected to the modem
Solid Green Connected to the modem
Blinking Green Router is connecting to the ISP/
indicates modem activity
2. Power LED
When you apply power to the Router or restart it, a short period of time
elapses while the Router boots up.
OFF Router is OFF
Solid Green Router is ready

9
G Wireless Router
SECTIONSTable of Contents 12 456789103
KNOWING YOUR ROUTER
5. Internet LED
This unique LED shows you when the Router is connected to the
Internet. When the light is OFF, the Router is NOT connected to the
Internet. When the light is blinking, the Router is attempting to connect
to the Internet. When the light is solid GREEN, the Router is connected
to the Internet. When using the “Disconnect after x minutes” feature,
this LED becomes extremely useful in monitoring the status of your
Router’s connection.
OFF Router is not connected to
the Internet
Blinking Green Router is attempting to connect
to the Internet
Solid Green Router is connected to
the Internet
6. Wired LEDs (1 – 2 – 3 – 4)
These LEDs are labeled 1–4 and correspond to the numbered ports on
the rear of the Router. When a computer is properly connected to one
of the wired computer ports on the rear of the Router, the LED will light.
GREEN means a 10/100Base-T device is connected. When information
is being sent over the port, the LED blinks rapidly.
OFF No device is linked to the port
Solid Green 10/100Base-T device connected
Blinking Green Port activity
(7)
(8)
(9)

10
G Wireless Router
SECTIONSTable of Contents 12 456789103
KNOWING YOUR ROUTER
7. Power Jack
Connect the included 9V DC power supply to this jack.
8. Connections to Computers (Wired Computer Ports) – Gray
Connect your wired (non-wireless) computers to these ports. These
ports are RJ45, 10/100 auto-negotiation, auto-uplinking ports for
standard UTP category 5 or 6 Ethernet cable. The ports are labeled 1
through 4. These ports correspond to the numbered LEDs on the front
of the Router.
9. Connection to Modem (Modem Port) – Yellow
This port is for connection to your cable or DSL modem. Use the cable
that was provided with the Router to connect the modem to this port.
Use of a cable other than the cable supplied with the Router may not
work properly.
10. Reset Button
The “Reset” button is used in rare cases when the Router may function
improperly. Resetting the Router will restore the Router’s normal
operation while maintaining the programmed settings. You can also
restore the factory default settings by using the “Reset” button. Use
the restore option in instances where you may have forgotten your
custom password.
a. Resetting the Router
Push and release the “Reset” button. The lights on the Router will
momentarily flash. The reset is complete in 60 seconds.
b. Restoring the Factory Defaults
Press and hold the “Reset” button for at least 10 seconds, then release
it. The lights on the Router will momentarily flash. The restore is
complete in 60 seconds.

11
G Wireless Router
SECTIONSTable of Contents 123 5678910
CONNECTING AND CONFIGURING YOUR ROUTER
4
Verify the contents of your box. You should have the following:
Ř Belkin G Wireless Router
Ř Quick Installation Guide
Ř Belkin Setup Assistant Software CD with User Manual
Ř RJ45 Ethernet Networking Cable (for connection of the Router to
the modem)
Ř Power Supply
Modem Requirements
Your cable or DSL modem must be equipped with an RJ45 Ethernet
port. Many modems have both an RJ45 Ethernet port and a USB
connection. If you have a modem with both Ethernet and USB, and are
using the USB connection at this time, you will be instructed to use the
RJ45 Ethernet port during the installation procedure. If your modem has
only a USB port, you can request a different type of modem from your
ISP, or you can, in some cases, purchase a modem that has an RJ45
Ethernet port on it.
Setup Assistant
Belkin has provided our Setup Assistant software to make installing your
Router a simple and easy task. You can use it to get your Router up and
running in minutes. The Setup Assistant requires that your Windows
2000/XP, Vista, or Mac OS X v10.4 or v10.5 computer be connected
directly to your cable or DSL modem and that the Internet connection is
active and working at the time of installation. If it is not, you must use
the “Alternate Setup Method” section of this User Manual to configure
your Router. Additionally, if you are using an operating system other
than Windows 2000/XP, Vista, or Mac OS X v10.4 or v10.5, you must
set up the Router using the “Alternate Setup Method” section of this
User Manual.
ALWAYS INSTALL YOUR ROUTER FIRST! If you are installing
numerous network devices for the first time, it is important that your
Router is connected and running before attempting to install other
network components such as notebook cards and desktop cards.

