Belkin USB 4-Port Plus Hub User manual

Introduction
User Manual
USB 4-Port Plus Hub

Table of Contents
Introduction
Features .........................................................................................................................................1
Package Contents.....................................................................................................................2
Technical Specifications........................................................................................................2
Installation...........................................................................................................................................3
Information .........................................................................................................................................5

Introduction
Introduction | 01
Congratulations and thank you for purchasing the Belkin USB Plus Hub. The Hub
provides four downstream USB ports that offer backward-compatible, Plug-and-Play
connectivity with all USB devices, including USB 1.1 (or low- and full-speed) devices, as
well as with USB 2.0 (or high-speed) devices. This includes such peripherals as scanners,
printers, mass-storage devices, and high-resolution cameras. The Hub is self-powered,
which allows you to cascade devices with additional hubs, so that up to 127 USB devices
may be connected to a single port.
The Hub lets you connect your peripherals through the back or top ports. Reserve the
top ports for flash drives and MP3 players while using the back ports for stationary
devices. The cable-management feature lets you easily remember which cables
correspond to each device. The Hub also provides a status LED for each individual port
and a master power LED.
Features
• Compliant with Universal Serial Bus specification 2.0 (data rate 1.5/12/480Mbps)
• Backward-compatible with Universal Serial Bus specification 1.1 (data rate
1.5/12Mbps)
• Compatible with Windows® 98 SE, Me, 2000, XP, and Vista™
• Approved by USB Implementers Forum (USB-IF)
• Support for Plug-and-Play specifications
• Support for “hot swapping” of USB devices
• Individual port-status-indicator LEDs
• Four 480Mbps downstream ports
• Fully compatible with USB 1.1 and USB 2.0 devices
• Cord-management feature keeps cables organized in one location

Package Contents
• USB Plus Hub
• AC Power Adapter
• User Manual
• USB Device Cable
Technical Specifications
Upstream Ports: 1
Downstream Ports: 4
Per-Port Voltage: DC +5V
Per-Port Current: 500mA (max) (self-powered mode)
Power Mode: Self-powered/bus-powered
Operating Temperature: 5° C ~ 40° C
Storage Temperature: -20° C ~ 60° C
Enclosure: ABS
Power Supply:
Output: DC 5V, 2.6A
Plug Size: 3.5mm (outer)
1.0mm (center)
Plug Polarity: Center-pin positive
Main-Power-LED Color Definitions
Off: Not operational
Amber: Operational
Port-Status-LED Color Definitions
Off: Not operational
Green: Fully operational
Introduction | 02
Introduction

Installation | 03
Important Note: Please do not connect any USB devices to the Hub until instructed to
do so in step 4 of this installation procedure.
1. Plug the AC adapter into a wall outlet or surge protector. Plug the DC connector into
the DC power jack found on the rear of the Hub.
Note: The Hub may be used without the power supply when connecting low-power
devices such as keyboards and mice.
2. Plug the flat end of the provided USB device cable into the downstream port of your
computer, or downstream port of another hub, then plug the mini-USB connector on
the device cable into the upstream port on the rear of the Hub.
Installation

Installation
Installation
| 04
Important Note: The Hub must be connected to a USB 2.0-compliant host in order
to function in high-speed mode (480Mbps data rate). If the Hub is connected to
a USB 1.1-compliant host, it will operate only in low-speed or full-speed mode
(1.5Mbps/12Mbps).
3. Windows will now detect your Hub and install the required driver support. (The
Windows “Install New Hardware Wizard” may prompt you to provide your Windows
Installation CD to complete the driver installation process.)
Important Note: High-speed hub drivers are included with most USB 2.0 PCI
upgrade cards, and are preinstalled along with the PCI card drivers. If you purchased
an upgrade card prior to the release of high-speed hub support, please check
with your PCI card vendor for an updated USB 2.0 driver. The Belkin USB 2.0 driver
supports all competitive cards based on the NEC host controller with the exception
of Adaptec.
4. Plug the USB A connector of the USB device, or an additional hub, into any of the
downstream ports of the Hub.
Important Note: When moving a device from one port on the Hub to another, it may
be necessary to reinstall the USB drivers for that device.