12
G Wireless Router
SECTIONSTable of Contents 123 56789104
CONNECTING AND CONFIGURING YOUR ROUTER
Step 1: Hardware Connections
A. Unplug your modem’s power cord. Put the Router next to the
modem. Raise the Router’s antenna.
B. Locate the networking cable that connects your modem and
computer. Unplug that cable from your modem, and plug it into any
gray port on the back of the Router.
C. Find your new networking cable (included in the box with your
Router) and connect it to the yellow port on the back of the Router.
Connect the other end to your modem, in the port that’s now free.
D. Plug in your modem’s power cord. Wait 60 seconds for the modem
to start up. Plug the Router’s power supply into the black port on
the back. Plug the other end into the wall outlet.
E. Wait 20 seconds for the
Router to start up. Look
at the display on the front
of the Router. Make sure
the “Wired” and “Power”
icons are lit up in green.
If they are not, recheck
your connections.
LAN
WAN








13
G Wireless Router
SECTIONSTable of Contents 123 56789104
CONNECTING AND CONFIGURING YOUR ROUTER
Note for Windows Users: If the Setup Assistant does not start
up automatically, select your CD-ROM drive from “My Computer”
and double-click on the file named “SetupAssistant” to start the
Setup Assistant.
Step 2: Set Up the Router – Run the Setup Assistant Software
A. Shut down any programs that are running on your computer at this
time. Turn off any firewall or Internet-connection-sharing software
on your computer.
B. Insert the CD into your computer. The Setup Assistant will
automatically appear on your computer’s screen within 15
seconds. Click on “Go” to run the Setup Assistant. Follow the
instructions there.
IMPORTANT: Run the Setup Assistant from the computer that is
directly connected to the Router from Step 1.B.

14
G Wireless Router
SECTIONSTable of Contents 123 56789104
CONNECTING AND CONFIGURING YOUR ROUTER
Confirmation Screen
Verify that you have completed all QIG steps by checking the box to the
right of the arrow. Click “Next” to continue.
Select Country
Select your country from the drop-down box. Click “Begin” to continue.

15
G Wireless Router
SECTIONSTable of Contents 123 56789104
CONNECTING AND CONFIGURING YOUR ROUTER
2.1 Checking Settings
The Setup Assistant will now examine your computer’s network settings
and gather information needed to complete the Router’s connection to
the Internet.
Progress Screen
Setup Assistant will show you a progress screen each time a step in the
setup has been completed.

16
G Wireless Router
SECTIONSTable of Contents 123 56789104
CONNECTING AND CONFIGURING YOUR ROUTER
2.3 Naming your Wireless Network
The Setup Assistant will display the default wireless network name or
Service Set Identifier (SSID). This is the name of your wireless network
to which your computers or devices with wireless network adapters
will connect. You can either use the default or change it to something
unique. Write down this name for future reference.
2.2 Verifying Hardware Connections
The Setup Assistant will now verify your hardware connection.

17
G Wireless Router
SECTIONSTable of Contents 123 56789104
CONNECTING AND CONFIGURING YOUR ROUTER
If your Internet account requires a login and password, you will be
prompted with a screen similar to the illustration below. Click “Next”
to continue.
2.4 Requesting Internet Account Info (if needed)
Select your ISP from the drop-down boxes.

18
G Wireless Router
SECTIONSTable of Contents 123 56789104
CONNECTING AND CONFIGURING YOUR ROUTER
2.5 Configuring the Router
The Setup Assistant will now configure your Router by sending data to
the Router and restarting it. Wait for the on-screen instructions.
Note: Do not disconnect any cable or power off the Router while the
Router is rebooting. Doing so will render your Router inoperable.
2.6 Checking Internet Connection
We are almost done. The Setup Assistant will now check your
connection to the Internet.