Operating Instructions | 05
Information
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin International, Inc., of 501 West Walnut Street, Compton, CA 90220, declare
under our sole responsibility that the product:
F5U304
to which this declaration relates:
Complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation. This equipment may only be operated indoors. Operation outdoors is in
violation of 47 U.S.C. 301 and could subject the operator to serious legal penalties.
CE Declaration of Conformity
We, Belkin International, Inc., declare under our sole responsibility that the F5U304,
to which this declaration relates, is in conformity with Generic Emissions Standard
EN55022:1998 Class B, EN50081-1, and with Generic Immunity Standard EN50082-1:1992.
Belkin International, Inc., Limited Lifetime Product Warranty
What this warranty covers.
Belkin International, Inc., warrants to the original purchaser of this Belkin product that
the product shall be free of defects in design, assembly, material, or workmanship.
What the period of coverage is.
Belkin International, Inc., warrants the Belkin product for the lifetime of the product.

Troubleshooting
Troubleshooting
| 06
What will we do to correct problems?
Product Warranty.
Belkin will repair or replace, at its option, any defective product free of charge (except
for shipping charges for the product).
What is not covered by this warranty?
All above warranties are null and void if the Belkin product is not provided to Belkin
International, Inc., for inspection upon Belkin’s request at the sole expense of the
purchaser, or if Belkin International, Inc., determines that the Belkin product has been
improperly installed, altered in any way, or tampered with. The Belkin Product Warranty
does not protect against acts of God (other than lightning) such as flood, earthquake,
war, vandalism, theft, normal-use wear and tear, erosion, depletion, obsolescence,
abuse, damage due to low voltage disturbances (i.e. brownouts or sags), non-authorized
program, or system equipment modification or alteration.
How to get service.
To get service for your Belkin product you must take the following steps:
1. Contact Belkin International, Inc., at 501 W. Walnut St., Compton CA 90220, Attn:
Customer Service, or call (800)-223-5546, within 15 days of the Occurrence. Be
prepared to provide the following information:
a. The part number of the Belkin product.
b. Where you purchased the product.
c. When you purchased the product.
d. Copy of original receipt.
2. Your Belkin Customer Service Representative will then instruct you on how to
forward your receipt and Belkin product and how to proceed with your claim.

Information | 07
Information
Belkin International, Inc., reserves the right to review the damaged Belkin product. All
costs of shipping the Belkin product to Belkin International, Inc., for inspection shall
be borne solely by the purchaser. If Belkin determines, in its sole discretion, that it is
impractical to ship the damaged equipment to Belkin International, Inc., Belkin may
designate, in its sole discretion, an equipment repair facility to inspect and estimate the
cost to repair such equipment. The cost, if any, of shipping the equipment to and from
such repair facility and of such estimate shall be borne solely by the purchaser. Damaged
equipment must remain available for inspection until the claim is finalized. Whenever
claims are settled, Belkin International, Inc., reserves the right to be subrogated under
any existing insurance policies the purchaser may have.
How state law relates to the warranty.
THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN INTERNATIONAL,
INC., THERE ARE NO OTHER WARRANTIES, EXPRESSED OR, EXCEPT AS REQUIRED BY
LAW, IMPLIED, INCLUDING THE IMPLIED WARRANTY OR CONDITION OF QUALITY,
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND SUCH IMPLIED
WARRANTIES, IF ANY, ARE LIMITED IN DURATION TO THE TERM OF THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the
above limitations may not apply to you.
IN NO EVENT SHALL BELKIN INTERNATIONAL, INC., BE LIABLE FOR INCIDENTAL, SPECIAL,
DIRECT, INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH AS, BUT NOT LIMITED
TO, LOST BUSINESS OR PROFITS ARISING OUT OF THE SALE OR USE OF ANY BELKIN
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
This warranty gives you specific legal rights, and you may also have other rights, which may
vary from state to state. Some states do not allow the exclusion or limitation of incidental,
consequential, or other damages, so the above limitations may not apply to you.

F5U304uk P75342uk
